Drive Dimensions
Figure 8. D1 drive dimensions - sheet 1 of 2
35.2
33.4
26.1
12.8
12.0
6.6
Figure 9. D1 drive dimensions - sheet 2 of 2
SO-SVN048A-EN
GLAND PLATE
MAINS
TERMINALS
7.55
GROUND 3.14
0
14.5
MOTOR
TERMINALS
3.14 GROUND
Dimensions
2.9 7.1
33.2
2.5 7.9
.9
15
