Texas Instruments SimpleLink CC2651R3SIPA Manual page 75

MOU0050A
PIN 1 CORNER
1.51
1.35
0.5 TYP
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
A
0.372
0.292
0.338
46 X
0.262
15
13
40
1.6
51
6.2
1
54
57
1
39
7 X 0.6
QFM - 1.51 mm max height
SCALE 2.200
7.1
6.9
PKG
16
50
PKG
53
56
59
28
1
6.2
www.ti.com
PACKAGE OUTLINE
QUAD FLAT MODULE
B
7.1
6.9
C
SEATING PLANE
0.1 C
0.538
46 X
0.462
0.15 C A B
0.05 C
0.338
9 X
0.262
0.15 C A B
0.05 C
0.538
4 X
0.462
0.15 C A B
0.05 C
4226342/B 12/2020
