www.ti.com
TAPE AND REEL INFORMATION
REEL DIMENSIONS
QUADRANT ASSIGNMENTS FOR PIN 1 ORIENTATION IN TAPE
*All dimensions are nominal
Device Package
Type
CC2651R3SIPAT0MOUR QFM
Reel
Diameter
A0 Dimension designed to accommodate the component width
B0 Dimension designed to accommodate the component length
K0 Dimension designed to accommodate the component thickness
W Overall width of the carrier tape
P1 Pitch between successive cavity centers
Reel Width (W1)
Q1 Q2 Q1
Q3 Q4 Q3
Pocket Quadrants
Package Pins SPQ
Drawing Diameter
(mm)
MOU 50 2000 330.0
Pack Materials-Page 1
PACKAGE MATERIALS INFORMATION
TAPE DIMENSIONS
K0 P1
Cavity A0
Sprocket Holes
Q2
User Direction of Feed
Q4
Reel Reel A0 B0
Width (mm) (mm)
W1 (mm)
16.4 7.4 7.4
21-Sep-2022
B0 W
K0 P1 W Pin1
(mm) (mm) (mm) Quadrant
1.88 12.0 16.0 Q1
