Table 10-1 provides the bill of materials for a typical application using the CC2651R3SIPA module with the
internal antenna as shown in
using the CC2651R3SIPA module with an external antenna as shown in
Table 10-1. Bill of Materials for Internal Antenna Configuration
PART
VALUE
REFERENCE
(1)
C14, C15, C91 15 pF
C81 12 pF
J7 U.FL
U1 CC2651R3SIPA
Y6 32.768kHz
(1) C15 is placed when using the integrated antenna. C14 is placed when using an external antenna
Table 10-2. Bill of Materials for External Antenna Configuration
PART
VALUE
REFERENCE
C1, C91 15 pF
C81 12 pF
J1 SMA
U2 CC2651R3SIPA
Y6 32.768kHz
(1)
Z2 15 pF
(1) Z2 is the recommended series matching component to use when using connecting to an SMA connector. Additional Shunt components
Z1 and Z3 can be used for additional tuning for external antenna performance.

10.2 Alternate Application Circuit

Figure 10-3 shows the alternate application schematic using the CC2651R3SIPA module. This circuit
implementation should be used when the 4-layer stackup and layout recommendations in
be followed, and thus the alternate layout guidelines in
be assembled when using the integrated antenna option within the module. C14 should be assembled if the
module is to be used with an external antenna, in which case its recommended to follow the typical application
circuit as outlined in Section
Files.
