T = 25 °C, V = 3.0 V, unless otherwise noted.
c DDS
PARAMETER
Output voltage range
Load = Low Power Clocked
Comparator
(1) 1 LSB (V 3.8 V/3.0 V/1.8 V/DCOUPL/ADCREF) = 14.10 mV/11.13 mV/6.68 mV/4.67 mV/5.48 mV
REF
(2) Includes comparator offset
(3) A load > 20 pF will increases the settling time
(4) Keysight 34401A Multimeter
Copyright © 2023 Texas Instruments Incorporated
TEST CONDITIONS
V = VDDS = 3.8 V, code 1
REF
V = VDDS = 3.8 V, code 255
REF
V = VDDS = 3.0 V, code 1
REF
V = VDDS= 3.0 V, code 255
REF
V = VDDS= 1.8 V, code 1
REF
V = VDDS = 1.8 V, code 255
REF
V = DCOUPL, pre-charge OFF, code 1
REF
V = DCOUPL, pre-charge OFF, code 255
REF
V = DCOUPL, pre-charge ON, code 1
REF
V = DCOUPL, pre-charge ON, code 255
REF
V = ADCREF, code 1
REF
V = ADCREF, code 255
REF
Product Folder Links:
SWRS278B – FEBRUARY 2022 – REVISED AUGUST 2023
MIN
CC2651R3SIPA
CC2651R3SIPA
TYP MAX UNIT
0.03
3.61
0.02
2.85
0.02
1.71
V
0.02
1.20
1.27
2.46
0.02
1.42
