(Oqpsk Dsss1:8, 250 Kbps) - Rx - Texas Instruments SimpleLink CC2651R3SIPA Manual

CC2651R3SIPA
SWRS278B – FEBRUARY 2022 – REVISED AUGUST 2023
8.13 Zigbee - IEEE 802.15.4-2006 2.4 GHz (OQPSK DSSS1:8, 250 kbps) - RX
When measured on the CC2651RSIPA-EM
DC/DC enabled unless otherwise noted. All measurements are performed conducted.
PARAMETER
General Parameters
Receiver sensitivity
Receiver saturation
Adjacent channel rejection
Alternate channel rejection
Channel rejection, ±15 MHz or more
Blocking and desensitization,
5 MHz from upper band edge
Blocking and desensitization,
10 MHz from upper band edge
Blocking and desensitization,
20 MHz from upper band edge
Blocking and desensitization,
50 MHz from upper band edge
Blocking and desensitization,
–5 MHz from lower band edge
Blocking and desensitization,
–10 MHz from lower band edge
Blocking and desensitization,
–20 MHz from lower band edge
Blocking and desensitization,
–50 MHz from lower band edge
Spurious emissions, 30 MHz to 1000
MHz
Spurious emissions, 1 GHz to 12.75
GHz
Frequency error tolerance
Symbol rate error tolerance
RSSI dynamic range
RSSI accuracy
18 Submit Document Feedback
reference design with T
TEST CONDITIONS
PER = 1%
PER = 1%
Wanted signal at –82 dBm, modulated interferer at ±5 MHz,
PER = 1%
Wanted signal at –82 dBm, modulated interferer at ±10 MHz,
PER = 1%
Wanted signal at –82 dBm, undesired signal is IEEE
802.15.4 modulated channel, stepped through all channels
2405 to 2480 MHz, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Measurement in a 50-Ω single-ended load
Measurement in a 50-Ω single-ended load
Difference between the incoming carrier frequency and the
internally generated carrier frequency
Difference between incoming symbol rate and the internally
generated symbol rate
Product Folder Links:
= 25 °C, V = 3.0 V, f
c DDS RF
MIN
Copyright © 2023 Texas Instruments Incorporated
CC2651R3SIPA
www.ti.com
= 2440 MHz with
TYP MAX UNIT
–99 dBm
> 5 dBm
36 dB
57 dB
59 dB
57 dB
63 dB
63 dB
66 dB
60 dB
60 dB
63 dB
65 dB
–66 dBm
–53 dBm
> 350 ppm
> 1000 ppm
95 dB
±4 dB
