Bluetooth Low Energy - Receive (Rx) - Texas Instruments SimpleLink CC2651R3SIPA Manual

CC2651R3SIPA
SWRS278B – FEBRUARY 2022 – REVISED AUGUST 2023

8.11 Bluetooth Low Energy - Receive (RX)

When measured on the CC2651RSIPA-EM
DC/DC enabled unless otherwise noted. All measurements are performed conducted.
PARAMETER
125 kbps (LE Coded)
Receiver sensitivity
Receiver saturation
Frequency error tolerance
Data rate error tolerance
Data rate error tolerance
(1)
Co-channel rejection
(1)
Selectivity, ±1 MHz
(1)
Selectivity, ±2 MHz
(1)
Selectivity, ±3 MHz
(1)
Selectivity, ±4 MHz
(1)
Selectivity, ±6 MHz
Selectivity, ±7 MHz
(1)
Selectivity, Image frequency
Selectivity, Image frequency ±1
(1)
MHz
500 kbps (LE Coded)
Receiver sensitivity
Receiver saturation
Frequency error tolerance
Data rate error tolerance
Data rate error tolerance
(1)
Co-channel rejection
(1)
Selectivity, ±1 MHz
(1)
Selectivity, ±2 MHz
(1)
Selectivity, ±3 MHz
(1)
Selectivity, ±4 MHz
(1)
Selectivity, ±6 MHz
Selectivity, ±7 MHz
(1)
Selectivity, Image frequency
Selectivity, Image frequency ±1
(1)
MHz
14 Submit Document Feedback
reference design with T
TEST CONDITIONS
–3
Differential mode. BER = 10
–3
Differential mode. BER = 10
Difference between the incoming carrier frequency and
the internally generated carrier frequency
Difference between incoming data rate and the internally
generated data rate (37-byte packets)
Difference between incoming data rate and the internally
generated data rate (255-byte packets)
Wanted signal at –79 dBm, modulated interferer in
–3
channel, BER = 10
Wanted signal at –79 dBm, modulated interferer at ±1
–3
MHz, BER = 10
Wanted signal at –79 dBm, modulated interferer at ±2
–3
MHz, BER = 10
Wanted signal at –79 dBm, modulated interferer at ±3
–3
MHz, BER = 10
Wanted signal at –79 dBm, modulated interferer at ±4
–3
MHz, BER = 10
Wanted signal at –79 dBm, modulated interferer at ≥ ±6
–3
MHz, BER = 10
Wanted signal at –79 dBm, modulated interferer at ≥ ±7
–3
MHz, BER = 10
Wanted signal at –79 dBm, modulated interferer at image
–3
frequency, BER = 10
Note that Image frequency + 1 MHz is the Co- channel
–1 MHz. Wanted signal at –79 dBm, modulated interferer
at ±1 MHz from image frequency, BER = 10
–3
Differential mode. BER = 10
–3
Differential mode. BER = 10
Difference between the incoming carrier frequency and
the internally generated carrier frequency
Difference between incoming data rate and the internally
generated data rate (37-byte packets)
Difference between incoming data rate and the internally
generated data rate (255-byte packets)
Wanted signal at –72 dBm, modulated interferer in
–3
channel, BER = 10
Wanted signal at –72 dBm, modulated interferer at ±1
–3
MHz, BER = 10
Wanted signal at –72 dBm, modulated interferer at ±2
–3
MHz, BER = 10
Wanted signal at –72 dBm, modulated interferer at ±3
–3
MHz, BER = 10
Wanted signal at –72 dBm, modulated interferer at ±4
–3
MHz, BER = 10
Wanted signal at –72 dBm, modulated interferer at ≥ ±6
–3
MHz, BER = 10
Wanted signal at –72 dBm, modulated interferer at ≥ ±7
–3
MHz, BER = 10
Wanted signal at –72 dBm, modulated interferer at image
–3
frequency, BER = 10
Note that Image frequency + 1 MHz is the Co- channel
–1 MHz. Wanted signal at –72 dBm, modulated interferer
at ±1 MHz from image frequency, BER = 10
Product Folder Links:
= 25 °C, V = 3.0 V, f
c DDS RF
MIN
–3
–3
Copyright © 2023 Texas Instruments Incorporated
CC2651R3SIPA
www.ti.com
= 2440 MHz with
TYP MAX UNIT
–103 dBm
>5 dBm
> (–300 / 300) kHz
> (–320 / 240) ppm
> (–125 / 125) ppm
–1.5 dB
(2)
8 / 4.5 dB
(2)
44 / 39 dB
(2)
46 / 44 dB
(2)
44 / 46 dB
(2)
48 / 44 dB
(2)
51 / 45 dB
39 dB
(2)
4.5 / 44 dB
–99 dBm
> 5 dBm
> (–300 / 300) kHz
> (–450 / 450) ppm
> (–175 / 175) ppm
–3.5 dB
(2)
8 / 4 dB
(2)
44 / 37 dB
(2)
46 / 42 dB
(2)
45 / 43 dB
(2)
46 / 45 dB
(2)
49 / 45 dB
37 dB
(2)
4 / 46 dB
