Country-specific channel settings

The tools work in the license-free 2.4 GHz/5 GHz ISM band.
Band
2.4 GHz IEEE802.11b/g
5 GHz IEEE802.11a
U‑NII‑1
5 GHz IEEE802.11a
U‑NII‑2
5 GHz IEEE802.11a
U‑NII‑2 ext
6
Data
-95 dBm (typ. @ 1 Mbps DSSS, 2.4 GHz)
-66.3 dBm (typ. @ 40 MHz MCS7 MM 4K)
-92.5 dBm (typ. @ 6 Mbps OFDM, 5 GHz)
-69.3 dBm (typ. @ 40 MHz MCS7 MM 4K, 5 GHz)
CCK/DSSS/OFDM
2 (2×2 MIMO)
1, 2, 3 Mbps
GFSK@ 1 Mbps
Pi/4-DQPSK@ 2 Mbps
8-DPSK@ 3 Mbps
Channel Frequency in
GHz
1 2.412
2 2.417
3 2.422
4 2.427
5 2.432
6 2.437
7 2.442
8 2.447
9 2.452
10 2.457
11 2.462
12 2.467
13 2.472
36 5.180
40 5.200
44 5.220
48 5.240
52 5.260
56 5.280
60 5.300
64 5.320
100 5.500
104 5.520
108 5.540
112 5.560
116 5.580
120 5.600
P2545KA | 2022-12 | REV C
World Europe
World CE
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
– x
– x
x x
x x
x x
x x
– x
– x
– x
– x
– x
– x
– x
– x
– x
– x
USA/
Canada
FCC
x
x
x
x
x
x
x
x
x
x
x
–
–
x
x
x
x
x
x
x
x
x
x
x
x
x
–
