Initial operation
4
EN
Parameter
Wireless channel
<Scan channels>
Transmit power
Roaming Aggressiveness
<OK>
<Cancel>
7. Confirm settings with <OK>.
8. Press <Apply>.

9. Confirm the following message with <Yes>:
Toolserial: xxxxxxx
Builddate: xx.xx.xx
Configure Tool?
10. Confirm the following message with <OK>:
Configuration done!
11. Installing the tool on the controller.
4.3

Configuring Bluetooth settings

Perform the following steps only when Bluetooth communication is to be established. A Bluetooth connec-
tion is only possible with mPro200GC-AP. For WLAN communication see chapter 2.1 WLAN communica-
tion, page 5.
Configuring Bluetooth Settings
1. Switch on the tool.
2. Using mProRemote Professional to access the controller and select Navigator > Utility > System
Settings > Cordless Tools.
3. Open the Bluetooth AP Configuration tab.
4. Select the Activate Bluetooth Communication check box.
5. Press <Start pairing...>.
6. Activate Bluetooth on the tool: Select
7. Use the tool to scan for Bluetooth devices: Select
8. Select the desired controller

9. Set the node number: Select
10. Installing the tool on the controller.
14
Description
There are two setting options:
Auto The corresponding channel is automatically searched for.
•
The channels are unlocked and can be selected manually.
•
Scan radio channel. The button is not active if a channel is selected at Wire-
less channel.
This function is not required when using the mPro200GC-AP, since only one
channel can be selected.
Set transmission power.
Setting option, from which signal strength the tool connects with another ac-
cess point.
Select Low because the mPro200GC-AP has an integrated access point in
the controller..
Exit the input window, the settings are saved.
Exit input window, the settings are not saved.
Settings are written onto the tool.
When the Bluetooth connection is established, the field is highlighted in green.
P2545KA | 2022-12 | REV C
> > .
> .
and confirm with the button.
> .
