How to Use
9. Use the Mopping Function
It is recommended that all floors are vacuumed at least three times before
the first mopping session to achieve a better cleaning effect.
1) Dampen the mop pad and wring out excess water. Slide the
pad all the way into the slot of the water tank until it is securely in
place.
2) Open the water tank lid, fill the tank with water, then securely
close the lid.
Note: Do not use detergent or disinfectant.
12
3) Align the mopping module as indicated by the arrow, then
slide it into the back of the robot until it clicks into place. Press the
button or use the Mi Home/Xiaomi Home app to start cleaning.
Click
Click
Note:
• It is not recommended to use the mopping function on carpets.
• Use the app to adjust the water flow as required.
4) Press the two side clips inwards and slide the water tank
backwards to separate it from the robot.
Note: When the robot is charging or not in use, remove the mopping
module, pour out all the remaining water in the tank, and clean the mop
pad to prevent mildew or odor.

Routine Maintenance

Clean the Dust Bin and Filter
1. Open the robot cover, then press the dust bin clip to remove the
dust bin.
2. Open the dust bin cover as indicated by the diagram.
3. Remove the filter and tap its basket gently.
Note: Do not attempt to clean the filter with a brush or finger.
4. Rinse the dust bin and filter with water until they are clean.
Thoroughly dry the filter before re-installing.
Note:
• Only clean water should be used to clean the filter. Do not use detergent.
• Keep it in a well-ventilated or cool place.
