- Page 1 PSEN ma1.4a-57 PSEN sensor technology Operating Manual-22124-EN-06...
- Page 2 Preface This document is a translation of the original document. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for internal purposes. Suggestions and comments for improving this documentation will be gratefully received.
-
Page 3: Table Of Contents
Wiring Pin assignment Requirements and connection to evaluation devices Installation Installation type 1 Installation type 2 Adjustment Periodic test Dimensions in mm Technical details Safety characteristic data Order reference System Accessories EC declaration of conformity Operating Manual PSEN ma1.4a-57 22124-EN-06... -
Page 4: Introduction
PSEN ma1.4a-57 Introduction Validity of documentation This documentation is valid for the product PSEN ma1.4a-57. It is valid until new document- ation is published. This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. -
Page 5: Safety
If installed in other environments, measures should be taken to comply with the applicable standards and directives for the respective installation site with regard to in- terference. Operating Manual PSEN ma1.4a-57 22124-EN-06... -
Page 6: Safety Regulations
In safety-related applications, please comply with the mission time T in the safety-re- lated characteristic data. When decommissioning, please comply with local regulations regarding the disposal of electronic devices (e.g. Electrical and Electronic Equipment Act). Operating Manual PSEN ma1.4a-57 22124-EN-06... -
Page 7: For Your Safety
LED will light. The safety switch is designed for applications in series connections. Operate the PSEN ma1.4a-57 in conjunction with the following components: Actuator PSEN ma1.4-03 or actuator PSEN ma1.4-10 (see... -
Page 8: Block Diagram
Block diagram Safety switch Actuator Magnet Operating distances (mm) omin Legend Assured operating distance Min. operating distance omin Assured release distance The offset-independent values for the switching distances are included in the Technical details [ 18]. Operating Manual PSEN ma1.4a-57 22124-EN-06... -
Page 9: Lateral And Vertical Offset
Lateral offset Vertical offset 0 mm 2 mm 4 mm 6 mm 8 mm 0 mm 10.0 10.0 2 mm 10.0 10.0 4 mm 6 mm The stated values are valid at a temperature of 20 °C. Operating Manual PSEN ma1.4a-57 22124-EN-06... -
Page 10: Wiring
Pin assignment NOTICE The colour marking for the connection lead only applies for the cable that Pilz supplies as an accessory The safety switch is shown in an unoperated condition. Pink Layout of the 8-core cable... -
Page 11: Requirements And Connection To Evaluation Devices
PSEN ma1.4a-57 Requirements and connection to evaluation devices For use of PSEN ma1.4a-57 in accordance with DIN EN 60947-5-3 an evaluation device must be connected. Connect the PSEN ma1.4a-57 either with a certified Pilz evaluation device or with an evaluation device with defined properties... - Page 12 23 24 33 34 43 44 11 12 21 22 31 32 41 11 12 21 22 33 34 43 44 PSENmag Fig.: Dual-channel connection of four PSENmag to the input circuits of an evaluation device Operating Manual PSEN ma1.4a-57 22124-EN-06...
- Page 13 PSEN ma1.4a-57 Examples for connection to Pilz evaluation devices: PNOZ s3 PSEN ix1 PSENmag white pink yellow green PNOZmulti PSEN ix1 PSENmag white pink yellow green Auxiliary contact with LED The auxiliary contact and the LED indicate the status of the safety contacts.
-
Page 14: Installation
S can change. – Check the assured release distance S Safety switches and actuators must be positioned so that they are secured against a change of position. Operating Manual PSEN ma1.4a-57 22124-EN-06... - Page 15 4. Align actuator to sensor. INFORMATION The inscribed area on the actuator (sensing face) should face the sensor. 5. Slide the actuator on to the screws. 6. Align sensor and tighten screws with max. 0,8 Nm. Operating Manual PSEN ma1.4a-57 22124-EN-06...
-
Page 16: Installation Type 2
11. Installation of sensor and actuator is now complete. INFORMATION Seals (1), (2), (3) meet the requirements of UL 94 V0, seal (4) does not meet UL requirements. Installation type 2 Install the sensor as shown for installation type 1 Operating Manual PSEN ma1.4a-57 22124-EN-06... -
Page 17: Adjustment
Seals (1), (2), (3) meet the requirements of UL 94 V0, seal (4) does not meet UL requirements. Adjustment The safety switch may only be used with the corresponding actuator PSEN ma1.4-03 or PSEN ma1.4-10. Always test the function with the PSEN ix1 interface and connected evaluation device. Operating Manual PSEN ma1.4a-57 22124-EN-06... -
Page 18: Periodic Test
Classification in accordance with EN 60947-5-3 PDDB PDDB Electrical data 506325 506327 Supply voltage Voltage 24 V 24 V Kind -20 %/+20 % -20 %/+20 % Voltage tolerance Supply voltage Max. current 200 mA 200 mA Operating Manual PSEN ma1.4a-57 22124-EN-06... - Page 19 0,0 mm 0,0 mm Min. operating distance Somin Typical operating distance So 3,5 mm 12,5 mm Assured release distance Sar 12 mm 22 mm Typical release distance Sr 6 mm 16 mm Repetition accuracy switching distances Operating Manual PSEN ma1.4a-57 22124-EN-06...
-
Page 20: Safety Characteristic Data
You must comply with the safety-related characteristic data in order to achieve the required safety level for your plant/machine. B10d in accordance with EN ISO 13849-1: 2015 TM [year] in accordance with EN ISO and EN 62061 13849-1:2015 7.300.000 Operating Manual PSEN ma1.4a-57 22124-EN-06... -
Page 21: Order Reference
European Parliament and of the Council. The complete EC Declaration of Conformity is available on the Internet at www.pilz.com/downloads. Representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2, 73760 Ost- fildern, Germany Operating Manual PSEN ma1.4a-57...
