4.5.5.2. Fax Diagnostics
Fax NVM Read/Write
•
Diagnostics > Fax Diagnostics Fax NVM Read/Write
Purpose
To change a configuration value for fax firmware.
Operation Procedure
When the main "NVM Read/Write" window displays, users can navigate through the list of
configuration values that display along with description.
Users can also input a code to the text box to find a configuration value directly.
After selecting one value, pressing "Edit" button will open an interface for user input.
Verification
N/A
Specification
N/A
Reference
N/A
Code
Name
20-200
Pause Dial Time
20-210
Dial Pulse M/B ratio
20-220
Auto Dial Start Pause Time
20-300
Ring On Time
20-310
Ring Off Time
20-320
Ring Detection Freq
20-330
Ring On Max Time
20-340
Ring Off Max Time
20-400
DTMF High-Freq Level
20-410
DTMF Low-Freq Level
20-420
DTMF Timing
20-500
Dial Mode
Copyright© 1995-2017 SAMSUNG. All rights reserved.
Description
Pause Time (value * 1000ms)
33 / 66 40 / 60
Pause time before auto-dialing (second)
Ring On Time (ms)
Ring Off Time (ms)
sets the Call Indication frequency range
that will be detected by LIU
Ring On Max Time (ms)
Ring Off Max Time (ms)
DTMF High-Freq. Level (dBm)
DTMF Low-Freq. Level (dBm)
DTMF duration of on/off output ( Ms)
Select Tone / Pulse
4. Troubleshooting
Default
Range
Country
0~200
Value
Country
0=OPTION_DP_33
Value
1=OPTION_DP_40
2=OPTION_DP_37
3=OPTION_DP_50
1
0~10
170
90~800
560
90~800
1
1=12-80hz
2=16-55hz
3=20-55hz
4=22-55hz
5100
3000~12000
11100
9000~22000
Country
0~15
Value
Country
0~15
Value
8
1=80/80
2=70/70
3=70/150
4=60/60
5=80/100
6=150/50
7=150/240
8=100/100
9=100/80
Country
0=OPTION_TONE_MODE
Value
1=OPTION_PULSE_MODE
4-40
