Part Code : JC92-02925A
-
Part Name : PBA-OPE HUB
•
Connection
1
2
3
4
5
6
7
8
9
10
Copyright© 1995-2017 SAMSUNG. All rights reserved.
MAIN Board USB I/F
Reset & Speaker I/F
OPE LVDS I/F
Main Borad Power I/F
Main Borad LVDS I/F
Speaker
Keyborad
External USB Host Slot
WLAN / NFC
WLAN / NFC
2. Product Specifications and Description
