Remote Controller
58
The remote controller should be used with the aircraft.
Through the joystick and function buttons on the remote controller, user can operate
the aircraft and camera within distance up to 6000m ( under FCC, non blocking and non-
interference environment), and display high-definition images on the mobile phone in real time
through the app.
The telescopic foldable mobile phone support at the bottom of the remote controller is used
to place the mobile phone. The joystick is detachable and easy to pack and carry.
The remote controller is equipped with 2600 mAh rechargeable lithium battery, Minimum
working time is 2.5h, based on different phone type.

1. Status indicator of remote controller

Two groups of LED lights are set on the RC, LED a on the left is used to indicate the current
aircraft connection status, and light b on the right are used to indicate the current RC power.
Refer to the following description for the lighting mode and meaning of indicator lights:
a Connection status indicator -- LED
No. Indicator light
1 Solid green light
2 Solid red light
b Power indicator -- LED
No. Indicator light
1 Flashing green light during
2 Solid green light during charging
3 Solid green light
4 Green light flashes slowly
5 Green light flashes doubly

2. Function instructions of remote controller

1) RC power on/off
Power on and power off the remote controller by pressing the power button for more than 2
seconds.
a
Sound
Not
Not
Sound Status
Not Charging.
Not Charging complete.
Not The remote controller is working normally.
B-B-B-······ Low battery alarm, please charge.
The remote controller is idle for more than 9 minutes after
B-B-B-······
power-on; the prompt disappears automatically once operate.
Copyright 2022 C-Fly all rights reserved
b
Status
RC and aircraft is paired.
RC and aircraft is not paired.
RC power on/off
