C-Fly Faith2 Pro Operation Manual page 47

(4). Charge the battery
Before using the aircraft battery, make sure the battery is fully charged. Please refer to the
instructions on P50 to check the current battery power of the aircraft. If the battery power is
insufficient, please take out the charger and charging cable and charge according to the figure:
Charger
Note:
● The aircraft battery must be charged using the officially supplied dedicated charger.
● The power of USB power adapter determines the charging time.
● With 5V 2A adaptor, the charging time is about 270 minutes.
(5). Installation of obstacle avoidance
a).Open the protective cover on the top
shell.
Note: Ensure that the aircraft is shut down when installing or removing the obstacle avoidance
module. Disassembly and assembly of the obstacle avoidance module when the aircraft is
started may damage the obstacle avoidance module, resulting in abnormal function
(6). Battery installation
As shown in the figure below, insert the battery into the battery compartment and press it
inward to ensure that the latches on both sides of the battery are completely locked.
Warning:
● Please install the battery with both hands. Installing the battery with one hand may lead to
improper installation of the battery. If the battery is not installed in place, it may cause the
aircraft to lose power and fall during flight.
● Be careful: the buckle will make a "click" sound when the battery is inserted, that is, it is installed
in place.
Battery
Red light flashing (charging),
Turns to green light solid
(charging completed)
Copyright 2022 C-Fly all rights reserved
Product Overview
Charge wire Power adapter
b).Insert the obstacle avoidance module into the
upper interface of the top shell and ensure that it
is firmly fixed.
43
Household
power socket
