DESCRIPTION
EN
KNOW THE MOWER (Fig. A1 & A2)
1. Seat
2. Charging Port
3. Power Unit
4. LED Rear Light
5. Storage Compartment
6. Cup Holders
7. LED Sidelight
8. Rear Wheel (Drive Wheel)
9. Wash Port
10. Deck
11. Deck Protector
12. Anti-Scalp Wheel
13. Front Wheel
14. Parking-Brake Pedal
15. Daytime Running Lights
16. LED Headlights
17. Side-Discharge Chute
18. Deck-Height Adjustment Lever
19. Seat-Suspension Adjustment Knob
20. Seat Position Adjustment Lever
21. Lap Bars
22. Mower Status Indicator
23. LCD Screen
24. PTO Switch
25. Start/Stop Button
26. Safety Key
27. Phone Storage Slot
28. Baffle Bar
29. Mower Fuel-Gauge & Status Indicator
29a Mower Fuel-Gauge Indicator
29b Mower Status Indicator
30. Foot-Rest Area
31. Power-unit Cover Release Button
32. Power-unit Cover
33. Power unit with six battery compartments
34. Battery-Release Button
35. Hitch
36. Attachment Mounting Cover
37. Attachment Mounting Cover Storage
24
ZERO TURN RIDE-ON MOWER — ZT5200E-L
38. USB Port
KNOW THE LCD SCREEN (Fig. A3)
Refer to the section "MOWER STATUS REFERENCE &
FAULT CODE" for more information about the icons and
indicators on the LCD screen.
1. Safety Key Icon
2. LED Lights Icon
3. Auto-Parking Icon
4. USB Icon
5. Blade Speed Indicator
6. Safety Device Status Indicator
7. Hour Meter
8. Vacant Battery Compartment Icon
9. Temperature Icon
10. Occupied Battery Compartment Icon
11. Driving Mode
12. Fault Code Indicator
13. Overload Indicator
14. Low Power Indicator
15. Driving Speed Indicator
16. Load Indicator
17. Fuel Gauge
18. Blade Speed Adjustment Button
19. Set Button
20. Driving Mode Button
21. LED Light Switch
22. Driving Speed Adjustment Button
UNPACKING
NOTICE: Save the packing materials until you have
carefully inspected and satisfactorily operated the
product. If any parts in packing list assembled on the
machine please instantly contact EGO service.
NOTICE:: Except the tools in below packing list, all other
tools mentioned in the manuals are just recommended
but not provided.
PACKING LIST (Fig. B)
Zero Turn Ride-On
B-1
Mower
B-2 Seat
B-6 Safety Keys
Open-End Wrenches
B-7
(13mm)
