Diagnostics map details

When an error occurs in the Base or Remote, a flag will be set in a Bit corresponding to each item of
diagnostic information.
The errors for the system diagnostics 1 to 4 are for the entire system. Therefore, even if there is only one
unit which has an error in the constructed system, a flag will be set in a Bit corresponding to the error
content.
It is possible to identify the abnormal Remote using the Remote diagnostic information.
(It is necessary to set the "Diagnostic allocation" to "Advanced".)
Regardless of the setting of the "Diagnostic allocation", the abnormal module and unit can be identified
using the I/O Configurator provided by SMC.
Bit
Item Byte
No.
User setting
0 lower level
detection
User setting
1 upper limit
detection
Detection of
2 the range lower
limit
System
Detection of
diagnosis 0
3 the range
1
upper limit
Detection of
upper limit of
4
ON/OFF
operation cycle
Detection of
5 unconnected
load
Content of diagnostics
Effective
Item Details diagnostic
coverage
Detected that the
analog setting has
exceeded the lower
limit of the user set
value.
Detected that the
analog setting has
exceeded the upper
limit of the user set
value.
Detected that the
analog setting has
exceeded the lower
limit of the setting
range.
Detected that the
analog setting has
exceeded the upper
limit of the setting
range.
The number of
ON/OFF operating
cycles has
exceeded the upper
limit of the setting
value.
Detects the broken
wire.
Diagnosed area and
processing upon error
How to
I/O
reset
processing
upon
diagnosis
Automatic
Unit Continue
reset
Automatic
Unit Continue
reset
Automatic
Unit Continue
reset
Automatic
Unit Continue
reset
Automatic
Unit Continue
reset
Manual/
Unit Continue automatic
reset
-89-
Remarks
Reset conditions (LED indications,
etc.)
Select an appropriate
range so that they are
within the user set value
range. Or disable the
diagnostics.
Select an appropriate
range so that they are
within the user set value
range. Or disable the
diagnostics.
Select an appropriate
range so that the input
value is within the set
range.
Base
W-MS: Flashes
Select an appropriate
*1
range so that the input red
value is within the set Remote
range. MS: Flashes red
Reset the
ON/OFFcycles to zero.
Ordisable the
diagnostics.
(1) Replace the valve or
the input/output
equipment, and check
the operation.
(2) Replace the valve or
the output equipment,
and check the
operation.
No.EX※※-OMA1031-B
