Refer to the system configuration example below.
System configuration example
Wireless Wireless
No.
Base Remote
1 EXW1 EXW1
2 EXW1 EXW1+EX600
3 EXW1 EX600
4 EX600 EXW1
5 EX600 EXW1+EX600
6 *5 EX600 EX600
*1: For more details, check the system settings of the Base.
*2: Only available in Protocol V.2.0.
*3: Up to 100 m between an EXW1 series Base and Remote, and up to 10 m between an EXW1 series Base
and an EX600-W series Remote.
*4: The settings and monitor function are restricted when communication is established between EX600-
WEN/WPN and EXW1-R*.
*5: This configuration consists solely of EX600-W series units; refer to the operation manual for the product
in use.
○ System configuration example 1
Wireless Base : EXW1-BECAC
Wireless Remote : EXW1 series
<Wireless Base>
<Wireless Remote>
Communication
Protocol
distance
V.1.0/
Up to 100 m
V.2.0
*1
*3 V.1.0
Up to 10 m V.1.0
Up to 10 m V.1.0
Up to 10 m V.1.0
Up to 10 m V.1.0
-15-
Applicable function
Frequency
channel
Parameter
select function
(CoE bject)
(F.C.S.)
Available *2 Available
NA NA
NA NA
NA NA
NA NA
NA NA
WEB
function
*2 -
-
-
Available *4
Available *4
Available
