8 Bill of Materials, Layout, and Schematics

8.1 Bill of Materials

Table 8-1 lists the bill of materials (BOM) for the ADS1258EVM.
Designator Quantity
C1, C13, C14, C21,
C22, C27, C28, C33, 9
C34
C2, C6, C7, C8, C17 5
C3, C39 2
C4, C9, C10, C37 4
C5, C38 2
C11, C12, C15, C16,
C18, C19, C23, C24,
16
C25, C26, C29, C30,
C31, C32, C35, C36
C20 1
D1, D2 2
H1, H2 2
H3, H4 2
H5, H6, H7, H8 4
J1, J2 2
J3 1
J4 1
J5 1
J6 1
J7 1
SBAU126E – MAY 2007 – REVISED JUNE 2023
Submit Document Feedback
Table 8-1. Bill of Materials
Value Description
CAP, CERM, 470 pF,
470 pF 50 V, +/- 5%, C0G/
NP0, 0603
CAP, CERM, 0.1 uF,
0.1 uF 25 V, +/- 5%, X7R,
0603
CAP, CERM, 22 µF,
22 uF 25 V,+/- 10%, X7R,
1210
CAP, CERM, 10 uF,
10 uF 25 V, +/- 10%, X7R,
1206_190
CAP, CERM, 1 µF, 16
1 uF V,+/- 10%, X7R, AEC-
Q200 Grade 1, 0603
CAP, CERM, 47 pF,
47 pF 50 V, +/- 5%, C0G/
NP0, 0603
CAP, CERM, 2200 pF,
2200 pF 50 V, +/- 5%, C0G/
NP0, 0603
Green LED, Green, SMD
Machine Screw Pan
PHILLIPS M3
ROUND STANDOFF
M3 STEEL 5MM
Bumpon, Cylindrical,
0.312 X 0.200, Black
Terminal Block,
3.5mm, 8-Pos, TH
Terminal Block,
3.5mm, 3x1, Tin, TH
Terminal Block, 2x1,
3.5mm, TH
Header(Shrouded),
19.7mil, 30x2, Gold,
SMT
Header, 100mil, 9x2,
Gold, TH
Header, 100mil, 10x1,
Gold, TH
Copyright © 2023 Texas Instruments Incorporated
Bill of Materials, Layout, and Schematics
Package Reference Part Number
0603 06035A471JAT2A
0603 C0603C104J3RACTU
1210 CL32B226KAJNFNE
C1206C106K3RACT
1206_190
CGA3E1X7R1C105K
0603
080AC
C0603C470J5GACT
0603
GRM1885C1H222JA
0603
01D
LED_0805 APT2012LZGCK
RM3X4MM 2701
ROUND STANDOFF
9774050360R
M3 STEEL 5MM
Black Bumpon SJ61A1
Terminal Block,
ED555/8DS
3.5mm, 8-Pos, TH
Terminal Block,
691214110003
3.5mm, 3x1, Tin, TH
2x1 Terminal Block OSTTE020161
Header (Shrouded),
QTH-030-01-L-D-A
19.7mil, 30x2, SMT
9x2 Header TSW-109-07-G-D
10x1 Header TSW-110-07-G-S
ADS1258EVM-PDK Evaluation Module
Manufacturer
AVX
Kemet
Samsung Electro-
Mechanics
Kemet
U
TDK
Kemet
U
MuRata
Kingbright
APM HEXSEAL
Wurth Elektronik
3M
On-Shore Technology
Wurth Elektronik
On-Shore Technology
Samtec
Samtec
