Output Audio Meters Indicate PGM output and Headphone output.
❼
❽ HDMI 1 Delay
❾ MIC 1 Delay

3.10 Video Output

Tap【OUTPUT】or push Button【7】to set parameters for video output.
Multi-view
Click Multi-view to set parameters.
Default to be Multi-view preview, which can be switched to Program or 1~4 HDMI inputs for various
applications.
Users can return to main interface to check input source preview on the touch screen.
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
● Tap to play it in PGM.
● Configure audio delay for a camera input to keep audio in sync with the video.
● Range: 0~300mm, increase or reduce 10mm each time.
●Configure audio delay for MIC 1 input to keep audio in sync with the video.
●Range: 0~300mm, increase or reduce 10mm each time.
