real time. (More details please refer to 3.10 Settings)
In addition, the four HDMI input ports all support embedded audio. Turn on AFV, the audio follows
the video switch to perform a soft gradual transition when video is switched.
There are 8 audio inputs in total, which can be controlled via operation board to achieve audio
mixing and monitoring.
If the sound and the video are not synchronous, it is necessary to do audio delay setting. Users can
also increase or reduce the Delay value for HDMI and MIC audios to ensure audio and video
synchronization. (More details please refer to 3.8 Audio)
Warning:
1. Noise may occur during plugging, unplugging and audio tuning. When connecting audio output port
(main output and monitor port) to the speaker, if the speaker is powered on, it may be damaged during
unplugging process. Therefore, please power on speaker after connection, and power off it first before
unplugging.
2. MIC 2 supports access to wireless microphone with a 3.5mm female to 6.5mm male single-track adapter.
LINE supports access to wireless microphone with a 3.5mm female to 6.5mm male dual-track adapter.
2.5 Connect USB for Streaming and Recording
The USB port labeled number 2 is for video capture, which allows users to capture videos to
computer and the captured video content can be streamed to Facebook, YouTube, Zoom, Twitter
and other streaming media platforms via a third-party Video Media Player software like OBS.
Insert a U disk to the other USB 3.0 port labeled number 1 by USB 3.0 cable to perform recording.
mini-mx supports recording streaming media content to an external USB storage device, such as U
disk or SSD. The SSD storage can reach up to 2T, and the USB storage can support up to 64G. The
supported format is exFAT.
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
15
