RGBlink mini-mx User Manual page 11

❺ Listen & Mute Buttons
T-Bar
❻
❼ Page Up
❽ Page Down
❾ Button 1~8
❿ 5-Direction Joystick
⓫ MENU Button
ON AIR
⓬
⓭ 5.5-inch Touch Screen
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
to right.
● Listen Button: Audio management for monitoring port. Button in green
allows users to monitor the audio from a channel ; no button light indicates
monitoring function is OFF.
● Mute button: Mute that channel on PGM port. When a channel is muted,
the button will be illuminated red; no button light indicates the channel is
ON at PGM port.
PVW and PGM views can be transitioned manually by pushing the T-bar
bidirectionally from the top to the bottom or from the bottom to the top.
Press to return to the previous page.
Press to enter the next page.
● Button 1~8 indicate 8 selections in Main Menu correspondingly with
button light in white.
● Button 1~4 can also be used as 1~4 HDMI inputs switch button. When
the signal is in PGM, the button will be illuminated red; when the signal is
being edited, the button will be illuminated green.
● Set pan, tilt and zoom for PTZ camera.
● Position adjustment for layer.
● Press to switch interface between Preview Interface、Main Interface、
Preset Interface.
● Press to start or end streaming.
● Check streaming status on LCD screen: steady red shows ON AIR、 flashing
red shows unstable network、unlit shows streaming is finished.
For menu operation and multi-view window monitoring.
10
