Interface Panel - RGBlink mini-mx User Manual

1.2.3 Interface Panel

❶ ❷
USB-C 3.0 Stream Port
❶
USB-C 3.0 Record Port
❷
Ethernet Port
❸
HDMI-A (PROGRAM)
❹
HDMI-A (MUITI-VIEW)
❺
HDMI 1~4 Inputs
❻
Locking Hole
❼
© Xiamen RGBlink Science & Technology Co., Ltd.
| support@rgblink.com | www.rgblink.com
Ph: +86 592 5771197
❹
❺
❸
⓫
❿
Recognized as webcam for streaming or video conference.
● Insert SSD or U disk for recording.
● Insert a U disk to import audio, video and graphic files.
● Use with USB-C cable provided to share network with mobile phone.
For web streaming, PTZ control and firmware upgrade.
PROGRAM output port. Default as Program Output, can set as Multi-view Preview
or Test Pattern optional Output by menu.
MULTI-VIEW output port. Default as Multi-view Preview Output, can set as Program
or HDMI 1~4 optional Output by menu.
● Connect to HDMI video sources.
● 4K resolution and downward compatible with all resolution.
Use with T-lock to fix the device.
❻
❼
⓬ ⓭
⓮
❾
❽
⓯
11
