USER MANUAL
PRECELLYS
Evolution Touch
®
1. Enter a protocol name using the virtual keyboard
2. Select icon to be associated with the protocol.
3. Save by using the button,
of the protocols available in the library menu. However, it is possible to
cancel the saving operation and return to the setting part if necessary by
clicking on the bouton
The operator is responsible for the settings of the equipment. For each
lysing kit, the manufacturer recommends ranges of use.
Note: to prevent the motor from overheating during a long grinding
phase, the Precellys® Evolution Touch has a safety system that prevents
the device from running when the motor temperatures are too high.
Should this occur, let the device cool down before using it.
3.1.4.5
Access to the protocol list
In order to select an existing protocol, press the "Protocol library" icon on
the home screen. The screen below then appears:
1
3
1. Global protocol settings overview.
2. Name of the saved protocol.
3. Create a new protocol based on the selected protocol.
By choosing a protocol in the list, (right side of the screen) the associated
parameters are visible (left side of the screen).
Once a protocol selected it is possible:
• To run the protocol by pressing the start button on the instrument
(below the screen). The system creates a vacuum underneath the
indented plate. Once the tubes are correctly held in place (i.e. sufficient
vacuum), the protocol begins.
• Edit a protocol by pressing the Edit icon. When the required parameters
Page
16
, the protocol is directly added to the list
.
2
of the protocol are set, launch the protocol by pressing the start button of the
instrument (below the screen) or save the modified protocol under another
name.
3.1.4.6
Running protocol
While a protocol is running on the instrument, the following screen is displayed:
Light signal:
-
Flashing green: lysing cycle in progress.
-
Flashing red: equipment fault message will appear (see
paragraphs 7 for further details) .
3.1.4.7
Protocol end
At the end of a protocol, the following screen appears:
Click Ok on the pop-up message, then open the lid by pinching the locker..
Green light signal
Cycle number/ total number
of cycle
Cycle running time
Pause time
Total remaining time
Page
17
