USER MANUAL
PRECELLYS Evolution Touch
®
2. Carefully remove the Precellys® Evolution Touch from its box and place
it on a clean, horizontal and stable work surface (weight of the device
= 27 kg): the height of the 4 feet can be adjusted in order to make the
equipment more stable.
Given its mass, the device should preferably be handled by two operators.
3. Check its external appearance. Immediately report any defect to the
carrier.
4. Keep the original carton box, the protective foam pads and the original
documentation. These items will be needed in the event of a return.
Page 24
Do not lift the device by holding the lid when
removing it from its box. It must be lifted either using
the extraction handles provided or by holding the
equipment from underneath at the notches provided
on the side of the casing (see paragraph 2.1). There are
also notches provided in the protective foam.
In the event of a significant temperature difference between
the storage area and the laboratory, allow the device to
return to room temperature to avoid any condensation.
5.2

Installation and connection

1.Remove the foam pad from the tube holder and replace the containment
seal if necessary (voir § 9.3.2).
Keep the foam pad, which must be put back in place
before transporting the device. If the device is returned
to the dealer or manufacturer without this protection,
the warranty will not apply.
The containment seal must be fitted in accordance with
the instructions in this manual in order to adequately
protect the operator. Indeed, the containment seal is
an important element of the system used to contain
the electrical parts of the device and protect them
from getting sprayed by liquids.
2.Fit the vacuum joint (voir §9.3.1).
Page 25
