USER MANUAL
PRECELLYS Evolution Touch
®
3.1.4.3 Setting up protocols on the Precellys® Evolution Touch
The Precellys® Evolution Touch operates at a maximum speed of10000
rpm.
A homogenization protocol for a Precellys® Evolution Touch is made up of
one or more steps between which the lid must not be opened.
The Speed and other settings can be set using the touch screen.
In order to program an homogenization protocol, press the "Protocol
Setup" icon on the home screen. The screen below then appears:
1. Click on an icon on the left side to choose the setting that you want to
modify.
2. An adjustment bar appears on the right of the screen.
3. Change the value by dragging the slider from right to left or by using
the -/+ symbols.
Page 14
Icon
Protocol settings
Grinding time
Speed
Number of grinding cycles
Pause time between cycles
Tube size
Cooling module
Setpoint temperature
Cooling control mode
Once all the parameters are set, it is possible to either run the protocol by
pressing the start button on the instrument below the screen, or to save
the protocol in the instrument library.
3.1.4.4 Saving the protocol
To save a protocol, press on the disc icon on the cycles parameters screen
(bottom left of the screen). The screen below then appears:
Values
5 to 120 s
4500 to 6800 rpm and
7200 to 10 000 rpm,
100 rpm increments
1 to 10
5 to 120 s
0.3 mL to 50 mL
ON or OFF
From 0 to 10°C in
increments of 1°C
Manual or Automatic
Page 15
