USER MANUAL
PRECELLYS Evolution Touch
®
1. Click on "Export logs to USB" icon to back up the equipment's file
history: protocols launched, alerts, date changes
2. Click on the «Export library to USB» icon to save the list of protocols of
the equipment.
3. Click on the «import library from USB» icon to replace the library of the
equipment with the one saved on the USB stick.
WARNING: this action will delete all the protocols registered in the
unit.
Press the arrow to go back to the Parameters screen then press the home
icon to back to home screen.
3.2

Characteristics

Technical characteristics
Supply voltage and frequency
Consumption
Fuse
Button battery
Safety
Physical characteristics
Width
Depth
Height
Mass
Temperature of use and storage
Humidity
Altitude
Noise
Pollution level
Operating characteristics
Speed
Number of periods
Duration of period
Time delay between two periods
Page 20
110 V~ / 230 V~ (+/- 10%)- 50 Hz / 60 Hz
<1 kVA
5x20 – T 10A – H 250
Panasonic CR-2032/BN : 3Vdc – 225 mAh
Class I device
380 mm
520 mm
400 mm (635 mm with the lid open)
27.2 kg
15-30°C
50-85% RH
<2,000 m
<70 dB
No. 2: standard environment
4500 –10000 tr/min
1 - 10
10 – 90 secondes
1 – 120 secondes
User interface
Keyboard 1 push Button
1 x 5-inch LCD capacitive touchscreen
Display
1 indicator (green and red)
Capacity
Number of tubes 96 24
Total volume of a tube 0.3ml 0.5 ml/2 ml 7 ml
3.3

Noise level

In normal operation (rotation at 10 000 rpm), the device emits a noise
level lower than 70 dB.
3.4

Warranty

Bertin Technologies warrants that the equipment is free of defects when it
is shipped.
This warranty is limited to a period of one (1) year and does not include
the following parts: fuses, anti-rotation kit, vacuum and containment seals,
blocking plate and tube holder.
This warranty begins when the equipment is installed and registered online
on the www.bertin-technologies.com .
It does not apply in the following cases:
The equipment has not been installed, operated or maintained
in accordance with the instructions described in this manual.
The equipment has been repaired or altered by unqualified
personnel.
The serial number of the equipment is damaged or removed.
3.5

Manufacturer's Address

Bertin Technologies
Parc d'activité du Pas du Lac
10 bis, avenue Ampère
78180 MONTIGNY-LE-BRETONNEUX
France
3.6

Technical assistance

If you cannot resolve a problem after reading this manual, contact the
local office of your dealer.
12 6 3
15 ml 50 ml
