Audio I2S Connector ( P1)

This connector has all I2S signals, it can be interfaced with external custom boards if required or used for probing.
The pinout can be found in the schematic.

SigmaStudio+ ( P2)

This connector interfaces with SigmaStudio+ through the
header. The pinout can be found in the schematic.

Multipurpose pins( P5 )

For use of interfacing with the multi-purpose pins of the ADAU1701. Further information can be found in the
schematic.

ADC Input Connector( P7 )

The ADAU1701 has two Σ-Δ ADCs. P7 will supply the input signal through a 3.5 mm stereo TRS connector
Part Description
3.5mm headphone jack

DAC Output Connector( P20 )

The ADAU1701 includes four Σ-Δ DACs. will supply output signals through a 3.5 mm TRS connector.
Part Description
3.5mm headphone jack
2
A B ( P27 and P21)
P21 is used to connect towards a Sub Node and P27is used to connect towards the main node. These connectors
allow the AD2437 on the eval board to allow communication with other A
Part Description
RJ45 - Ethernet
Ethernet cable assembly
EVAL-AD2437B1MZ Manual
Manufacturer
CUI Devices
Manufacturer
CUI Devices
Manufacturer
Amphenol ICC
Mating Cable
EVAL-ADUSB2EBZ board. The connector is a 0.1"
Part Number
SJ-3523-SMT
Part Number
SJ-3523-SMT
2
B devices on the bus.
Part Number
RJE73-188-00210
Connectors
3–3
