Table 6-1
Starting State
Unplugged
NOPOWER
NOPOWER
NOPOWER
ON
ON
ON
ON
*Based on the default BIOS power settings.
**Microsoft Windows: Pressing the power button begins a graceful shutdown. This
behavior is based on the Windows power button management setting. Oracle Linux
for MICROS: Pressing the power button initiates a graceful shutdown.
Workstation 820 Port Power Considerations for Peripheral
Devices
The following table lists the Workstation 820 IO ports and the power consumed by
each port, depending on BIOS or Diagnostics Utility configurations. Use the table
when considering peripherals. Note that some ports do not accept peripherals.
Table 6-2
Port or Connector
Power In
Network
USB (CFD)

Workstation 820 Port Power Considerations for Peripheral Devices

Power Management State Changes
Event
AC power is connected to a wall outlet and
the last recorded power state was not the
ON state.
The operator touches the power button for 2
second until a beep is heard.
A server application sends a Wake On LAN
command.
AC power fails and then is restored.
The operator touches the power button for 3
seconds until three beeps are heard.
The application shuts down the workstation. NOPOWER
The Client Application Loader sends a
Restart command.
AC power fails and then is restored.
Workstation 820 Port Power Specifications
Available Power Capability
Accepts the Workstation 8 Series power supply only.
Accepts the Ethernet adapter cable for Oracle MICROS
Workstation 8 Series only.
Auto-switching power delivery up to 15V 3A. Supports the 7-
Inch Customer Facing Display.
Chapter 6
Resulting State
NOPOWER
ON
ON
NOPOWER*
NOPOWER**
NOPOWER and then
ON
ON*
