Plug the power cord into a power outlet, and then touch the power button for two
10.
seconds to power on the Workstation 820.

Mounting the Workstation 820 on the Low Profile Stand

Unpack the Low Profile Stand box. Retain the box and foam for potential storage
1.
or shipping needs.
Insert the Workstation 820 into the four openings on the Low Profile Stand
2.
mounting plate until it clicks into place, and then use the Oracle 2.5mm hex key or
equivalent to
Figure 4-12
Connect the Workstation 8 Series power supply to the Power In port on the
3.
Workstation 820. Follow the cable routing path as shown below.
lock the assembly (optional).
Mounting the Workstation 820 on the Low Profile Stand
Note:
Workstation 8 Series ports and cables are color-coded to simplify
assembly.
Mounting the Workstation 820 on the Low Profile Stand
Chapter 4
4-8
