the selected parameter will turn red, at which point you can use + or - to increase or
decrease the value. Once you've completed the necessary adjustments, press MENU to
leave the selected parameter. Move the highlight bar to Exit, and press MENU/ENTER
again to exit.
Please note: The H-Position and V-Position are only available when component or PC
input is selected. Neither are available when the HDMI input is selected.
Picture mode - There are four picture modes to choose from:
User: Select to adjust to your favorite settings (stored for later use)
Standard: Standard factory default settings for optimal display in a normal
environment
Vivid: High saturation picture for optimal display in a bright room
Movie: Picure for comfortable low brightness display in a dark room
Scale - Select overscan when the input source is SD or HD video, to ensure no black
band appears around the screen border. Select underscan when the input
source is a PC signal, to ensure full picture content falls within the screen border.
Noise Reduction - This function only works when input is analog RGB or component
video. It will not work for HDMI input.
H & V position - To adjust for optimal positioning within the screen
Output - VS310HD2HDMI can output a wide variety of PC and HD resolutions as
follows:
VGA (up to 100MH) DVI/HDMI(Up to 165MH)
480i
480p
576i
576p
720p @ 50/60Hz
1080i @ 25/30Hz
1080p @ 50/60Hz
VGA @ 60Hz
SVGA @ 60Hz
XGA @ 60 Hz
SXGA @ 60Hz
UXGA
WXGA @ 60Hz
WSXGA @ 60Hz
WUXGA @ 60Hz
Instruction Manual
Resolution
480i
480p
576i
576p
720p @ 50/60Hz
1080i @ 25/30Hz 1920 x 1080
1080p @ 50/60Hz 1920 x 1080
VGA @ 60Hz
SVGA @ 60Hz
XGA @ 60 Hz
SXGA @ 60Hz 1280 x 1024
UXGA @ 60Hz 1600 x 1200
WXGA @ 60Hz
WSXGA @ 60Hz 1680 x 1050
WUXGA @ 60Hz 1920 x 1200
8
i/p* Format
720 x 480 i RGBHV
720 x 480 p RGBHV
720 x 576 i RGBHV
720 x 576 p RGBHV
1280 x 720 p RGBHV
i RGBHV
p RGBHV
640 x 480 p RGBHV
800 x 600 p RGBHV
1024 x 768 p RGBHV
p RGBHV
p RGBHV
1280 x 800 p RGBHV
p RGBHV
p RGBHV
