- Page 1 INSTRUCTION MANUAL AIR06-B www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
- Page 4 TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x35mm SCREW M3.5x45mm SCREW 8PCS+1spare 12PCS+1spare M3.0x20mm SCREW M3.5x25mm SCREW 4PCS+1spare 20PCS+1spare M3.0x16mm SCREW Roof hinge 16PCS+1spare 2PCS Chewing toy M4.0x20mm SCREW 1PCS 2PCS+1spare...
- Page 5 PARTS Front panel of upper area Left side panel Right side panel Front panel of down area Tray supporting bars Back panel of down area 2PCS Roof Back panel of upper area Divider...
- Page 6 PARTS Left piece of feeder Tray Ramp Right piece of feeder Front board of feeder Bottom tray Metal ramp supporting Brake casters Casters without brake 2PCS 2PCS...
-
Page 7: Product Assembly
PRODUCT ASSEMBLY Upper Area Down Area... - Page 8 PRODUCT ASSEMBLY ① Attach back panel up Part H and down Part E by P4x4. ② Screw the ramp suppor Part R to the down Part E by P8x2 according to the predrill screw holes. Attach two side panel Part A and Part B to the whole back panel by P2x10.
- Page 9 PRODUCT ASSEMBLY Attach the wooden feeder Part L, M and Part N by P3x4. Screw the wooden feeder into Part C from inner by P2x2.
- Page 10 PRODUCT ASSEMBLY Attach the front panels Part C and Part D to the sides by P1x8. Put down supporting bars 2pcs of Part F.
- Page 11 PRODUCT ASSEMBLY Screw the ramp Part J to the supporting bars by P5x2. Slide in the middle tray Part K and bottom tray Part O.
- Page 12 PRODUCT ASSEMBLY ① Put in the divider Part G as show on picture. ② Put in the chewing toy P7 in the cage wherver you want. Screw two casters without brake Part P to the front of hutch legs by P3x4 each.
- Page 13 PRODUCT ASSEMBLY Screw two brake casters Part Q to the back of hutch legs by P3x4 each. Attach the roof Part I to the back panel of hutch by P5x6.
- Page 14 PRODUCT ASSEMBLY Screw the roof hinge P6 to connect the roof and side panel by P5x4 each side. Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
