- Page 1 INSTRUCTION MANUAL AIR06-C www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x60mm SCREW M6.0x50mm BOLT 3PCS+1spare 2PCS+1spare M3.5x40mm SCREW M3.5x35mm SCREW 11PCS+1spare 9PCS+1spare M3.5x25mm SCREW M3.5x20mm SCREW 16PCS+1spare 5PCS+1spare M3.0x16mm SCREW M3.0x10mm SCREW 18PCS+1spare 2PCS+1spare... - Page 4 HARDWARE 2PCS M3.5x20mm SCREW 4PCS+1spare...
- Page 5 PARTS Back upper panel Front upper panel Front down panel Back down panel Right side panel Left side panel Upper divider Down plastic tray Upper plastic tray 2PCS...
- Page 6 PARTS Down divider Supporter of tray Upper ramp 1 PC Down ramp Platform Supporter of ramp Brake casers Casters without brake Roof 2PCS 2PCS...
- Page 7 PARTS Folding metal feeder...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY ① Connect the back Part C & D by 5xP6. ② Screw the ramp supporter Part N to the down panel Part D by 2xP4. Attach the side panel Part E & F to the back by 8xP4. - Page 9 PRODUCT ASSEMBLY Attach the platform Part O to the left side panel by bolt 2xP1. Fix the platform from back side by bolt 1xP1.
- Page 10 PRODUCT ASSEMBLY ① Attach the front Part A & B to the sides by 8xP3. ② Fix Part A & B by 2xP2. ① Insert the divider Part J to the down level. ② Slide in the down plastic tray Part H.
- Page 11 PRODUCT ASSEMBLY ① Insert the tray supporter Part K to upper layer. ② Fix the Part K from front side by 1XP3. Fix the Part K from back side by 1XP4. ③ Screw the ramp Part M to the platform by 2xP7. ④ ...
- Page 12 PRODUCT ASSEMBLY ① Screw the upper ramp Part L by 2xP7. ② Put the chewing toy P10 into the hutch. Attach the folding metal feeder Part S to the hutch by 2xP8.
- Page 13 PRODUCT ASSEMBLY Screw two casters without brake Part Q to the front of hutch legs by P5x8. Screw two brake casters Part R to the back of hutch legs by P5x8.
- Page 14 PRODUCT ASSEMBLY Attach the roof Part P to the hutch by 6xP7. ① Attach the roof hinge P9 with 4xP7 each. ② Attach the lock P11 by 4xP12.
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
