- Page 1 INSTRUCTION MANUAL AIR 77 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x35mm SCREW M3.5x45mm SCREW 8PCS+1spare 8PCS+1spare M3.0x20mm SCREW M3.5x25mm SCREW 4PCS+1spare 16PCS+1spare M3.0x16mm SCREW Roof hinge 16PCS+1spare 2PCS M4.0x20 mm BOLT 2PCS+1 spare... - Page 4 PARTS Metal ramp supporting Upper Back Panel Lower Back Panel Left Panel Upper Front Panel Right Panel Casters without brake Brake casters Lower Front Panel 2PCS 2PCS...
- Page 5 PARTS Lower Tray Upper Tray Tray Supporter 2PCS Divider Roof Ramp...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY ① Attach the back panel Part A and B by 4XP4 screws. ② Attach the ramp supporter Part C by 2XP7 screws. Attach the back panel to the side panels Part D & E by 8XP2 screws. - Page 7 PRODUCT ASSEMBLY Attach the front panel Part F & G by 8XP1 screws. Attach the caster Part H & I by 4XP3 screws each.
- Page 8 PRODUCT ASSEMBLY Put the tray supporter Part J into the slot. Slide in the tray Part K & L.
- Page 9 PRODUCT ASSEMBLY Attach the ramp Part M by 2XP5 screws. Put in the divider Part N.
- Page 10 PRODUCT ASSEMBLY Attach the roof Part O by 6XP5 screws.
- Page 11 PRODUCT ASSEMBLY Attach the roof hinge P6 by 4XP5 screws. Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
