Maintenance

Engine Compartment Panel
Fuse Replacement
Blade fuse/Cartridge fuse
B0468KO03
B0468KO04
[A] : Blade type
[B] : Cartridge type
1. Turn the vehicle off.
2. Turn all other switches off.
3. Remove the fuse panel cover by
pressing the tap and pulling up.
4. Check the removed fuse; replace it if it
is blown. To remove or insert the fuse,
use the fuse puller in the engine
compartment fuse panel.
5. Push in a new fuse of the same rating,
and make sure it fits tightly in the clips.
If it fits loosely, consult an authorized
HYUNDAI dealer.
NOTICE
After checking the fuse panel in the
engine compartment, securely install the
fuse panel cover. You may hear a clicking
sound if the cover is securely latched. If it
9-46
is not securely latched, electrical failure
may occur from water contact.
Multi fuse
B0468KO02
If the multi fuse is blown, it must be
removed as follows:
1. Turn off the engine.
2. Disconnect the negative battery cable.
3. Remove the fuse panel cover by
pressing the tab and pulling it up.
4. Remove the nuts shown in the picture
above.
5. Replace the fuse with a new one of the
same rating.
6. Reinstall in the reverse order of
removal.
Information
If the multi fuse is blown, consult an
authorized HYUNDAI dealer.
