ProLights ECLJZIPLZ1530 User Manual page 6

4 ECLJZIP
ELECTRONICS
• Dimmer: linear 0~100% electronic dimmer
• Dimmer curves: 4 different dimming curves available
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -20° ~ +45°
• Flicker: flicker free operation
• Selectable PWM: 600~25K Hz
ELECTRICAL
• Power consumption: 136 W
• Power supply: 100-240V – 50/60Hz
• Power consumption (at 230V): 136W
• Power consumption (at 120V): 138.6W
• Power factor: pF 0.98 @ 120V - pF 0.97 @ 230V
PHYSICAL
• Cooling: forced air with low noise fan
• Sospension and fixing: hanging bracket suitable for safe hanging and positioning
• Signal connection: Seetronic XLR 5p IN/OUT connectors
• Power connection: Seetronic powerCON waterproof IN/OUT connectors
• IP rating: 65 for temporary outdoor application, not for fixed installation
• Dimensions with ECLJZIPLZ2550 (WxHxD): 537x310x489mm
• Dimensions with ECLJZIPLZ1530 (WxHxD): 619x310x489mm
• Weight: 7.9kg
310 262
310 344
ECLJZIPLZ1530 ECLJZIPLZ2550
275 275
Fig.1 - Technical drawings
ECLJZIP
