Table 8. PCIe adapters supported in the 8001-22C or 8005-22N system (continued)
Feature code Description
EKED Broadcom (LSI) 9300-8E SAS3 HBA PCIe3.0 x8 LP Adapter (Adapter FRU number:
AOC-SAS3-9300-8E)
EKEG SMC quad-port NVMe Host Bus Adapter (PEX9733) PCIe3.0 x8 LP with cables (Adapter FRU
number: AOC-K-SLG3-4E2PB-IB001)
EKEH SMC AOC-K-S3008L-L8i 12 Gbps SAS3/RAID 0,1 and 10 PCIe3.0 x8 LP with cables (Adapter
FRU number: AOC-K-9361-8I2B-IB001)
1
EKFH Intel XL710 Ethernet Converged Network Adapter Quad-port 10G/1G SFP+ PCIe3.0 x8 LP
(Adapter FRU number: AOC-STG-I4S)
Note: This adapter must go in WIO Slot1 in the 8005-12N system.
EKN2 PCIe3 1.6 TB NVMe Flash Adapter (Adapter FRU number: HDS-AVM-HUSPR3216AHP301)
AOC-S3008L-L8e-

12 Gb/s Eight-Port SAS Internal HBA Adapter (Adapter FRU number: AOC-S3008L-L8e-P)

2
P Note: This adapter must go in UIO Slot1 in the 8005-12N system.
1
This adapter is supported on the 8001-22C and 8005-22N.
2
This adapter is only supported on the 8005-22N.
12 Gb/s Eight-Port SAS Internal HBA Adapter (Adapter FRU number:
AOC-S3008L-L8e-P)
Learn about the specifications and operating system requirements for the 12 Gb/s Eight-Port SAS Internal
HBA Adapter .
Overview
The 12 Gb/s Eight-Port SAS Internal HBA Adapter is a PCI Express Gen-3 (PCIe3) x8 adapter. The
adapter can be used in either an x8 or x16 PCIe slot in the system. The adapter expands virtualization
beyond the server level to the network level and combines with hardware optimizations and offloads. It
features 8 internal SAS connectors for high-performance storage connectivity. The adapter uses a
Broadcom 3008 I/O processor with Fusion-MPT (Message Passing Technology) for optimum performance
and a PCI Express host interface for increased bandwidth. The 12 Gb/s Eight-Port SAS Internal HBA
Adapter supports 122 devices as a HBA in IT mode.
