Getting Started and Commonly Used Functions
Download Over Ethernet
1. Connect the BoX2 device to the PC via an Ethernet connection.
2. Open your project in iX Developer.
Select the Project tab and click Download.
3.
The Download Project dialog opens, and all devices connected in the network are listed with
4.
information about IP address and device type.
Select your BoX2 device from the list.
Check that the IP address is correct and click Download.
5.
a. Optional: Click the Include compressed project check box, to compress the project and save
it as a ZIP file.
b. Optional: Click the Password protected check box and enter a password, to protect the ZIP
file.
c. Optional: Click the Copy downloaded project to Memory card check box, to enable SD card
backup of project and settings.
6. The BoX2 device responds to a download request by stopping any current project. The LED will
show purple on/off every 0.5 seconds.
7. Wait until you get a blue LED-indication.
The installation is now completed.

5.2. Data Exchange Between Two Controllers

5.2.1. Configure Controllers
NOTE
In iX Developer, COM port settings can be adjusted on the System ribbon tab.
2023-06 24 Beijer Electronics, MAEN363
