- Page 1 BoX2 base Installation Manual English MAEN274, 2018-03...
- Page 3 The information in this document is subject to change without notice and is provided as available at the time of printing. Beijer Electronics AB, including all its group companies, reserves the right to change any information without updating this publication. Beijer Electronics AB, including all its group companies, assumes no responsibility for any errors that may appear in this document.
- Page 4 Foreword Beijer Electronics, MAEN274...
-
Page 5: Table Of Contents
Grounding the operator panel ........21 Ethernet Connection in the Operator Panel ....22 To Achieve Better EMC Protection ......23 Ambient Temperature ........... 24 Safety ............. 25 Galvanic Isolation ..........26 Cable and Bus Termination RS-485 ......27 Beijer Electronics, MAEN274... - Page 6 Contents Beijer Electronics, MAEN274...
-
Page 7: Safety Precautions
GB/T 26572-2011 standard. O： 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572-2011 规定的限 量要求以下。 X: Indicates that the concentration of the hazardous substance of at least one of all homogeneous materials in the parts is above the relevant threshold of the GB/T Beijer Electronics, MAEN274... -
Page 8: Disposal Requirements Under Weee Regulations
“EXPANSION”. At the moment there are no such units evaluated or allowed. SEULES LES UNITÉS D'EXTENSION CERTIFIÉES UL ET cUL PEUVENT ÊTRE RACCORDÉES AU PORT DÉSIGNÉ « EXPANSION ». À L'HEURE ACTUELLE, AUCUNE UNITÉ DE CE TYPE N'A ÉTÉ TESTÉE OU AUTORISÉE Beijer Electronics, MAEN274... -
Page 9: During Installation
Only qualified personnel may install the operator panel. • Separate the high voltage, signal, and supply cables. • Make sure that the voltage and polarity of the power source is correct before • connecting the operator panel to the power outlet. Beijer Electronics, MAEN274... -
Page 10: During Use
Dismantling and Scrapping The operator panel or parts thereof shall be recycled according to local • regulations. The following components contain substances that might be hazardous to • health and the environment: lithium battery and electrolytic capacitor. Beijer Electronics, MAEN274... -
Page 11: Installation
No tools required - standard usage • 1. Unpack and check the delivery. If damage is found, notify the supplier. Note: Place the operator panel on a stable surface during installation. Dropping the operator panel or letting it fall may cause damage. Beijer Electronics, MAEN274... -
Page 12: Connections To The Controller
Connect cable D. The recommended cross-section of the cable is 1.5 – 2.1.1 Connections to the Controller For information about the cables to be used when connecting the operator panel to the controller, please refer to the help file for the driver in question. Beijer Electronics, MAEN274... -
Page 13: Other Connections And Peripherals
Installation 2.1.2 Other Connections and Peripherals Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier. Beijer Electronics, MAEN274... - Page 14 Installation Beijer Electronics, MAEN274...
-
Page 15: Technical Data
Vibration 1g, according to EN/IEC 60068-2-6, Test Fc Mechanical shock 15g, half-sine, 11ms according to EN/IEC60068-2-27 Approvals and CE / FCC / KC certifications Information is available on www.beijerelectronics.com UL approval Yes, information available at UL.com Beijer Electronics, MAEN274... - Page 16 Technical Data Beijer Electronics, MAEN274...
-
Page 17: Chemical Resistance
The material shows little or no resistance to the following chemicals at room temperature: Acetone Methylisobutyl ketone Ammonia solution, diluted Naphthalene Aniline Nitrobenzene Aromatic hydrocarbons Oleic acid Benzene Olive oil Bromin Phenol Butter Potassium carbonate, sat. Chlorine Sodium hydroxide solution 10% Diethyl ether Soya oil Iodine Toluene Lard Trichloroethylene Beijer Electronics, MAEN274... - Page 18 Chemical Resistance Beijer Electronics, MAEN274...
-
Page 19: Operator Panel Drawings
COM 2 COM 3 COM 4 RS422 Tx+ RS422 Tx+ RS485 Tx+/Rx+ RS485 Tx+/Rx+ RS232 RxD RS232 RxD RS232 TxD RS232 TxD RS422 Rx+ RS422 Tx- RS422 Tx- RS485 Tx-/Rx- RS485 Tx-/Rx- RS232 RTS RS232 CTS RS422 Rx- Beijer Electronics, MAEN274... -
Page 20: Box2 Base Outline
Operator Panel Drawings BoX2 base Outline Note: A Step CAD file is available on the web site www.beijerelectronics.com Beijer Electronics, MAEN274... -
Page 21: Additional Installation Tips
3 turns around the ferrite core provide 9 times the suppression of 1 turn. Connect a wire or grounding braid, that is sized correctly according to local electrical codes, between the chassis of the operator panel and the closest grounding point. Beijer Electronics, MAEN274... -
Page 22: Ethernet Connection In The Operator Panel
1. Check whether the other Ethernet unit has its shield directly grounded or grounded via a capacitor. Note: In many cases, connecting the shielded Ethernet cabling to the chassis at both ends is inappropriate. Hum or grounding loops can occur. Unshielded cabling may even result in fewer communication errors. Beijer Electronics, MAEN274... -
Page 23: To Achieve Better Emc Protection
The shield can be grounded via an external 0.1 μF/250 V film capacitor, see 5 in drawing above. This connects the HF transients to ground. To Achieve Better EMC Protection Initially, use the original cabling from Beijer Electronics primarily. • Use shielded cables for RS-232 communication. -
Page 24: Ambient Temperature
An approximate value of the net power consumption for the operator panel can be calculated by multiplying the supply voltage with the current drawn by the operator panel. This is assuming that all supplied power is transformed to heat. Beijer Electronics, MAEN274... -
Page 25: Safety
Transients on the 24 V feed are connected to the ground. • No risk that the 24 V feed is at a high level in relationship to the ground. This • is not unusual since there is high static electricity. Beijer Electronics, MAEN274... -
Page 26: Galvanic Isolation
24 V feed, disturbances and grounding currents from the 0 V on the 24 V side disrupt the communication. Using this type of unit solves one problem but creates a larger problem! A substandard installation may work now, but problems may arise when other devices are connected. Beijer Electronics, MAEN274... -
Page 27: Cable And Bus Termination Rs-485
Depending on the recipients’ design, the bus wires may be on the same level or require pull-up or pull-down to ensure that no faulty signals are detected when the bus is in resting mode (all transmitters are disconnected). Beijer Electronics, MAEN274... - Page 28 Head office Beijer Electronics AB Box 426 201 24 Malmö, Sweden www.beijerelectronics.com / +46 40 358600...
