JetCon 1301 Series Industrial Media Converter
Quick Installation Guide V1.6
Overview
JetCon 1301 Industrial Media Converter, conforming IEEE 802.3 and 802.3u standard,
supports 1 10/100Base TX plus one 100FX Fast Ethernet Fiber port. JetCon 1301 adopts slim
and compact industrial design to save rail space of compact system requirement. In order to
survive under harsh environment, JetCon 1301 chooses industrial-grade aluminum case with
IP30 standard protection.
e 4-Pin DIP switch can con gure JetCon 1301 to operate in
switch mode or pure converter mode.
e JetCon1301 "-w" model extends support for wide
operation temperature. To extend the link distance and network infrastructure, JetCon1301-s
equips with a transceiver for large power budget for single mode ber to reach 30KM link
distance. JetCon1301 is recommended to be powered by DC24V (18~32V) from the 2-pin
terminal block. For JetCon1301-48V, it is recommended to be powered by DC48V (36~60V).
e power input provides polarity reverse protection to avoid system damage.
Package Check List
JetCon 1301 Industrial Media Converter
Quick Installation Guide
Installation
Mount the unit
Din-Rail mount: Mount the din-rail clip screwed on the rear of
JetCon 1301 on the DIN rail
Grounding JetCon 1301
There is one grounding screw on the bottom
side of JetCon1301. Connect the frame
grounding of JetCon1301 to the grounding
surface to ensure safety and prevent noise.
Wiring the Power Inputs
1. Insert the positive and negative wires into
V+
the V+ and V- contact on the terminal
block connector.
2. Tighten the wire-clamp screws to prevent
the power wires from being loosened.
Notes:
e recommended working voltage is DC24V
Connecting to Network
1. Connecting the Ethernet Ports: Connect one end of an Ethernet cable into the UTP port
of JetCon 1301, while the other end is connected to the attached networking device. UTP
port support auto MDI/MDIX function.
indicate RJ-45 port link and the packets received and transmitted from RJ-45.
2. Connecting the Fiber Port: Connect the ber port on your JetCon 1301 to another Fiber
Ethernet device, by following the gure below. Wrong connection or ber cable type will
cause the ber port not working properly.
ATTENTION
!
DIP Switch Settings for Alarm Relay Output
Pin Nr. #
Pin1
Pin2
Pin3
Pin4
Note: After adjust the DIP-switch, please reboot the unit to activate the new settings.
DC24 V+ V-
Note:
e Link Loss Forwarding function only works when two JetCon 1301 devices are
Earth Ground
connected via ber.
V-
Accept 24AWG wire.
JetCon1301 provide
polarity reverse protection
e LNK / ACT LED will turn on and ash to
This is a Class 1 Laser/LED product.
Don't look into the Laser/LED Beam.
Cable Wiring(SC to SC)
TX A
RX A
Status
Description
Alarm Switch
ON
Enable Link Loss Forwarding function.
Off
Disable Link Loss Forwarding function (Default).
ON
Set RJ-45 in 100Mbps Full Duplex mode.
Off
Set RJ-45 in Auto-Negotiation mode.(Default).
Set Fiber port in Half duplex mode.
ON
Off
Set Fiber port in Full duplex mode.(Default).
Set JetCon1301 in pure converter mode.
ON
Off
Set JetCon1301 in Switch converter mode.(Default).
Support
5 Years Warranty
Each of Beijer Electronics 's product is designed, produced, and tested with high industrial
standard. Beijer Electronics warrants that the product(s) shall be free from defects in materials
and workmanship for a period of ve (5) years from the date of delivery provided that the
product was properly installed and used.
is warranty is voided if defects, malfunctions or failures of the warranted product are caused
by damage resulting from force measure (such as oods, re, etc.), other external forces such
as power disturbances, over spec power input, or incorrect cabling; or the warranted product is
misused, abused, or operated, altered and repaired in an unauthorized or improper way.
RX
RX
Attention! To avoid system damage caused by sparks, please DO NOT plug in power
connector when power is on.
The product is in compliance with Directive 2002/95/EC and 2011/65/EU of the European
TX
TX
Parliament and of the Council of 27 January 2003 on the restriction of the use of certain
RX B
hazardous substances in electrical and electronics equipment (RoHS Directives & RoHS 2.0)
TX B
1 2 3
4
