- Page 1 Installation Manual BoX2 base MAEN274 2023-09...
- Page 2 The information in this document is subject to change without notice and is provided as availa- ble at the time of printing. Beijer Electronics AB, including all its group companies, reserves the right to change any information without updating this publication. Beijer Electronics AB, in- cluding all its group companies, assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
6.3. To Achieve Better EMC Protection ............16 6.4. Ambient Temperature ................17 6.5. Safety ..................... 19 6.6. Galvanic Isolation ................20 6.7. Cable and Bus Termination RS-485 ............20 6.8. USB Flash Drive .................. 21 Beijer Electronics, MAEN274 2023-09... -
Page 5: Safety Precautions
(EEE), please contact your dealer or supplier for further information. For disposal in countries outside of the European Union: If you wish to discard this product please contact your local authorities or dealer and ask for the correct method of disposal. Beijer Electronics, MAEN274 2023-09... -
Page 6: Ul And Cul Installation
LE BOÎTIER OFFRE UN DEGRÉ DE PROTECTION D'AU MOINS IP20, MAIS LORSQU'IL EST INSTALLÉ DANS UN APPAREIL, IL DOIT ÊTRE DE CLASSE IP65. 1.5. During Installation • Install the device according to the accompanying installation instructions. • Ground the device according to the accompanying installation instructions. 2023-09 Beijer Electronics, MAEN274... -
Page 7: During Use
• Before carrying out any cleaning or maintenance operations, disconnect the equipment from the electrical supply. • The battery must be replaced by an authorized Beijer Electronics service center. 1.8. Dismantling and Scrapping • Recycle the device and parts of it according to local regulations. -
Page 8: Installation
Unpack and check the delivery. If damage is found, notify the supplier. NOTE Place the device on a stable surface during installation. Dropping the device or letting it fall may cause damage. Connect the cables in the specified order, according to the following drawing and steps. 2023-09 Beijer Electronics, MAEN274... -
Page 9: Connections To The Controller
Cables. 2.1.2. Other Connections and Peripherals Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier. Beijer Electronics, MAEN274 2023-09... -
Page 10: Technical Data
Technical Data 3. Technical Data Parameter BoX2 base Front panel, W×H×D 130 × 89 × 35 mm Standalone mounting VESA 75 × 75 Note: Maximum screw length for VESA mounting is 4 mm. Usage of longer screws may lead to damage. - Page 11 Technical Data Parameter BoX2 base Vibration 1g, according to IEC 60068-2-6, Test Fc Mechanical shock 15g, half-sine, 11ms according to IEC60068-2-27 Approvals and CE/FCC/KCC Information is available on www.beijerelectronics.com certifications UL approval Information is available on www.beijerelectronics.com UL.com Beijer Electronics, MAEN274...
-
Page 12: Chemical Resistance
The material shows little or no resistance to the following chemicals at room temperature: Acetone Methylisobutyl ketone Ammonia solution, diluted Naphthalene Aniline Nitrobenzene Aromatic hydrocarbons Oleic acid Benzene Olive oil Bromin Phenol Butter Potassium carbonate, sat. Chlorine Sodium hydroxide solution 10% Diethyl ether Soya oil Iodine Toluene Lard Trichloroethylene 2023-09 Beijer Electronics, MAEN274... -
Page 13: Device Drawings
COM 1 COM 2 COM 3 COM 4 RS-422 TX+ RS-485 Tx+/Rx+ RS-485 Tx+/Rx+ RS-232 RxD RS-232 RxD RS-232 TxD RS-232 TxD RS-422 Rx+ RS-422 TX- RS-485 Tx-/Rx- RS-485 Tx-/Rx- RS-232 RTS RS-232 CTS RS-422 RX- Beijer Electronics, MAEN274 2023-09... -
Page 14: Device Outline
Device Drawings 5.2. Device Outline NOTE A Step CAD file is available on www.beijerelectronics.com 2023-09 Beijer Electronics, MAEN274... -
Page 15: Additional Installation Tips
Multi-wire conductors are better than single wire conductors with the same area. A braided conductor wire with the same area is even better. The best is a short, thick grounding braid. Beijer Electronics, MAEN274 2023-09... -
Page 16: Ethernet Connection For The Device
This connects the HF transients to ground. 6.3. To Achieve Better EMC Protection • Initially, use the original cabling from Beijer Electronics primarily. • Place the 24 V DC and communications cabling in one cable trunk/cable duct and 230/380 V AC in another. -
Page 17: Ambient Temperature
2-4 times around the cores are approximately 5-25 times more efficient. 6.4. Ambient Temperature The maximum ambient temperature for the BoX2 device is provided in the specifications. The ambient temperature refers to the temperature in the device cabinet which cools the BoX2 device's electronics. Beijer Electronics, MAEN274 2023-09... - Page 18 This is assuming that all supplied power is transformed to heat. NOTE Please ensure that the temperature will not exceed the maximum ambient operating temperature in the enclosure. This can be influenced by other heat generating devices. 2023-09 Beijer Electronics, MAEN274...
-
Page 19: Safety
• Transients on the 24 V feed are connected to the ground. • No risk that the 24 V feed is at a high level in relationship to the ground. This is not unusual since there is high static electricity. Beijer Electronics, MAEN274 2023-09... -
Page 20: Galvanic Isolation
Depending on the recipients’ design, the bus wires may be on the same level or require pull-up or pull-down to ensure that no faulty signals are detected when the bus is in resting mode (all transmitters are disconnected). 2023-09 Beijer Electronics, MAEN274... -
Page 21: Usb Flash Drive
The USB port, or ports, are of 2.0 standard and support FAT16, FAT32 and exFAT file systems for USB flash drives (option, sold separately). Size limitations for file systems: • FAT16: up to 2 GB • FAT32: up to 32 GB • exFAT: up to 2 TB Beijer Electronics, MAEN274 2023-09...
