- Page 1 BoX2 extreme Installation Manual English MAEN276, 2018-03...
- Page 3 The information in this document is subject to change without notice and is provided as available at the time of printing. Beijer Electronics AB, including all its group companies, reserves the right to change any information without updating this publication. Beijer Electronics AB, including all its group companies, assumes no responsibility for any errors that may appear in this document.
- Page 4 Foreword Beijer Electronics, MAEN276...
-
Page 5: Table Of Contents
COM B ............20 BoX2 extreme Outline .......... 21 6 Additional Installation Tips .......... - Page 6 Contents Beijer Electronics, MAEN276...
-
Page 7: Safety Precautions
SJ/T 11363–2014. O： 表示该有害物质在该部件所有均质材料中的含量均在 SJ/T 11363–2014 规定的限 量要求以下。 X: Indicates that this toxic or hazardous substance contained in at least one of the homogenous materials for this part is above the limit requirement in SJ/T 11363–2014. Beijer Electronics, MAEN276... -
Page 8: Disposal Requirements Under Weee Regulations
Potential electrostatic charging hazard, see instrucions. To avoid electrostatic charge build-up, it must not be rubbed or cleaned with solvents or a dry cloth when installed/used within a potentially explosive atmosphere. POTENTIEL ÉLECTROSTATIQUE RISQUE DE CHARGEMENT, VOIR INSTRUCTIONS. Beijer Electronics, MAEN276... -
Page 9: Iecex/Atex Certificate And Dust Rating
Make sure that the voltage and polarity of the power source is correct before • connecting the operator panel to the power outlet. Peripheral equipment must be appropriate for the application and location. • Use only UL certified and approved M12 cables according to the • accompanying installation instructions. Beijer Electronics, MAEN276... -
Page 10: During Use
• Before carrying out any cleaning or maintenance operations, disconnect the • equipment from the electrical supply. The battery must be replaced by an authorized Beijer Electronics service • center. 1.10 Dismantling and Scrapping The operator panel or parts thereof shall be recycled according to local •... -
Page 11: Installation
900-1618-01 cable TxBR-2 M12 male 4p to blank 3 meter (lan) [EX] – 900-1621-01 cable TxBR-2 M12 male 8p to blank 3 meter (com) [EX] – Other lengths may also be available; please contact Beijer Electronics for details. Beijer Electronics, MAEN276... - Page 12 3. Drill the correct hole pattern in panel outlined above or install unit on VESA compliant mounting bracket. Connect cable A to the terminal, using 14-20 AWG (2.08–0.52 mm – 180–220 N-cm torque. Note: Use minimum 85°C copper conductors only. Beijer Electronics, MAEN276...
-
Page 13: Protective Connector Shield Installation Process
Installation 2.1.1 Protective Connector Shield Installation Process 1. Install the protective connector shield as shown. 2. Secure the cables to the protective connector shield using the included cable ties Beijer Electronics, MAEN276... -
Page 14: Connections To The Controller
file for the driver in question. 2.1.3 Other Connections and Peripherals Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier. Beijer Electronics, MAEN276... -
Page 15: Technical Data
Technical Data Technical Data Parameter BoX2 extreme Dimensions, W × H × D 234 × 183 × 62 mm Sealing IP65 Frame material Powder-coated aluminum Weight 1.5 kg i.MX 6Quad Quad ARM Cortex-A9 Core 1.0 GHz 1 MB L2 cache... - Page 16 Technical Data Parameter BoX2 extreme Approvals and CE / FCC / KC certifications Information is available on www.beijerelectronics.com UL approval Information is available on www.beijerelectronics.com Marine certificates Information is available on www.beijerelectronics.com Beijer Electronics, MAEN276...
-
Page 17: Chemical Resistance
The powder paint shows little or no resistance to the following chemicals at room temperature: Acetic acid, conc. Methyl-ethyl ketone Toluene Acetone Nitric acid 30% Trichlorethylene Ammonia 5% Phenol Xylene Ammonia, conc. Sodium hydroxide 5% 97 octane unleaded petrol Ethyl acetate Sodium hydroxide 30% 98 octane leaded petrol Beijer Electronics, MAEN276... - Page 18 Chemical Resistance Beijer Electronics, MAEN276...
-
Page 19: Operator Panel Drawings
Serial communication port 5.1.1 Power Supply Description M12. 4 pin male 5.1.2 COM A COM 1 COM 2 COM 3 M12, 8 pin male RS422 Tx+ CAN-H RS485 Tx+/Rx+ RS232_RxD RS232_TxD RS422_Rx+ RS422 Tx- CAN-L RS485 Tx-/Rx- RS232_RTS RS422_Rx- Beijer Electronics, MAEN276... -
Page 20: Usb 1/2
USB 1 D- USB 1 D+ 5.1.4 LAN A / LAN B LAN A LAN B M12, 4pin male 5.1.5 COM B COM 3 M12, 8 pin male RS-485 Tx+/Rx+ CAN-H TERM+ TERM+ RS-485 Tx-/Rx- CAN-L TERM- TERM- Beijer Electronics, MAEN276... -
Page 21: Box2 Extreme Outline
Operator Panel Drawings BoX2 extreme Outline 34.2 3.80 178.4 163.2 71.7 Note: A Step CAD file is available on the web site www.beijerelectronics.com Beijer Electronics, MAEN276... - Page 22 Operator Panel Drawings Beijer Electronics, MAEN276...
-
Page 23: Additional Installation Tips
Multi-wire conductors are better than single wire conductors with the same area. A braided conductor wire with the same area is even better. The best is a short, thick grounding braid. To Achieve Better EMC Protection Initially, use the original cabling from Beijer Electronics primarily. • Use shielded M12 cables. •... - Page 24 Ferrite cores that are snapped onto the shielded cabling may remove minor disturbances. Large ferrite pieces that are snapped onto unshielded cabling and where the wires go 2-4 times around the cores are approximately 5-25 times more efficient. Beijer Electronics, MAEN276...
-
Page 25: Safety
Transients on the 24 V feed are connected to the ground. • No risk that the 24 V feed is at a high level in relationship to the ground. This • is not unusual since there is high static electricity. Beijer Electronics, MAEN276... -
Page 26: Galvanic Isolation
24 V feed, disturbances and grounding currents from the 0 V on the 24 V side disrupt the communication. Using this type of unit solves one problem but creates a larger problem! A substandard installation may work now, but problems may arise when other devices are connected. Beijer Electronics, MAEN276... -
Page 27: Cable And Bus Termination Rs-485
Depending on the recipients’ design, the bus wires may be on the same level or require pull-up or pull-down to ensure that no faulty signals are detected when the bus is in resting mode (all transmitters are disconnected). Beijer Electronics, MAEN276... - Page 28 Head office Beijer Electronics AB Box 426 201 24 Malmö, Sweden www.beijerelectronics.com / +46 40 358600...
