Summary of Contents for Beijer Electronics BoX2 extreme
- Page 1 Installation Manual BoX2 extreme MAEN276 2023-09...
- Page 2 The information in this document is subject to change without notice and is provided as availa- ble at the time of printing. Beijer Electronics AB, including all its group companies, reserves the right to change any information without updating this publication. Beijer Electronics AB, in- cluding all its group companies, assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
6.4. Galvanic Isolation ................23 6.5. Cable and Bus Termination RS-485 ............24 6.6. CAN Interface ..................24 6.6.1. Cable Recommendations .............. 24 6.6.2. Termination ................24 6.6.3. Restrictions and Recommendations ..........25 6.7. USB Flash Drive .................. 25 Beijer Electronics, MAEN276 2023-09... -
Page 5: Safety Precautions
(EEE), please contact your dealer or supplier for further information. For disposal in countries outside of the European Union: If you wish to discard this product please contact your local authorities or dealer and ask for the correct method of disposal. Beijer Electronics, MAEN276 2023-09... -
Page 6: Ul And Cul Installation
• Use only UL certified and approved M12 cables or M12 connector with cable gland. See section Installation Process for installation details. See step 3 in the process for UL approved M12 cables sets and M12 connector with cable gland. 2023-09 Beijer Electronics, MAEN276... -
Page 7: During Use
• Before carrying out any cleaning or maintenance operations, disconnect the equipment from the electrical supply. • The battery must be replaced by an authorized Beijer Electronics service center. WARNING On versions with Codesys runtime included, do not replace the battery before a backup of the Codesys retain variables and content has been made! For more information contact our local support team or look in help online. -
Page 8: Installation
Installation 2. Installation 2.1. Installation Process 178.4 163.2 71.7 M3 x 0.5 6 mm min. (4x) M4 x 0.7 6 mm min. (4x) 2023-09 Beijer Electronics, MAEN276... - Page 9 Type 4X, C1D2 Environments (M12 connector with cable gland) below. NOTE M12 connector with cable gland torque: 3 Nm. Drill the correct hole pattern in device outlined above or install unit on VESA compliant mounting bracket. Beijer Electronics, MAEN276 2023-09...
- Page 10 SS 8p male 5.5 - 5.5 - 7.5 mm OD, -30° 7.5 mm Gland C to 70° C (COM) PLTC cable rated 300V, 22AWG, 4 conductor, 5.5 mm – 7.5 mm OD, -30° C to 70° C 2023-09 Beijer Electronics, MAEN276...
-
Page 11: Protective Connector Shield Installation Process
7.5 mm Gland (LAN) Binder 100-1150 99-1430-992-04 X2 extreme Connector, M12 SS 4p female 5.5 - 7.5 mm Gland (Power) 2.1.1. Protective Connector Shield Installation Process Do the following: Install the protective connector shield as shown. Beijer Electronics, MAEN276 2023-09... -
Page 12: Connections To The Controller
2.1.3. Other Connections and Peripherals Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier. 2023-09 Beijer Electronics, MAEN276... -
Page 13: Technical Data
Technical Data 3. Technical Data Parameter BoX2 extreme Front panel, W×H×D 234x183x62 mm Sealing IP66 (IP65 for IECEx\ATEX) Frame material Powder-coated aluminum Weight 1.5 kg i.MX 6Quad Quad ARM Cortex-A9 Core 1.0 GHz 1 MB L2 cache Serial port COM A M12 (8 pin,female) 1×RS-232 Rx/Txwith RTS(no CTS) -
Page 14: Compass Safe Distance
UL.com Marine certificates Information is available on www.beijerelectronics.com 3.1. Compass Safe Distance Variant Condition Standard Compass Steering Compass BoX2 extreme (SC) Non-energized 10 cm 5 cm Non-energized after 15 cm 5 cm magnetization Energized and operating 10 cm 5 cm... -
Page 15: Chemical Resistance
The powder paint shows little or no resistance to the following chemicals at room temperature: Acetic acid, conc. Methyl-ethyl ketone Toluene Acetone Nitric acid 30% Trichlorethylene Ammonia 5% Phenol Xylene Ammonia, conc. Sodium hydroxide 5% 97 octane unleaded petrol Ethyl acetate Sodium hydroxide 30% 98 octane leaded petrol Beijer Electronics, MAEN276 2023-09... -
Page 16: Device Drawings
Serial communication port 5.2. Connectors Connector Description Power supply +24 V DC (18–32 V DC) LAN A 1×10/100 Base-T (shielded RJ45) LAN B 1×10/100 Base-T (shielded RJ45) Serial communication port 5.2.1. Power Supply Description M12. 4 pin male 2023-09 Beijer Electronics, MAEN276... -
Page 17: Communication Ports
The connector supports galvanic isolated RS-485 or CAN. USB 1/2 M12, 8 pin female USB 2 D- USB 2 D+ USB 1 D- USB 1 D+ LAN A / LAN B LAN A LAN B M12, 4pin female Beijer Electronics, MAEN276 2023-09... - Page 18 RS-485 Tx+/Rx+ RS-232_RxD RS-232_TxD RS-422_Rx+ RS-422 Tx- CAN-L RS-485 Tx-/Rx- RS-232_RTS RS-422 Rx- NOTE The connector supports up to two independent serial communication channels and can be configured for RS-232, and RS-422 or RS-485 or CAN. 2023-09 Beijer Electronics, MAEN276...
-
Page 19: Device Outline
Device Drawings 5.3. Device Outline 34.2 3.80 178.4 163.2 71.7 NOTE A Step CAD file is available on the web site www.beijerelectronics.com Beijer Electronics, MAEN276 2023-09... -
Page 20: Additional Installation Tips
Multi-wire conductors are better than single wire conductors with the same area. A braided conductor wire with the same area is even better. The best is a short, thick grounding braid. 2023-09 Beijer Electronics, MAEN276... -
Page 21: To Achieve Better Emc Protection
Additional Installation Tips 6.2. To Achieve Better EMC Protection • Initially, use the original cabling from Beijer Electronics primarily. • Place the 24 V DC and communications cabling in one cable trunk/cable duct and 230/380 V AC in another. If the cables need to be crossed, cross them at 90° only. Avoid combining the cabling for stronger 24 V DC outputs with the communication cabling. -
Page 22: Safety
If there is a substantial distance between the relay contacts for 24 V DC and 230 V AC, it is OK to use the same 24 V devices for all feeds. See 3 in drawing above. Connect 0 V on the 24 V power supply to the ground, see 4 in drawing above. This offers three advantages: 2023-09 Beijer Electronics, MAEN276... -
Page 23: Galvanic Isolation
HMI panel, and can cause errors. Use external units to improve communication and achieve galvanic isolation. Westermo has good industry-standard insulators that are also insulated from the 24 V DC feed. Beijer Electronics, MAEN276 2023-09... -
Page 24: Cable And Bus Termination Rs-485
120 Ohm/1%/0.25W on each end. • Place the termination resistor near the CAN bus connector (as close as possible). • This product has no integrated termination resistors. They must be added externally. 2023-09 Beijer Electronics, MAEN276... -
Page 25: Restrictions And Recommendations
The USB port, or ports, are of 2.0 standard and support FAT16, FAT32 and exFAT file systems for USB flash drives (option, sold separately). Size limitations for file systems: • FAT16: up to 2 GB • FAT32: up to 32 GB • exFAT: up to 2 TB Beijer Electronics, MAEN276 2023-09...
