Macintosh Users - Edirol UM-1 Owner's Manual

Macintosh Users

Using OMS on the Macintosh
Installing OMS
* If the OMS 2.3.7 or a later version is installed, you do not need to install this version of
OMS. Proceed to the next step and install the USB MIDI Driver.
* Check the version of OMS required for your software. If the software requires later
versions, follow the instructions in the owner's manual of your software and install OMS.
* Disconnect the USB cable of the UM-1 from your Macintosh before powering up.
1.
Start up your Macintosh.
2.
Insert the UM-1 Driver CD-ROM into the CD-ROM drive.
3.
In the "UM-1 Drivers"–"UM-1-Driver E"–"OMS"–"OMS 2.3.7" folder of the CD-ROM, find
"Install OMS 2.3.7" and double-click the icon.
4.
Follow the on-screen instructions to perform the installation.
5.
After the installation completes, re-start the Macintosh.
Installing the USB MIDI Driver
* The USB MIDI Driver (for OMS) requires Opcode OMS 2.3.5 or later. If this is not
installed, you must first install OMS, and then install the USB MIDI Driver.
* 64 MB or more memory is required. Virtual memory cannot be used. You must make
memory setting to turn virtual memory "off" before using this.
* Disconnect the USB cable of the UM-1 from your Macintosh before powering up.
1.
Start up your Macintosh.
2.
Insert the UM-1 Driver CD-ROM into the CD-ROM drive.
3.
Connect the USB cable to the USB port on your Macintosh. A dialog indicating that the
software cannot be found will appear, but you should simply click [OK].
* If you connect the UM-1 to the USB port on the keyboard of your Macintosh, this message
will appear: "The USB device 'Unknown Device' cannot operate because it needs more
power than is available." Make sure to connect the UM-1 to a USB connector on the
computer itself.
4.
In the "UM-1 Drivers"–"UM-1 Driver E"–"OMS" of the CD-ROM, double-click the "UM-1
OMS Driver-E Installer" icon.
5.
Follow the on-screen instructions to perform the installation.
21
