Operation
5. The following message appears for 10 to 20 seconds and the Trouble LED extinguishes.
6. Connect the standby batteries as shown in Figure 2-20. The Trouble LED will again light and the
buzzer will sound. The display will indicate the following messages:
7. Press the <SYSTEM ACKNOWLEDGE> Key to silence the buzzer and change the Trouble LED
from flashing to steady illumination.
8. Proceed to Step 6 after the "SLC Not Monitoring On" messages disappear and the number of
active troubles changes from 002 to 001.
9. Set the time and date as follows:
February 2011
SYSTEM INITIALIZING
FENWALNET 8000-ML X.X.X/UI VX.X.X
SLC1Vx.x.x/SLC2vx.x.x/CPCvx.x.x
Figure 4-6. Initialization Message
PASSWORD NOT SET ON
SLC X NOT MONITORING ON
003 ACTIVE TROUBLES REMAIN
PRESS SCROLL TO VIEW
Figure 4-7. Boot-Up Message
a. Press the 0 Key. This display will show this message:
PLEASE ENTER PASSWORD
* * * * * *
Figure 4-8. Password Prompt
b. Press the default Level-1 (Owner) Password (973480) keys and press the
<ENTER> Key. The top-level menu will appear:
1: ISOLATE
3: SET
Figure 4-9. Top-Level Menu Selections
c. Press the 3 Key to select "SET"
1: TIME/DATE
3: SLC DEVICES
5: GLOBALS
7: CONTROL MODULES
Figure 4-10. Set Menu
d. Press the 1 Key to select "TIME/DATE"
1: SET TIME
3: SET TIME FORMAT
Figure 4-11. Time/Date Sub-Menu
2: LIST
4: TEST
2: PORT CONTROL
4: PROGRAMMING
6: OUTPUTS/BACKPLANE
SCROLL for more
2: SET DATE
