88
2. Press the MAKE NEW WAYPOINT soft key.
The waypoint is placed at the current vessel position, or if not available, the
cursor position. It is added to the Waypoint List and named with the next
available number.
To return to the default soft key display, press ENTER or CLEAR three times.

Selecting a Waypoint

Positioning the cursor over a waypoint selects that waypoint and accesses the
waypoint soft keys. These keys enable you to go to (described in Section 5.5),
edit (symbol, name, position), erase or move the waypoint.
Selecting a waypoint from the List allows you to GOTO and EDIT (symbol, name,
position, erase) the waypoint. The Waypoint List also provides options to make
a new waypoint and transfer waypoints.
➤ To select a waypoint using the cursor:
1. Move the cursor over the waypoint, until the letters WPT are displayed.
The Waypoint Data box (see Waypoint Data Display below) and the
following soft keys are displayed:
The selected waypoint can be edited via these soft keys.
➤ To select a waypoint using the Waypoint List:
1. Press MARKS, followed by the WAYPOINT LIST soft key.
The Waypoint List and associated soft keys are displayed.
The list details all waypoints in alpha-numeric order. The selected
waypoint is indicated by the grey selection bar; its position, bearing and
range are provided.
2. Use the trackpad to move the selection bar up and down the list to highlight
the required waypoint.
The selected waypoint can be edited via the soft keys displayed.

Waypoint Data Display

Waypoint data can be viewed in two ways: you can use the context-sensitive
cursor to select the waypoint and thus display the waypoint data box, or you can
view waypoint details on the waypoint list.
Note: To permanently display the target waypoint data box, select it in the
System Set Up menu (see Chapter 7) and use the SCREEN soft key to switch data
boxes on.
HSB Series LCD Display
D4163-1
