Summary of Contents for Toyota RAV4 2019

  • Page 3 Pictorial index Search by illustration For safety Make sure to read through them and security (Main topics: Child seat, theft deterrent system) Vehicle status Reading driving-related information information and (Main topics: Meters, multi-information display) indicators Opening and closing the doors and windows, Before driving adjustment before driving (Main topics: Keys, doors, seats)
  • Page 4: Table Of Contents

    TABLE OF CONTENTS For your information ......3-2. Opening, closing and locking the doors Reading this manual...... How to search ....... Side doors......Pictorial index ........ Back door......Smart entry & start system .104 For safety and security 3-3. Adjusting the seats Front seats......108 1-1.
  • Page 5 TABLE OF CONTENTS Engine (ignition) switch (vehicles Toyota parking assist-sensor with smart entry & start system) ..........243 ..........149 Stop & Start system ....250 Automatic transmission..153 Driving mode select switch CVT (Continuously Variable Multi-terrain Select (AWD vehi- Transaxle)......157 cles) .........259 Manual transmission...160...
  • Page 6 TABLE OF CONTENTS 7-2. Steps to take in an emergency Maintenance and care If your vehicle needs to be towed ..........361 6-1. Maintenance and care If you think something is wrong ..........366 Cleaning and protecting the vehicle exterior ....312 Fuel pump shut off system..367 Cleaning and protecting the If a warning light turns on or a...
  • Page 7 TABLE OF CONTENTS Index What to do if... (Troubleshooting) ..........426 Alphabetical Index .....429...
  • Page 8: For Your Information

     Seat belt pretensioner system Toyota vehicles are currently avail- able in the market. Using these Be sure to check with your Toyota spare parts and accessories which dealer for precautionary measures are not genuine Toyota products...
  • Page 9 EDR under normal • For use by Toyota in a lawsuit driving conditions and no personal • For research purposes where the data (e.g., name, gender, age, and data is not tied to a specific vehicle or crash location) are recorded.
  • Page 10 • For use by Toyota in a lawsuit reading can result in a collision with However, if necessary, Toyota may: resulting death or serious injury to you, your occupants or others.
  • Page 11 WARNING ■ General precaution regarding children’s safety Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehi- cle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the side windows, the moon roof or the panoramic moon roof, or other...
  • Page 12: Reading This Manual

    Reading this manual Symbols Meanings Indicates the action (push- Explains symbols used in this ing, turning, etc.) used to operate switches and manual other devices. Indicates the outcome of Symbols in this manual an operation (e.g. a lid opens). Symbols Meanings WARNING: Explains something that, if...
  • Page 13: How To Search

    ■ How to search Searching by title  Table of contents: P.2 ■ Searching by name  Alphabetical index: P.429 ■ Searching by installation posi- tion  Pictorial index: P.12 ■ Searching by symptom or sound  What to do if... (Troubleshoot- ing): P.426...
  • Page 14: Pictorial Index

    Pictorial index Pictorial index ■Exterior Side doors ..................P.88 Locking/unlocking ................P.88 Opening/closing the side windows...........P.120 Locking/unlocking by using the key ...........P.89, 388 Warning messages ................P.375 Back door ..................P.93 Opening from inside the cabin ............P.97 Opening from outside..............P.96, 97 Warning messages ................P.375 Outside rear view mirrors .............P.118 Adjusting the mirror angle ..............
  • Page 15 Pictorial index Precautions against car wash ............P.313 Replacing the wiper insert..............P.337 Fuel filler door ................P.178 Refueling method................P.178 Fuel type/fuel tank capacity .............P.402 Tires ....................P.331 Tire size/inflation pressure ...............P.407 Winter tires/tire chain ...............P.272 Checking/rotation ................P.331 Coping with flat tires.................P.378 Hood....................P.322 Opening ...................P.322 Engine oil ..................P.402 Coping with overheat ...............P.395 Warning messages ................P.375...
  • Page 16 Pictorial index ■Instrument panel Engine switch.................P.148, 149 Starting the engine/changing the modes ......P.148, 149, 151 Emergency stop of the engine ............P.358 When the engine will not start............P.386 Warning messages ................P.375 Shift lever................P.153, 157, 160 Changing the shift position..........P.154, 158, 160 Precautions against towing ..............P.361 When the shift lever does not move (vehicles with automatic transmission or CVT) ...............P.155, 158...
  • Page 17 Pictorial index Multi-information display ..............P.70 Display ....................P.70 When the warning messages are displayed ........P.375 Turn signal lever ................P.163 Headlight switch ................P.169 Headlights/front position lights/tail lights/ license plate lights/daytime running lights........P.169 Fog lights ..................P.174 Windshield wiper and washer switch ..........P.174 Rear window wiper and washer switch ........P.176 Usage..................P.174, 176 Adding washer fluid................P.330 Warning messages ................P.375...
  • Page 18 Pictorial index ■Switches “ODO TRIP” switch..............P.65, 69 Driving position memory switches ..........P.111 Outside rear view mirror switches ..........P.118 Window lock switch...............P.122 Power window switches..............P.120 Door lock switches ................P.91 Automatic High Beam switch ............P.171 *1, 2 Camera switch Power back door switch ...............P.97 : If equipped : Refer to “Navigation and Multimedia System Owner’s Manual”...
  • Page 19 Pictorial index Meter control switches ..............P.71 Vehicle-to-vehicle distance switch ........P.215, 226 Cruise control switches Dynamic radar cruise control with full-speed range ...... P.211 Dynamic radar cruise control ............P.222 Cruise control ................P.232 Audio remote control switches LTA (Lane Tracing Assist) switch ..........P.192 LDA (Lane Departure Alert with steering control) switch ..P.201...
  • Page 20 Pictorial index VSC OFF switch ................P.267 Seat heater switches ..............P.291 Seat heater/ventilator switches ...........P.291 Stop & Start cancel switch ............P.251 Parking brake switch ..............P.164 Applying/releasing................P.164 Precautions against winter season ..........P.273 Warning buzzer/message ............P.373, 375 Brake hold switch ................P.167 Driving mode select switch............P.257 Multi-terrain Select switch ............P.259 “DAC”...
  • Page 21 Pictorial index : If equipped...
  • Page 22 Pictorial index ■Interior SRS airbags..................P.30 Floor mats..................P.24 Front seats..................P.108 Rear seats..................P.109 Head restraints................P.114 Seat belts ..................P.27 Console box ...................P.295 Inside lock buttons ................P.92 Cup holders ..................P.295 Assist grips ..................P.309...
  • Page 23 Pictorial index ■Ceiling Auxiliary box ..................P.296 Moon roof switches ..............P.123 Interior lights ................P.292 Personal lights ................P.293 Electronic sunshade switch ............P.125 Vanity mirrors.................P.302 Sun visors ..................P.302 Inside rear view mirror ..............P.117 : If equipped : NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
  • Page 24 Pictorial index...
  • Page 25: For Safety And Security

    For safety and security 1-1. For safe use Before driving ..... For safe driving ....Seat belts......SRS airbags ....... Exhaust gas precautions ..1-2. Child safety Riding with children .... Child restraint systems ..1-3. Theft deterrent system Engine immobilizer system . Double locking system..
  • Page 26: For Safe Use Before Driving

    Do not use floor mats designed for other models or different model the carpet. year vehicles, even if they are Insert the retaining hooks (clips) Toyota Genuine floor mats. into the floor mat eyelets. ● Only use floor mats designed for the driver’s seat.
  • Page 27: For Safe Driving

    1-1. For safe use For safe driving WARNING ● With the engine stopped and the shift lever in P (automatic transmis- For safe driving, adjust the sion or CVT) or N (manual trans- seat and mirror to an appropri- mission), fully depress each pedal ate position before driving.
  • Page 28 1-1. For safe use Adjusting the mirrors WARNING Observe the following precautions. Make sure that you can see back- Failure to do so may result in death or ward clearly by adjusting the inside serious injury. ● rear view mirror and outside rear Do not adjust the position of the driver’s seat while driving.
  • Page 29: Seat Belts

    Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.
  • Page 30 If seat belt regulations exist in the coun- the seat belts. Have any necessary try where you reside, please contact repairs carried out by your Toyota your Toyota dealer for seat belt replace- dealer. Inappropriate handling may ment or installation. lead to incorrect operation.
  • Page 31 Toyota dealer. serious injuries in the event of a sud- Failure to do so may cause death or den stop, sudden swerve or accident.
  • Page 32: Srs Airbags

    1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. SRS airbag system ■...
  • Page 33 1-1. For safe use Can help protect primarily the head of occupants in the outer seats ■ SRS airbag system components Front impact sensors SRS warning light Side impact sensors (front door) Curtain shield airbags Seat belt pretensioners and force limiters Side impact sensors (front) Side airbags Side impact sensors (rear)
  • Page 34 1-1. For safe use toxic gas to help restrain the motion of the occupants. ● Depending on the type of collision, it is ■ If the SRS airbags deploy (inflate) possible that only the seat belt preten- ● sioners will activate. Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, ■...
  • Page 35 In the following cases, the vehicle will ● Collision from the side to the vehicle require inspection and/or repair. Contact body other than the passenger com- your Toyota dealer as soon as possible. partment ● Any of the SRS airbags have been ●...
  • Page 36 1-1. For safe use side and curtain shield airbags to WARNING inflate. ■ SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
  • Page 37 An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Toyota strongly recommends that all infants and ● children be placed in the rear seats...
  • Page 38 ● If the areas where the SRS airbags deploying airbag, thus causing a are stored, such as the steering danger. wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
  • Page 39: Exhaust Gas Precautions

    Repairs or modifications of the front closed, open the side windows and fender, front bumper, or side of the have the vehicle inspected at your occupant compartment Toyota dealer as soon as possible. ● Installation of a grille guard (bull ■ When parking bars, kangaroo bar, etc.), snow...
  • Page 40 The exhaust system needs to be checked periodically. If there is a hole or crack caused by corrosion, dam- age to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer.
  • Page 41: Child Safety

    1-2. Child safety Riding with children 1-2.Child safety WARNING ■ When children are in the vehicle Observe the following precau- Never leave children unattended in the vehicle, and never allow children tions when children are in the to have or use the key. vehicle.
  • Page 42: Child Restraint Systems

    P.47 vided in this manual. • Fixed with a seat belt: P.48 ● Toyota strongly urges the use of a • Fixed with an ISOFIX rigid proper child restraint system that anchor: P.50 conforms to the weight and size of •...
  • Page 43 1-2. Child safety When using a child restraint WARNING system ● Holding a child in your or someone else’s arms is not a substitute for a ■ When installing a child child restraint system. In an acci- dent, the child can be crushed restraint system to a front pas- against the windshield or between senger seat...
  • Page 44 1-2. Child safety ● Extreme Hazard! Do not use a rear- WARNING ward facing child restraint on a seat ■ When using a child restraint sys- protected by an airbag in front of it! This is because the force of the rapid inflation of the front passen- Observe the following precautions.
  • Page 45 1-2. Child safety ● Use a child restraint system suit- WARNING able to the age and size of the child ● Only put a forward-facing child and install it to the rear seat. restraint system on the front seat ● If the driver’s seat interferes with when unavoidable.
  • Page 46 1-2. Child safety ■ Before confirming the compat- UN(ECE) R129 approval mark ibility of each seating position is indicated. with child restraint systems Checking the category of the Checking the child restraint sys- child restraint system. tem standards. Check the approval mark of the Use a child restraint system that child restraint system for which of the following categories the...
  • Page 47 1-2. Child safety ■ Compatibility of each seating : Move the front seat fully rearward. If the passenger seat height can be position with child restraint adjusted, move it to the upper most systems position. : Adjust the seatback angle to the most upright position.
  • Page 48 1-2. Child safety ■ Detail information for child restraint systems installation Seating position Seat position number Seating position suitable for univer- Forward sal belted (Yes/No) facing only i-Size seating position (Yes/No) Seating position suitable for lateral fixture (L1/L2/No) Suitable rearward facing fixture R1, R2X, R1, R2X, (R1/R2X/R2/R3/No)
  • Page 49 1-2. Child safety Fixture Description Junior seat Junior seat ence. When securing some types of child restraint systems in rear seat, it  If the seat belt shoulder anchor is may not be possible to properly use ahead of the child seat belt the seat belts in positions next to guide, move the seat cushion the child restraint without interfering...
  • Page 50 1-2. Child safety Installation method Page Seat belt attachment P.48 ISOFIX rigid anchor P.50 attachment Child restraint anchor fit- P.51 ting attachment is not within the “universal” cate- Child restraint system fixed gory (or the necessary information with a seat belt is not in the table), refer to the ■...
  • Page 51 You may need a locking clip to install the child restraint system. Follow the instructions provided by the manufac- turer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Toyota dealer: Locking clip for...
  • Page 52 1-2. Child safety child restraint system outboard rear seats. (Tags display- (Part No. 73119-22010) ing the location of the anchors are attached to the seats.) WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury.
  • Page 53 1-2. Child safety restraint can be removed, ● When using the lower anchors, be remove the head restraint. Oth- sure that there are no foreign objects around the anchors and erwise, put the head restraint in that the seat belt is not caught the upper most position.
  • Page 54 1-2. Child safety  Center rear seat When installing the child restraint sys- tem with the head restraint being raised, be sure to have the top strap pass underneath the head restraint. Anchor fitting Upper anchorage strap Attaching clip ■ Fixing the strap to the anchor Upper anchorage strap fitting...
  • Page 55 1-2. Child safety WARNING ■ Using child restraint anchorages WARNING: child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult seat- belts, harnesses, or for attaching other items or equipment to the vehi- cle.
  • Page 56: Theft Deterrent System

    1-3. Theft deterrent system Engine immobilizer sys- 1-3.Theft deterrent system The vehicle’s keys have built- in transponder chips that pre- vent the engine from starting if a key has not been previously registered in the vehicle’s on- board computer.  Vehicles with smart entry &...
  • Page 57: Double Locking System

    1-3. Theft deterrent system Double locking system NOTICE ■ To ensure the system operates correctly : If equipped Do not modify or remove the system. Unauthorized access to the If modified or removed, the proper vehicle is prevented by dis- operation of the system cannot be abling the door unlocking guaranteed.
  • Page 58 1-3. Theft deterrent system ■ Canceling Using the entry function: Hold the front outside door handle. Using the wireless remote control: Press WARNING ■ Double locking system precau- tion Never activate the double locking sys- tem when there are people in the vehicle because all the doors cannot be opened from inside the vehicle.
  • Page 59: Vehicle Status Information And Indicators

    Vehicle status informa- tion and indicators 2-1. Instrument cluster Warning lights and indicators ......... Gauges and meters (with 4.2- inch display)...... Gauges and meters (with 7- inch display)...... Multi-information display ..Fuel consumption information .........
  • Page 60: Warning Lights And Indicators

    2-1. Instrument cluster Warning lights and indicators 2-1.Instrument cluster The warning lights and indicators on the instrument cluster, center panel and outside rear view mirrors inform the driver of the status of the vehicle’s various systems. Instrument cluster For the purpose of explanation, the following illustrations display all warning lights and indicators illuminated.
  • Page 61 2-1. Instrument cluster  When analog speedometer is displayed  When digital speedometer is displayed Charging system warn- Warning lights ing light (P.368) Warning lights inform the driver of High coolant tempera- malfunctions in the indicated vehi- ture warning light cle’s systems.
  • Page 62 (if equipped)/Drive-Start are not available to help protect you in an accident, which could result in Control warning light death or serious injury. Have the vehi- (P.372) cle inspected by your Toyota dealer immediately if this occurs. Brake hold operated indicator (P.373)
  • Page 63 222, 232) (if equipped) (P.73) LTA indicator (if equipped) (P.197) Parking brake indicator (P.164) LDA indicator (if equipped) (P.205) AUTO EPB OFF indicator Toyota parking assist-sensor (if equipped) (P.164) indicator Eco drive mode indicator equipped) (P.244) (P.257) Sport mode indicator (P.257)
  • Page 64 Have the vehicle system. If this occurs, have the vehicle inspected by your Toyota dealer. inspected by your Toyota dealer. : Depending on the operating condi- tions of the system, the color and state (illuminated/blinking) of the indicator change.
  • Page 65: Inch Display)

    2-1. Instrument cluster Gauges and meters (with 4.2-inch display) The meters display various drive information. Meter display Tachometer Displays the engine speed in revolutions per minute Outside temperature (P.64) Clock (P.65) Multi-information display Presents the driver with a variety of driving-related data (P.70) Displays warning messages if a malfunction occurs (P.375) Speedometer Displays the vehicle speed...
  • Page 66 ● When “--” or “E” is displayed, the sys- excessive engine braking and possi- tem may be malfunctioning. bly an accident resulting in death or Take your vehicle to your Toyota injury. dealer. ● Displays the outside temperature NOTICE within the range of -40°C (-40°F) to...
  • Page 67 2-1. Instrument cluster dia System Owner’s Manual” or Using the “ODO TRIP” “Multimedia Owner’s Manual”. switch Switches the items of the odometer, trip meter A, trip meter B and the brightness of the instrument cluster lights by pressing the “ODO TRIP” switch.
  • Page 68: Gauges And Meters (With 7-Inch Display)

    2-1. Instrument cluster Gauges and meters (with 7-inch display) The meters display various drive information. Meter display The display of the speedometer can be selected from two types, analog or digital. (P.75)  Analog speedometer Tachometer Displays the engine speed in revolutions per minute Speedometer Displays the vehicle speed Clock (P.69)
  • Page 69 2-1. Instrument cluster Trip meters “A” and “B” can be used to record and display different distances inde- pendently. Instrument cluster light control: Displays the brightness of the instrument cluster lights that can be adjusted. Outside temperature (P.68) Multi-information display Presents the driver with a variety of driving-related data (P.70) Displays warning messages if a malfunction occurs (P.375) Shift position and shift range/gear step indicator...
  • Page 70 (at the entrance/exit of a garage, tunnel, etc.) ● When “--” or “E” is displayed, the sys- tem may be malfunctioning. Take your vehicle to your Toyota dealer. ● Displays the outside temperature within the range of -40°C (-40°F) to...
  • Page 71 2-1. Instrument cluster  When the instrument cluster light WARNING control display is displayed, ■ The information display at low pressing and holding the switch temperatures will adjust the brightness of the Allow the interior of the vehicle to instrument cluster lights. warm up before using the liquid crys- tal information display.
  • Page 72: Multi-Information Display

    2-1. Instrument cluster Multi-information display speed range (if equipped) (P.211) • Dynamic radar cruise control (if equipped) (P.222) The multi-information display • Cruise control (if equipped) (P.232) is used to display fuel effi- Menu icons (P.71) ciency related information and various types of driving- Information display area related information.
  • Page 73 2-1. Instrument cluster Information display area Scroll the screen /switch the dis- A variety of information can be dis- play /move the cursor played by selecting a menu icon. Press: Enter/Set Additionally, warning or sugges- Press and hold: Reset/Display tion/advice pop-up displays will be dis- customizable items played in some situations.
  • Page 74 2-1. Instrument cluster played automatically depending on the Displays the driving range with remain- situation. ing fuel. (P.73) ■ Fuel Economy Icon Display Following information is displayed. Driving information display (P.72) Driving support system information display (P.74) Audio system-linked dis- play (P.74) Vehicle information display (P.74)
  • Page 75 2-1. Instrument cluster ■ Eco Driving Indicator (if play equipped)/Distance to empty Suggests the Zone of Eco driving with current Eco driving ratio based on  Display contents acceleration. Eco driving ratio based on acceleration If the acceleration exceeds Zone of Eco driving, the right side of Eco Driving Indicator Zone Display will illuminate.
  • Page 76 2-1. Instrument cluster speed, distance and total time) can Driving support system be displayed vertically.The dis- information display played information changes ■ Driving support system infor- according to the “Drive Info Type” mation display setting (since the system was started or between resets). (P.75) Select to display the operational status of the following systems: Use the displayed information as a ref-...
  • Page 77 2-1. Instrument cluster ■ AWD system display (AWD switches. models) ■ Setting procedure Operate of the meter control switches and select Operate of the meter control switches and select the desired item. • If the function is turned on and off or the volume, etc.
  • Page 78 Select to set the warning sensitivity.  “Volume”  “Sway Warning” Select to set the volume of the buzzer Select to enable/disable the vehicle which sounds when the Toyota parking sway warning. assist-sensor is operated.  “Sway Sensitivity” ■ RCTA (Rear Cross Traffic Select to set the vehicle sway warning Alert) (if equipped) (P.235)
  • Page 79 2-1. Instrument cluster  “Notification method” ■ Settings Select to change each notification  “Language” method used to warn the driver when Select to change the language on the the system recognizes excess speed, multi-information display. no overtaking and no-entry sign. ...
  • Page 80 2-1. Instrument cluster Select to enable/disable the following WARNING pop-up displays, which may appear in ■ Cautions during setting up the some situations. display • Intersection guidance display of the As the engine needs to be running navigation system-linked system (if during setting up the display, ensure equipped) that the vehicle is parked in a place...
  • Page 81: Fuel Consumption Information79

    2-1. Instrument cluster ■ Suggestion to turn off the Fuel consumption infor- headlights mation If the headlights are left on for a certain amount of time after the : If equipped engine switch has been turned off, The fuel consumption informa- a suggestion message will be dis- tion can be displayed on the played.
  • Page 82 2-1. Instrument cluster Select “ECO” on the “Informa- Select “Info” on the “Menu” tion” screen. screen. If the “History” screen is displayed, If the “Trip Information” screen is dis- select “Trip information”. played, select “History”. The image is an example only, and may ...
  • Page 83 2-1. Instrument cluster sumption data Resetting the history data The average fuel consumption his- tory is divided by color into past averages and the average fuel con- sumption since the last time updated. Use the displayed aver- age fuel consumption as a refer- ence.
  • Page 84 2-1. Instrument cluster...
  • Page 85: Before Driving

    Before driving 3-1. Key information Keys........3-2. Opening, closing and locking the doors Side doors ......Back door ......Smart entry & start system104 3-3. Adjusting the seats Front seats......108 Rear seats ......109 Driving position memory ...111 Head restraints ....114 3-4.
  • Page 86: Key Information Keys

    3-1. Key information Keys 3-1.Key information Key number plate ■ When riding in an aircraft Key types When bringing a key with wireless remote control function onto an aircraft, The following keys are provided make sure you do not press any buttons with the vehicle.
  • Page 87 1 m (3 have not had a new electronic key regis- ft.) of the following electrical appli- tered, ask your Toyota dealer to check if ances that produce a magnetic field: an unknown electronic key (other than •...
  • Page 88 Carrying the electronic key on your person (vehicles with smart : These settings must be customized entry & start system) at your Toyota dealer. Carry the electronic key 10 cm (3.9  Vehicles with smart entry & start in.) or more away from electric appli- ances that are turned on.
  • Page 89 3-1. Key information depleted Using the mechanical key ● Near a TV tower, electric power plant, (vehicles with smart entry & gas station, radio station, large dis- start system) play, airport or other facility that gen- erates strong radio waves or electrical noise To take out the mechanical key, ●...
  • Page 90 Unlocks all the doors Press and hold to open the side win- dows. : These settings must be customized at your Toyota dealer.  Vehicles with smart entry & start system Grip the front door handle to unlock the doors.
  • Page 91 5 seconds while pressing and hold- panoramic moon roof (if equipped). : These settings must be customized The setting changes each time an oper- at your Toyota dealer. ation is performed, as shown below. ■ Using the key (When changing the setting continu- ously, release the buttons, wait for at ...
  • Page 92 3-2. Opening, closing and locking the doors remote control. (Locked: Once; topside sensor area is touched, try touching both the topside and underside Unlocked: Twice) sensor areas at the same time. Side windows: A buzzer sounds to indi- When gloves are being worn, remove cate that the side windows are operating the gloves.
  • Page 93 3-2. Opening, closing and locking the doors (P.89, 388) ■ When using the wireless remote ■ control, key or mechanical key Customization and operating the power win- Settings (e.g. unlocking function using a dows, moon roof (if equipped) or key) can be changed. panoramic moon roof (if (Customizable features: P.413) equipped)
  • Page 94 3-2. Opening, closing and locking the doors ■ ■ Using the inside lock buttons When all the doors are locked with the entry function (vehicles with smart entry & start system), wire- less remote control or key ● The doors cannot be unlocked with the door lock switch.
  • Page 95: Back Door

    3-2. Opening, closing and locking the doors or canceled: Back door For instructions on customizing, refer to P.411. The back door can be locked/unlocked and Function Operation opened/closed by the follow- All doors are auto- ing procedures. matically locked Speed linked door when vehicle WARNING locking function...
  • Page 96 3-2. Opening, closing and locking the doors ● Vehicles without power back door: WARNING The back door may suddenly shut if ■ Back door handles it is not opened fully. It is more diffi- cult to open or close the back door Do not hang any object to the back on an incline than on a level sur- door handles.
  • Page 97 When installing an mately 30 seconds after the vehicle is accessory part to the back door, unlocked using the wireless remote con- using a genuine Toyota part is rec- ommended. trol, the security feature automatically locks the vehicle again.
  • Page 98 3-2. Opening, closing and locking the doors after 20 minutes. Opening/closing the back door (vehicles without power back door) ■ Open Raise the back door while pressing up the back door opener switch. ■ If the back door opener is inopera- tive The back door can be unlocked from the inside.
  • Page 99 The power back door automatically opens/closes. ● Do not attach any accessories other than genuine Toyota parts to Unlock the back door before operating. the back door. Pressing the switch while the power ●...
  • Page 100 3-2. Opening, closing and locking the doors again during the halted operation, the back door will perform the reverse operation. ■ Using the back door opener switch When the back door is unlocked: ■ Using the back door handles Press the back door opener switch. Lower the back door using the back When the back door is locked: While carrying the electronic key on...
  • Page 101 3-2. Opening, closing and locking the doors ● When the power back door automati- cally opens, if an abnormality due to people or objects is detected, opera- tion will stop. ■ Jam protection function Sensors are equipped on both sides of the power back door.
  • Page 102 3-2. Opening, closing and locking the doors A buzzer sounds and the emergency flashers flash to indicate that all the doors have been closed and locked. ● If the electronic key is placed inside the vehicle after starting a close oper- ation via the door reserve lock func- tion, the electronic key may become locked inside the vehicle.
  • Page 103 When installing an obstacles or anything that could accessory part to the back door, cause any of your belongings to get using a genuine Toyota part is rec- caught. ommended. ● If anyone is in the vicinity, make ■...
  • Page 104 Do not attach heavy accessories to the back door. When attaching, ask ing the “Vehicle Settings” - “PBD” your Toyota dealer for details. screen from the screen of the ● Do not place your hand on the spin- multi-information display.
  • Page 105 3-2. Opening, closing and locking the doors Adjusting the open position of the back door (vehicles with power back door) The open position of the power back door can be adjusted. Stop the back door in the desir- ■ Customization able position.
  • Page 106: Smart Entry & Start System104

    3-2. Opening, closing and locking the doors ■ Smart entry & start sys- Effective range (areas within which the electronic key is detected) : If equipped The following operations can be performed simply by carry- ing the electronic key on your person, for example in your pocket.
  • Page 107 3-2. Opening, closing and locking the doors ● When an interior alarm pings continu- While the battery-saving mode is set, ously the smart entry & start system cannot be used. To cancel the function, press any Correction proce- Situation of the electronic key buttons. dure The engine switch was turned to ACC...
  • Page 108 3-2. Opening, closing and locking the doors ● that emit radio waves Even if the electronic key is not inside • Portable radio, cellular phone, cord- the vehicle, it may be possible to start less phone or other wireless commu- the engine if the electronic key is near nication devices the window.
  • Page 109 Locking and unlocking the doors: Use such medical devices. the mechanical key. (P.388) ● Starting the engine: P.389 Ask your Toyota dealer for details on disabling the entry function. ■ Customization Settings (e.g. smart entry & start sys- tem) can be changed.
  • Page 110: Adjusting The Seats

    3-3. Adjusting the seats Front seats  Power seat (driver’s side only) 3-3.Adjusting the seats The seats can be adjusted (lon- gitudinally, vertically, etc.). Adjust the seat to ensure the correct driving posture. Adjustment procedure  Manual seat Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle...
  • Page 111: Rear Seats

    3-3. Adjusting the seats Rear seats WARNING ● Manual seat only: After adjusting the seat, make sure that the seat is Reclining adjustments and locked in position. folding the seatbacks can be ■ Seat adjustment done with lever operation. To reduce the risk of sliding under the lap belt during a collision, do not Adjustment procedure recline the seat more than necessary.
  • Page 112 3-3. Adjusting the seats adjustment lever , fold the seat- WARNING back down. ● After adjusting the seat, make sure that the seat is locked in position. If the seatback is not securely locked, the red marking will be visible. Make sure that the red marking is not visi- ble.
  • Page 113: Driving Position Memory

    3-3. Adjusting the seats Driving position mem- WARNING ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to P (automatic transmis- : If equipped sion or CVT) or N (manual trans- This feature automatically mission).
  • Page 114 3-3. Adjusting the seats ■ will be overwritten. Operating the driving position memory after turning the engine switch to OFF Recorded seat positions can be acti- vated up to 180 seconds after the driver’s door is opened and another 60 seconds after it is closed again.
  • Page 115 3-3. Adjusting the seats recorded properly. If 2 or more keys are in the vehicle, the driving position cannot be can- Check that the shift lever is in P. celed properly. Turn the engine switch to ON. Check that the shift lever is in P. Recall the driving position that Turn the engine switch to ON.
  • Page 116: Head Restraints

    3-3. Adjusting the seats ■ Head restraints Rear seats Head restraints are provided for all seats. WARNING ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ●...
  • Page 117 3-3. Adjusting the seats If the head restraint touches the ceiling, making the removal difficult, change the seat height or angle. (P.108) Installing the head restraints Align the head restraint with the installation holes and push it down to the lock position. Press and hold the lock release button when lowering the head...
  • Page 118: Adjusting The Steering Wheel And Mirrors

    3-4. Adjusting the steering wheel and mirrors Steering wheel 3-4.Adjusting the steering wheel and mirrors ■ After adjusting the steering wheel Make sure that the steering wheel is Adjustment procedure securely locked. Otherwise, the steering wheel may Hold the steering wheel and move suddenly, possibly causing an accident, and resulting in death or push the lever down.
  • Page 119: Inside Rear View Mirror

    3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suf- ficient confirmation of the rear view. Adjusting the height of rear Normal position view mirror Anti-glare position The height of the rear view mirror ...
  • Page 120: Outside Rear View Mirrors

    3-4. Adjusting the steering wheel and mirrors Outside rear view mir- ■ To prevent sensor error (vehicles rors with auto anti-glare inside rear view mirror) To ensure that the sensors operate The rear view mirror’s position properly, do not touch or cover them. can be adjusted to enable suf- ficient confirmation of the rear view.
  • Page 121 3-4. Adjusting the steering wheel and mirrors Adjustment procedure Folding the mirrors  To select a mirror to adjust, Manual type press the switch. Push the mirror back in the direc- tion of the vehicle’s rear. Left  Power type Right To adjust the mirror, press the switch.
  • Page 122: Opening, Closing The Windows And Moon Roof

    3-5. Opening, closing the windows and moon roof Power windows window movement is stopped and the 3-5.Opening, closing the windows and moon roof side window is opened slightly. ■ Catch protection function Opening and closing the If an object becomes caught between power windows the door and side window while the side window is opening, side window move-...
  • Page 123 If the side window reverses and cannot order to prevent accidental opera- be fully closed or opened, have the vehi- tion, especially by a child, do not let cle inspected by your Toyota dealer. a child operate the power windows. ■ Door lock linked power window...
  • Page 124 3-5. Opening, closing the windows and moon roof WARNING ● When exiting the vehicle, turn the engine switch to OFF, carry the key and exit the vehicle along with the child. There may be accidental operation, due to mischief, etc., that may possibly lead to an accident.
  • Page 125: Moon Roof

    ■ closed using the wireless remote con- Tilting up and down trol. (P.88) : These settings must be customized at your Toyota dealer. ■ When the moon roof does not close normally Perform the following procedure: Stop the vehicle. Press and hold the “CLOSE” switch.
  • Page 126 Toyota dealer. ● Do not sit on top of the moon roof. ■ If the moon roof does not move ■...
  • Page 127: Panoramic Moon Roof

    3-5. Opening, closing the windows and moon roof Panoramic moon roof WARNING ● When using the wireless remote control or mechanical key and oper- : If equipped ating the moon roof, operate the Use the overhead switches to moon roof after checking to make operate the panoramic moon sure that there is no possibility of any passenger having any of their...
  • Page 128 3-5. Opening, closing the windows and moon roof ■ Tilting the panoramic moon : Quickly slide and release the roof up and down switch in either direction to stop the panoramic moon roof partway. Press the switch to tilt the panoramic moon roof up.
  • Page 129 ● The electronic sunshade is closing. performing the above procedure cor- rectly, have the vehicle inspected by ■ Closing both the panoramic moon your Toyota dealer. roof and electronic sunshade ■ Panoramic moon roof open reminder function Slide the switch forward.
  • Page 130 3-5. Opening, closing the windows and moon roof ● When using the wireless remote WARNING control or mechanical key and oper- ■ Opening the panoramic moon ating the panoramic moon roof, roof operate the panoramic moon roof ● after checking to make sure that Do not allow any passengers to put there is no possibility of any pas- their hands or head outside the...
  • Page 131 3-5. Opening, closing the windows and moon roof NOTICE ■ To prevent damage to the pan- oramic moon roof ● Before opening the panoramic moon roof, make sure that there are no foreign objects, such as stones or ice, around the opening. ●...
  • Page 132 3-5. Opening, closing the windows and moon roof...
  • Page 133: Driving

    & start ........222 system) ......149 Cruise control....232 Automatic transmission ..153 BSM (Blind Spot Monitor) .235 CVT (Continuously Variable Toyota parking assist-sensor Transaxle).......157 ........243 Manual transmission..160 Stop & Start system ..250 Turn signal lever ....163 Driving mode select switch Parking brake ....164...
  • Page 134: Before Driving

    4-1. Before driving ■ Driving the vehicle Stopping 4-1.Before driving  Automatic transmission or CVT The following procedures With the shift lever in D, depress should be observed to ensure the brake pedal. safe driving: If necessary, set the parking brake.
  • Page 135 4-1. Before driving Set the parking brake. (P.164) Press the parking brake switch and parking brake is released If parking on a hill, shift the shift lever to 1 or R as needed. manually. (P.164) Turn the engine switch to OFF ■...
  • Page 136 Make Select (AWD models). sure to operate the pedals properly. ■ Breaking in your new Toyota • Make sure to keep a correct driving To extend the life of the vehicle, observ- posture even when moving the ing the following precautions is recom- vehicle only slightly.
  • Page 137 4-1. Before driving ■ When driving on slippery road WARNING surfaces ● During normal driving, do not turn ● Sudden braking, acceleration and off the engine. Turning the engine steering may cause tire slippage off while driving will not cause loss and reduce your ability to control of steering or braking control, but the vehicle.
  • Page 138 Have the brake pads checked and to a fire. replaced by your Toyota dealer as • The temperature inside the vehicle soon as possible. may cause the plastic lenses and Rotor damage may result if the pads plastic material of glasses to are not replaced when needed.
  • Page 139 4-1. Before driving ■ When braking WARNING ● When the brakes are wet, drive ● Do not attach adhesive discs to the more cautiously. windshield or windows. Do not Braking distance increases when place containers such as air fresh- the brakes are wet, and this may eners on the instrument panel or cause one side of the vehicle to dashboard.
  • Page 140 In the event that you drive on a flooded road and the vehicle is ● Do not shift the shift lever to R with- flooded, be sure to have your Toyota out the vehicle completely stopped. dealer check the following: Doing so may damage the clutch, ●...
  • Page 141: Cargo And Luggage

    4-1. Before driving Cargo and luggage NOTICE ● Lubricant condition for the propel- ler shaft (AWD models), bearings Take notice of the following and suspension joints (where possi- information about storage pre- ble), and the function of all joints, cautions, cargo capacity and bearings, etc.
  • Page 142 4-1. Before driving ● If driving for a long distance, on WARNING rough roads, or at high speeds, ● Do not place cargo or luggage in or stop the vehicle now and then on the following locations. during the trip to make sure the cargo remains in its place.
  • Page 143: Trailer Towing (Except For Australia And New Zealand)

    Toyota does not recommend vehicle. Towing a trailer will towing a trailer with your vehi- have an adverse effect on han- cle. Toyota also does not rec- dling, performance, braking, ommend the installation of a durability, and fuel consump- tow hitch or the use of a tow tion.
  • Page 144 NOTICE  M20A-FKS engine: 800 kg (1764 ■ lb.) Brakes Toyota recommends trailers with  A25A-FKS engine: 1500 kg (3307 brakes that conform to all applicable lb.) federal and state/provincial regula- ● The gross combined weight (sum of tions.
  • Page 145 Front: 1150 kg (2535 lb.) Towing a trailer Rear: 1150 kg (2535 lb.)  AWD models Contact your Toyota dealer for fur- Front: 1220 kg (2690 lb.) ther information about additional requirements such as a towing kits Rear: 1220 kg (2690 lb.) etc.
  • Page 146 Please consult your dealer when ● Use only the position recom- installing trailer lights, as incorrect mended by your Toyota dealer. Do installation may cause damage to not install the trailer hitch on the bumper; this may cause body dam- the vehicle’s lights.
  • Page 147 4-1. Before driving after driving a short distance. the trailer wheels will be closer than the vehicle wheels to the  Practice turning, stopping and inside of the turn. Compensate reversing with the trailer attached by making a larger than normal in an area away from traffic until turning radius.
  • Page 148 Stop and apply the brakes. only after performing the follow- Have someone retrieve the ing: blocks. Apply the brakes and keep them applied. ■ Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new...
  • Page 149 4-1. Before driving power train components (engine, trans- vehicle-trailer increases as speed mission, differential, wheel bearings, increases. etc.) to tow a trailer for the first 800 km (500 miles) of driving. WARNING ■ Maintenance ■ To avoid an accident ● If you tow a trailer, your vehicle will ●...
  • Page 150: Engine (Ignition) Switch (Vehicles Without Smart Entry & Start System)

    Firmly depress the brake pedal ● If the engine becomes difficult to start or stalls frequently, have your (automatic transmission or CVT) vehicle checked by your Toyota or clutch pedal (manual trans- dealer immediately. mission). Turn the engine switch to Changing the engine switch START to start the engine.
  • Page 151: Engine (Ignition) Switch (Vehicles With Smart Entry & Start System)

    4-2. Driving procedures the audio system can be used. Engine (ignition) switch (vehicles with smart ON (“ON” position) entry & start system) All electrical components can be used. START (“START” position) Performing the following oper- For starting the engine. ations when carrying the elec- tronic key on your person ■...
  • Page 152 ■ If the battery is discharged malfunctioning. Have the vehicle inspected by your Toyota dealer immedi- The engine cannot be started using the ately. smart entry & start system. Refer to P.391 to restart the engine.
  • Page 153 If the engine becomes difficult to succession. (P.358) start or stalls frequently, have your However, do not touch the engine vehicle checked by your Toyota switch while driving except in an dealer immediately. emergency. Turning the engine off while driving will not cause loss of ■...
  • Page 154 4-2. Driving procedures the engine switch with brake pedal ■ Auto power off function (automatic transmission or CVT) or  Vehicles with automatic transmission clutch pedal (manual transmission) or CVT released. (The mode changes each If the vehicle is left in ACC for more than time the switch is pressed.) 20 minutes or ON (the engine is not run- ning) for more than an hour with the shift...
  • Page 155: Automatic Transmission

    4-2. Driving procedures shift lever in a position other than P, Automatic transmission the engine switch will not be turned to OFF but instead be turned to : If equipped ACC. Perform the following proce- Select the shift position dure to turn the switch to OFF: depending on your purpose Check that the parking brake is and situation.
  • Page 156 When the warning message goes out, the vehicle can be driven again. If the warning message does not go out after waiting a while, have your vehicle inspected by your Toyota dealer. While the engine switch is ■ Restraining sudden start (Drive-...
  • Page 157 Have the vehicle inspected out of P, the vehicle may suddenly by your Toyota dealer immediately. start, possibly leading to an accident The following steps may be used as an resulting in death or serious injury.
  • Page 158 Downshifting This may indicate a malfunction in the automatic transmission system. Have The selected shift range, from S1 to S8 the vehicle inspected by your Toyota will be displayed on the multi-informa- dealer immediately. (In this situation, the tion display.
  • Page 159: Cvt (Continuously Variable Transaxle)

    Neutral If the warning message does not go out Normal driving after waiting a while, have your vehicle inspected by your Toyota dealer. 10-speed sport sequential ■ Restraining sudden start (Drive- shiftmatic mode driving Start Control) (P.159)
  • Page 160 Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an While the engine switch is emergency measure to ensure that the shift lever can be shifted.
  • Page 161 4-2. Driving procedures the shift knob. The shift lever can be shifted while both buttons are pressed. Upshifting Downshifting WARNING ■ The gear changes once every time the To prevent an accident when shift lever is operated. releasing the shift lock Before pressing the shift lock override The selected gear step, from M1 to button, make sure to set the parking...
  • Page 162: Manual Transmission

    This may indicate a malfunction in the ■ Shifting the shift lever transmission system. Have the vehicle inspected by your Toyota dealer immedi- ately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.) Depress the clutch pedal firmly.
  • Page 163 4-2. Driving procedures ● Do not shift the shift lever to R with- out depressing the clutch pedal. ■ Maximum downshifting speed Observe the downshifting speeds in the following table to prevent over-revving the engine.  Vehicles with 225/65R17 102H tires Shift position Maximum speed ●...
  • Page 164 ■ If the “iMT” indicator illuminates in yellow The iMT may be temporarily unavailable or malfunctioning. Have the vehicle inspected at your Toyota dealer. The “iMT” indicator will illuminate in WARNING green. Press the switch again to cancel ■ iMT.
  • Page 165: Turn Signal Lever

    4-2. Driving procedures ■ Turn signal lever If the turn signals stop flashing before a lane change has been per- formed Operating instructions Operate the lever again. ■ To discontinue flashing of the turn signals during a lane change Operate the lever in the opposite direc- tion.
  • Page 166: Parking Brake

    4-2. Driving procedures Parking brake sary to operate the parking brake while driving. Push the switch to release the The parking brake can be set parking brake or released automatically or • Operate the parking brake switch manually. In automatic mode, while depressing the brake pedal.
  • Page 167 4-2. Driving procedures  Vehicles with automatic trans- mission or CVT  When the shift position is shifted from P, the parking brake will be released, and the parking brake indicator light and parking brake lamp will turn off.  When the shift position is shifted to P, the parking brake will be ■...
  • Page 168 Have the the danger of the vehicle moving that vehicle inspected by your Toyota dealer. may lead to an accident resulting in death or serious injury. ■...
  • Page 169: Brake Hold

    4-2. Driving procedures ● Brake Hold The driver is not wearing the seat belt. If any of the conditions above are detected when the brake hold system is The brake hold system keeps enabled, the system will turn off and the brake hold standby indicator light will go the brake applied when the off.
  • Page 170 4-2. Driving procedures ■ When an inspection at your Toyota NOTICE dealer is necessary ■ When parking the vehicle When the brake hold standby indicator (green) does not illuminate even when The brake hold system is not the brake hold switch is pressed with the...
  • Page 171: Operating The Lights And Wipers

    4-3. Operating the lights and wipers Headlight switch  Type B 4-3.Operating the lights and wipers The headlights can be oper- ated manually or automatically. Turning on the headlights Operating the switch turns on the lights as follows:  Type A The front position, tail, license plate and instrument panel lights turn on.
  • Page 172 To turn the lights on again, turn the the multi-information display engine switch to ON or turn the light The system may be malfunctioning. Have the vehicle inspected by your switch off once and then back to Toyota dealer. position. ■ Customization ■ Light reminder buzzer Settings (e.g.
  • Page 173: Automatic High Beam

    4-3. Operating the lights and wipers Automatic High Beam Turning on the high beam headlights : If equipped The Automatic High Beam uses an in-vehicle camera sen- sor to assess the brightness of streetlights, the lights of vehi- cles ahead etc., and automati- cally turns the high beam on or off as necessary.
  • Page 174 4-3. Operating the lights and wipers The Automatic High Beam indicator will • When vehicles ahead appear from the come on when the system is operating. faraway lane on a wide road • When vehicles ahead have no lights ● The high beam may be turned off if a vehicle ahead that is using fog lights without using the headlights is...
  • Page 175 If “Headlight System Malfunction Visit Your Dealer” is displayed on the multi-information display The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer. Turning the high beam on/off manually ■ Switching to the low beam Pull the lever to original position.
  • Page 176: Fog Light Switch

    4-3. Operating the lights and wipers Fog light switch Windshield wipers and washer The fog lights offer improved visibility in difficult driving Operating the lever can switch conditions, such as in rain and between automatic operation fog. and manual operation, or can use the washer.
  • Page 177 4-3. Operating the lights and wipers sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehi- cle speed. The sensor sensitivity can be adjusted when “AUTO” is selected. ● If the wiper switch is turned to the “AUTO”...
  • Page 178: Rear Window Wiper And Washer

    ■ When a nozzle becomes blocked use the washer. In this case, contact your Toyota dealer. NOTICE Do not try to clear it with a pin or other object. The nozzle will be damaged.
  • Page 179 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota Washer/wiper dual oper- dealer. ation Do not try to clear it with a pin or other object.
  • Page 180: Refueling

    4-4. Refueling Opening the fuel tank 4-4.Refueling ● Always hold the grips on the fuel tank cap and turn it slowly to remove it. A whooshing sound may be heard when the fuel tank cap is loosened. Perform the following steps to Wait until the sound cannot be open the fuel tank cap: heard before fully removing the...
  • Page 181: Opening The Fuel Tank Cap.178

    ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in Turn the fuel tank cap slowly to death or serious injury.
  • Page 182: Using The Driving Support Systems

    Toyota Safety Sense WARNING ■ Toyota Safety Sense : If equipped The Toyota Safety Sense is designed to operate under the assumption that The Toyota Safety Sense con- the driver will drive safely, and is sists of the following drive...
  • Page 183 • If the inner side of the windshield If the front of the radar sensor or the where the front camera is installed is dirty, contact your Toyota dealer. front or back of the grille cover is dirty or covered with water droplets, snow, etc., clean it.
  • Page 184 Contact your Toyota dealer for ice. (P.281, 286) details. ● If water droplets cannot be properly ●...
  • Page 185 Actions and the system will become opera- tional. If the front camera If the message does not disappear, con- is hot, such as tact your Toyota dealer. after the vehicle had been parked Situation Actions in the sun, use the...
  • Page 186: Pcs (Pre-Collision System)184

    If the message does not disappear, con- avoid the collision. If the sys- tact your Toyota dealer. tem determines that the possi- • When the temperature around the bility of a frontal collision with...
  • Page 187 4-5. Using the driving support systems System functions WARNING ■ Limitations of the pre-collision ■ Pre-collision warning system When the system determines that ● The driver is solely responsible for safe driving. Always drive safely, the possibility of a frontal collision is taking care to observe your sur- high, a buzzer will sound and a roundings.
  • Page 188 4-5. Using the driving support systems ● When the vehicle is raised on a lift WARNING with the engine running and the ● If the vehicle is stopped by the tires are allowed to rotate freely operation of the pre-collision brak- ●...
  • Page 189 4-5. Using the driving support systems The system is automatically enabled The warning timing setting is retained each time the engine switch is turned to when the engine switch is turned to OFF. However, if the pre-collision sys- tem is disabled and re-enabled, the If the system is disabled, the PCS operation timing will return to the warning light will turn on and a...
  • Page 190 4-5. Using the driving support systems Relative speed between Detectable objects Vehicle speed your vehicle and object Approx. 30 to 180 km/h (20 Approx. 30 to 180 km/h (20 Vehicles to 110 mph) to 110 mph) Approx. 30 to 80 km/h (20 Approx.
  • Page 191 4-5. Using the driving support systems • When rapidly closing on a detectable • When a detectable object approaches object, etc. very close and then stops before • When approaching objects on the entering the path of your vehicle roadside, such as detectable objects, •...
  • Page 192 4-5. Using the driving support systems reflects radio waves, such as a large • If a detectable object cuts or suddenly truck or guardrail emerges in front of your vehicle • When driving near a TV tower, broad- • When the front of your vehicle is hit by casting station, electric power plant, or water, snow, dust, etc.
  • Page 193 4-5. Using the driving support systems • If a pedestrian/bicyclist is wearing ing, sufficient braking force may not oversized clothing (a rain coat, long be obtained, preventing the system skirt, etc.), making their silhouette from performing properly: obscure • If the braking functions cannot operate •...
  • Page 194: Lta (Lane Tracing Assist)

    4-5. Using the driving support systems LTA (Lane Tracing WARNING Assist) ■ Before using LTA system ● Do not rely solely upon the LTA sys- tem. The LTA system does not : If equipped automatically drive the vehicle or When driving on highways and reduce the amount of attention that freeways with white (yellow) must be paid to the area in front of...
  • Page 195 ● Do not modify the suspension etc. If lane. (Your vehicle may follow the the suspension etc. needs to be preceding vehicle and depart from replaced, contact your Toyota the lane.) dealer. ● When the follow-up cruising dis- ●...
  • Page 196 4-5. Using the driving support systems ● The vehicle is driven in an area WARNING without white (yellow) lines, such as ● Objects or patterns that could be in front of a tollgate or checkpoint, mistaken for white (yellow) lines are or at an intersection, etc.
  • Page 197 4-5. Using the driving support systems move the vehicle back to the center of WARNING the lane. ● The vehicle is extremely tilted due Vehicles with Blind Spot Monitor: When to carrying heavy luggage or having the system determines that the vehicle improper tire pressure.
  • Page 198 4-5. Using the driving support systems not being firmly gripped, a warning is displayed on the multi-information dis- play and the function is temporarily canceled. Vehicles with Blind Spot Monitor: When the system determines that the vehicle might depart from its lane and that the possibility of a collision with an overtak- ing vehicle in the adjacent lane is high, the steering assist function will operate...
  • Page 199 4-5. Using the driving support systems canceled. Indications on multi-infor- mation display Turning LTA system on Press the LTA switch to turn the LTA indicator LTA system on. The illumination condition of the indica- The LTA indicator illuminates and a tor informs the driver of the system message is displayed on the multi-infor- operation status.
  • Page 200 4-5. Using the driving support systems lane centering function is operating.  Inside of displayed lines is white Both outer sides of the lane are dis- played: Indicates that steering wheel assist of the lane centering function is operating. One outer side of the lane is displayed: Indicates that steering wheel assist of the steering assist function is operating.
  • Page 201 4-5. Using the driving support systems • Vehicle speed is approximately 50 lines or a course . (When a white km/h (32 mph) or more. [yellow] line or course is recognized • Width of traffic lane is approximately 3 on only one side, the system will oper- m (9.8 ft.) or more.
  • Page 202 4-5. Using the driving support systems ● If the operation conditions (P.198) are no longer met while the lane cen- tering function is operating, the buzzer may sound to indicate that the func- tion has been temporarily canceled. ■ Steering assist function/lane cen- tering function ●...
  • Page 203: Lda (Lane Departure Alert With Steering Control)

    “LTA Malfunction Visit Your Dealer” camera and radar. The system may not be operating prop- erly. Have the vehicle inspected by your : Boundary between asphalt and the Toyota dealer. side of the road, such as grass, soil, or a curb ● “LTA Unavailable”...
  • Page 204 Do not modify the suspension etc. If attention may lead to an accident, the suspension etc. needs to be resulting in death or serious injury. replaced, contact your Toyota dealer. ● When not using the LDA system, ●...
  • Page 205 4-5. Using the driving support systems ● The vehicle is driven in an area WARNING without white (yellow) lines, such as ● Objects or patterns that could be in front of a tollgate or checkpoint, mistaken for white (yellow) lines are or at an intersection, etc.
  • Page 206 4-5. Using the driving support systems might depart from its lane and that the WARNING possibility of a collision with an overtak- ● The vehicle is extremely tilted due ing vehicle in the adjacent lane is high, to carrying heavy luggage or having the lane departure alert will operate improper tire pressure.
  • Page 207 4-5. Using the driving support systems Vehicles with Blind Spot Monitor: When the system determines that the vehicle might depart from its lane and that the possibility of a collision with an overtak- ing vehicle in the adjacent lane is high, the steering assist function will operate even if the turn signals are operating.
  • Page 208 4-5. Using the driving support systems  Inside of displayed lines is white Indications on multi-infor- mation display Indicates that the system is recognizing white (yellow) lines or a course . When the vehicle departs from its lane, the LDA indicator white line displayed on the side the The illumination condition of the indica- vehicle departs from flashes orange.
  • Page 209 4-5. Using the driving support systems ■ Temporary cancelation of functions lines or a course . (When a white [yel- When operation conditions are no lon- low] line or course is recognized on ger met, a function may be temporarily only one side, the system will operate canceled.
  • Page 210 The system may not be operating prop- road conditions, the warning may not erly. Have the vehicle inspected by your operate. Also, if the system determines Toyota dealer. that the vehicle is driving around a ● “LDA Unavailable” curve, warnings will occur earlier than The system is temporarily canceled due during straight-lane driving.
  • Page 211: Rsa (Road Sign Assist)

    4-5. Using the driving support systems more. RSA (Road Sign Assist) ■ Customization Function settings can be changed. : If equipped (P.75) The RSA system recognizes specific road signs using the front camera to provide infor- mation to the driver via the dis- play.
  • Page 212 4-5. Using the driving support systems ■ Automatic turn-off of RSA sign dis- play In the following situations, a displayed speed limit sign will stop being displayed automatically: ● A new sign is not recognized for a cer- tain distance. ●...
  • Page 213: Dynamic Radar Cruise Control With Full-Speed Range

    Dealer” is shown Use the dynamic radar cruise The system may be malfunctioning. control with full-speed range Have the vehicle inspected by your on freeways and highways. Toyota dealer. ■  Vehicle-to-vehicle distance Customization Some functions can be customized. control mode (P.214) (P.75)
  • Page 214 4-5. Using the driving support systems Indicators • Conditions under which the vehicle- to-vehicle distance control mode ■ Operation switches may not function correctly: P.221 ● Set the speed appropriately depending on the speed limit, traffic flow, road conditions, weather con- ditions, etc.
  • Page 215 4-5. Using the driving support systems ● Assisting the driver to operate the WARNING vehicle ■ Cautions regarding the driving The dynamic radar cruise control with assist systems full-speed range does not include Observe the following precautions, as functions which will prevent or avoid there are limitations to the assistance collisions with vehicles ahead of your provided by the system.
  • Page 216 4-5. Using the driving support systems WARNING ● When there is rain, snow, etc. on the front surface of the radar or front camera ● In traffic conditions that require fre- quent repeated acceleration and deceleration ● When your vehicle is towing a trailer or during emergency towing : Vehicles that can tow a tailer.
  • Page 217 4-5. Using the driving support systems Example of deceleration cruising and follow-up cruising When a preceding vehicle driving slower than the set speed appears When a vehicle is detected running ahead of you, the system automatically deceler- ates your vehicle. When a greater reduction in vehicle speed is necessary, the sys- tem applies the brakes (the stop lights will come on at this time).
  • Page 218 4-5. Using the driving support systems increased or decreased as follows: The vehicle speed at the moment the Fine adjustment: By 1 km/h (0.6 mph) switch is released becomes the set speed. or 1 mph (1.6 km/h) each time the switch is pressed Large adjustment: Increases or decreases in 5 km/h (3.1 mph)
  • Page 219 4-5. Using the driving support systems Long Resuming follow-up cruis- Medium ing when the vehicle has Short been stopped by system control (vehicle-to-vehicle The vehicle-to-vehicle distance is set automatically to long mode when the distance control mode) engine switch is turned to ON. After the vehicle ahead of you If a vehicle is running ahead of you, the starts off, press the “+RES”...
  • Page 220 4-5. Using the driving support systems pedal does not cancel the setting.) speed Pressing the “+RES” switch  Immediately after the cruise con- resumes the cruise control and trol speed was set returns vehicle speed to the set  When depressing the accelerator speed.
  • Page 221 4-5. Using the driving support systems [20 mph]) and press the “-SET” switch to set the speed. Cruise control “SET” indicator will come The vehicle speed at the moment the switch is released becomes the set speed. Adjusting the speed setting: P.216 Canceling and resuming the speed set- ting: P.217 ...
  • Page 222 ■ Automatic cancelation of vehicle- than the above, there may be a malfunc- to-vehicle distance control mode tion in the system. Contact your Toyota Vehicle-to-vehicle distance control mode dealer. is automatically canceled in the follow- ■...
  • Page 223 4-5. Using the driving support systems ● outside of the speed range that the When your vehicle is pointing dynamic radar cruise control system upwards (caused by a heavy load in can operate the luggage compartment, etc.) ■ Brake operation A brake operation sound may be heard and the brake pedal response may change, but these are not malfunctions.
  • Page 224: Dynamic Radar Cruise Control

    4-5. Using the driving support systems Dynamic radar cruise control : If equipped In vehicle-to-vehicle distance control mode, the vehicle auto- matically accelerates and ● When the vehicle ahead of you decel- erates suddenly decelerates to match the ● When driving on a road surrounded by speed changes of the preced- a structure, such as in a tunnel or on a ing vehicle even if the acceler-...
  • Page 225 4-5. Using the driving support systems ■ Operation switches ● Set the speed appropriately depending on the speed limit, traffic flow, road conditions, weather con- ditions, etc. The driver is responsi- ble for checking the set speed. ● Even when the system is function- ing normally, the condition of the preceding vehicle as detected by the system may differ from the con-...
  • Page 226 4-5. Using the driving support systems ● On steep downhills, or where there WARNING are sudden changes between sharp ● Assisting the driver to judge proper up and down gradients following distance Vehicle speed may exceed the set The dynamic radar cruise control speed when driving down a steep hill.
  • Page 227 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar to detect the presence of vehicles up to approx- imately 100 m (328 ft.) ahead, determines the current vehicle-to-vehicle fol- lowing distance, and operates to maintain a suitable following distance from the vehicle ahead.
  • Page 228 4-5. Using the driving support systems set speed The system accelerates until the set speed is reached. The system then returns to constant speed cruising. speed. Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the cruise control main switch to activate the cruise con- trol.
  • Page 229 4-5. Using the driving support systems Short or 1 mph (1.6 km/h) each time the switch is pressed The vehicle-to-vehicle distance is set automatically to long mode when the Large adjustment: Increases or engine switch is turned to ON. decreases in 5 km/h (3.1 mph) or 5 If a vehicle is running ahead of you, the mph (8 km/h)
  • Page 230 4-5. Using the driving support systems Canceling and resuming the speed control ■ Warnings may not occur when In the following instances, warnings may not occur even when the vehi- Pressing the cancel switch can- cle-to-vehicle distance is small. cels the speed control. ...
  • Page 231 4-5. Using the driving support systems Immediately after the switch is pressed, Dynamic Radar Cruise Con- the dynamic radar cruise control indica- trol with Road Sign Assist tor will come on. Afterwards, it switches to the cruise control indicator. (vehicles with RSA) Switching to constant speed control mode is only possible when operating When this function is enabled and...
  • Page 232 ● The shift lever is in range 2nd or Contact your Toyota dealer. higher. ■ Automatic cancelation of constant ● Depending on the control mode, this...
  • Page 233 (P.228) may not be tion in the system. Contact your Toyota activated. dealer. ● Vehicles that cut in suddenly ■...
  • Page 234: Cruise Control

    4-5. Using the driving support systems ■ Conditions under which the vehi- Cruise control cle-to-vehicle distance control mode may not function correctly : If equipped In the case of the following conditions, operate the brake pedal (or accelerator Use the cruise control to main- pedal, depending on the situation) as tain a set speed without necessary.
  • Page 235 4-5. Using the driving support systems cruise control. WARNING ■ To avoid operating the cruise control by mistake Switch the cruise control off using the cruise control main switch when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations.
  • Page 236 4-5. Using the driving support systems The speed setting is also canceled when the brakes are applied or the clutch pedal (manual transmission only) is depressed. Pressing the “+ RES” switch resumes the constant speed control. Resuming is available when the vehicle speed is more than approximately 30 Increases the speed km/h (20 mph).
  • Page 237: Bsm (Blind Spot Monitor)

    The Blind Spot Monitor is a tem. Have the vehicle inspected by your system that has 2 functions: Toyota dealer.  The BSM (Blind Spot Monitor) function Assists the driver in making a decision when changing lanes ...
  • Page 238 4-5. Using the driving support systems tors WARNING BSM function: ■ Cautions regarding the use of When a vehicle is detected in a blind the RCTA function spot of the outside rear view mirrors or The driver is solely responsible for approaching rapidly from behind into a safe driving.
  • Page 239 There may be a sensor malfunction or your Toyota dealer. misaligned. Have the vehicle inspected ● Do not subject a sensor or its sur- at a Toyota dealer. rounding area on the rear bumper ■ Customization to a strong impact.
  • Page 240 Toyota dealer. ● Do not paint the rear bumper any color other than an official Toyota color. The Blind Spot Monitor function ■ Vehicles that can be detected by the Blind Spot Monitor...
  • Page 241 4-5. Using the driving support systems The range of each detection area is: Approximately 0.5 m (1.6 ft.) to 3.5 m (11.5 ft.) from either side of the vehicle The area between the side of the vehicle and 0.5 m (1.6 ft.) from the side of the vehicle cannot be detected.
  • Page 242 4-5. Using the driving support systems tion of a vehicle and/or object may • Immediately after the BSM func- tion/RCTA function are turned on occur. • When towing a trailer ■ Conditions under which the BSM ● Instances of the BSM function unnec- function may not function correctly essarily detecting a vehicle and/or ●...
  • Page 243 (if equipped) or multimedia system (if equipped) screen.  When the Toyota parking assist monitor (if equipped) is displayed The buzzer can alert the driver of faster vehicles approaching from farther away.
  • Page 244 4-5. Using the driving support systems ■ Conditions under which the RCTA ■ The RCTA function is operational function may not function correctly when ● The RCTA function may not detect The RCTA function operates when all of vehicles correctly in the following situ- the following conditions are met: ations: ●...
  • Page 245: Toyota Parking Assist-Sensor

    4-5. Using the driving support systems Toyota parking assist- sensor The distance from your vehicle to objects, such as a wall, when parallel parking or maneuvering into a garage is • Immediately after the RCTA function measured by the sensors and is turned on •...
  • Page 246 (if equipped) screen depending on the position and distance to the object.  When the Toyota parking assist monitor (if equipped) is displayed A simplified image is displayed on the upper corner of the screen when an obstacle is detected.
  • Page 247 4-5. Using the driving support systems When the Toyota parking assist-sensor ■ When to disable the function function is disabled, the Toyota parking In the following situations, disable the assist-sensor OFF indicator (P.61) function as it may operate even illuminates on the multi-information dis- though there is no possibility of a colli- sion.
  • Page 248 Have the vehicle ● inspected by your Toyota dealer. The vicinity of the vehicle is noisy due to vehicle horns, motorcycle engines, ■...
  • Page 249 4-5. Using the driving support systems water, such as when driving on a Sensor detection display, flooded road. object distance ● If the vehicle is significantly tilted. ● The vehicle is approaching a tall or ■ Detection range of the sensors curved curb.
  • Page 250 4-5. Using the driving support systems • Rear center sensor: 150 cm (4.9 ft.) to 65 cm (2.1 ft.) Multi-information display Navigation or multimedia system screen  Approximate distance to object • Front center sensor: 60 cm (2.0 ft.) to 47.5 cm (1.56 ft.) •...
  • Page 251 4-5. Using the driving support systems  Approximate distance to object: Less than 28 cm (0.9 ft.) Navigation or multimedia system screen Multi-information display : The distance segments will blink rapidly. ■ Buzzer operation and dis- tance to an object A buzzer sounds when the sensors are operating.
  • Page 252: Stop & Start System

    4-5. Using the driving support systems  Vehicles with manual transmis- Stop & Start system sion Fully depress the clutch pedal : If equipped and depress the brake pedal to The Stop & Start system stops stop the vehicle. and starts the engine accord- Move the shift lever to N and ing to brake pedal (vehicles release the clutch pedal.
  • Page 253 4-5. Using the driving support systems the Stop & Start system, if the Disabling the Stop & Start brake pedal is released the system engine will remain stopped. Press the Stop & Start cancel  If the accelerator pedal is switch to disable the Stop &...
  • Page 254 Start system. This is not a malfunction may affect the Stop & Start system. of the Stop & Start system. Contact your Toyota dealer for details. • When the air conditioning system is ● When stopping the vehicle for a lon- being used.
  • Page 255 4-5. Using the driving support systems ● engine was restarted is short. When the engine is stopped by the • When the vehicle is stopped fre- Stop & Start system, the engine may quently, such as when in a traffic jam. restart automatically in the following •...
  • Page 256 • If displayed continuously for a long Multi-information display mes- time (more than 60 minutes) sages The battery may be deteriorated. Con- tact your Toyota dealer for details. If the following situations, and a message may be displayed on the multi- “Stop & Start System Unavail- information display.
  • Page 257 4-5. Using the driving support systems Close the hood, turn the engine • The windshield defogger has been turned on. switch off, wait for 30 seconds or more, and then start the engine. “Battery Charging” “In Preparation” • The battery charge may be low. The engine is restarted to prioritize •...
  • Page 258 ■ Replacing the battery the Stop & Start system may not oper- ate correctly. Have your vehicle P.393 inspected by your Toyota dealer. ■ If the Stop & Start cancel indicator ● While the driver’s seat belt is fas- flashes continuously tened, the driver’s and front pas-...
  • Page 259: Driving Mode Select Switch

    4-5. Using the driving support systems Driving mode select Normal mode switch Suitable for normal driving. The driving mode returns to normal mode if the switch is pressed while in The driving modes can be Eco drive mode or sport mode. selected to suit the driving and Sport mode usage conditions.
  • Page 260 4-5. Using the driving support systems operations compared to normal mode lowing procedures to increase the air conditioning performance. and restraining air conditioning system ● operations (heating/cooling). Vehicles with automatic air condition- ing system: Turn eco air conditioning When the switch is pressed while not in mode off (P.287) Eco drive mode, the system switches to ●...
  • Page 261: Multi-Terrain Select (Awd Vehicles)

    4-5. Using the driving support systems Multi-terrain Select ● The road conditions listed in Guide- (AWD vehicles) lines for selecting each mode are for reference only. There is a chance that the function may not be the most appropriate in terms of Multi-terrain Select is a sys- road conditions such as pitch, slip- tem that improves drivability in...
  • Page 262 4-5. Using the driving support systems to Rock & Dirt mode and the Rock & Changing the mode Dirt mode indicator illuminates on the ■ multi-information display. Dynamic Torque Control AWD ■ vehicles Dynamic Torque Vectoring AWD vehicles Mud & Sand mode Mud &...
  • Page 263 Operating noise may be heard from more the engine compartment If the vehicle speed drops below the ■ When an inspection at your Toyota above speeds, the system automatically dealer is necessary switches to the AWD control suitable for In the following situations, the system each mode.
  • Page 264: Snow Mode Switch

    4-5. Using the driving support systems ● When the slip indicator light illumi- Snow mode switch nates while Mud & Sand or Rock & Dirt mode is selected ● : If equipped When the indicator for each mode does not illuminate even though Mud Snow mode can be selected to &...
  • Page 265: Downhill Assist Control System

    4-5. Using the driving support systems When the switch is pressed again, the Downhill assist control snow mode indicator turns off. system : If equipped The downhill assist control system helps to prevent exces- sive speed on steep downhill slopes. The system will operate when the vehicle is traveling under 25 km/h (15 mph) with the...
  • Page 266 • The shift lever is in a position other than D or 1 range of S (vehicles with In the following cases, have your vehicle automatic transmission) or M mode checked by your Toyota dealer. (vehicles with CVT), mode or R. ● The downhill assist control system •...
  • Page 267: Driving Assist Systems

    4-5. Using the driving support systems Driving assist systems WARNING ■ The system may not operate on the following surfaces, which To keep driving safety and per- may lead to an accident causing formance, the following sys- death or serious injury tems operate automatically in ●...
  • Page 268 4-5. Using the driving support systems ■ ■ Trailer Sway Control Dynamic Torque Control AWD system (AWD models) Helps the driver to control trailer sway by selectively applying brake Automatically switches from front- pressure for individual wheels and wheel drive to all-wheel drive reducing driving torque when trailer (AWD) according to the driving con- sway is detected.
  • Page 269 Pressing to turn the system off may your Toyota dealer. make it easier for you to rock the vehicle ■ Operating conditions of hill-start in order to free it.
  • Page 270 4-5. Using the driving support systems ■ Sounds and vibrations caused by tion sounds and vibrations may be gen- the ABS, brake assist, VSC, Trailer erated, but this is not a malfunction. Sway Control, TRC and hill-start ■ EPS operation sound assist control systems When the steering wheel is operated, a ●...
  • Page 271 If the message does not disappear, have your vehicle checked by your Toyota dealer immediately. A malfunction occurred in the AWD system. “AWD System Malfunction  Have your vehicle checked by your Toyota dealer 2WD Mode Engaged Visit Your Dealer” immediately.
  • Page 272 4-5. Using the driving support systems the engine until the display message has turned off. ● When Active Cornering Assist fre- WARNING quently operates, Active Cornering ■ The ABS does not operate effec- Assist may temporarily stop operat- tively when ing to ensure proper operation of ●...
  • Page 273 Control systems will not function cor- cle and trailer should stabilize. rectly if different tires are installed on the vehicle. (P.141) Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspen-...
  • Page 274: Driving Tips

    4-6. Driving tips Winter driving tips 4-6.Driving tips ● Do not drive at speeds in excess of the speed limit or the speed limit specified for the snow tires being Carry out the necessary prepa- used. rations and inspections before ●...
  • Page 275 When parking the vehicle lem with the shift lock system. Have  Park the vehicle and move the the vehicle inspected by your Toyota dealer immediately. shift lever to P (automatic trans- mission or CVT) or 1 or R (man-...
  • Page 276 4-6. Driving tips local regulations before installing Selecting tire chains chains.  Vehicles without 235/55R19 ■ 101V tires Tire chain installation Observe the following precautions when Use the correct tire chain size when installing and removing chains: mounting the tire chains. Chain size ●...
  • Page 277: Utility Vehicle Precautions

    4-6. Driving tips Utility vehicle precau- WARNING tions ■ Utility vehicle precautions Always observe the following precau- tions to minimize the risk of death, This vehicle belongs to the serious injury or damage to your vehi- utility vehicle class, which has cle: higher ground clearance and ●...
  • Page 278 4-6. Driving tips cautions to ensure your driving ● After driving through tall grass, enjoyment and to help prevent the mud, rock, sand, rivers, etc., check that there is no grass, bush, paper, closure of areas to off-road vehi- rags, stone, sand, etc. adhering or cles: trapped on the underbody.
  • Page 279 4-6. Driving tips NOTICE ■ Inspection after off-road driving ● Sand and mud that has accumu- lated around brake discs may affect braking efficiency and may damage brake system components. ● Always perform a maintenance inspection after each day of off-road driving that has taken you through rough terrain, sand, mud, or water.
  • Page 280 4-6. Driving tips...
  • Page 281: Interior Features

    Interior features 5-1. Using the air conditioning system and defogger Manual air conditioning system ........280 Automatic air conditioning sys- .........285 Seat heaters/Seat ventilators ........290 5-2. Using the interior lights Interior lights list....292 5-3. Using the storage features List of storage features ..294 Luggage compartment features ........298...
  • Page 282: Manual Air Conditioning System

    5-1. Using the air conditioning system and defogger 5-1.Using the air conditioning system and defogger Manual air conditioning system : If equipped Air conditioning controls Temperature control switch Fan speed control switch On/off switch Rear window defogger and outside rear view mirror defoggers switch Windshield defogger switch Airflow mode control switch Outside/recirculated air mode switch...
  • Page 283 5-1. Using the air conditioning system and defogger switch. Set the outside/recirculated air mode switch to outside air mode if the recircu- lated air mode is used. To defog the windshield and the side windows quickly, turn the air flow and temperature up.
  • Page 284 5-1. Using the air conditioning system and defogger ● ■ Adjust the temperature setting Air conditioning system opera- tions when the engine is stopped ● Turn off Eco drive mode (P.257) due to the Stop & Start system ■ Fogging up of the windows (vehicles with Stop &...
  • Page 285 5-1. Using the air conditioning system and defogger ■ Adjusting the air flow direction WARNING and opening/closing the air ■ When the outside rear view mir- outlets ror defoggers are operating  Front Do not touch the rear view mirror sur- faces when the outside rear view mir- ror defoggers are on.
  • Page 286 5-1. Using the air conditioning system and defogger WARNING ■ To not interrupt the windshield defogger from operating Do not place anything on the instru- ment panel which may cover the air outlets. Otherwise, air flow may be obstructed, preventing the windshield defoggers from defogging.
  • Page 287: Automatic Air Conditioning System

    5-1. Using the air conditioning system and defogger Automatic air conditioning system : If equipped Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls “DUAL” switch Left-hand side temperature control switch Right-hand side temperature control switch Automatic mode switch “A/C”...
  • Page 288 5-1. Using the air conditioning system and defogger ■ Adjusting the temperature set- ting Turn driver’s side temperature con- trol dial clockwise to increases the temperature and turn the dial coun- terclockwise to decreases the tem- perature. The air conditioning system switches between individual and simultaneous modes each time the “DUAL”...
  • Page 289 5-1. Using the air conditioning system and defogger switch. on, the indicator illuminates on the eco air conditioning mode switch. Set the outside/recirculated air mode ■ S-FLOW mode switch to outside air mode if the recircu- lated air mode is used. (It may switch Priority for airflow is given to the automatically.) front seats, and the airflow and air...
  • Page 290 5-1. Using the air conditioning system and defogger ■ ing capacity Air conditioning system opera- • Fan speed restricted when automatic tions when the engine is stopped mode is selected due to the Stop & Start system (vehicles with Stop & Start system) ●...
  • Page 291 5-1. Using the air conditioning system and defogger the ambient conditions. WARNING Therefore, the fan may stop for a while ■ To prevent the windshield from until warm or cool air is ready to flow fogging up immediately after the automatic mode switch is pressed.
  • Page 292: Seat Heaters/Seat Ventilators

    5-1. Using the air conditioning system and defogger Seat heaters /Seat venti- If equipped lators  Rear : If equipped Seat heaters warm up the seat upholstery. Seat ventilators maintain good ventilation by pulling air through the seat upholstery WARNING Direct air flow to the left or right, ■...
  • Page 293 5-1. Using the air conditioning system and defogger Hi (3 segments lit)  Mid (2 seg- Seat heaters ments lit)  Lo (1 segment lit)  High temperature Low temperature Turns the seat heater on When the seat heater is on, the The level indicators (yellow) light indicator illuminates on the seat...
  • Page 294: Using The Interior Lights

    5-2. Using the interior lights Interior lights list 5-2.Using the interior lights Location of the interior lights Open tray lights (if equipped) Front interior lights/personal lights (P.292, 293) Rear interior light (P.293) Footwell lights (if equipped) Front cup holder lights (if equipped) : These lights turn on when a door is unlocked.
  • Page 295 5-2. Using the interior lights Operating personal lights Turns the lights on/off ■ Illuminated entry system The lights automatically turn on/off according to the engine switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are Turns the door position on opened/closed.
  • Page 296: Using The Storage Features

    5-3. Using the storage features List of storage features 5-3.Using the storage features Location of the storage features Open tray (P.297) Auxiliary box (P.296) Card holder (P.297) Bottle holders (P.296) Console box (P.295) Cup holders (P.295) Glove box (P.295)
  • Page 297 5-3. Using the storage features WARNING ■ Items that should not be left in the vehicle Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ● Glasses may be deformed by heat or cracked if they come into contact with other stored items.
  • Page 298 5-3. Using the storage features  Rear WARNING ■ Items unsuitable for the cup ■ Bottle holders holders ● When storing a bottle, close the cap. Do not place anything other than cups ● The bottle may not be stored depend- or beverage cans in the cup holders.
  • Page 299 5-3. Using the storage features Open tray  Driver’s side WARNING ■ Caution while driving Do not leave the auxiliary box open  Front passenger’s side while driving. Injuries may result in the event of an accident or sudden braking. ■...
  • Page 300: Luggage Compartment Features

    5-3. Using the storage features Luggage compartment WARNING features ■ Items unsuitable for the open tray Observe the following precautions Cargo hooks when putting items in the open tray. Failure to do so may cause items to Raise the hook to use. be thrown out of the tray in the event of sudden braking or steering.
  • Page 301 5-3. Using the storage features Pull up the tab to raise the deck board and move it toward you to remove Place the deck board through Original position the groove and move forward Underside (resin side) ■ Changing the deck board posi- tions (except for vehicles with full-size spare tire) Height of the deck floor can be...
  • Page 302 5-3. Using the storage features Fold the deck board and place ■ Removing the partition plate the rear edge into the holes. WARNING ■ When operating the deck board Do not place anything on the deck board when operating the board. Oth- erwise, your fingers may be caught or an accident may result causing inju- ries.
  • Page 303 5-3. Using the storage features ■ Removing the luggage cover Place the both ends of the lug- gage cover into the holder. Release the cover from the left and right anchors and allow it to retract. WARNING ■ Luggage cover Compress the end of the lug- ●...
  • Page 304: Features

    5-4. Using the other interior features Other interior features 5-4.Using the other interior features NOTICE ■ To prevent battery discharge Sun visors Do not leave the vanity lights on for extended periods while the engine is off. Portable ashtray (if equipped) The ashtray can be installed in the cup holder.
  • Page 305 5-4. Using the other interior features ■ Console box (if equipped) ■ The power outlet can be used when Open the console box and open the The engine switch is in ACC or ON. lid. ■ When turning the engine switch off Disconnect electrical devices with charging functions, such as mobile bat- tery packs.
  • Page 306 5-4. Using the other interior features ● charging only. They are not If a device designed to communicate with a personal computer, such as a designed for data transfer or other USB memory device, is connected purposes. ● If the connected external device is Depending on the external device, turned off (depending on device) it may not charge properly.
  • Page 307 5-4. Using the other interior features ■ Name for all parts Wireless charger (if equipped) A portable device can be charged by just placing Qi standard wireless charge compatible portable devices according to the Wireless Power Consortium, such as smartphones and mobile batteries, etc., on the charge area.
  • Page 308 ■ Lighting conditions of opera- Suspected causes Handling method tion indicator light Vehicle to charger Contact your Operation communication Toyota dealer. indicator Conditions failure. light When the Wireless char- Turning off ger power supply is off On Standby (charging possible state)
  • Page 309 5-4. Using the other interior features • Repeatedly flashes 3 times con- accessory, it may not be possible to charge. When charging is not performed tinuously (Orange) even with the portable device placed on the charge area, remove the cover and Suspected causes Handling method accessories.
  • Page 310 ● Do not attempt to dismantle for dis- is malfunctioning. Contact authorized assembly or modifications Toyota dealer. ● Do not hit or apply a strong force ■ To prevent failure or damage to data ●...
  • Page 311 5-4. Using the other interior features NOTICE ● Do not leave portable devices in the cabin. The temperature inside the cabin may become high, when under the sun, and cause damage to the device. ■ To prevent battery discharge When the engine is stopped, do not use the wireless charger for a long time.
  • Page 312 5-4. Using the other interior features WARNING ■ Items that must not be hanged on the hook Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
  • Page 313 Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior ....312 Cleaning and protecting the vehicle interior ....315 6-2. Maintenance Maintenance requirements318 6-3. Do-it-yourself maintenance Do-it-yourself service precau- tions ........320 Hood .........322 Positioning a floor jack..323 Engine compartment ..325 Tires........331 Tire inflation pressure...
  • Page 314: Cleaning And Protecting The Vehicle Exterior

    For details, ● contact your Toyota dealer. Brushes used in automatic car • When washing the vehicle, use water washes may scratch the vehicle sur- to wash off dirt.
  • Page 315 ■ Precaution regarding the rear bumper with Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may malfunction. If this occurs, consult your Toyota dealer.
  • Page 316 6-1. Maintenance and care ■ When using an automatic car NOTICE wash ■ To prevent paint deterioration Set the wiper switch to off position. and corrosion on the body and If the wiper switch is in “AUTO”, the components (aluminum wheels, wipers may operate and the wiper etc.) blades may be damaged.
  • Page 317: Cleaning And Protecting The Vehicle Interior

    6-1. Maintenance and care Cleaning and protecting WARNING the vehicle interior ■ Water in the vehicle ● Do not splash or spill liquid in the vehicle. Perform cleaning in a manner Doing so may cause electrical com- appropriate to each compo- ponents, etc., to malfunction or nent and its material.
  • Page 318 ■ Safety Sense) Caring for leather areas Do not allow glass cleaner to contact Toyota recommends cleaning the inte- the lens. Also, do not touch the lens. rior of the vehicle at least twice a year to (P.180) maintain the quality of the vehicle’s inte- rior.
  • Page 319 6-1. Maintenance and care  Wipe it off with a soft cloth damp- ened with neutral detergent diluted to approximately 1%.  Wring out any excess water from the cloth and thoroughly wipe off remaining traces of detergent and water.
  • Page 320: Maintenance

    It makes good sense to take your vehi- Improper maintenance could result in cle to your local Toyota dealer for the serious damage to the vehicle and maintenance service as well as other possible death or serious injury.
  • Page 321 ● Engine coolant temperature continu- ally higher than normal (P.63, 66) If you notice any of these clues, take your vehicle to your Toyota dealer as soon as possible. Your vehicle may need adjustment or repair.
  • Page 322: Do-It-Yourself Service Precautions

    Battery condi- • Conventional Radiator and tion  wrench (for terminal condenser (P.328) clamp bolts) (P.328) • “Toyota Super Long Tire inflation • Tire pressure gauge Life Coolant” or a pressure • Compressed air similar high quality (P.333) source ethylene glycol- •...
  • Page 323 6-3. Do-it-yourself maintenance ■ If the fluid level is low or high WARNING It is normal for the brake fluid level to ● Be careful not to touch the engine, go down slightly as the brake pads radiator, exhaust manifold, etc., wear or when the fluid level in the right after driving as they may be accumulator is high.
  • Page 324: Hood

    6-3. Do-it-yourself maintenance Hood Hold the hood open by inserting the supporting rod into the slot. Release the lock from the inside of the vehicle to open the hood. Opening the hood Pull the hood lock release lever. The hood will pop up slightly. WARNING ■...
  • Page 325: Positioning A Floor Jack

    6-3. Do-it-yourself maintenance Positioning a floor jack NOTICE ■ When closing the hood When using a floor jack, follow Be sure to return the support rod to its clip before closing the hood. Closing the instructions in the manual the hood without returning the support provided with the jack and per- rod properly could cause the hood to form the operation safely.
  • Page 326 6-3. Do-it-yourself maintenance ■ Rear...
  • Page 327: Engine Compartment

    6-3. Do-it-yourself maintenance Engine compartment Components Fuse box (if equipped) (P.343) Engine oil filler cap (P.325) Engine oil level dipstick (P.325) Battery (P.328) Radiator (P.328) Electric cooling fan Condenser (P.328) Washer fluid tank (P.330) Engine coolant reservoir (P.327) oil level on the dipstick. Checking and adding the ■...
  • Page 328 6-3. Do-it-yourself maintenance ■ engine and turning off the Checking the oil type and pre- engine, wait more than 5 min- paring the items needed utes for the oil to drain back into Make sure to check the oil type and the bottom of the engine.
  • Page 329 Do not dispose of used oil and fil- ters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
  • Page 330 If you cannot find a leak, have your Do not touch the engine compart- Toyota dealer, test the cap and check for ment. leaks in the cooling system. With the engine switch in ON, the...
  • Page 331 If you feel pain or burning, get med- engine switch mode prior to the bat- ical attention immediately. tery being disconnected is unknown. If the engine will not start even after mul- tiple attempts, contact your Toyota...
  • Page 332 6-3. Do-it-yourself maintenance If the level falls below the second hole WARNING from the bottom (the “LOW” position), ● refill the washer fluid. If electrolyte gets on your clothes It can soak through clothing on to your skin. Immediately take off the clothing and follow the procedure above if necessary.
  • Page 333: Tires

    Worn tread Also, do not mix tires of remarkably different treadwear. Treadwear indicator ● Do not use tire sizes other than The location of treadwear indicators is those recommended by Toyota. shown by a “TWI” or “ ” mark, etc.,...
  • Page 334 Tire rotation Rotate the tires in the order shown. 2WD models: To equalize tire wear and help extend tire life, Toyota recommends that tire rotation is carried out approximately every 10000 km (6000 miles). AWD models: To equalize tire wear and help extend...
  • Page 335: Tire Inflation Pressure

    Reduced safety road, etc.) ● Damage to the drive train If a tire needs frequent inflating, have it NOTICE checked by your Toyota dealer. ■ ■ When inspecting and adjusting Instructions for checking tire infla- tire inflation pressure tion pressure...
  • Page 336: Wheels

    Never use an inner tube in a leak- ing wheel which is designed for a tions tubeless tire. Doing so may result in an accident, causing death or seri-  Use only Toyota wheel nuts and ous injury. wrenches designed for use with your aluminum wheels.
  • Page 337: Air Conditioning Filter

    Removal method  Use only Toyota genuine balance Turn the engine switch off. weights or equivalent and a plas- tic or rubber hammer when bal- Open the glove box and slide off ancing your wheels.
  • Page 338 6-3. Do-it-yourself maintenance pull toward the seat to detach Remove the air conditioning fil- the bottom of the glove box. ter and replace it with a new one. Do not use excessive force if the glove box does not detach when lightly pulled.
  • Page 339: Wiper Insert Replacement

    6-3. Do-it-yourself maintenance Wiper insert replace- NOTICE ment ■ To prevent damage to the filter cover When moving the filter cover in the When replacing the wiper direction of arrow to release the fit- insert, perform the following ting, pay attention not to apply exces- procedure to operate each sive force to the claws.
  • Page 340 6-3. Do-it-yourself maintenance rag. the stopper, and pull out the wiper insert. Slide the wiper blade to remove it from the wiper arm. Stopper When installing, reverse the steps listed. Claw Remove the 2 metal plates from the wiper insert pulled out, and install the plates to a new wiper insert.
  • Page 341 6-3. Do-it-yourself maintenance them to the replacement wiper Rear window wiper insert. Move the wiper blade until a click sound can be heard and the claw detaches, and then remove the wiper blade from the wiper arm. Insert the wiper insert starting from the claw at the center of the wiper blade.
  • Page 342 Improper handling may result in damage to the wiper blades or wiper insert. If you have any concerns about replacing the wiper blades or wiper insert yourself, contact your Toyota dealer. NOTICE ■ When lifting the windshield wip- ●...
  • Page 343: Wireless Remote Control/Elec- Tronic Key Battery

    ● Batteries can be purchased at your Insert a new battery with the “+” termi- Toyota dealer, local electrical appli- nal facing up. ance shops or camera stores. ● Replace only with the same or equiva- lent type recommended by the manu- facturer.
  • Page 344 6-3. Do-it-yourself maintenance cover into the key. cover damaged. To prevent damage to the key, cover the tip of the flathead screwdriver with a rag. Install the key cover. Align the key cover with the key and then press it straight into the key. Remove the depleted battery Make sure that the key cover is using a small flathead screw-...
  • Page 345: Checking And Replacing Fuses

    6-3. Do-it-yourself maintenance Checking and replacing WARNING fuses ■ Removed battery and other parts These parts are small and if swal- lowed by a child, they can cause If any of the electrical compo- choking. Keep away from children. nents do not operate, a fuse Failure to do so could result in death may have blown.
  • Page 346 6-3. Do-it-yourself maintenance  Engine compartment: Type B the pullout tool. fuse box ) and ( Push claw ( ) to com- pletely release the lock, and then lift up the cover. Check if the fuse is blown. Replace the blown fuse with a new fuse of an appropriate amperage rating.
  • Page 347 NOTICE ■ Before replacing fuses Have the cause of electrical overload determined and repaired by your Toyota dealer as soon as possible. ■ To prevent damage to the engine compartment fuse box cover When opening the fuse box, com- Normal fuse pletely release the claw locks before lifting up the cover.
  • Page 348: Light Bulbs

    As there is a danger that compo- nents may be damaged, we recommend that replacement is carried out by your Toyota Front turn signal lights dealer. Fog lights Preparing for light bulb...
  • Page 349 LED lights The lights other than the following lights each consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ● Front turn signal ●...
  • Page 350 6-3. Do-it-yourself maintenance Remove the screws. Turn the bulb base counter- clockwise. Remove the screws and clips, Set the new light bulb. partly remove the fender liner. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clock- wise to set.
  • Page 351 6-3. Do-it-yourself maintenance Reinstall the fender liner. Remove the securing screws and remove the unit. Remove the lamp assembly by pulling it directly backward from the rear of the vehicle. Turn the bulb base counter- clockwise. Reinstall the screws. Remove the light bulb. ■...
  • Page 352 6-3. Do-it-yourself maintenance unit by inserting it and turning Reinstall the screws. the bulb base clockwise. Reinstall the cover. Align the grooves on the light unit with the claws, and insert the light unit straight so that the pin on the light unit fit into the hole.
  • Page 353 6-3. Do-it-yourself maintenance turning the bulb base. after installing the bulb base. Remove the light bulb. Reinstall the cover. ■ Install a new light bulb. Outer foot lights (if equipped) Press the upper part of the out- side rear view mirror to tilt the mirror face upward, and discon- nect the four tabs behind the mirror.
  • Page 354 6-3. Do-it-yourself maintenance drop the mirror. Disconnect the tabs behind the mirror cover, and remove the mirror cover. Disconnect the connectors behind the mirror, and remove the mirror. Fold the mirror before removing Make sure to check the connectors, to the light unit.
  • Page 355 6-3. Do-it-yourself maintenance damage the tabs. Remove the light bulb. Install a new light bulb then install the bulb base to the light unit by inserting it and turning the bulb base clockwise. Secure the cord with the clip back again after installing the bulb base.
  • Page 356 6-3. Do-it-yourself maintenance 12Reconnect the connectors of the the two screws. mirror. 13Align the tabs, and secure the mirror by pushing in each diago- nally-opposite pair of tabs in 10Extend the mirror. order. Make sure to insert the tabs in order as shown in the illustration, and push them in until a click is heard.
  • Page 357 6-3. Do-it-yourself maintenance WARNING ■ Replacing light bulb ● Turn off the light. Do not attempt to replace the bulb immediately after turning off the light. The bulb become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands.
  • Page 358 6-3. Do-it-yourself maintenance...
  • Page 359: When Trouble Arises

    When trouble arises 7-1. Essential information Emergency flashers..358 If your vehicle has to be stopped in an emergency358 If the vehicle is trapped in rising water.......360 7-2. Steps to take in an emer- gency If your vehicle needs to be towed ......361 If you think something is wrong...
  • Page 360: Emergency Flashers

    7-1. Essential information Emergency flashers If your vehicle has to be 7-1.Essential information stopped in an emer- gency The emergency flashers are used to warn other drivers when the vehicle has to be Only in an emergency, such as stopped in the road due to a if it becomes impossible to breakdown, etc.
  • Page 361 7-1. Essential information  Vehicles without smart entry & ● Vehicles without smart entry & start start system system: Never attempt to remove the key, as doing so will lock the Turn the engine switch to ACC. steering wheel.  Vehicles with smart entry &...
  • Page 362: If The Vehicle Is Trapped In Rising Water

    However, an emergency hammer can not shatter the wind- shield as it is laminated glass. : Contact your Toyota dealer or any reliable repairer, or aftermarket accessory manufacturer for further information about an emergency hammer.
  • Page 363: Steps To Take In An Emergency

    If the vehicle is towed with the front wheels ommend having your vehicle contacting the ground, the drivetrain towed by your Toyota dealer or and related parts may be damaged. commercial towing service, using a wheel-lift type truck or flatbed truck.
  • Page 364 If not securely installed, towing eyelet may come loose during towing. The following may indicate a prob- lem with your transmission. Contact your Toyota dealer or commercial NOTICE towing service before towing. ■ To prevent damage to the vehicle ...
  • Page 365 7-2. Steps to take in an emergency Towing with a wheel-lift type Using a flatbed truck truck If your vehicle is transported by a flatbed truck, it should be tied down  From the front (2WD models) at the locations shown in the illus- Release the parking brake.
  • Page 366 7-2. Steps to take in an emergency  Type A Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing eyelets. This should only be attempted on hard surfaced roads for at most 80 km (50 miles) at under 30 km/h (18 mph).
  • Page 367 7-2. Steps to take in an emergency  Type B If the engine does not start, turn the engine switch to ON. Vehicles with Stop & Start system: Before towing the vehicle, turn the engine switch to OFF once, and then start the engine.
  • Page 368: If You Think Something Is Wrong

    If you notice any of the follow- touches the floor ing symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms  Fluid leaks under the vehicle (Water dripping from the air con- ditioning after use is normal.)
  • Page 369: Fuel Pump Shut Off System367

    7-2. Steps to take in an emergency Fuel pump shut off sys- To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the sup- ply of fuel to the engine. Restarting the engine Follow the procedure below to restart the engine after the system...
  • Page 370: If A Warning Light Turns On Or A

    ■ Brake system warning light Warning light Details/Actions Indicates a malfunction in the parking brake system  Have the vehicle inspected by your Toyota dealer immediately. (Yellow) ■ Charging system warning light Warning light Details/Actions Indicates a malfunction in the vehicle’s charging sys-...
  • Page 371  The electronic engine control system;  The electronic throttle control system;  The emission control system (if equipped); or  The electronic CVT control system  Have the vehicle inspected by your Toyota dealer immediately. ■ SRS warning light...
  • Page 372 7-2. Steps to take in an emergency ■ Electric power steering system warning light (warning buzzer) Warning light Details/Actions Indicates a malfunction in the EPS (Electric Power Steering) system  Have the vehicle inspected by your Toyota (Red/yellow) dealer immediately. ■ iMT indicator Warning light Details/Actions Indicates a malfunction in the iMT ...
  • Page 373 7-2. Steps to take in an emergency ■ Stop & Start cancel indicator Warning light Details/Actions Indicates a malfunction in the Stop & Start system  Have the vehicle inspected by your Toyota (Flashes) dealer immediately. (If equipped) ■ Toyota parking assist-sensor OFF indicator (warning buzzer)
  • Page 374  The VSC/Trailer Sway Control system;  The TRC system;  The hill-start assist control system; or  The downhill assist control system (if equipped)  Have the vehicle inspected by your Toyota dealer immediately. ■ Brake Override System/Drive-Start Control (if equipped) warning...
  • Page 375 7-2. Steps to take in an emergency ■ Brake hold operated indicator (warning buzzer) Warning light Details/Actions Indicates a malfunction in the brake hold system  Have the vehicle inspected by your Toyota dealer immediately. (Flashes) ■ Parking brake indicator Warning light...
  • Page 376 If the steering wheel becomes heavier If the malfunction indicator lamp does than usual when operating, hold firmly not go off, contact your Toyota dealer as and operate using more force than soon as possible. usual. ■...
  • Page 377: If A Warning Message Is Displayed

    If a message about an operation of ■ If a message that indicates the the accelerator pedal or brake pedal is need for visiting your Toyota dealer shown is displayed A warning message about an operation The system or part shown on the multi- of the brake pedal may be shown while information display is malfunctioning.
  • Page 378 ● PCS (Pre-Collision System) Immediately stop the vehicle in a safe ● LTA (Lane Tracing Assist) place and contact your Toyota dealer. ● Continuing to drive the vehicle may be LDA (Lane Departure Alert with steer- dangerous. ing control) •...
  • Page 379 ■ “High Power Consumption Par- tial Limit On AC/Heater Opera- tion” is frequently shown There is a possible malfunction relat- ing to the charging system or the bat- tery may be deteriorating. Have the vehicle inspected by your Toyota dealer.
  • Page 380: If You Have A Flat Tire

    7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P.331 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
  • Page 381 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Jack Tool bag Jack handle Wheel nut wrench Towing eyelet Spare tire ● Only use the tire jack that comes WARNING with this vehicle for replacing a flat ■...
  • Page 382 7-2. Steps to take in an emergency Vehicles with full-size spare tire: WARNING Take out the deck board. ● Put the jack properly in its jack Take out the jack. point. Do not touch the threaded portion of the jack as it is greased. ●...
  • Page 383 7-2. Steps to take in an emergency secures the spare tire. Remove the wheel ornament using the wrench. Vehicles with full wheel ornament: To protect the wheel ornament, place a rag between the wrench and the wheel ornament. WARNING ■ When storing the spare tire Be careful not to catch fingers or other body parts between the spare...
  • Page 384 Remove all the wheel nuts and tions in the bolt screws, nut threads the tire. or bolt holes of the wheel, have the vehicle inspected by your Toyota When resting the tire on the ground, dealer. place the tire so that the wheel design faces up to avoid scratching the wheel •...
  • Page 385 7-2. Steps to take in an emergency contact with the disc wheel seat WARNING ● For vehicles with power back door: In cases such as when replacing tires, make sure to turn off the power back door system (P.102). Failure to do so may cause the back door to operate unintentionally if the power back door switch is accidentally touched, resulting in...
  • Page 386 7-2. Steps to take in an emergency Lower the vehicle. ■ The compact spare tire (if equipped) ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporar- ily, and only in an emergency.
  • Page 387 • Panoramic view monitor (if Do not use more than one compact equipped) spare tire simultaneously. ● • Toyota parking assist monitor (if Replace the compact spare tire with a standard tire as soon as possible. equipped) ● Avoid sudden acceleration, abrupt •...
  • Page 388: If The Engine Will Not Start

    7-2. Steps to take in an emergency If the engine will not NOTICE start ■ Be careful when driving over bumps with the compact spare tire installed on the vehicle (if If the engine will not start even equipped) though correct starting proce- The vehicle height may becomes dures are being followed lower when driving with the compact...
  • Page 389 Toyota dealer. nals may be disconnected.  There may be a malfunction in the (vehicles with smart entry & start system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.
  • Page 390: If You Lose Your Keys

    In such cases, the doors can risk of vehicle theft increases signifi- be opened and the engine can cantly. Visit your Toyota dealer imme- diately with all remaining electronic be started by following the pro- keys that were provided with your cedure below.
  • Page 391  Automatic transmission or CVT Ensure that the shift lever is in P and depress the brake pedal. Touch the Toyota emblem side Closes the windows and the moon of the electronic key to the roof or panoramic moon roof engine switch.
  • Page 392 Ensure that the shift lever is in N immediately when the battery is and depress the clutch pedal. depleted. (P.341) Touch the Toyota emblem side ■ Changing engine switch modes of the electronic key to the ...
  • Page 393: If The Vehicle Battery Is Discharged

    The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. Restarting the engine If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
  • Page 394: If Your Vehicle

    OFF. nected. Once the engine starts, have the Vehicles without smart entry & start system: Maintain the vehicle inspected at your Toyota engine speed of the second dealer as soon as possible. vehicle and start the engine of ■...
  • Page 395 When replacing the battery removed, the information stored in the ● Vehicles with Stop & Start system: ECU is cleared. Before removing the battery terminals, contact your Toyota Use a genuine battery specifically dealer. designed for use with the Stop & Start ■...
  • Page 396 When replacing the battery ● Make sure each jumper cable is For information regarding battery connected to the correct terminal replacement, contact your Toyota and that it is not unintentionally in dealer. contact with any other than the intended terminal.
  • Page 397: Overheats

    7-2. Steps to take in an emergency If your vehicle overheats NOTICE ■ When handling jumper cables The following may indicate that When connecting the jumper cables, ensure that they do not become your vehicle is overheating. entangled in the cooling fans or ...
  • Page 398 (radia- tor) for any leaks. If a large amount of coolant leaks, immediately contact your Toyota dealer. Start the engine and turn the air conditioning system on to check that the radiator cooling fan operate and to check for coolant leaks from the radiator or hoses.
  • Page 399: If The Vehicle Becomes Stuck

    7-2. Steps to take in an emergency If the vehicle becomes WARNING stuck ■ When inspecting under the hood of your vehicle Observe the following precautions. Carry out the following proce- Failure to do so may result in serious dures if the tires spin or the injury such as burns.
  • Page 400 7-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or peo- ple.
  • Page 401: Vehicle Specifications

    Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.) .......400 Fuel information ....410 8-2. Customization Customizable features..411 8-3. Initialization Items to initialize ....423...
  • Page 402: Maintenance Data (Fuel, Oil Level, Etc.)

    Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identifi- cation number for your Toyota. It is used in registering the ownership of your vehicle. This number is also on the manu-...
  • Page 403 8-1. Specifications This number is also stamped under  M20A-FKS engine the right-hand front seat.  A25A-FKS engine ■ Engine number The engine number is stamped on the engine block as shown. Engine  M20A-FKS Model M20A-FKS Type 4-cylinder in line, 4-cycle, gasoline 80.5 ...
  • Page 404 ■ Engine oil selection API grade SL, SM or SN multigrade engine oil “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota Recommended viscosity (SAE): approved “Toyota Genuine Motor If you use SAE 10W-30 or a higher Oil”...
  • Page 405 8-1. Specifications API Service Symbol Top portion: “API SERVICE SN” means the oil quality designation by American Petroleum Institute (API). Center portion: “SAE 0W-16” means Temperature range anticipated the SAE viscosity grade. before next oil change Lower portion: “Resource-Conserving” Oil viscosity (0W-16 is explained means that the oil has fuel-saving and here as an example): environmental protection capabilities.
  • Page 406 Do not use plain water alone. : The coolant capacity is the quantity of reference. If replacement is necessary, contact your Toyota dealer. Ignition system (spark plug) M20A-FKS engine DENSO FC20HR-Q8 Make A25A-FKS engine DENSO FC16HR-Q8 0.8 mm (0.031 in.)
  • Page 407 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may ultimately damage the transmission of your vehicle. CVT (Continuously Variable Transaxle) Without Stop & Start system 8.6 L (9.1 qt., 7.6 Imp.qt.) Fluid capacity With Stop &...
  • Page 408 ● Your Toyota vehicle is filled with “TOYOTA Genuine Manual Transmission Gear Oil LV GL-4 75W” at the factory. Use Toyota approved “TOYOTA Genuine Man- ual Transmission Gear Oil LV GL-4 75W” or an equivalent oil of matching quality that satisfies the above specifications. Please contact your Toyota dealer for fur- ther details.
  • Page 409 Toyota Genuine Differential gear oil LX Oil type and viscosity 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equiva- lent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
  • Page 410 8-1. Specifications 17  7J Wheel size Wheel nut torque 103 N•m (10.5 kgf•m, 76 ft•lbf)  Type B Tire size 225/60R18 100H Tire inflation pressure Front 230 kPa (2.3 kgf/cm or bar, 33 psi) (Recommended cold Rear 230 kPa (2.3 kgf/cm or bar, 33 psi) tire inflation pressure) 18 ...
  • Page 411 8-1. Specifications Light bulbs Light bulbs Type Fog lights Front turn signal lights Rear turn signal lights Exterior Back-up lights Outer foot lights Vanity lights Front interior lights/personal lights Interior Rear interior light Luggage compartment light A: H16 halogen bulbs B: Wedge base bulbs (amber) C: Wedge base bulbs (clear) D: Double end bulbs (clear)
  • Page 412: Fuel Information

    Number of 91 or higher. ■ Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
  • Page 413: Customization

    The method of performing detailed set- display, navigation/multimedia ting differs for each screen. Please system, or at your Toyota refer to the advice sentence displayed on the screen. dealer. To go back to the previous screen or...
  • Page 414 Customizable Features Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Vehicles with navigation system or multimedia system: Settings that can be changed using the navigation system or multimedia system...
  • Page 415 8-2. Customization Customized set- Default setting Function ting Multi-Information display off – – On (when the vehicle is Suggestion function – stopped) : For details about each function: P.75 : Vehicles with 7-inch display only : If equipped : AWD models ■...
  • Page 416 8-2. Customization Customized set- Function Default setting ting Time elapsed before the auto- 60 seconds matic door lock function is acti- 30 seconds – vated if a door is not opened 120 seconds after being unlocked Open door reminder buzzer –...
  • Page 417 8-2. Customization ■ Wireless remote control (P.86) Customized set- Function Default setting ting Wireless remote control – – Driver’s door All doors unlocked in first Unlocking operation unlocked in first step, all doors – step unlocked in sec- ond step The function that activates the On (Unlocking all the door)
  • Page 418 8-2. Customization Customized set- Function Default setting ting Power back door open operation when the opener switch is – – pressed with the back door fully closed : If equipped : The operation buzzer that sounds when the back door begins to operate cannot be turned off.
  • Page 419 8-2. Customization Customized set- Function Default setting ting Side windows open warning – – function Sliding roof open warning func- – – tion : If equipped ■ Turn signal lever (P.163) Customized set- Function Default setting ting The number of times the turn signal lights flash automatically when the turn signal lever is –...
  • Page 420 8-2. Customization ■ Rear window wiper (P.176) Customized set- Function Default setting ting Back door opening linked rear – – window wiper stop function Washer linked rear window – – wiper operation Shift position linked rear win- Only once – –...
  • Page 421 8-2. Customization ■ LDA (Lane Departure Alert with steering control) (P.201) Customized set- Function Default setting ting Steering assist function – – Alert sensitivity Standard High – – Vehicle sway warning function – – Vehicle sway warning sensitivity Standard – –...
  • Page 422 Level 1 Level 2 – – Buzzer volume Level 3 : If equipped : This setting is linked with the buzzer volume of the Toyota parking assist-sensor. ■ Toyota parking assist-sensor (P.243) Customized set- Function Default setting ting Display setting (When Toyota parking assist-sensor is operat- –...
  • Page 423 8-2. Customization ■ Stop & Start system (P.250) Customized set- Function Default setting ting Change the Stop & Start system Standard Extended – – duration when the A/C is on : If equipped ■ Automatic air conditioning system (P.285) Customized set- Function Default setting ting...
  • Page 424 8-2. Customization ■ Vehicle customization ● When the speed linked door locking function and shift position linked door locking function are both on, the door lock operates as follows. • If the vehicle is started with all the doors locked, the speed linked door locking function would not operate.
  • Page 425: Initialization

    P.120 the battery P.123 Moon roof • After changing a fuse P.127 Panoramic moon roof Refer to Toyota parking assist monitor “Navigation and Multime- • After reconnecting or changing dia System the battery Owner’s Panoramic view monitor • After changing a fuse Manual”...
  • Page 426 8-3. Initialization...
  • Page 427 Index What to do if... (Troubleshoot- ing) ........426 Alphabetical Index ...429...
  • Page 428: System

    Open the rear door mechanical keys can be made from outside and then unlock the by your Toyota dealer. (P.388) child-protector lock. (P.92)  Vehicles with smart entry & start system:...
  • Page 429: Sounds

    What to do if... (Troubleshooting) while firmly depressing the brake It is locked to prevent theft of the pedal (vehicles with automatic vehicle if the key is removed transmission or CVT) or the from the engine switch. (P.148) clutch pedal (vehicles with man- ...
  • Page 430 What to do if... (Troubleshooting) types of warning buzzer may also sound. (P.368, 375) warning buzzer sounds when leaving the vehicle (vehi- cles with smart entry & start system)  Is the message displayed on the multi-information display? Check the message on the multi- information display.
  • Page 431 Alphabetical Index Alphabetical Index S-FLOW mode ......287 Alarm A/C ......... 280, 285 Warning buzzer ......368 Air conditioning filter....335 Anchor fittings ........51 Automatic air conditioning system Antenna (Smart entry & start system) ..........285 .............104 Eco air conditioning mode..287 Anti-lock brake system (ABS) ..265 Manual air conditioning system..
  • Page 432 Alphabetical Index Child restraint system....40 ter ..........272 Replacing ........393 How your child should wear the seat Warning light ......368 belt ..........28 Blind Spot Monitor (BSM) .... 235 Moon roof precautions ....124 Blind Spot Monitor function ..238 Panoramic moon roof precautions Rear Cross Traffic Alert function 240 ..........127...
  • Page 433 LTA (Lane-Tracing Assist) ..197 Function ........222 Multi-information display ....70 Warning message ......375 RCTA.......... 236 Dynamic radar cruise control with Toyota parking assist-sensor ..243 full-speed range Warning messages ....375 Function ........211 Do-it-yourself maintenance ..320 Warning message ......375...
  • Page 434 Alphabetical Index How to start the engine ..148, 149 EDR (Event data recorder)....7 Identification number....401 Elapsed time ........74 Electric Power Steering (EPS) If the engine will not start ...386 Function ........266 If your vehicle has to be stopped in Warning light ......
  • Page 435 Alphabetical Index Current fuel consumption .....79 Fluid Fuel filler door.......179 Automatic transmission....405 Brake.......... 407 Refueling ........178 Clutch......... 406 Fuel gauge.........63, 66 Continuously Variable Transaxle 405 Fuel pump shut off system ..367 Washer........330 Fuses ..........343 Fog lights Replacing light bulbs....346 Switch ........
  • Page 436 Alphabetical Index Ignition switch (Engine switch). 148, Keyless entry Auto power off function ....152 Smart entry & start system..104 Changing the engine switch modes Wireless remote control ....86 ..........151 Keys ..........84 Changing the engine switch posi- Battery-saving function....105 tions .........
  • Page 437 Alphabetical Index Meters ........63, 66 Light switch ........ 169 Replacing light bulbs....346 Multi-information display ....70 Light bulbs Settings ........ 75, 411 Replacing ........346 Units ........77, 412 Wattage........409 Warning lights......368 Lights Warning messages.....375 Automatic High Beam system..171 Meter control switches....71 Fog light switch ......
  • Page 438 Alphabetical Index Settings ........ 75, 411 Suggestion function ..... 78 Panoramic moon roof Toyota parking assist-sensor ..243 Jam protection function ....126 Units........77, 412 Operation ........125 Vehicle information display ..74 Warning message ......127 Warning message display .... 78 Parking assist sensors (Toyota park- Warning messages ....
  • Page 439 Alphabetical Index Radar cruise control Seat belt reminder light..373, 374 Dynamic radar cruise control with Seat belts.........27 full-speed range ....... 211 Adjusting the seat belt shoulder Dynamic radar cruise control ..222 anchor height ......29 Radiator ......... 328 Child restraint system installation.48 RCTA (Rear Cross Traffic Alert) Cleaning and maintaining the seat RCTA Function....
  • Page 440 LTA (Lane Tracing Assist) ..192 Steering lock system warning mes- Rain-sensing windshield wipers. 175 RCTA.......... 237 sage .........150 Toyota parking assist-sensor ..243 Steering wheel Toyota Safety Sense ....180 Adjustment ......... 116 Service reminder indicators ..58 Meter control switches ....71 S-FLOW mode.......
  • Page 441 Dynamic radar cruise control with Seat ventilator switches ..... 291 full-speed range ....... 211 Snow mode switch ..... 262 Dynamic radar cruise control ..222 Toyota parking assist-sensor ..244 LDA (Lane Departure Alert with Vehicle-to-vehicle distance switch steering control) .......201 ......... 211, 222 LTA (Lane Tracing Assist)...192...
  • Page 442 Seat belt reminder...... 373 Power windows ......120 Toyota parking assist-sensor OFF Window lock switch......122 indicator ........371 Windows Toyota parking assist-sensor ..249 Power windows ......120 Vehicle sway warning..196, 205 Rear window defogger ..281, 287 Warning lights Washer.......174, 176...
  • Page 443 “Navigation and Multimedia System Owner’s Manual” or “Multi- media Owner’s Manual” for information regarding the equipment listed below. · Navigation system · Audio system · Rear view monitor system · Toyota parking assist monitor · Panoramic view monitor...
  • Page 444 Alphabetical Index...
  • Page 445 Alphabetical Index...
  • Page 446 GAS STATION INFORMATION Auxiliary catch lever (P.322) Back door opener switch (P.97) Fuel filler door (P.179) Hood lock release lever (P.322) Tire inflation pressure (P.407) : Vehicles with power back door Fuel tank capacity 55 L (14.5 gal., 12.1 lmp.gal.) (Reference) Fuel type Unleaded gasoline only...

This manual is also suitable for:

Rav4

Table of Contents
