Page 1 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING 2 Wheel Drive 4 Wheel Drive Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor AUTO LSD Automatic Limited Slip Differential Average Child Restraint System Downhill Assist Control DISP Display Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering GAWR...
Page 2 Abbreviation list ABBREVIATIONS MEANING TPMS Tire Pressure Warning System TRAC Traction control Vehicle Identification Number Vehicle Stability Control I n f o r ma t i o n P r o v i d e d b y :...
Page 3: For Your Information
A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available on the market. You should know that these parts are not covered by Toyota warranty and that Toyota is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 4 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 5 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 6 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 7 I n f o r ma t i o n P r o v i d e d b y :...
Page 8: Table Of Contents
TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other features interior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 9 Pictorial index Exterior Headlights (low beam) P. 165 ∗ Headlights (high beam) and daytime Moon roof P. 84 running lights P. 166 Outside rear view Hood P. 354 mirrors P. 79 ∗ Turn signal lights P. 153 Front turn signal/parking and front side marker lights P.
Page 10 With spare tire Spare tire P. 438 ∗ Roof luggage carrier P. 202 License plate light P. 165 Side doors P. 42 Rear window defogger P. 240 Rear window wiper P. 171 Fuel filler door P. 88 Back door P. 46 Tires ●Rotation P.
Page 11 Pictorial index Interior Head restraints P. 65 Seat belts P. 68 SRS driver airbag P. 98 Power window switches P. 81 SRS front passenger airbag P. 98 Bottle holders P. 316 Cup holders P. 315 Rear seats P. 54 Glove box P.
Page 12 Vanity mirrors P. 320 Sun visors P. 319 Overhead console P. 314 ∗ Moon roof switches P. 84 SRS curtain shield airbags P. 98 Interior light P. 309 Coat hooks P. 330 Personal/interior lights P. 308 Anti-glare inside rear view mirror P.
Page 13 Pictorial index Interior Door lock switch P. 43 Window lock switch P. 81 Inside door lock buttons P. 43 Power window switches P. 81 I n f o r ma t i o n P r o v i d e d b y :...
Page 14 Cup holders P. 315 Shift lever P. 150 Parking brake lever P. 154 AUX port P. 269 Outside rear view mirror switches P. 79 I n f o r ma t i o n P r o v i d e d b y :...
Page 15: Instrument Panel
Pictorial index Instrument panel Horn P. 155 ∗ Gauges and meters P. 156 Four-wheel drive lock switch P. 196 Headlight switch P. 165 Audio system P. 243 Turn signal lever Navigation system * P. 153 ∗ Fog light switch P. 168 Emergency flasher switch P.
Page 16 Instrument panel light control dial P. 157 ∗ “DAC” switch P. 193 ∗ : If equipped *: Refer to “Navigation System Owner’s Manual”. I n f o r ma t i o n P r o v i d e d b y :...
Page 17 Pictorial index Instrument panel Without hands-free phone system ∗ Audio remote control switches P. 270 “DISP” switch P. 163 Engine (ignition) switch (without smart key system) P. 147 Cruise control switch P. 172 With hands-free phone system Telephone switch P. 278 Audio remote control switches P.
Page 18 With a manual air conditioning system Air conditioning system P. 226 Security indicator P. 92 Rear window defogger switch P. 240 ∗ Outside rear view mirror defogger switch P. 240 With an automatic air conditioning system Engine (ignition) switch (with smart key system) P.
Page 19 Pictorial index Instrument panel ∗ Seat heater switch P. 327 ∗ Windshield wiper de-icer switch P. 242 Power outlet P. 322 VSC OFF switch P. 187 Cup holders P. 315 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 20 Pictorial index Luggage compartment ∗ Luggage cover P. 334 ∗ Second seatback release lever P. 57 Grocery bag hooks P. 332 ∗ Storage boxes P. 332 Cargo hooks P. 332 Power outlet P. 322 ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
Page 21: Quick Reference
RAV4 CUSTOMER EXPERIENCE CENTER 2 0 1 1 1-800-331-4331 QUICK REFERENCE GUIDE Printed in U.S.A. 8/10 Cert no. SGSNA-COC-005612 00505-QRG11-RAV4 10-TCS-03984 I n f o r ma t i o n P r o v i d e d b y :...
Page 22 Tool bag capabilities and limitations. Removing the spare tire Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new RAV4. A word about safe vehicle operations This Quick Reference Guide is not a full description of RAV4 operations.
Page 23 Spare tire & tools Tire Pressure Monitoring (warning) System 24 Visit your Toyota dealer for information on customizing this feature. I n f o r ma t i o n P r o v i d e d b y :...
Page 24 OVERVIEW Instrument panel Steering wheel controls Without telephone controls With telephone controls Steering wheel audio controls Telephone controls Trip information display switch Speech command button Cruise control Headlight, turn signal and fog light control Wiper and washer controls Four-wheel drive lock switch (4WD models) Audio system/Navigation system Emergency flasher switch Air Conditioning controls...
Page 25 With manual Air Conditioning system With automatic Air Conditioning system Front passenger occupant classification indicator Rear window and outside rearview mirror defogger switch 12V DC Power outlet Seat heater switch VSC OFF switch Ignition switch (standard key) Tilt and telescopic steering release Downhill Assist Control (DAC) switch Instrument panel light control If equipped...
Page 26 I f i nd i c ator d oes not turn of f wi thi n a f ew sec ond s of starti ng engi ne, there m ay be a m alf unc ti on. H ave vehi c le i nspec ted by your Toyota d ealer.
Page 27 Airbag warning Automatic Transmission fluid temperature warning Low Tire Pressure Warning 4WD warning Electric power steering system warning Low windshield washer fluid level warning Front passenger occupant classification indicator Headlight low/high beam indicator Turn signal indicator Fog light indicator Automatic Transmission indicator (4-speed) Automatic Transmission indicator (5-speed) Four-wheel drive lock indicator Vehicle Stability Control (VSC) OFF indicator...
Page 28 OVERVIEW Keyless entry Beep sound can be switched ON or OFF. Refer to the Owner’s Manual for more details. Locking operation Without Smart Key system With Smart Key system Push Unlocking operation Without Smart Key system With Smart Key system Push ONCE: Driver door TWICE: All doors NOTE:...
Page 29 Smart Key system (if equipped) Start function Green indicator ON Depress Push Carrying brake pedal NOTE: Gear shift lever must be in Park and brake pedal depressed. Power (without starting engine) Without depressing the brake pedal, pressing the “ENGINE START STOP” switch will change the operation mode in succession from: ACCESSORY Accessories such as the radio will operate.
Page 30 OVERVIEW Fuel tank door release and cap Driver seat Turn to open Pull up Store NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Hood release Pull up latch and raise hood Pull Engage support rod...
Page 31 Engine maintenance 4 cylinder (2AR-FE) engine V6 (2GR-FE) engine Engine coolant reservoir Engine oil filler cap Engine oil level dipstick Windshield and back window washer fluid tank NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Warranty Maintenance Guide.”...
Page 32 FEATURES/OPERATIONS Automatic Transmission 4-speed models Park* Reverse Neutral Drive Third gear Second gear First gear 5-speed models Park* Reverse Neutral Drive Fourth gear Third gear Second gear First gear * The ignition/“ENGINE START STOP” switch must be “ON” and the brake pedal depressed to shift from Park.
Page 33 Active torque control 4WD Auto lock functions (4WD models) Four-wheel drive lock switch Push the switch to ensure that the engine torque is applied to the four wheels. NOTE: Should ONLY be used when wheel spinning occurs on loose or unpaved surfaces.
Page 34 FEATURES/OPERATIONS Seat adjustments-Front Manual seat Power seat (driver side only) Seat position (forward/backward) Height crank (driver side only) Seatback angle Seat position, cushion angle and height Seatback angle Lumbar support Seat adjustments-Second row seats Vehicles with third row seats Vehicles without third row seats Seat position (forward/backward) Seatback angle Seatback lock release...
Page 35 Seats-Folding down second row seats From inside (2) Lower (3) Pull down (1) Push From outside (vehicles without third row seats) Seats-Stowing third row seats (if equipped) (2) Lower (4) Fold down (3) Pull (1) Push (5) Pull up (6) Lift up (8) Push to lock in (7) Push down (9) Push to lock in...
Page 36 FEATURES/OPERATIONS Lights & turn signals Headlights Auto (if equipped) Headlights Parking lights High beam flasher Low beam High beam -Daytime Running Light system (DRL) (if equipped) Automatically turns on the headlights at a reduced intensity. -Automatic light cut off system Will automatically turn lights off after a delay of 30 seconds.
Page 37 Windshield wipers & washers Front Single wipe Adjust frequency* Interval wipe Slow Pull to wash and wipe Fast * Intermittent windshield wiper frequency adjustment Rotate to increase/decrease wipe frequency. Rear Wash and wipe Wipe Interval wipe Wash and wipe Windows-Power Driver side Windows lock switch Down...
Page 38 FEATURES/OPERATIONS Moonroof (if equipped) Sliding operation Open Push once to open Recommended open partway; again to position to minimize open completely. wind noise Close Tilting operation Close Tilt NOTE: If battery is disconnected, the moonroof needs to be reinitialized. Refer to the Owner’s Manual for more details. Door locks Unlock Lock...
Page 39 Refer to “Using the hands-free phone system (for cellular phone),” Section 3-3 in the Owner’s Manual, or go to Toyota.LetsTalk.com for more information about phone connections and compatibility. Tilt and telescopic steering wheel...
Page 40 FEATURES/OPERATIONS Seat heaters (if equipped) Left front seat Right front seat Air Conditioning/Heating Automatic Air Conditioning Temperature selector (driver side) Recirculate cabin air (fresh air when OFF) Airflow vent In “ ” mode, use fresh air (“ ” indicator OFF) to reduce window fogging.
Page 41 Manual Air Conditioning Airflow vent “ ” or “ ” mode uses fresh air only (“ ” indicator “OFF”) to reduce window fogging. Fan speed Temperature selector Air Conditioning ON/OFF Select for maximum cooling. Air intake will automatically be set to recirculate.
Page 42 FEATURES/OPERATIONS Audio Type 1 Preset buttons - functions in other Push to turn modes indicated above number. ON/OFF Push to adjust tone & balance Eject CD Push to skip Seek station/ up/down folder CD track select Station/CD Mode View CD text track scan Type 2 additional functions Load CD(s)
Page 43 Radio To preset stations Tune in the desired station and hold down a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select. To scan stations Push “SCAN.” Push and hold to scan preset stations. Push again to hold selection.
Page 44 FEATURES/OPERATIONS Power outlets-12V DC Inside center console Instrument panel Luggage compartment NOTE: Designed for car accessories. Ignition switch/“ENGINE START STOP” switch must be in the “ACC” or “ON” position to be used. Power outlets-120V AC (if equipped) Rear console NOTE: Ignition switch/“ENGINE START STOP” switch must be in the “ON” position to be used.
Page 45 Hill-start Assist Control (HAC) (if equipped) Brake pedal HAC helps prevent rolling backwards on an incline. To engage, push further down on brake pedal while at a complete stop until a beep sounds and slip indicator illuminates. HAC holds for approximately 2 seconds after releasing brake pedal.
Page 46: Safety And Emergency Features
” indicator will come on. Correctly adjusting tire inflation will turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer. Refer to the Owner’s Manual for more details.
Page 47: Before Driving
TABLE OF CONTENTS Index 1-6. Theft deterrent system Before driving Engine immobilizer system ........ 92 Theft prevention labels 1-1. Key information (U.S.A.)....... 95 Keys ........24 1-7. Safety information 1-2. Opening, closing and Correct driving posture ..96 locking the doors SRS airbags ......
Page 48: Interior Features
2-3. Operating the lights and Interior features wipers Headlight switch....165 Fog light switch ....168 3-1. Using the air conditioning Windshield wipers and system and defogger washer ......169 Manual air conditioning Rear window wiper and system......226 washer ......171 Automatic air conditioning system......
Page 49: Maintenance And Care
TABLE OF CONTENTS Index Security and system Maintenance and care setup ........ 296 Using the phone book ..299 4-1. Maintenance and care 3-4. Using the interior lights Cleaning and protecting Interior lights list ....307 the vehicle exterior ... 338 •...
Page 50: Vehicle Specifications
If your vehicle needs to be Vehicle specifications towed ........ 415 If you think something is wrong ........ 422 6-1. Specifications Fuel pump shut off Maintenance data system ......423 (fuel, oil level, etc.) ... 474 Event data recorder .... 424 Fuel information....
Page 51: Key Information
1-1. Key information Keys The following keys are provided with the vehicle. Vehicles without smart key system Master keys Operating the wireless remote control function (→P. 38) Valet key Key number plate Vehicles with smart key system Electronic keys • Operating the smart key system (→P.
Page 52 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 460) ■...
Page 53: Opening, Closing And Locking The Doors
1-2. Opening, closing and locking the doors ∗ Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Electronic key Electronic key Electronic key Locks and unlocks the doors (→P.
Page 54 1-2. Opening, closing and locking the doors Unlocking and locking the doors and back door (front and back door handles only) Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The doors cannot be unlocked for 3 seconds after the doors are locked.
Page 55 1-2. Opening, closing and locking the doors Antenna location and effective range ■ Antenna location Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage compartment I n f o r ma t i o n P r o v i d e d b y :...
Page 56 1-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handles and back door.
Page 57 1-2. Opening, closing and locking the doors ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
Page 58 1-2. Opening, closing and locking the doors The setting changes each time an operation is performed, as shown below. (When changing the setting continuously, release the buttons, wait for at least 5 seconds, and repeat step 2.) Mode Unlocking doors Beep Hold the driver's door han- dle to unlock only the...
Page 59 1-2. Opening, closing and locking the doors ■ Electronic key battery depletion ● The standard battery life is 1 to 2 years. (The battery becomes depleted even if the electronic key is not used.) If the smart key system or the wireless remote control function does not operate, or the detection area becomes smaller, the battery may be depleted.
Page 60 1-2. Opening, closing and locking the doors ● The doors may unlock if a large amount of water splashes on the door handle, such as in the rain or in a car wash. (The doors will automatically be locked after approximately 60 seconds if the doors are not opened and closed.) ●...
Page 61 1-2. Opening, closing and locking the doors ● When an alarm sounds: Take appropriate measures according to the following table. Alarm Situation Correction procedure Tried to lock the doors Retrieve the elec- Exterior alarm using the entry function tronic key from the sounds once for while the electronic key is passenger compart-...
Page 62 1-2. Opening, closing and locking the doors Alarm Situation Correction procedure Tried to close the driver’s door after carrying the key Shift the shift lever to outside the vehicle with the Interior and exte- P, turn the “ENGINE “ENGINE START STOP” rior alarms sound START STOP”...
Page 63 1-2. Opening, closing and locking the doors ■ Customization that can be configured at Toyota dealer It is possible to deactivate the smart key system etc. (Customizable features →P. 500) ■ Certification for the smart key system For vehicles sold in the U.S.A.
Page 64 (→P. 28) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the entry function.
Page 65: Wireless Remote Control
1-2. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Vehicles without smart key system Locks all doors Pushing holding: Sounds alarm Unlocks all doors Pressing the button unlocks the driver’s door.
Page 66 1-2. Opening, closing and locking the doors ■ Panic mode Vehicles without smart key system When is pushed for longer than about one second, an alarm will sound for about 60 seconds and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle.
Page 67 Vehicles with smart key system →P. 30 ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control) can be changed. (Customizable features →P. 500) I n f o r ma t i o n P r o v i d e d b y :...
Page 68 1-2. Opening, closing and locking the doors ■ Certification for wireless remote control (vehicles without smart key system) For vehicles sold in the U.S.A. FCC ID: HYQ12BBY FCC ID: HYQ13BBZ FCC ID: HYQ12BDC FCC ID: HYQ13BDC NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 69: Side Doors
1-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control, key or door lock switch. ■ Entry function (vehicles with smart key system) →P. 26 ■ Wireless remote control →P.
Page 70 1-2. Opening, closing and locking the doors ■ Door lock switch Locks all doors Unlocks all doors ■ Inside lock button Locks the door Unlocks the door Pulling the door handle can open the front door even if the lock button is in the lock posi- tion.
Page 71 1-2. Opening, closing and locking the doors Locking the front doors from the outside without the wireless remote control or key Move the inside door lock button to the lock position. STEP Close the door. STEP Rear door child-protector locks The door cannot be opened from inside the vehicle when the child- protector lock is set.
Page 72 Depending on the position of the electronic key, the key may not be detected correctly and the door may be locked. ■ Customization that can be configured at Toyota dealer Settings (e.g. door unlocking function) can be changed. (Customizable features →P. 500) CAUTION ■...
Page 73: Back Door
■ Wireless remote control →P. 38 ■ Door lock switch →P. 43 ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control) can be changed. (Customizable features →P. 500) CAUTION ■ Caution while driving ● Keep the back door closed while driving.
Page 74 1-2. Opening, closing and locking the doors CAUTION ■ Caution while parking If the open back door hides the stop, tail or rear turn signal lights, other road users must be warned of the presence of your vehicle by a warning triangle or other device.
Page 75 ● Do not attach any accessories other than genuine Toyota parts to the back door. Such additional weight on the back door may interfere with the safety opening and closing operation of the back door.
Page 76: Adjustable Components (Seats, Mirrors, Steering Wheel)
1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) I n f o r ma t i o n P r o v i d e d b y :...
Page 77 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat (driver’s side only) Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch Vertical height adjustment switch Seat lumbar support adjust- ment switch I n f o r ma t i o n P r o v i d e d b y :...
Page 78 1-3. Adjustable components (seats, mirrors, steering wheel) Flattening front seatbacks The front seats can be moved into a flat seat arrangement. Manual seat STEP Slide the second seats as far back as possible. (→P. 54) STEP Remove the front head restraint. (→P. 65) Slide the front seat further for- STEP ward than the front-most lock...
Page 79 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat STEP Slide the second seats as far back as possible. (→P. 54) STEP Remove the front head restraint. (→P. 65) Push the seat position adjusting STEP switch forward to slide the seat to the front-most position.
Page 80 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure. These do not indicate problems. During rear-end collision...
Page 81: Rear Seats
1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats ■ Second seats Vehicles with third seat Seat position adjustment levers Seatback angle adjustment levers When a person sits in the sec- ond center position, align all seatbacks at the same angle. I n f o r ma t i o n P r o v i d e d b y :...
Page 82 1-3. Adjustable components (seats, mirrors, steering wheel) Vehicles without third seat Seat position adjustment levers Seatback angle adjustment levers When a person sits in the sec- ond center position, align all seatbacks at the same angle. I n f o r ma t i o n P r o v i d e d b y :...
Page 83 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Third seats (if equipped) The third seats do not have a seat adjustment function. Moving a second seats for third seats entry (vehicles with third seats) ■ Getting in the vehicle (right side only) Pull the lever forward and fold down the seatback.
Page 84 1-3. Adjustable components (seats, mirrors, steering wheel) Folding second seats Folding down the second seats will enlarge the luggage compart- ment. ■ Before folding the second seats STEP Stow the second center seat belt. (→P. 70) Make sure the outside seat belt STEP passes through the hanger when folding the second seat.
Page 85 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Folding second seats STEP Slide the second seats as far back as possible. (→P. 54) From inside Pull down the seatback angle STEP adjustment lever and fold down the seatback. From outside (vehicles without third seats) Open the back door and pull the STEP lock release lever to fold down...
Page 86 1-3. Adjustable components (seats, mirrors, steering wheel) Stowing third seats (vehicles with third seats) ■ Before stowing the third seats Stow the third seat belt buckles. STEP Pass the seat belts through the STEP seat belt hangers. This prevents the shoulder belt from being damaged.
Page 87 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Stowing third seats Pull and hold the seat lock STEP release strap and lift up the seat rearward and then push the seat down. Push the seat on the front side STEP against the floor and push the seat on rear side against the floor.
Page 88 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Returning third seats Pull the seat lock release strap, STEP lift the seat up and move the seat forward. Lock the seat into place. Make sure it is locked securely. Pull the seatback lock release STEP strap and raise the seatback.
Page 89 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Seat adjustment Observe the following precautions. Failure to do so may result in death or serious injuries. ● The seat belts provide maximum protection in a frontal or rear collision when the driver and the front passenger are sitting up straight and well back in the seats.
Page 90 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ When folding second seats ● Do not fold the second seatback when passengers sit or luggage is placed on the seat. ● Do not allow passengers to ride on the folded seat or in the luggage com- partment while driving.
Page 91 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ After adjusting a seat ● After adjusting the seat position, try sliding it forward and backward to make sure it is locked in position. ● After adjusting the seatback, push your body adjust the seatback to make sure it is locked in position.
Page 92: Head Restraints
1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push the head restraint down while pushing the lock release button. Lock release button Second seats Lock release buttons Third seats (if equipped) Lock...
Page 93 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Removing the head restraints Except second center seat Pull the head restraint up while pushing the lock release button. Second center seat ■ Installing the head restraints Except second center seat Align the head restraint with the installa- tion holes and push it down while press- ing the lock release button.
Page 94 1-3. Adjustable components (seats, mirrors, steering wheel) Second center seat ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. ■...
Page 95: Seat Belts
1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 96 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed. Second center seat belt The second center seat belt is a 3-point type restraint with 2 buckles. Both seat belt buckles must be correctly located and securely latched for proper operation.
Page 97 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Releasing method The second center seat belt can be completely released only when necessary such as when folding down the second seats. Insert the key into the hole on STEP the center seat belt buckle to release the tab (with hook end), and allow the belt to retract.
Page 98 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 99 1-3. Adjustable components (seats, mirrors, steering wheel) ■ When not using the rear seat belts Second seats Pass the outer seat belts through the seat belt hangers and secure the seat belt plates to prevent the shoulder belts from being damaged. Third seats Pass the seat belts through the seat belt hangers to prevent the shoulder belts...
Page 100 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 101 ● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 102 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ When using the second center seat belt Do not use the second center seat belt with either buckle released. Fastening only one of the buckles may result in death or serious injury in case of sudden braking or a collision.
Page 103: Steering Wheel
1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP press the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
Page 104: Anti-Glare Inside Rear View Mirror
1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and the reflected light is automatically reduced.
Page 105 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down. ■ To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them.
Page 106: Outside Rear View Mirrors
1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Vehicles without smart key system Mirror angle can be adjusted using the switch when the engine switch is in the “ACC” or “ON” position. Vehicles with smart key system Mirror angle can be adjusted using the switch when the “ENGINE START STOP”...
Page 107 1-3. Adjustable components (seats, mirrors, steering wheel) Folding back the mirrors Push backward to fold the mir- rors. ■ When the mirrors are fogged up (vehicles with outside rear view mirror defoggers) Turn on the mirror defoggers to defog the mirrors. (→P. 240) CAUTION ■...
Page 108: Opening And Closing The Windows And Moon Roof
1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing (driver’s window only) Opening One-touch opening (driver’s window only) Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 109 1-4. Opening and closing the windows and moon roof ■ The power windows can be operated when Vehicles without smart key system The engine switch is in the “ON” position. Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. ■...
Page 110 1-4. Opening and closing the windows and moon roof CAUTION ■ Closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 111: Moon Roof
1-4. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open The moon roof stops slightly before the fully opened posi- tion.
Page 112 1-4. Opening and closing the windows and moon roof ■ Operating the moon roof after turning the engine off Vehicles without smart key system The moon roof can be operated for approximately 45 seconds after the engine switch is turned to the “ACC” or “LOCK” position. They cannot, how- ever, be operated once either front door is opened.
Page 113 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 114 1-4. Opening and closing the windows and moon roof CAUTION ■ Opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury. ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 115: Refueling Opening The Fuel Tank Cap
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Vehicles without smart key system Turn the engine switch to the “LOCK” position and ensure that all the doors and windows are closed. Vehicles with smart key system Turn the “ENGINE START STOP”...
Page 116 1-5. Refueling Hang the fuel tank cap on the STEP back of the fuel filler door. Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction.
Page 117 ■ When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury. I n f o r ma t i o n P r o v i d e d b y :...
Page 118 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle's painted surface. I n f o r ma t i o n P r o v i d e d b y :...
Page 119: Theft Deterrent System
1-6. Theft deterrent system Engine immobilizer system The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles without smart key system: The indicator light flashes after the key has been...
Page 120 1-6. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the key is in contact with a metallic object ● If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle ■...
Page 121 1-6. Theft deterrent system NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed. I n f o r ma t i o n P r o v i d e d b y :...
Page 122: Theft Prevention Labels (U.s.a.)
1-6. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law. I n f o r ma t i o n P r o v i d e d b y :...
Page 123: Safety Information
1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 49) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 124 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver's seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 125: Srs Airbags
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 126 1-7. Safety information Airbag system components Curtain shield airbags SRS warning light Side airbags Driver airbag Front passenger airbag Driver’s seat position sen- Side and curtain shield air- bag sensors Driver’s seat belt buckle switch Front airbag sensors Airbag sensor assembly Front passenger’s seat belt buckle switch Front passenger occupant...
Page 127 1-7. Safety information The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sensor and an airbag sensor. In certain types of severe frontal or side impacts, the SRS airbag sys- tem triggers the airbag inflators.
Page 128 1-7. Safety information ■ SRS airbag deployment conditions Front airbags ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 129 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
Page 130 1-7. Safety information ■ Types of collisions that may not deploy the SRS side airbags and cur- tain shield airbags The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 131 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 132 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 133 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
Page 134 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 135 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board or steering wheel pad. These items can become projectiles when SRS driver and front passenger airbags deploy.
Page 136 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ■ Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer.
Page 137: Front Passenger Occupant Classification System
1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light Front passenger's seat belt reminder light “AIR BAG OFF”...
Page 138 1-7. Safety information Conditions and operation of the front passenger occupant classification system ■ Adult* “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ SRS warning light warning light Front passenger's seat belt reminder Flashing* light Front passenger airbag Side airbag on the front passenger seat Devices...
Page 139 1-7. Safety information ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” Not illumi- indicator lights nated Indicator/ SRS warning light warning light Front passenger's seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front Activated...
Page 140 1-7. Safety information : Never install a rear-facing child restraint system on the front pas- senger seat. A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (→P. 117) : In case the indicator is not illuminated, consult this manual as for installing the child restraint system properly.
Page 141 1-7. Safety information CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger's seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 142 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the second seat should not contact the front seatbacks.
Page 143: Child Restraint Systems
1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 144 1-7. Safety information Types of child restraint Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing ⎯ Infant seat/convertible seat Forward facing ⎯ Convertible seat Booster seat I n f o r ma t i o n P r o v i d e d b y :...
Page 145 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 146 1-7. Safety information CAUTION ■ Child restraint precautions ● Do not use the seat belt extender when installing a child restraint system on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of a sudden stop, sudden swerve or accident.
Page 147: Installing Child Restraints
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the outside rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 148 1-7. Safety information Second outside seats: Anchor brackets (for top tether strap) Anchor brackets are provided for the second outside seats. Second center seat: Anchor brackets (for top tether strap) An anchor bracket is provided for the second center seat. I n f o r ma t i o n P r o v i d e d b y :...
Page 149 1-7. Safety information Installation with LATCH system (second outside seats only) Fold the seatback while pulling STEP the lever. Return the seatback and secure it at the 1st lock posi- tion (most upright position). Adjust the seatback to the 7th lock position.
Page 150 1-7. Safety information Type B Latch the buckles onto the STEP LATCH anchors. The bars are installed in the clearance between the seat cush- ion and seatback. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.
Page 151 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat ■ Place the child seat on the rear STEP seat facing the rear of the vehi- cle. Run the seat belt through the STEP child seat and insert the plate into the buckle.
Page 152 1-7. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 153 1-7. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 154 1-7. Safety information Removing a child restraint installed with a seat belt Push the buckle release button STEP and fully retract the seat belt. Second center seat: Release the STEP center seat belt as shown in the illustration after removing the child restraint.
Page 155 1-7. Safety information Slide the seats forward slightly if STEP it is in the rear-most position. Secure the child restraint using STEP Front of vehicle the seat belt. Latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched.
Page 156 1-7. Safety information ■ Center seat Open the anchor bracket cover. Secure the child restraint using the seat belt. Latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched. ■...
Page 157 1-7. Safety information CAUTION ■ When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode. (→P. 71) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
Page 158 1-7. Safety information CAUTION ■ When installing a child restraint system ● When installing a child restraint system in the rear center seat, adjust both seat cushions to the same position and align seatbacks at the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sudden braking, sudden swerving or an accident.
Page 159 1-7. Safety information I n f o r ma t i o n P r o v i d e d b y :...
Page 160: Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine →P. 143, 147 ■ Driving STEP With the brake pedal depressed, shift the shift lever to D. (→P. 150) STEP Release the parking brake.
Page 161 This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drums are replaced. Have your Toyota dealer perform the bedding-down. I n f o r ma t i o n P r o v i d e d b y :...
Page 162 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. I n f o r ma t i o n P r o v i d e d b y :...
Page 163 2-1. Driving procedures CAUTION ● Do not under any circumstances shift the shift lever to P, R or N while the vehicle is moving. Doing so can cause significant damage to the transmission system and may result in a loss of vehicle control. ●...
Page 164 2-1. Driving procedures CAUTION ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. ● Sudden changes in engine speed, such as engine braking caused by up- shifting or down-shifting, may cause the vehicle to skid, resulting in an accident.
Page 165 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 166 2-1. Driving procedures CAUTION ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, you may accidentally move the shift lever or depress the accelerator pedal, which could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
Page 167 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
Page 168 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. ● Brake function ●...
Page 169: Engine (Ignition) Switch (Vehicles With Smart Key System)
2-1. Driving procedures Engine (ignition) switch (vehicles with smart key system) Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine The engine can be started in any mode by operating the “ENGINE START STOP”...
Page 170 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) OFF* The emergency flashers can be used.
Page 171 ■ When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Auto power off function If the vehicle is left in ACCESSORY mode for more than an hour with the shift lever in P, the “ENGINE START STOP”...
Page 172 2-1. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver's seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 173: Engine (Ignition) Switch (Vehicles Without Smart Key System)
2-1. Driving procedures Engine (ignition) switch (vehicles without smart key system) ■ Starting the engine STEP Check that the parking brake is set. STEP Check that the shift lever is set in P. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP Turn the engine switch to the “START”...
Page 174 2-1. Driving procedures ■ Turning the key from “ACC” to “LOCK” STEP Shift the shift lever to P. (→P. 150) STEP Push in the key and turn to the “LOCK” position. ■ Steering lock release When starting the engine, the engine switch may seem stuck in the “LOCK”...
Page 175 2-1. Driving procedures NOTICE ■ To prevent battery discharge Do not leave the key in the “ACC” or “ON” position for a long period if the engine is not running. ■ When starting the engine ● Do not crank for more than 30 seconds at a time. This may overheat the starter and wiring systems.
Page 176: Automatic Transmission
2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever 4-speed models 5-speed models I n f o r ma t i o n P r o v i d e d b y :...
Page 177 2-1. Driving procedures Vehicles without smart key system: While the engine switch is in the “ON” position, depress the brake pedal and move the shift lever. Vehicles with smart key system: While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever.
Page 178 2-1. Driving procedures ■ Downshifting restrictions The shift lever cannot be downshifted if the following speeds are exceeded. 4-speed models (2WD) mph (km/h) Downshifting Maximum speed 3 → 2 75 (121) 2 → L 37 (60) 4-speed models (4WD) mph (km/h) Downshifting Maximum speed 3 →...
Page 179: Turn Signal Lever
2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change. The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 180: Parking Brake
2-1. Driving procedures Parking brake Canada U.S.A. Sets the parking brake Fully apply the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton. ■ Usage in winter time See “Winter driving tips”...
Page 181: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 182: Instrument Cluster Gauges And Meters
2-2. Instrument cluster Gauges and meters Vehicles without smart key system The following gauges, meters and displays illuminate when the engine switch is in the “ON” position. Vehicles with smart key system The following gauges, meters and displays illuminate when the “ENGINE START STOP”...
Page 183 2-2. Instrument cluster Trip information display →P. 162 Automatic transmission shift position indicator lights →P. 150 Odometer/trip meter Odometer Displays the total distance the vehicle has been driven. Trip meter Displays the distance the vehicle has been driven since the meter was last reset.
Page 184 2-2. Instrument cluster NOTICE ■ To prevent damage to the engine and its components ● Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed. ● The engine may be overheating if the temperature gauge is in the red zone (H).
Page 185: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. ■ Instrument cluster ■ Center panel I n f o r ma t i o n P r o v i d e d b y :...
Page 186 Have the vehicle inspected by your Toyota dealer for details. I n f o r ma t i o n P r o v i d e d b y :...
Page 187 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 188: Trip Information Display
2-2. Instrument cluster Trip information display The trip information display presents the driver with a variety of driv- ing-related data, including the current outside temperature. Trip information (→P. 163) Displays outside temperature and fuel consumption. I n f o r ma t i o n P r o v i d e d b y :...
Page 189 2-2. Instrument cluster Trip information Type A Push the “DISP” button to dis- play trip information. Display items can be switched by pressing the “DISP” button. Type B Push the “DISP” button to dis- play trip information. Display items can be switched by pressing the “DISP”...
Page 190 2-2. Instrument cluster ■ Average fuel consumption Displays the average fuel consumption since the function was reset. To reset the calculations, return the mode to “AVG” and push and hold the “DISP” button until the display shows “0”. ■ Display In the following situations, the correct outside temperature may not be displayed, or the display may take longer than normal to change.
Page 191: Operating The Lights And Wipers
2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. The daytime running lights turn on. The side marker, park- ing, tail, license plate, daytime running lights and instrument panel lights turn on. U.S.A.Canada The headlights and all lights listed...
Page 192 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
Page 193 To turn the lights on again, turn the “ENGINE START STOP” switch to IGNI- TION ON mode, or turn the headlight switch off and then back to ■ Customization that can be configured at Toyota dealer Settings (e.g. light sensor sensitivity) can be deactivated. (Customizable features →P. 500) NOTICE ■...
Page 194: Fog Light Switch
2-3. Operating the lights and wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam. Front fog lights on ∗...
Page 195: Windshield Wipers And Washer
2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation. Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency I n f o r ma t i o n P r o v i d e d b y :...
Page 196 2-3. Operating the lights and wipers Wash/wipe operation Wipers operate automatically. ■ The windshield wipers and washer can be operated when Vehicles without smart key system The engine switch is in the “ON” position. Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. ■...
Page 197: Rear Window Wiper And Washer
2-3. Operating the lights and wipers Rear window wiper and washer Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion ■ The rear window wiper and washer can be operated when Vehicles without smart key system The engine switch is in the “ON”...
Page 198: Using Other Driving Systems
2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicator Cruise control switch ■ Setting the vehicle speed Press the “ON-OFF” button to STEP activate the cruise control. Press the button again to deactivate the cruise control.
Page 199 2-4. Using other driving systems ■ Adjusting the set speed Increase the speed Decrease the speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed can be made by lightly pushing the lever up or down and releasing it.
Page 200 Have the vehicle inspected by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 201 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 202: Rear View Monitor System (Vehicles With Auto Anti-Glare Inside Rear View Mirror)
2-4. Using other driving systems Rear view monitor system (vehicles with auto anti-glare inside rear view mirror) The rear view monitor system assists the driver by displaying an image of the area behind the vehicle. The image is displayed in reverse on the screen.
Page 203 2-4. Using other driving systems ■ The rear view monitor system can be operated when Vehicles without smart key system The shift lever is in R, the back door is fully closed and the engine switch is in the “ON” position. Vehicles with smart key system The shift lever is in R, the back door is fully closed and the “ENGINE START STOP”...
Page 204 2-4. Using other driving systems ● To constantly disable the rear view monitor system Push and hold the “AUTO” button for 12 to 15 seconds. The screen will turn off and on after 6 seconds. Keep pushing the button until the screen turns back off. The indicator will flash amber. Vehicles without smart key system The system will not automatically turn on again after the engine switch is OFF and then turned to the “ON”...
Page 205 2-4. Using other driving systems ■ Displayed area Vehicles without spare tire The area covered by the camera is lim- ited. Objects that are close to either corner of the bumper or under the bumper cannot be seen on the screen. The area displayed on the screen may vary according to vehicle orientation or road conditions.
Page 206 2-4. Using other driving systems ■ Rear view monitor system camera Vehicles without spare tire In the following cases, it may become difficult to see images on the screen even if the system functions correctly. ● The vehicle is in a dark area, such as at night.
Page 207 2-4. Using other driving systems Vehicles with spare tire In the following cases, it may become difficult to see images on the screen even if the system functions correctly. ● The vehicle is in a dark area, such as at night. ●...
Page 208 2-4. Using other driving systems ■ Smear effect If a bright light, such as sunlight reflected off the vehicle body, is picked up by the camera, a smear effect* char- acteristic to the camera may occur. *: Smear effect: A phenomenon that occurs when a bright light is picked up by the camera;...
Page 209 If the camera lens is extremely dirty, wash with a mild cleanser and rinse. ● When replacing tires, please consult your Toyota dealer. If you replace the tires, the area displayed on the screen may change. NOTICE ■...
Page 210: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 211 2-4. Using other driving systems ■ Enhanced VSC (Enhanced Vehicle Stability Control) Provides cooperative control of the ABS, TRC, VSC and EPS. Helps to maintain directional stability when swerving on slippery road surface by controlling steering performance. ■ Hill-start assist control (if equipped) (→P.
Page 212 2-4. Using other driving systems To disable TRAC and/or VSC (2WD models) If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. The AUTO LSD function is activated when the system is in TRAC off mode.
Page 213 2-4. Using other driving systems To disable TRAC and/or VSC (4WD models) If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. ■...
Page 214 2-4. Using other driving systems ■ Automatic reactivation of TRAC and VSC Vehicles without smart key system Turning the engine switch OFF after turning off the TRAC and VSC systems will automatically re-enable them. Vehicles with smart key system Turning the “ENGINE START STOP” switch OFF after turning off the TRAC and VSC systems will automatically re-enable them.
Page 215 10 minutes. ■ If the slip indicator comes on It may indicate a malfunction in the VSC, TRAC and AUTO LSD function. Contact your Toyota dealer. CAUTION ■ The ABS does not operate effectively when ●...
Page 216 The ABS and VSC systems will not function correctly if different tires are fit- ted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
Page 217: Hill-Start Assist Control
2-4. Using other driving systems ∗ Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on an incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 218 Use the slip indicator status (flashing or off) to confirm if hill-start assist control is operating. ■ If the slip indicator comes on It may indicate a malfunction in the system. Contact your Toyota dealer. CAUTION ■ Hill-start assist control ●...
Page 219: Downhill Assist Control System
2-4. Using other driving systems ∗ Downhill assist control system With the downhill assist control system, the vehicle is able to descend a steep hill while maintaining a constant low speed of about 3 mph (5 km/h) without brake pedal operation. ■...
Page 220 ■ If the slip indicator comes on It may indicate a malfunction in the system. Contact your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 221 2-4. Using other driving systems CAUTION ■ Conditions which may affect the downhill assist control system opera- tion ● Do not rely too heavily on the downhill assist control system. On extremely steep inclines, icy surfaces or muddy roads, the vehicle may slip and the system may not be able to maintain the constant low vehicle speed of about 3 mph (5 km/h), leading to an accident causing death or serious injury.
Page 222: Four-Wheel Drive Lock Switch (4Wd Models)
2-4. Using other driving systems Four-wheel drive lock switch (4WD models) Four-wheel drive lock mode can be used when a large amount of drive power needs to be applied to all the wheels, such as when the vehicle gets stuck in mud and you need to free it. Press the switch.
Page 223: Driving Information
2-5. Driving information Utility vehicle precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
Page 224 2-5. Driving information CAUTION ■ Off-road vehicle precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 225 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 226 2-5. Driving information CAUTION ■ Off-road driving precautions Always observe the following precautions to minimize the risk of death or serious personal injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 227 2-5. Driving information NOTICE ■ When you drive through water If driving through water, such as when crossing shallow streams, first check the depth of the water and the bottom of the stream for firmness. Drive slowly and avoid deep water. ■...
Page 228: Cargo And Luggage
2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 229 2-5. Driving information Slide the cross rails to the appro- STEP priate position for loading lug- gage turn knobs clockwise to tighten the cross rails securely. Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) - (Total weight of occupants) Steps for Determining Correct Load Limit⎯...
Page 230 2-5. Driving information (6)If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Example on your vehicle Cargo capacity Total load capacity When 2 people with the combined weight of 366 lb.
Page 231 2-5. Driving information As shown in the above example, if the number of occupants increases, the cargo and luggage load will be reduced by an amount that equals the increased weight due to the additional occupants. In other words, if an increase in the number of occupants causes an excess of the total load capacity (combined weight of occupants plus cargo and luggage load), you must reduce the cargo and luggage on your vehicle.
Page 232 2-5. Driving information CAUTION ■ Capacity and distribution ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant's weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking con- trol which may cause death or serious injury.
Page 233 2-5. Driving information NOTICE ■ When loading luggage (vehicles with moon roof) Be careful not to scratch the surface of the moon roof. I n f o r ma t i o n P r o v i d e d b y :...
Page 234: Vehicle Load Limits
2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. ■ Total load capacity: Without third seat 825 lb. (370 kg) With third seat 1155 lb. (520 kg) Total load capacity means the combined weight of occupants, cargo and luggage.
Page 235 2-5. Driving information CAUTION ■ Overloading the vehicle Do not overload the vehicle. It may not only cause damage to the tires, but also degrade steering and braking ability, resulting in an accident. I n f o r ma t i o n P r o v i d e d b y :...
Page 236: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 237 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake.
Page 238 2-5. Driving information ■ Tire chain installation Observe the following precautions when installing and removing chains. ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires. ● Install tire chains following the instructions provided in the accompanying manual.
Page 239 Vehicles with a tire pressure warning system: ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 240: Trailer Towing
Towing a trailer will have an adverse effect on handling, perfor- mance, braking, durability, and fuel consumption. For your safety and the safety of others, do not overload the vehicle or trailer. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. ■...
Page 241 2-5. Driving information ■ Trailer tongue load The trailer cargo load should be distributed so that the tongue load is 9 to 11% of the total trailer weight, not exceeding the maximum load of the following. (Tongue load / Total trailer weight x 100 = 9 to 11%) 2.5 L 4-cylinder (2AR-FE) engine: 150 lb.
Page 242 2-5. Driving information Towing a trailer Contact your Toyota dealer for further information about additional requirements such as a towing kit, etc. Hitch Trailer hitch assemblies have different weight capacities established by the hitch manufacturer. Even though the vehicle may be rated for towing a higher weight, the operator must never exceed the maxi- mum weight rating specified for the trailer hitch.
Page 243 2-5. Driving information Selecting a trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
Page 244 ■ Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
Page 245 2-5. Driving information CAUTION ■ To avoid accident or injury ● Do not exceed the trailer hitch assembly weight, gross vehicle weight, gross axle weight and trailer tongue load capacities. ● Never load more weight in the back than in the front of the trailer. About 60% of the load should be in the front half of the trailer, and the remaining 40% in the rear.
Page 246 ■ When installing a trailer hitch ● Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ● Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
Page 247 2-5. Driving information ● Reversing with a trailer attached is difficult and requires practice. Grip the bottom of the steering wheel and move your hand to the left to move the trailer to the left. Move your hand to the right to move the trailer to right.
Page 248 2-5. Driving information ● Due to the added load of the trailer, your vehicle's engine may overheat on hot days (at temperatures over 85°F [30°C]) when driving up a long or steep grade. If the engine coolant temperature gauge indicates overheating, immediately turn off the air condition- ing (if in use), pull your vehicle off the road and stop in a safe spot.
Page 249 2-5. Driving information CAUTION ■ To avoid an accident ● Do not exceed 45 mph (72 km/h) or posted towing speed limit, whichever is lower. As instability (swaying) of the towing vehicle-trailer combination increases as speed increases, exceeding 45 mph (72 km/h) may cause loss of control.
Page 250: Dinghy Towing
2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with 4 wheels on the ground.
Page 251: Using The Air Conditioning System And Defogger Manual Air Conditioning System
3-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Air outlet selection dial Temperature control dial Outside air or recirculated air mode Air conditioning on/off switch Fan speed control dial Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool).
Page 252 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Set the air outlet selection dial to an appropriate position. The positions between the air outlet selections shown below can be also selected for more detailed adjustment. Air flows to the upper body.
Page 253 3-1. Using the air conditioning system and defogger Air flows to the feet and the windshield defogger operates. The air intake is automatically switched to outside air mode. It is not possible to return to recircu- lated air mode when the dial is set at this position.
Page 254 3-1. Using the air conditioning system and defogger Adjusting the position of the air outlets Front outlets (center) Direct air flow to the left or right, up or down. Front outlets (right and left sides) Direct air flow to the left or right, up or down.
Page 255 There may be a problem in the air conditioning system if the indicator light keeps flashing. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ When...
Page 256 3-1. Using the air conditioning system and defogger NOTICE ■ To prevent battery discharge Do not leave the air conditioning system on longer than necessary when the engine is off. I n f o r ma t i o n P r o v i d e d b y :...
Page 257: Automatic Air Conditioning System
3-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Driver's side Changes the air outlets used temperature control Air flow display Outside air or recirculated air mode Air conditioning on/off switch...
Page 258 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press “∧” on to increase the temperature and “∨” to decrease the temperature. The air conditioning system switches between individual and simulta- neous modes each time is pressed.
Page 259 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press the desired button, The air flow shown on the display indicates the following. Air flows to the upper body. Air flows to the upper body and feet.
Page 260 3-1. Using the air conditioning system and defogger Air flows to the feet and the windshield defogger operates. : Vehicles with third seats ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) each time is pressed.
Page 261 3-1. Using the air conditioning system and defogger Micro dust and pollen filter Press Outside air mode will be switched to recirculated air mode. Pollen is removed from the air and the air flows to the upper part of the body.
Page 262 3-1. Using the air conditioning system and defogger Front outlets (right and left sides) Direct air flow to the left or right, up or down. Opening and closing the side outlets Open the vent. Close the vent. ■ Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions.
Page 263 There may be a problem in the air conditioning system if the indicator light keep flashing. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ Air conditioning odors ●...
Page 264 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 265: Rear Window And Outside Rear View Mirror Defoggers
3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers The rear window defogger is used to defog the rear window. The out- side rear view mirror defoggers are used to remove frost, dew or raindrops from the outside rear view mirrors.
Page 266 3-1. Using the air conditioning system and defogger ■ The defogger can be operated when Vehicles without smart key system The engine switch is in the “ON” position. Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. ■...
Page 267: Windshield Wiper De-Icer
3-1. Using the air conditioning system and defogger ∗ Windshield wiper de-icer This feature is used to prevent ice from building up on the wind- shield and wiper blades. On/off The de-icer will automatically turn off after approximately 15 minutes. ■...
Page 268: Using The Audio System Audio System Types
3-2. Using the audio system Audio system types With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. Without navigation system (type A) CD player with changer controller and AM/FM radio Without navigation system (type B) CD player with changer and AM/FM radio I n f o r ma t i o n P r o v i d e d b y :...
Page 269 3-2. Using the audio system Without navigation system (type C) CD player with changer and AM/FM radio Title Page Using the radio P. 246 Using the CD player P. 252 Playing back MP3 and WMA discs P. 259 Optimal use of the audio system P.
Page 270 3-2. Using the audio system CAUTION ■ For vehicles sold in U.S.A. and Canada (for U.S.A. and Canada) ● Part 15 of the FCC Rules FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device. ●...
Page 271: Using The Radio
3-2. Using the audio system Using the radio Power Volume Adjusting the frequency Station selector (AM, FM mode) or channel (SAT mode) Seeking the Changing the frequency channel Displaying radio text messages · SAT/FM mode buttons Scanning for receivable stations ®...
Page 272 3-2. Using the audio system ® Scanning radio stations (excluding XM Satellite Radio) ■ Scanning the preset radio stations STEP Press and hold until you hear a beep. Preset stations will be played for 5 seconds each. STEP When the desired station is reached, press once again.
Page 273 3-2. Using the audio system ■ Changing the channel category Press “∧” or “∨” on ® ■ Scanning XM Satellite Radio channels ● Scanning channels in the current category STEP Press STEP When the desired channel is reached, press again. ●...
Page 274 3-2. Using the audio system ■ When the battery is disconnected Station presets are erased. ■ Reception sensitivity ● Cargo loaded on the roof luggage carrier, especially metal objects, may ® adversely affect the reception of XM Satellite Radio. ● Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
Page 275 XM antenna cable is attached securely. “ANTENNA” There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to the XM Satellite Radio. The radio is being updated with the latest ®...
Page 276 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to “---” the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877- 438-9677 (Canada).
Page 277: Using The Cd Player
3-2. Using the audio system Using the CD player Power Volume Playback CD slot CD eject CD insert (type B and C) Track selection Displaying Search text playback messages Fast-forward Random playback Reverse Repeat play CD selection (with a CD changer) Loading CDs ■...
Page 278 3-2. Using the audio system ■ Loading multiple CDs (type B and C) STEP Press and hold until you hear a beep. “WAIT” is shown on the display. STEP Insert a CD when the indicator on the slot turns from amber to green.
Page 279 3-2. Using the audio system Fast-forwarding and reversing tracks To fast-forward or reverse, press (reverse) or (fast-for- ward). Scanning tracks STEP Press The first ten seconds of each track will be played. STEP Press again when the desired track is reached. Selecting a CD (with a CD changer) ■...
Page 280 3-2. Using the audio system Random playback ■ Current CD Press (RAND). Tracks are played in a random order until is pressed once more. ■ All CDs (with a CD changer) Press and hold (RAND) until you hear a beep. Tracks on all loaded CDs are played in a random order until pressed once more.
Page 281 Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played back. ■ Discs that can be used Discs with the marks shown below can be used.
Page 282 3-2. Using the audio system NOTICE ■ CDs that cannot be used Do not use the following types of CDs or Dual Discs. Doing so may damage the CD player and/or the CD insert/eject function. ● Type A: CDs that have a diameter other than 4.7 in.
Page 283 3-2. Using the audio system NOTICE ■ CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. ● Do not insert anything other than CDs into the CD slot. ●...
Page 284: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Fast-forward Power Volume CD insert CD slot (type B and C) File selection CD eject Folder File selection selection Search Displaying text playback messages Playback Random playback Reverse Repeat play CD selection (with a CD changer) Loading and ejecting MP3 and WMA discs →P.
Page 285 3-2. Using the audio system Selecting and scanning a folder ■ Selecting folders one at a time Press “∧” or “∨” on to select the desired folder. ■ Selecting the desired folder by cueing the first file of each folder Press and hold until you hear a beep.
Page 286 3-2. Using the audio system Repeat play ■ To repeat a file Press (RPT). ■ To repeat all of the files in a folder Press and hold (RPT) until you hear a beep. Random playback ■ To play files from a particular folder in random order Press (RAND).
Page 287 Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played back. “NO MUSIC”: This indicates that the MP3/WMA file is not included in the ■...
Page 288 3-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 289 3-2. Using the audio system ● Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
Page 290 3-2. Using the audio system ● Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 291: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- ting ● Sound quality and vol- ume balance (→P. 267) The sound quality and bal- ance setting changed to produce the best sound.
Page 292 3-2. Using the audio system Using the audio control function ■ Changing sound quality modes Pressing selects the mode to be changed in the following order. “BAS”→“MID”*→“TRE”→“FAD”→“BAL”→“ASL” *: Type C only ■ Adjusting sound quality Turning adjusts the level. Mode Sound qual- Turn to the Turn to the...
Page 293 3-2. Using the audio system ■ Adjusting the Automatic Sound Levelizer (ASL) Type A and B When “ASL” is selected, turning to the right changes the “ASL” level in the order of “LOW”, “MID” and “HIGH”. Turning to the left turns “ASL” off. ASL automatically adjusts the volume and tone quality according to vehi- cle speed.
Page 294: Using The Aux Port
3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. Open the cover and connect STEP the portable audio device. Press STEP ■...
Page 295: Using The Steering Wheel Audio Switches
3-2. Using the audio system ∗ Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio: Selects radio sta- tions CD: Selects tracks, files (MP3 and WMA) and discs Turns the power on, selects audio source Turning on the power...
Page 296 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the vol- ume. Press and hold to continue increasing or decreasing the volume. Selecting a radio station STEP Press to select the radio mode. STEP Press “∧”...
Page 297 3-2. Using the audio system CAUTION ■ To reduce the risk of an accident Exercise care when operating the audio switches on the steering wheel. I n f o r ma t i o n P r o v i d e d b y :...
Page 298: Using The Hands-Free Phone System (For Cellular Phone)
3-3. Using the hands-free phone system (for cellular phone) ∗ Hands-free phone system (for cellular phone) features ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone.
Page 299 3-3. Using the hands-free phone system (for cellular phone) ■ Required profiles for the cellular phone ● HFP (Hands Free Profile) Ver. 1.0 ● OPP (Object Push Profile) Ver. 1.1 ® If your cellular phone does not support HFP, the Bluetooth phone cannot be entered and OPP serviced cannot be provided separately.
Page 300 3-3. Using the hands-free phone system (for cellular phone) NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 301 3-3. Using the hands-free phone system (for cellular phone) CAUTION ■ Caution while driving ® Do not use a cellular phone or connect the Bluetooth phone. NOTICE ■ To prevent damage to a cellular phone Do not leave a cellular phone in the vehicle. The temperature inside may become high resulting in damage to the phone.
Page 302 3-3. Using the hands-free phone system (for cellular phone) ∗ Using the hands-free phone system (for cellular phone) ■ Audio unit Displays such items as messages, name, phone number Lower-case characters and special characters, such as an umlaut, cannot be dis- played.
Page 303 3-3. Using the hands-free phone system (for cellular phone) ■ Steering wheel telephone switches Volume The voice guidance volume cannot be adjusted using this button. Hands-free phone system off/ends a call/refuses a call Hands-free phone system on/starts a call Press: Voice command sys- tem on Press and hold: Voice com- mand system off...
Page 304 3-3. Using the hands-free phone system (for cellular phone) Operating the system using a voice command By following voice guidance instructions output from the speaker, voice commands can be given to allow for operation of the hands- free phone system without checking the display or operating ■...
Page 305 3-3. Using the hands-free phone system (for cellular phone) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a cellular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
Page 306 3-3. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system ■ Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in Callback the incoming call history memory Dialing a number stored in Redial the outgoing call history memory...
Page 307 3-3. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Phonebook Locking the phone book Security Lock Phonebook Unlocking the phone book Unlock Registering the cellular Pair Phone phone to be used Changing a registered name Change Name...
Page 308 3-3. Using the hands-free phone system (for cellular phone) ■ Using a short cut key First menu Second menu Operation detail Dialing a number registered Dial “XXX (name)” in the phone book Phone book add Adding a new number entry Changing the name of a Phone book change phone number in the phone...
Page 309 3-3. Using the hands-free phone system (for cellular phone) ■ Automatic adjustment of volume When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. ■...
Page 310: Making A Phone Call
3-3. Using the hands-free phone system (for cellular phone) Making a phone call ■ Making a phone call ● Dialing by inputting a number “Dial by number” ● Dialing by inputting a name “Dial by name” ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial”...
Page 311 3-3. Using the hands-free phone system (for cellular phone) Dialing by inputting a number STEP Press and say “Dial by number”. STEP Press and say the phone number. STEP Dial by one of the following methods: a. Press b. Press and say “Dial”.
Page 312 3-3. Using the hands-free phone system (for cellular phone) Dialing by inputting a name STEP Press and say “Dial by name”. STEP Select a registered name to be input by either of the following methods: a. Press and say a registered name. b.
Page 313 3-3. Using the hands-free phone system (for cellular phone) When receiving a phone call ■ Answering the phone Press ■ Refusing the call Press Transferring a call A call can be transferred between the cellular phone and system while dialing or receiving a call, or during a call. Use one of the follow- ing methods: a.
Page 314 3-3. Using the hands-free phone system (for cellular phone) Using the call history memory Follow the procedure below to use a number stored in the call history memory: STEP Press and say “Redial” (when using a number stored in the outgoing call history memory) or “Call back” (when using a number stored in the incoming call history memory).
Page 315 3-3. Using the hands-free phone system (for cellular phone) ■ Call history Up to 5 phone numbers can be stored in each of the outgoing and incoming call history memories. ■ When talking on the phone ● Do not talk simultaneously with the other party. ●...
Page 316: Setting A Cellular Phone
3-3. Using the hands-free phone system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following functions can be used for reg- istered cellular phones: ■ Functions and operation procedures To enter the menu for each function, follow the steps below using a voice command or ●...
Page 317 3-3. Using the hands-free phone system (for cellular phone) Selecting the cellular phone to be used STEP Select “Select Phone” using a voice command or Pattern A STEP Select the cellular phone to be used by either of the following methods, and select “Confirm”...
Page 318 3-3. Using the hands-free phone system (for cellular phone) b. Press and say “List phones”. While the desired phone name is being read aloud, press c. Select the desired phone name using STEP Press or select “Record Name” using , and say a new name.
Page 319 3-3. Using the hands-free phone system (for cellular phone) Deleting a cellular phone STEP Select “Delete” using a voice command or Pattern A STEP Select the cellular phone to be deleted by either of the follow- ing methods and select “Confirm” using a voice command or a.
Page 320 3-3. Using the hands-free phone system (for cellular phone) Pattern B STEP Select a 4 to 8-digit number using The number should be input 1 digit at a time. STEP When the entire number to be registered as a passkey has been input, press once again.
Page 321: Security And System Setup
3-3. Using the hands-free phone system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: ■ Security setting items and operation procedure ● Setting or changing the PIN (Personal Identification Number) 1.
Page 322 3-3. Using the hands-free phone system (for cellular phone) STEP Enter the registered PIN using a voice command or STEP Enter a new PIN using a voice command or When using , input the code 1 digit at a time. Locking or unlocking the phone book STEP Select “Phonebook lock (Phbk Lock)”...
Page 323 3-3. Using the hands-free phone system (for cellular phone) Initialization STEP Select “Initialize” and then “Confirm” using STEP Select “Confirm” using ■ Initialization ● The following data in the system can be initialized: • Phone book • Outgoing and incoming call history •...
Page 324: Using The Phone Book
3-3. Using the hands-free phone system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: ● Adding a new phone number 1. “Phonebook” → 2. “Add Entry” ● Setting speed dial 1.
Page 325 3-3. Using the hands-free phone system (for cellular phone) ■ Adding procedure STEP Select “Add Entry” using a voice command or STEP Use one of the following methods to input a phone number: Inputting a phone number using a voice command STEP2-1:Select “By Voice”...
Page 326 3-3. Using the hands-free phone system (for cellular phone) Inputting a phone number using STEP2-1:Select “Manual Input” using STEP2-2:Input a phone number using Input the phone number 1 digit at a time. STEP2-3:When the entire number has been input, press once again.
Page 327 3-3. Using the hands-free phone system (for cellular phone) STEP Select the name to be registered by either of the following methods, and select “Confirm” using a voice command or a. Press and say the desired name. b. Select “Record Name” using , and say the desired name.
Page 328 3-3. Using the hands-free phone system (for cellular phone) b. Press , and say “List names”. While the desired name is being read aloud, press , and select “Con- firm” using a voice command or c. Select the desired data using STEP Select the desired preset button, and register the data into speed dial by either of the following methods:...
Page 329 3-3. Using the hands-free phone system (for cellular phone) b. Press , and say “List names”. While the desired name is being read aloud, press , and select “Con- firm” using a voice command or c. Select the desired name using STEP Press or select “Record Name”...
Page 330 3-3. Using the hands-free phone system (for cellular phone) b. Press , say “List phones”. While the name of the desired phone number is being read aloud, press Pattern B STEP Select the data to be deleted using Deleting speed dials STEP Select “Delete Speed Dial (Del Spd Dial)”...
Page 331 3-3. Using the hands-free phone system (for cellular phone) ■ Limitation of number of digits A phone number that exceeds 24 digits cannot be registered. I n f o r ma t i o n P r o v i d e d b y :...
Page 332: Using The Interior Lights
3-4. Using the interior lights Interior lights list Your Toyota is equipped with the illuminated entry system to assist in entering the vehicle. Owing to the function of the system, the lights shown in the following illustration (except the luggage com-...
Page 333: Personal/Interior Light Main Switch
3-4. Using the interior lights Personal/interior light main switch and personal/interior lights Personal/interior light main switch Type A Door position The personal lights and interior light come on when a door is opened. They go off when the doors are closed. The personal lights and interior light can be individually turned on or off.
Page 334: Interior Light
3-4. Using the interior lights Personal/interior lights and interior light and luggage compartment light Type B On/off Interior light Door position Luggage compartment light I n f o r ma t i o n P r o v i d e d b y :...
Page 335 20 minutes. ■ Customization that can be configured at Toyota dealer Settings (e.g. the time elapsed before lights turn off) can be changed. (Customizable features →P. 500)
Page 336: Using The Storage Features
3-5. Using the storage features List of storage features Cup holders Bottle holders Auxiliary box Glove box Overhead console Console box CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 337: Glove Box
3-5. Using the storage features Glove box Glove box Unlock with the master key (vehicles without smart key system) or mechanical key (vehicles with smart key sys- tem) Lock with the master key (vehicles without smart key system) or mechanical key (vehicles with smart key sys- tem) Open (pull lever)
Page 338: Console Box
3-5. Using the storage features Console box Console box Upper tray Lift the lid. Lower box Pull the lever up and lift the lid. CAUTION ■ Caution while driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking. I n f o r ma t i o n P r o v i d e d b y :...
Page 339: Overhead Console
3-5. Using the storage features Overhead console Overhead console The overhead console is useful for temporarily storing sunglasses and similar small items. Press the lid. CAUTION ■ Caution while driving Keep the overhead console closed. Injuries may result in the event of an accident or sudden braking. ■...
Page 340: Cup Holders
3-5. Using the storage features Cup holders Cup holders Type A Removing the adapters changes the size. (→P. 315) Type B To use the cup holders, pull the strap forward and fold down the center seatback. ■ Adjusting size of the cup holders (type A only) Remove the adapters.
Page 341: Bottle Holders
3-5. Using the storage features Cup holders and bottle holders CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 342 3-5. Using the storage features Bottle holders Third seat CAUTION ■ Items unsuitable for the bottle holder Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 343: Auxiliary Box
3-5. Using the storage features Auxiliary box Auxiliary box To open and close the auxiliary box, press the button. CAUTION ■ Caution while driving Keep the auxiliary box closed. Injuries may result in the event of an accident or sudden braking. NOTICE ■...
Page 344: Other Interior Features
3-6. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position then slide backwards. I n f o r ma t i o n P r o v i d e d b y :...
Page 345: Vanity Mirrors
3-6. Other interior features Vanity mirrors Slide the cover. The light turns on when the cover is opened. I n f o r ma t i o n P r o v i d e d b y :...
Page 346: Clock
3-6. Other interior features Clock Vehicles with a manual air conditioning system Adjusts the hours. Adjusts the minutes. Rounds nearest hour.* *: e.g. 1:00 to 1:29 → 1:00 1:30 to 1:59 → 2:00 Vehicles with an automatic air conditioning system Adjusts the hours.
Page 347: Power Outlets
3-6. Other interior features Power outlets The power outlet can be used for a following component. 12 V: Accessories that use less than 10 A. 120 VAC: Accessories that use less than 100 W. ■ 12 V Type A Type B Type C I n f o r ma t i o n P r o v i d e d b y :...
Page 348 3-6. Other interior features ■ 120 VAC (if equipped) ■ The power outlet can be used when 12 V ● Vehicles without smart key system The engine switch is in the “ACC” or “ON” position. ● Vehicles with smart key system The “ENGINE START STOP”...
Page 349 Do not modify, disassemble or repair the power outlet or its inverter in any way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact your Toyota dealer for any necessary repairs. ■...
Page 350 3-6. Other interior features NOTICE ■ To avoid damaging the power outlet and the plug ● Close the power outlet lid when not in use. ● Do not allow foreign objects or liquids to enter the power outlet, as this may cause a short circuit.
Page 351 ■ If the power outlet is loose when an electrical appliance plug is con- nected Replace the outlet. Contact your Toyota dealer for any necessary replace- ments. ■ If the power outlet gets dirty Use a soft, clean cloth to wipe it gently.
Page 352: Seat Heaters
3-6. Other interior features ∗ Seat heaters Heats the driver’s seat Heats the front passenger’s seat The indicator light is on while the seat heater is operating. Push the switch once again to turn off the seat heater. ■ The seat heaters can be used when Vehicles without smart key system The engine switch is in the “ON”...
Page 353 3-6. Other interior features NOTICE ■ To prevent seat heater damage Do not put unevenly weighted objects on the seat and do not stick sharp objects (needles, nails, etc.) into the seat. ■ To prevent battery discharge Turn the switches off when the engine is not running. I n f o r ma t i o n P r o v i d e d b y :...
Page 354: Armrest
3-6. Other interior features Armrest To use the armrest, pull the strap forward and fold down the center seatback. NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest. I n f o r ma t i o n P r o v i d e d b y :...
Page 355: Coat Hooks
3-6. Other interior features Coat hooks CAUTION ■ Items that must not be hung on the hook Do not hang a coat hanger or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles that cause death or serious injury.
Page 356: Floor Mat
When installing the driver's floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver's seat. ●...
Page 357: Luggage Compartment Features
3-6. Other interior features Luggage compartment features ■ Cargo hooks Cargo hooks are provided for securing loose items. ■ Grocery bag hooks ■ Storage box (vehicles without third seats) Type A The rear deck board can be folded up into two positions. Lift the rear deck board.
Page 358 3-6. Other interior features Fold up the deck board. STEP The lid can be removed. Type B Lift the front deck board. I n f o r ma t i o n P r o v i d e d b y :...
Page 359 3-6. Other interior features ■ Luggage cover (if equipped) Attach the hooks to the head STEP restraints. If necessary, move the second seats to enable the hook engagement. Pull out the luggage cover and STEP hook onto the anchors. Removing the luggage cover (if equipped) The luggage cover can be removed by following the procedure below.
Page 360 3-6. Other interior features Stowing the luggage cover (if equipped) Open the rear deck board and STEP remove the deck side cover. Insert the right end of the lug- STEP gage cover into the recess, then compress the left end of the lug- gage cover and insert it into the recess.
Page 361 3-6. Other interior features CAUTION ■ When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their stowed positions. ■ Caution while driving ● Do not drive with any of the deck boards opened. Items may fall out and cause injury.
Page 362: Maintenance And Care
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 363 4-1. Maintenance and care ■ Aluminum wheels ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. ●...
Page 364 4-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 365: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 366 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 367 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ●...
Page 368: Maintenance
It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 369 4-2. Maintenance ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 370: General Maintenance
“Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 371 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
Page 372 4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tires •...
Page 373: Emission Inspection And Maintenance (I/M) Programs
If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
Page 374: Do-It-Yourself Maintenance
Brake fluid level (→P. 367) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 375 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 392) as original Radiator and condenser ⎯ (→P. 366) • Tire pressure gauge Tire inflation pressure (→P. 380) • Compressed air source • Water washer fluid containing Washer fluid (→P.
Page 376 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing, and tools away from the moving fans and engine drive belt.
Page 377 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment.
Page 378: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the auxiliary catch lever STEP and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into the slot.
Page 379 4-3. Do-it-yourself maintenance CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 380: Positioning A Floor Jack
4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ■ Front ■ Rear I n f o r ma t i o n P r o v i d e d b y :...
Page 381 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 382: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment 2.5 L 4-cylinder (2AR-FE) engine Fuse boxes (→P. 392) Radiator (→P. 366) Engine coolant reservoir Condenser (→P. 366) (→P. 365) Electric cooling fans Engine oil filler cap Engine oil level dipstick (→P. 362) (→P. 361) Battery (→P.
Page 383 4-3. Do-it-yourself maintenance 3.5 L V6 (2GR-FE) engine Fuse boxes (→P. 392) Radiator (→P. 366) Engine coolant reservoir Condenser (→P. 366) (→P. 365) Electric cooling fans Engine oil filler cap Engine oil level dipstick (→P. 362) (→P. 361) Battery (→P. 369) Washer fluid tank (→P.
Page 384 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment cover ■ Installing the clips I n f o r ma t i o n P r o v i d e d b y :...
Page 385 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil STEP Park the vehicle on level ground. After turning off the engine, wait more than five minutes for the oil to drain back into the bottom of the engine.
Page 386 4-3. Do-it-yourself maintenance 3.5 L V6 (2GR-FE) engine Full ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 387 1000 km) ● If your vehicle consumes more than 1.1 qt. (1.0 L, 0.9 Imp. qt.) every 600 miles (1000 km), contact your Toyota dealer. ■ Changing the engine oil (U.S.A. only) To reset the oil change system, follow the procedure below:...
Page 388 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 389 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, engine coolant reservoir cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. ■...
Page 390 Radiator and condenser Check the radiator and condenser, and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
Page 391 4-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Make sure to check the fluid type and prepare the necessary items. ■ Adding fluid Fluid type SAE J1703 or FMVSS No.116 DOT 3 brake fluid Items Clean funnel...
Page 392 4-3. Do-it-yourself maintenance CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces. If fluid gets on your hands or in your eyes, flush the affected area with clean water immediately.
Page 393 4-3. Do-it-yourself maintenance Battery ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Checking battery fluid Check that the level is between the “UPPER”...
Page 394 4-3. Do-it-yourself maintenance ■ After recharging/reconnecting the battery (vehicles with smart key sys- tem) In some cases, the engine may not start. Follow the procedure below to ini- tialize the system. STEP Shift the shift lever to P, and turn the “ENGINE START STOP” switch OFF.
Page 395 4-3. Do-it-yourself maintenance CAUTION ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
Page 396 4-3. Do-it-yourself maintenance Washer fluid For vehicles sold in U.S.A. Add washer fluid in the following situations. ● Any washer does not work. ● The low washer fluid warning light comes on. For vehicles sold in Canada If any washer does not work or the low windshield washer fluid warn- ing light comes on, the washer tank may be empty.
Page 397: Tires
Vehicles with a spare tire of the same wheel type as the installed tires Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recom- mends that tire rotation is Front carried out at the same inter- val as tire inspection.
Page 398 ■ The tire pressure warning system (if equipped) Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 429)
Page 399 Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 375) Registering ID codes (vehicles with a tire pressure warning...
Page 400 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage. If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels (vehicles with a tire pressure warning...
Page 401 4-3. Do-it-yourself maintenance ■ Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 402 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 403 ● When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. ● When replacing tire valve caps, do not use tire valve caps other than those specified.
Page 404: Tire Inflation Pressure
4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 489) I n f o r ma t i o n P r o v i d e d b y :...
Page 405 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge STEP Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not within the recommended levels, adjust the pressure.
Page 406 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 407 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
Page 408: Wheels
● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 409 When replacing wheels (vehicles with a tire pressure warning sys- tem) The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.
Page 410: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method STEP Vehicles without smart key system: Turn the engine switch off. Vehicles with smart key system: Turn the “ENGINE START STOP”...
Page 411 4-3. Do-it-yourself maintenance ■ Replacement method Remove the air conditioning filter and replace it with a new one. The “UP↑” marks shown on the filter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 412: Key Battery
4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with a rag.) ●...
Page 413 4-3. Do-it-yourself maintenance Open the case cover using a STEP coin protected with tape etc. and remove the depleted bat- tery. Insert a new battery with the “+” terminal facing up. ■ Replacing the battery (vehicles with smart key system) Take out the mechanical key.
Page 414 Use a CR2016 (vehicles without smart key system) or CR1632 (vehicles with smart key system) lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer.
Page 415 4-3. Do-it-yourself maintenance NOTICE ■ For normal operation after replacing the battery Observe the following precautions to prevent accidents. ● Always work with dry hands. Moisture may cause the battery to rust. ● Do not touch or move any other components inside the remote control. ●...
Page 416: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Vehicles without smart key system: Turn the engine switch off.
Page 417 4-3. Do-it-yourself maintenance Under the instrument panel Remove the lid. STEP After a system failure, see “Fuse layout and amperage rat- ings” (→P. 396) for details about which fuse to check. Remove the fuse with the pull- STEP out tool. STEP Check if the fuse has blown.
Page 418 The amperage rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Contact your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 419 4-3. Do-it-yourself maintenance Type D Normal fuse Blown fuse Contact your Toyota dealer. Type E Normal fuse Blown fuse Contact your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
Page 420 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Type A (passenger’s side) Fuse Ampere Circuit SPARE 30 A Spare fuse SPARE 20 A Spare fuse SPARE 10 A Spare fuse Air conditioning system, power win- ECU-B2 7.5 A dows, smart key system ALT-S 7.5 A...
Page 421 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Gauges and meters, clock, main body ECU, wireless remote control, smart key system, audio system, front passenger occupant classifi- ECU-B 10 A cation system, ABS, TRAC, VSC, AUTO LSD, downhill assist control system, hill-start assist control sys- tem, Active Torque Control 4WD system Vanity lights, personal/interior...
Page 422 4-3. Do-it-yourself maintenance Fuse Ampere Circuit CDS* 30 A Electric cooling fan FAN 1* 50 A H-LP CLN 30 A No circuit : Vehicles with towing package : Vehicles with 2.5 L 4-cylinder (2AR-FE) engine : Vehicles with 3.5 L V6 (2GR-FE) engine Type B (driver’s side) Fuse Ampere...
Page 423 4-3. Do-it-yourself maintenance Fuse Ampere Circuit AM2-2 7.5 A Starting system Multiport fuel injection system/ EFI NO.1 10 A sequential multiport fuel injection system Multiport fuel injection system/ EFI NO.2 10 A sequential multiport fuel injection system EFI NO.3 7.5 A No circuit GROW 80 A...
Page 424 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 20 A A/F sensor, fuel pump : Vehicles without towing package : Vehicles with towing package : Vehicles with 2.5 L 4-cylinder (2AR-FE) engine : Vehicles with 3.5 L V6 (2GR-FE) engine ■ Under the instrument panel Fuse Ampere Circuit...
Page 425 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Audio system, power outlets, power rear view mirror control, 7.5 A automatic transmission shift lock system, main body ECU, clock, smart key system MIR HTR 10 A Outside rear view mirror defoggers PWR OUTLET 15 A Power outlet RR FOG...
Page 426 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 7.5 A On-board diagnosis system Stop/tail lights, high mounted stop- light, automatic transmission shift lock system, multiport fuel injection system/sequential multiport fuel STOP 10 A injection system, ABS, TRAC, VSC, AUTO LSD system, downhill assist control system, hill-start assist control system Main body ECU, power door lock...
Page 427 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
Page 428: Light Bulbs
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 429 4-3. Do-it-yourself maintenance ■ Rear bulb locations Vehicles without a spare tire Rear side marker lights License plate Rear turn signal and back-up lights lights Vehicles with a spare tire Rear side marker lights License plate light Rear turn signal and back-up lights I n f o r ma t i o n P r o v i d e d b y :...
Page 430 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlights Right side only: Remove the clip STEP and move it aside to allow easy access to the light bulbs. Turn the bulb base counterclock- STEP wise. Headlight (low beam) Headlight (high beam) Unplug connector while...
Page 431 4-3. Do-it-yourself maintenance Reinstalling the clip ■ Front turn signal, parking and front side marker lights Right side only: Remove the clip STEP and move it aside to allow easy access to the light bulbs. Turn the bulb base counterclock- STEP wise.
Page 432 4-3. Do-it-yourself maintenance Reinstalling the clip ■ Front fog lights (if equipped) Turn the steering wheel in the STEP opposite direction of the front fog light that you wish to replace. For example, if you wish to replace the front fog light on the right side, turn the steering wheel to the left.
Page 433 4-3. Do-it-yourself maintenance Unplug connector while STEP depressing the lock release. Turn the bulb base counterclock- STEP wise. ■ Back-up lights, rear turn signal and rear side marker lights Open the back door (→P. 46) STEP and remove the cover. Turn the bulb base counterclock- STEP wise.
Page 434 4-3. Do-it-yourself maintenance Remove the light bulb. STEP Rear side marker light Rear turn signal light Back-up light ■ License plate lights Vehicles without a spare tire Remove the cover as shown in STEP the illustration. Turn the bulb base counterclock- STEP wise.
Page 435 STEP ■ Light other than the above If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● High mounted stoplight ● Stop/tail lights ● Side turn signal lights (if equipped) I n f o r ma t i o n P r o v i d e d b y :...
Page 436 4-3. Do-it-yourself maintenance ■ Condensation build-up on the inside of the lens Contact your Toyota dealer for more information in the following situations. Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. ● Large drops of water are built up on the inside of the lens.
Page 437: Essential Information
5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
Page 438: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a wheel-lift type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 439 5-1. Essential information Emergency towing If a tow truck is not available, in an emergency your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet. This should only be attempted on hard surfaced roads for short distances at low speeds.
Page 440 5-1. Essential information Installing towing eyelet Remove the eyelet cover using a STEP flathead screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehicle body, as shown in the illustration. Insert the towing eyelet into the STEP hole and tighten partially by hand.
Page 441 5-1. Essential information Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front (2WD models) Release the parking brake. From the front (4WD models) Use a towing dolly under the rear wheels.
Page 442 5-1. Essential information From the rear Use a towing dolly under the front wheels. Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged.
Page 443 5-1. Essential information CAUTION ■ Caution while towing ● Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelet and the cables or chains. Always use caution for the surroundings and other vehicles while towing. ●...
Page 444 5-1. Essential information NOTICE ■ To prevent body damage when towing with a sling-type truck Do not tow with a sling-type truck, either from the front or rear. ■ To prevent causing serious damage to the transmission and Active Torque Control 4WD system (4WD models) when towing using a wheel- lift type truck 2WD models: Never tow this vehicle from the rear with the front wheels on the...
Page 445: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 446: Fuel Pump Shut Off System
5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 447: Event Data Recorder
5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
Page 448 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle's owner (or the leasing company for a leased vehicle) is obtained ●...
Page 449: Steps To Take In An Emergency
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer)* •...
Page 450 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
Page 451 5-2. Steps to take in an emergency Warning light Warning light/Details “ABS” warning light (U.S.A.) Indicates a malfunction in: • The ABS; • The brake assist system. (Canada) Electric power steering warning light Indicates a malfunction in the EPS system. Cruise control indicator light Indicates a malfunction in the cruise control system.
Page 452 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning light Warning light/Details Correction procedure Open door warning light Check that all doors are Indicates that a door is not closed.
Page 453 (if equipped) lever to P. Indicates that the auto- If the light does not go off, matic transmission fluid contact your Toyota dealer. temperature is too high. Low washer fluid warning light Fill the tank. Low level of washer fluid...
Page 454 5-2. Steps to take in an emergency *: Driver's and front passenger’s seat belt warning buzzers: The driver’s and front passenger’s seat belt warning buzzers sound to alert the driver and front passenger that his or her seat belt is not fastened. The buzzer sounds intermittently for 10 seconds after the vehicle has reached a speed of 12 mph (20 km/h).
Page 455 5-2. Steps to take in an emergency Interior Exterior Warning Correction Warning light/Details buzzer buzzer light procedure Smart key system warning Turn the light “ENGINE Indicates that the driver’s door START has been opened and closed STOP” switch with the shift lever in P, the 3 times OFF or con- Once...
Page 456 The malfunction indicator lamp will go off after taking several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. ■ Front passenger detection sensor and passenger seat belt reminder ●...
Page 457 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 458 Customization that can be configured at Toyota dealer The vehicle speed linked seat belt reminder buzzer can be disabled. (Customizable features →P. 500) However, Toyota recommends that the seat belt reminder buzzer be operational to alert the driver and front passen- ger that the seat belts are not fastened.
Page 459 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 460 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
Page 461: If You Have A Flat Tire (Vehicles With Standard Tires)
5-2. Steps to take in an emergency If you have a flat tire (vehicles with standard tires) Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ●...
Page 462 5-2. Steps to take in an emergency Taking out the jack Disengage claws STEP remove the cover. Loosen STEP Tighten Loosen and take out the jack. I n f o r ma t i o n P r o v i d e d b y :...
Page 463 5-2. Steps to take in an emergency Taking out the tool bag Disengage claws STEP remove the cover. Take out the tool bag. STEP I n f o r ma t i o n P r o v i d e d b y :...
Page 464 5-2. Steps to take in an emergency Taking out the spare tire (vehicles with the spare tire cover) Open the back door. Unlock the STEP latch handle which is on the bot- tom of the spare tire cover. STEP Close the back door. Remove the spare tire cover by STEP holding the bottom and lifting it...
Page 465 5-2. Steps to take in an emergency Taking out the spare tire (vehicles without the spare tire cover) Using the wheel nut wrench, STEP loosen the hold-down nuts by turning them counterclockwise until they can be loosened by hand. Follow the order shown in the illustration.
Page 466 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel Flat tire chock posi- tions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of...
Page 467 5-2. Steps to take in an emergency STEP Remove the wheel ornament using the wheel nut wrench as shown below. 16-inch wheel To protect the wheel ornament, place a rag between the wrench and the wheel ornament, as shown in the illustration. 17-inch and 18-inch wheels Slightly loosen the wheel nuts STEP...
Page 468 5-2. Steps to take in an emergency Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Type A: Assemble the jack han- STEP dle extension. Type B: Assemble the jack han- STEP dle extension.
Page 469 5-2. Steps to take in an emergency STEP Raise the vehicle until the tire is slightly raised off the ground. Type A Type B Type C I n f o r ma t i o n P r o v i d e d b y :...
Page 470 5-2. Steps to take in an emergency Remove all the wheel nuts and STEP the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface. Installing the tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur-...
Page 471 5-2. Steps to take in an emergency STEP Install the tire and loosely tighten each wheel nut by hand by approximately the same amount. Replacing a steel wheel with a steel wheel Tighten the nuts until the tapered Tapered portion portion comes into loose contact with the disc wheel seat.
Page 472 5-2. Steps to take in an emergency STEP Lower the vehicle. Type A Type B Type C I n f o r ma t i o n P r o v i d e d b y :...
Page 473 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) STEP Reinstall the wheel ornament. 16-inch wheel 17-inch and 18-inch wheels I n f o r ma t i o n P r o v i d e d b y :...
Page 474 5-2. Steps to take in an emergency Stowing the flat tire STEP Remove any dirt or foreign matter from the disc wheel seat and the wheel contact surface. Vehicles with aluminum wheels STEP and a steel wheel for the spare: Remove the plastic rings from the wheel nuts of the spare tire carrier.
Page 475 5-2. Steps to take in an emergency Upper slots STEP Hooks To install the spare tire cover, insert the hooks under the guides to the upper slots and lower the cover. Attach the cover by hooking the STEP 2 inner protrusions. Check that the cover is securely attached.
Page 476 5-2. Steps to take in an emergency STEP Stow the jack and all tools securely, and replace all the cov- ers. ■ When reinstalling the wheel ornament (vehicles with 16-inch wheels) Align the cutout of the wheel ornament with the valve stem as shown. ■...
Page 477 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 478 5-2. Steps to take in an emergency CAUTION ■ Replacing a flat tire Observe the following precautions to reduce the risk of death or serious injury: ● Do not try to remove the ornament by hand. Take due care in handling the ornament to avoid unexpected personal injury.
Page 479 When replacing the tires (vehicles with a tire pressure warning sys- tem) When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. ■...
Page 480: If You Have A Flat Tire (Vehicles With Run-Flat Tires)
5-2. Steps to take in an emergency If you have a flat tire (vehicles with run-flat tires) Take your vehicle to the nearest Toyota dealer or authorized tire dealer as soon as possible. ■ Run-flat tires (A “RFT” or “DSST” mark is molded on the...
Page 481: If The Engine Will Not Start
● There may be a malfunction in the steering lock system (vehi- cles with smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. I n f o r ma t i o n P r o v i d e d b y :...
Page 482: If The Shift Lever Cannot Be Shifted From P
(a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 483: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer. For vehicles with the smart key system, bring the other key and the key number stamped on the key number plate.
Page 484: If The Electronic Key Does Not Operate Properly (Vehicles With Smart Key System)
Changing “ENGINE START STOP” switch modes and starting the engine STEP Shift the shift lever to P and apply the brakes. Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch. If any of the doors is opened and...
Page 485 5 seconds after the buzzer sounds, keeping the brake pedal depressed. In the event that the “ENGINE START STOP” switch still cannot be operated, contact your Toyota dealer. ■ Stopping the engine Shift the shift lever to P and press the “ENGINE START STOP” switch as you normally do when stopping the engine.
Page 486: If The Battery Is Discharged
You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. STEP...
Page 487 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting.
Page 488 5-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. ● Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
Page 489: If Your Vehicle Overheats
Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fans are not operating: Stop the engine and call your Toyota dealer. After the engine has cooled STEP STEP...
Page 490 5-2. Steps to take in an emergency Have the vehicle checked at the nearest Toyota dealer as soon as possible. ■ Overheating If you observe the following, your vehicle may be overheating. ● The engine coolant temperature gauge enters the red zone or a loss of power is experienced.
Page 491: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. STEP Stop the engine. Set the parking brake and put the shift lever in P.
Page 492 5-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components ● Avoid spinning the wheels and do not rev the engine. ● If the vehicle remains stuck after trying these procedures, the vehicle may require towing to be freed.
Page 493: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: STEP Steadily step on the brake pedal with both feet and firmly...
Page 494 5-2. Steps to take in an emergency Vehicles with a smart key sys- STEP tem: Stop the engine by press- ing and holding the “ENGINE START STOP” switch for 3 consecutive seconds or more. Press and hold for 3 seconds or more STEP Stop the vehicle in a safe place by the road.
Page 495 5-2. Steps to take in an emergency I n f o r ma t i o n P r o v i d e d b y :...
Page 496: Specifications Maintenance Data (Fuel, Oil Level, Etc.)
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights 178.7 in. (4540 mm)* 180.7 in. (4590 mm)* Overall length 180.9 in. (4595 mm)* 181.1 in. (4600 mm)* 181.9 in. (4620 mm)* Without over fender 71.5 in. (1815 mm) Overall width With over fender 73.0 in.
Page 497 6-1. Specifications 2.5 L 4-cylinder (2AR-FE) engine 1500 lb. (680 kg) Towing capacity 3.5 L V6 (2GR-FE) engine (Trailer weight + cargo) 2000 lb. (905 kg) 3500 lb. (1585 kg)* : Without spare tire : 215/70R16 tires : 225/65R17 tires : 235/55R18 tires : With spare tire cover : Unladen vehicle...
Page 498 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 499 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. 2.5 L 4-cylinder (2AR-FE) engine 3.5 L V6 (2GR-FE) engine Engine Model 2AR-FE 2GR-FE 4-cylinder in line, 6-cylinder V type, Type 4-cycle, gasoline 4-cycle, gasoline 3.54 ×...
Page 500 6.4 qt. (6.1 L, 5.4 Imp. qt.) ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
Page 501 6-1. Specifications Recommended viscosity: 2.5 L 4-cylinder (2AR-FE) engine SAE 5W-20 or 0W-20 SAE 5W-20 or 0W-20 engine oil may be used. However, SAE 0W-20 is the best choice for good fuel economy and good starting in cold weather. Outside temperature The 0W portion of the oil viscosity rating indicates the characteristic of the oil which allows cold startability.
Page 502 3.5 L V6 (2GR-FE) engine 9.4 qt. (8.9 L, 7.8 Imp. qt.) 9.8 qt. (9.3 L, 8.2 Imp. qt.)* Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and...
Page 503 6-1. Specifications Ignition system Spark plug Make 2.5 L 4-cylinder (2AR-FE) engine DENSO, SK16HR11 3.5 L V6 (2GR-FE) engine DENSO FK20HR11 0.043 in. (1.1 mm) NOTICE ■ Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust gap when tuning the engine.
Page 504 NOTICE ■ Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the automatic transmis- sion of your vehicle.
Page 505 6-1. Specifications Brakes Pedal clearance* Without third seats 3.7 in. (95 mm) With third seats 4.7 in. (120 mm) 0.04 ⎯ 0.24 in. (1 ⎯ 6 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in.
Page 506 6-1. Specifications Tires and wheels Type A 215/70R16 99H, 225/65R17 101H, Tire size 235/55R18 99H Tire inflation pressure Front: 32 psi (220 kPa, 2.2 kgf/cm or bar) (Recommended cold tire Rear: 32 psi (220 kPa, 2.2 kgf/cm or bar) inflation pressure) Spare: 32 psi (220 kPa, 2.2 kgf/cm or bar) 16 ×...
Page 507 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights High beam 9005 Low beam 9006 ⎯ Front fog lights* Front turn signal/parking, front 7443 21/5 Exterior side marker lights ⎯ Rear side marker lights Rear turn signal lights 7440 Back-up lights License plate lights ⎯...
Page 508: Fuel Information
ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
Page 509 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. ●...
Page 510 6-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle's three-way catalytic converters causing the emission control system to malfunction and the emission control system to function improperly.
Page 511: Tire Information
6-1. Specifications Tire information Typical tire symbols Tire size (→P. 491) DOT and Tire Identification Number (TIN) (→P. 490) Uniform tire quality grading For details, see “Uniform tire quality grading” that follows. Location of treadwear indicators (→P. 373) Run-flat tire (RFT) or standard tire (→P.
Page 512 6-1. Specifications Load limit at maximum cold tire inflation pressure (→P. 376) Maximum cold tire inflation pressure (→P. 484) This means the pressure to which a tire may be inflated. Summer tire or all season tire (→P. 377) An all season tire has “M+S” on the sidewall. A tire not marked “M+S”...
Page 513 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 514 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 515 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 516 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
Page 517 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 518 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 519 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall...
Page 520 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load...
Page 521 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the...
Page 522: Customization
Your vehicle includes a variety of electronic features that can be personalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer. Customized Item Function Default setting...
Page 523 6-2. Customization Customized Item Function Default setting setting Wireless Operation signal remote con- (Buzzer) trol → P. 38) Panic function Driver's door Door lock unlocked in one All doors → P. 42, Unlocking using a key step, all doors unlocked in one 461) unlocked in two step...
Page 524 6-2. Customization Customized Item Function Default setting setting Seat belt Vehicle speed linked reminder seat belt reminder → P. 429) buzzer I n f o r ma t i o n P r o v i d e d b y :...
Page 525: Initialization Items To Initialize
6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference After reconnecting or changing the Power window P.
Page 526 6-3. Initialization I n f o r ma t i o n P r o v i d e d b y :...
Page 527: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 528: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 529 ATTENTION ■ Lorsque vous utilisez la ceinture de sécurité du siège central de la deuxième rangée N'utilisez pas la ceinture de sécurité du siège central de deuxième rangée si l'une des 2 boucles est déverrouillée. Si une seule des boucles est verrouillée, ceci peut entraîner des blessures graves, voire mortelles en cas de freinage brusque ou de collision.
Page 530: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. Sacs de sécurité...
Page 531 Sacs de sécurité gonflables latéraux et rideau Sacs de sécurité gonflables latéraux Participent à la protection du thorax des occupants des sièges avant. Sacs de sécurité gonflables rideau Participent principalement à la protection de la tête des occupants assis aux places extérieures. I n f o r ma t i o n P r o v i d e d b y :...
Page 532 Composition du système de sacs de sécurité gonflables Sacs de sécurité gonflables Témoins “AIR BAG ON” et rideau “AIR BAG OFF” Sacs de sécurité gonflables Voyant SRS latéraux Sac de sécurité gonflable Sac de sécurité gonflable conducteur passager avant Capteur de la position du Capteurs sacs siège conducteur...
Page 533 Votre véhicule est équipé de SACS DE SÉCURITÉ GONFLABLES INTELLIGENTS (ADVANCED AIRBAGS) conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le système de sac de sécurité gonflable contrôle la puissance de déploiement des sacs de sécurité gonflables conducteur et passager avant.
Page 534 ATTENTION ■ Précautions à observer avec les sacs de sécurité gonflables SRS Respectez les précautions suivantes avec les sacs de sécurité gonflables. À défaut, des blessures graves, voire mortelles, pourraient s'ensuivre. ● Le conducteur et tous les passagers à bord du véhicule doivent porter leur ceinture de sécurité...
Page 535 être grièvement blessés ou tués par le déploiement d'un sac de sécurité gonflable. Installez les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité dans un siège de sécurité enfant. Toyota recommande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement attachés.
Page 536 ATTENTION ■ Précautions à observer avec les sacs de sécurité gonflables SRS ●Ne vous asseyez pas sur le bord du siège et ne vous appuyez pas contre la planche de bord. ●Ne laissez pas un enfant rester debout devant le sac de sécurité gonflable SRS passager avant ou bien s'asseoir sur les genoux du passager avant.
Page 537 ATTENTION ■ Précautions à observer avec les sacs de sécurité gonflables SRS ● Ne fixez ni ne posez aucun objet sur la planche de bord ou la garniture centrale du volant de direction. Au déploiement des sacs de sécurité gonflables SRS conducteur et passager avant, tout objet...
Page 538 Toyota. I n f o r ma t i o n P r o v i d e d b y :...
Page 539 ■ Modification et mise au rebut des éléments du système de sacs de sécurité gonflables SRS Consultez impérativement votre concessionnaire Toyota si vous avez besoin d'intervenir sur votre véhicule ou de procéder à l'une des modifications suivantes. Les sacs de sécurité gonflables SRS risquent de ne pas fonctionner correctement ou de se déployer (gonfler) accidentellement, provoquant ainsi...
Page 540: Alphabetical Index
Alphabetical index Alphabetical index A/C........226, 232 Antenna ........249 ABS ...........184 Anti-lock brake system ... 184 Active head restraints ....53 Armrest ........329 Air conditioning filter....386 Audio input.......269 Air conditioning system Audio system Air conditioning filter....386 Antenna......... 249 Automatic air Audio input ......269 conditioning system ....232 AUX port .......269 Manual air conditioning...
Page 541 Alphabetical index Back-up lights Care Replacing light bulbs .... 404 Exterior........338 Wattage ........ 485 Interior ........341 Back door Seat belts ......342 Back door ....... 46 Cargo capacity ......208 Wireless remote control..38 Cargo hooks ......332 Smart key system....26 CD changer.......252 Battery CD player ........252 Checking ......
Page 542 Alphabetical index Child safety Daytime running light Airbag precautions ....105 system ........166 Battery precautions ..370, 465 Defogger Child restraint system....116 Rear window ......240 Child-protectors.......44 Side mirrors......240 How your child should wear Dimensions ......474 the seat belt ......72 Dinghy towing ......224 Installing child restraints..120 Display Moon roof precautions ....87...
Page 543 Alphabetical index Electric power steering... 184 Engine Electronic key Compartment ......358 If your electronic key Engine switch ....143, 147 battery is discharged..461 Hood........354 Emergency flasher How to start the Switch........414 engine ......143, 147 Emergency, in case of Identification number.....476 If a warning buzzer If the engine will not start ..458 sounds...
Page 544 Alphabetical index Floor mat........331 Gas station information ..536 Fluid Gauges........156 Brake........367 Glove box .........312 Washer........372 Grocery bag hooks ....332 Fog lights Replacing light bulbs .....404 Hands-free system Switch........168 (for cellular phone)....273 Wattage.........485 Hazard lights Front fog lights Switch ........414 Replacing light bulbs .....404 Head restraints...
Page 545 Alphabetical index I/M test........349 License plate lights Identification Replacing light bulbs .....404 Engine ........476 Wattage.........485 Vehicle........476 Light bulbs Ignition switch ....144, 147 Replacing ......404 Illuminated entry system ..307 Wattage.........485 Indicator lights ......159 Lights Initialization Door courtesy lights ....307 Items to initialize....
Page 546 Alphabetical index Maintenance Odometer........156 Do-it-yourself maintenance .......350 Engine oil ......361 General maintenance....346 Opener Maintenance data....474 Hood ........354 Maintenance requirements..344 Outside rear view mirrors Manual air conditioning Adjusting and folding....79 system ........226 Outside temperature Meter display ........163 Instrument panel light Overhead console....
Page 547 Alphabetical index Radiator........366 Seat belts Radio ........246 Adjusting the seat belt.....68 Rear seat Automatic Locking Adjustment ......54 Retractor .......71 Folding down second Child restraint system seatback....... 57 installation......120 Folding down third Cleaning and maintaining seatback....... 59 the seat belts ......342 Rear turn signal lights Emergency Locking Replacing light bulbs ....
Page 548 Alphabetical index Service reminder Stop lights indicators ......159 Replacing light bulbs..... 404 Shift lever Wattage......... 485 Automatic transmission ..150 Storage feature ......311 If the shift lever cannot Storage precautions ....205 be shifted from P....459 Stuck Shift lock system .....459 If your vehicle becomes Side airbags........98 stuck ........
Page 549 Alphabetical index Tachometer......156 Tools .........438 Tail lights Total load capacity....208 Replacing light bulbs .... 404 Towing Switch........165 Dinghy towing......224 Wattage ........ 485 Emergency towing....416 Talk switch....... 278 Trailer towing......214 Telephone switch ....278 Traction control......184 Theft deterrent system TRAC .........184 Engine immobilizer system..
Page 550 Alphabetical index Warning buzzers Washer Brake system ......426 Checking ....... 372 Seat belt reminder....429 Preparing and checking Warning lights before winter....... 210 Active Torque Control Switch ......169, 171 4WD system ....427, 429 Washing and waxing ....338 Anti-lock brake system ..427 Weight Automatic transmission Cargo capacity ......
Page 551: What To Do If
What to do if... What to do if... If you have a flat tire A tire punctures P. 438 P. 458 If the engine will not start The engine does not start P. 92 Engine immobilizer system P. 463 If the battery is discharged If the shift lever cannot be shifted The shift lever cannot be P.
Page 552: Warning Lights
What to do if... ■Warning lights Brake system warning Electric power steering light warning light P. 427 Active Torque Control 4WD sys- tem warning light P. 426 P. 427 Low fuel level warning Charging system warn- light ing light P. 427 P.
Page 553 What to do if... “ABS” warning light Tire pressure warning light P. 429 Smart key system warn- ing light P. 427 P. 431 Slip indicator light Cruise control indicator light* P. 427 P. 427 : The light flashes to indicate a malfunction. I n f o r ma t i o n P r o v i d e d b y :...
Page 554: Gas Station Information
P. 484 pressure Engine oil capacity (Drain and refill ⎯ P. 478 reference) Toyota Genuine Motor Oil or equivalent Oil grade: P. 478 ILSAC multigrade engine oil Engine oil type Recommended oil viscosity: SAE 5W-20 or 0W-20 (2.5 L 4-cylinder [2AR-FE] engine) SAE 5W-30 (3.5 L V6...
