Summary of Contents for Toyota RAV4

  • Page 1 Pictorial index Search by illustration For safety and Make sure to read through them security Instrument clus- How to read the gauges and meters, the variety of warning lights and indicators, etc. Operation Opening and closing the doors and windows, each component adjustment before driving, etc.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS For your information .......8 Instrument cluster Reading this manual.....12 How to search ......13 Pictorial index .......14 Instrument cluster Warning lights indica- For safety and security tors........102 Gauges and meters... 108 Multi-information display ... 109 1-1. For safe use Fuel consumption informa-...
  • Page 3 Engine (ignition) switch (vehi- tems cles with a smart entery & start system......238 Cruise control ....309 Automatic transmission(with S (Lane Departure mode).......246 Alert)........313 Automatic transmission (with M Toyota parking assist-sen- mode)........253 sor........321 Multidrive ......262 All-wheel drive lock switch (AWD mod- Manual transmission..270...
  • Page 4 TABLE OF CONTENTS 5-2. Using the audio system Interior features Audio system types ... 392 Using the radio ....395 Using the CD player ..402 5-1. Using the air conditioning sys- tem and defogger Playing back MP3 and WMA discs.........410 Manual air conditioning sys- tem........370...
  • Page 5 5-3. Using the interior lights Maintenance and care Interior lights list....483 • Interior lights ....484 6-1. Maintenance and care • Personal lights ....484 Cleaning and protecting the 5-4. Using the storage features vehicle exterior....512 List of storage features ..486 Cleaning and protecting the •...
  • Page 6 TABLE OF CONTENTS 7-2. Steps to take in an emergency When trouble arises If your vehicle needs to be towed.........611 think something 7-1. Essential information wrong.........618 Emergency flashers ...608 Fuel pump shut off system (gas- If your vehicle has to be stopped oline engine emer-...
  • Page 7 Vehicle specifications Index 8-1. Specifications What if... (Troubleshoot- ing)..........742 Maintenance data (fuel, oil level, etc)........702 Alphabetical index...... 750 Fuel information ....730 8-2. Customization Customizable features ..734 8-3. Items to initialize Items to initialize ....740 For vehicles with a navigation system or a multimedia system, refer to the “Navigation and multimedia system Owner’s manual”...
  • Page 8: For Your Information

    Accessories, spare parts and modification of your Toyota Both genuine Toyota and a wide variety of other spare parts and accessories for Toyota vehicles are currently available on the market. Should it be deter-...
  • Page 9 SRS airbag system  Seat belt pretensioner system Be sure to check with any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system. Further information regarding frequency bands, power levels, antenna posi-...
  • Page 10 Scrapping of your Toyota The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be...
  • Page 11 CAUTION  General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
  • Page 12: Reading This Manual

    Reading this manual CAUTION: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
  • Page 13: How To Search

    How to search Searching by name  • Alphabetical index ..P. 750 Searching installation  position • Pictorial index ....P. 14 Searching by symptom or  sound • What to do if... (Troubleshooting) ..P. 742 Searching by title ...
  • Page 14: Pictorial Index

    Pictorial index Pictorial index  Exterior Side doors ........P. 164 Locking/unlocking .
  • Page 15 Pictorial index Windshield wipers ....... . . P. 296 Precautions against winter season ..... P. 359 To prevent freezing (windshield wiper de-icer) .
  • Page 16 Pictorial index  Instrument panel (Left-hand drive vehicles) Engine switch ....... . P. 234, 238 Starting the engine/changing the modes .
  • Page 17 Pictorial index Shift lever (with S mode)......P. 246 Changing the shift position ......P. 246 Precautions against towing .
  • Page 18 Pictorial index Turn signal lever ........P. 274 Headlight switch .
  • Page 19 Pictorial index  Switches (Left-hand drive vehicles) Outside rear view mirror switches ....P. 194 Headlight leveling dial ......P. 283 VSC OFF switch.
  • Page 20 Pictorial index Audio remote control switches ....P. 444 Paddle shift switches ......P. 253, 262 1, 2 Telephone switches .
  • Page 21 Emergency flasher switch ......P. 608 Toyota parking-assist sensor switch ....P. 321 LDA (Lane Departure Alert) switch .
  • Page 22 Pictorial index  Interior (Left-hand drive vehicles) SRS airbags ........P. 46 Floor mats .
  • Page 23 Pictorial index Inside rear view mirror ......P. 191 Sun visors ........P. 501 Vanity mirrors .
  • Page 24 Pictorial index  Instrument panel (Right-hand drive vehicles) Engine switch ....... . P. 234, 238 Starting the engine/changing the modes .
  • Page 25 Pictorial index Shift lever (with S mode)......P. 246 Changing the shift position ......P. 246 Precautions against towing .
  • Page 26 Pictorial index Turn signal lever ........P. 274 Headlight switch .
  • Page 27 Pictorial index  Switches (Right-hand drive vehicles) Outside rear view mirror switches ....P. 194 Headlight leveling dial ......P. 283 VSC OFF switch.
  • Page 28 Pictorial index Audio remote control switches ....P. 444 Paddle shift switches ......P. 253, 262 1, 2 Telephone switches .
  • Page 29 BSM (Blind Spot Monitor) main switch ....P. 346 Toyota parking-assist sensor switch ....P. 321 Emergency flasher switch .
  • Page 30 Pictorial index  Interior (Right-hand drive vehicles) SRS airbags ........P. 46 Floor mats .
  • Page 31 Pictorial index Inside rear view mirror ......P. 191 Sun visors ........P. 501 Vanity mirrors .
  • Page 32 Pictorial index RAV4_OM_OM42873E_(EE)
  • Page 33: For Safety And Security

    For safety and security 1-1. For safe use Before driving.......34 For safety drive ....36 Seat belts......38 SRS airbags......46 Airbag manual on-off system .......59 Safety information for children......62 Child restraint systems ..63 Installing child restraints ..74 Exhaust gas precautions ..86 1-2. Theft deterrent system Engine immobilizer system .......87 Double locking system..94...
  • Page 34: 1-1. For Safe Use

    1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
  • Page 35 When installing the driver’s floor mat  Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats.  Only use floor mats designed for the driver’s seat. ...
  • Page 36: For Safety Drive

    1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
  • Page 37: Adjusting The Mirrors

    1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 191, 194) CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. Do not adjust the position of the driver’s seat while driving.
  • Page 38: Seat Belts

    1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts  Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
  • Page 39 1-1. For safe use Fastening the seat belt (for the rear center seat) Press the plate to release, and then pull the seat belt. Push the plate into the buckle in Plate “B” Plate “A” the order of plate “A” and plate “B”...
  • Page 40 1-1. For safe use Releasing and stowing the seat belt (for the rear center seat) To release the hooked buckle “B”, push the buckle release button. Release button To release the hooked plate “A”, insert the mechanical key (P. 122) or plate “B” or the wireless key into the hole on the buckle.
  • Page 41 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
  • Page 42  Seat belt regulations If seat belt regulations exist in the country where you reside, please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for seat belt replacement or installation. RAV4_OM_OM42873E_(EE)
  • Page 43  for more than one person at once, including children.  Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.  To achieve a proper seating position, do not recline the seat more than necessary.
  • Page 44 If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 45 Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. ...
  • Page 46: Srs Airbags

    1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. RAV4_OM_OM42873E_(EE)
  • Page 47 1-1. For safe use  SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas- senger from impact with interior components SRS driver knee airbag Can help provide driver protection ...
  • Page 48 1-1. For safe use SRS airbag system components Side impact sensors (front Side impact sensors (rear) doors) Seat belt pretensioners and Front passenger airbag force limiters Curtain shield airbags Driver’s seat position sensor Side airbags Driver’s seat belt buckle switch “PASSENGER AIR BAG”...
  • Page 49 1-1. For safe use The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occu- pants.
  • Page 50 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
  • Page 51 1-1. For safe use CAUTION  SRS airbag precautions Do not lean against the door, the roof  side rail or the front, side and rear pil- lars.  Do not allow anyone to kneel on the passenger seat toward the door or put their head or hands outside the vehicle.
  • Page 52 1-1. For safe use CAUTION  SRS airbag precautions Do not attach anything to areas such as  a door, windshield glass, side door glass, front or rear pillar, roof side rail and assist grip. (Except for the speed limit label P. 670) ...
  • Page 53 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 54 1-1. For safe use If the SRS airbags deploy (inflate)   Bruising and slight abrasions may result from contact with a deploying (inflating) SRS airbag. A loud noise and white powder will be emitted.   Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the front seats, parts of the front and rear pillars, and roof side rails may be hot for several minutes.
  • Page 55 1-1. For safe use  Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
  • Page 56 1-1. For safe use  Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
  • Page 57 In the following cases, the vehicle will require inspection and/or repair. Con- tact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. Any of the SRS airbags have been inflated.
  • Page 58 1-1. For safe use  The surface of the seats with the side airbag is scratched, cracked, or other- wise damaged.  The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked, or other- wise damaged.
  • Page 59: Airbag Manual On-Off System

    1-1. For safe use Airbag manual on-off system This system deactivates the front passenger airbag. Only deactivate the airbags when using a child restraint system on the front passenger seat. “PASSENGER AIR BAG” indi- cator Vehicles without a smart entry & start system: The ON indicator light turns on when the airbag system is on (only...
  • Page 60 “PASSENGER AIR BAG” indicator information If any of the following problems occur, it is possible that there is a malfunction in the system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 61 1-1. For safe use CAUTION  When installing a child restraint system For safety reasons, always install a child restraint system in a rear seat. In the event that the rear seat cannot be used, the front seat can be used as long as the airbag manual on-off system is set to “OFF”.
  • Page 62: Safety Information For Children

    1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
  • Page 63: Child Restraint Systems

    Toyota dealer or repairer, or another duly qualified and equipped professional for the child restraint system installation.  Toyota recommends that you use a child restraint system which conforms to the regulation ECE No.44. RAV4_OM_OM42873E_(EE)
  • Page 64 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 5 groups according to the regulation ECE No.44: Group 0: Up to 10 kg (22 lb.) (0 - 9 months) Group 0 : Up to 13 kg (28 lb.) (0 - 2 years) Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years) Group II:...
  • Page 65 1-1. For safe use Child restraint system suitability for various seating positions Information provided in the table shows your child restraint system suitability for various seating positions. Seating Front passenger seat position Rear seat Airbag manual on-off switch Outboard Center Mass groups 2, 3 Up to 10 kg...
  • Page 66 L2: Suitable for “Maxi Cosi Cabriofix plus Easybase2” (0 to 13 kg [0 to 28 lb.]) approved for the use in this mass group. L3: Suitable for “TOYOTA KIDFIX” (15 to 36 kg [34 to 79 lb.]) approved for the use in this mass group. Please fix by using both ISOFIX and seat belt.
  • Page 67 1-1. For safe use : Adjust the front seatback to the 4th lock position from the most upright position. Move the front seat cushion to the fully rearward. Remove the head restraint if it interferes with your child restraint system. Please follow these procedures: •...
  • Page 68 Size class Fixture child restraint Rear outboard systems seat ISO/L1 — Carrycot ISO/L2 — — “TOYOTA MINI”, ISO/R1 Up to 10 kg “TOYOTA MIDI” (22 lb.) — (0 - 9 months) ISO/R1 “TOYOTA MINI”, ISO/R2 Up to 13 kg “TOYOTA MIDI”...
  • Page 69 1-1. For safe use (1) For the CRS which do not carry the ISO/XX size class identifica- tion (A to G), for the applicable mass group, the car manufacturer shall indicate the vehicle specific ISOFIX child restraint system(s) recommended for each position. Key of letters inserted in the above table: IUF: Suitable for ISOFIX forward-facing child restraints systems of universal category approved for the use in the mass group.
  • Page 70 1-1. For safe use When using a “TOYOTA MINI” or “TOYOTA MIDI”, adjust the seat- back to the 8th lock position from the fully reclined position, adjust the support leg and ISOFIX connectors as follows: Lock the support leg where 7th hole can be seen.
  • Page 71 1-1. For safe use When installing a child restraint system on the front passenger seat  When you have to use a child restraint system on the front passenger seat, adjust the following: The seat cushion to the fully rearward ...
  • Page 72  Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 73 1-1. For safe use CAUTION  Child restraint precautions Do not allow the child to lean his/her head or any part of his/her body  against the door or the area of the seat, front and rear pillars or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system.
  • Page 74: Installing Child Restraints

    1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt or ISOFIX rigid anchors. Attach the top strap when installing a child restraint. Seat belts (An ELR belt requires a locking clip) ISOFIX rigid anchors (ISOFIX child restraint system)
  • Page 75 1-1. For safe use Installing child restraints using a seat belt Rear-facing  Baby seat (infant seat)/child seat (convertible  seat) Adjust the seatback to the 8th lock position from the fully reclined position. (P. 183) Fully reclined position 8th lock position If your child restraint system interferes with a head restraint and cannot be installed properly, install the child restraint system after removing the head restraint.
  • Page 76 1-1. For safe use Install a locking clip near the tab of the lap and shoulder belt by inserting the lap and shoulder webbing through the recesses of the locking clip. Buckle the belt again. If the belt has any slack, release the buckle and rein- stall the locking clip.
  • Page 77 1-1. For safe use Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Install a locking clip near the tab of the lap and shoulder belt by inserting the lap and shoulder webbing through the recesses of the locking...
  • Page 78 1-1. For safe use Junior seat (booster seat)  Adjust the seatback to the 8th lock position from the fully reclined position. (P. 183) Fully reclined position 8th lock position If your child restraint system interferes with a head restraint and cannot be installed properly, install the child restraint system after removing the head restraint.
  • Page 79 1-1. For safe use Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the buckle. Make sure that the belt is not twisted. Check that the shoulder belt is correctly positioned over the child’s shoulder and that the lap...
  • Page 80 1-1. For safe use Installation with ISOFIX rigid anchor Adjust the seatback to the 8th lock position from the fully reclined position. (P. 183) Fully reclined position 8th lock position For a rear-facing child restraint system with ISOFIX attached to shell, if latching is difficult, adjust the seatback by reclining the seat- back.
  • Page 81 1-1. For safe use Child restraint systems with a top strap Remove the head restraint. Secure the child restraint sys- tem using the seat belt or ISO- FIX rigid anchors. Latch the hook onto the anchor bracket and tighten the top strap.
  • Page 82 If your child restraint sys- tem does not provide a locking clip, you can purchase the following item from any authorized Toyota dealer or repairer, or another duly qualified and equipped professional: Locking clip for child restraint system (Part No.
  • Page 83 1-1. For safe use CAUTION  When installing a child restraint system Never use a rear-facing child restraint  system on the front passenger seat when the airbag manual on-off switch is on. (P. 59) The force of the rapid inflation of the front passenger airbag can cause death or serious injury to children in the event of an accident.
  • Page 84 When installing a child restraint system If child restraint system regulations exist in the country where you reside,  please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for the child restraint system installa- tion.
  • Page 85 1-1. For safe use CAUTION  When installing a child restraint system When using the left side seat for the  child restraint system, do not sit in the center seat. Seat belt function may be impaired, such as being positioned overly high or loose-fitting, which may result in death or serious injury in the event of sudden braking or an accident.
  • Page 86: Exhaust Gas Precautions

    If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional as soon as possible.
  • Page 87: Theft Deterrent System

    1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
  • Page 88 1-2. Theft deterrent system  Certifications for the engine immobilizer system RAV4_OM_OM42873E_(EE)
  • Page 89 1-2. Theft deterrent system The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/ RAV4_OM_OM42873E_(EE)
  • Page 90 1-2. Theft deterrent system RAV4_OM_OM42873E_(EE)
  • Page 91 1-2. Theft deterrent system RAV4_OM_OM42873E_(EE)
  • Page 92 1-2. Theft deterrent system RAV4_OM_OM42873E_(EE)
  • Page 93 1-2. Theft deterrent system NOTICE  To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed. RAV4_OM_OM42873E_(EE)
  • Page 94: Double Locking System

    1-2. Theft deterrent system  Double locking system Unauthorized access to the vehicle is prevented by disabling the door unlocking function from both the interior and exterior of the vehicle. Vehicles employing this system have labels on the window glass of both front doors.
  • Page 95: Alarm

    1-2. Theft deterrent system  Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set:  A locked door is unlocked or opened in any way other than using the entry function (vehicles with a smart entry &...
  • Page 96 1-2. Theft deterrent system Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarms:  Unlock the doors using the entry function (vehicles with a smart entry & start system) or wireless remote control. ...
  • Page 97 1-2. Theft deterrent system  The battery is recharged or replaced when the vehicle is locked. (P. 692)  Alarm-operated door lock When the alarm is operating, the doors are locked automatically to prevent  intruders.  Do not leave the key inside the vehicle when the alarm is operating, and make sure the key is not inside the vehicle when recharging or replacing the battery.
  • Page 98: Intrusion Sensor And Tilt Sensor

    1-2. Theft deterrent system Intrusion sensor and tilt sensor  The intrusion sensor detects intruders or movement in the vehicle.  The tilt sensor detects changes in vehicle inclination, such as when the vehicle is towed away. (if equipped) This system is designed to deter and prevent vehicle theft but does not guarantee absolute security against all intrusions.
  • Page 99 1-2. Theft deterrent system Canceling and automatic re-enabling of the intrusion sensor and tilt sen-   The alarm will still be set even when the intrusion sensor and tilt sensor are canceled.  Vehicles without a smart entry & start system: After the intrusion sensor and tilt sensor are canceled, turning the engine switch to the “ON”...
  • Page 100  Do not spray air fresheners or other products directly into the sensor holes.  Installing accessories other than genuine Toyota parts or leaving objects between the driver’s seat and front passenger’s seat may reduce the detection performance. RAV4_OM_OM42873E_(EE)
  • Page 101 Instrument cluster Instrument cluster Warning lights and indicators ....102 Gauges and meters ...108 Multi-information display ..109 Fuel consumption information.......118 RAV4_OM_OM42873E_(EE)
  • Page 102: Instrument Cluster

    2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
  • Page 103: Instrument Cluster

    2. Instrument cluster  Outside rear view mirrors (vehicles with BSM) Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. 1, 2 Master warning light Stop & Start cancel (P. 629) indicator (P. 622) (if equipped) Brake system warning Slip indicator (P.
  • Page 104 Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. : The light flashes to indicate a malfunction. : The light comes on to indicate that Toyota parking assist-sensor is dirty or covered with ice. Indicators The indicators inform the driver of the operating state of the vehicle’s...
  • Page 105 (if equipped) Engine preheating “AUTO LSD” indicator indicator (P. 234, 238) (P. 337) (if equipped) (if equipped) Downhill assist control Toyota parking system indicator assist-sensor indicator (P. 343) (P. 321) (if equipped) (if equipped) Security indicator LDA indicator (P. 313) (P.
  • Page 106 They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if the lights do not come on, or turn off. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 107 Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately if this occurs.
  • Page 108: Gauges And Meters

    2. Instrument cluster Gauges and meters The units used on the speedometer may differ depending on the target region. Tachometer Displays the engine speed in revolutions per minute Speedometer Displays the vehicle speed Fuel gauge Displays the quantity of fuel remaining in the tank Shift position and shift range (vehicles with an automatic transmis- sion or a Multidrive) Displays the selected shift position or selected shift range...
  • Page 109: Multi-Information Display

    2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of driv- ing-related data including the current outside air temperature.  Outside temperature display (P. 111)  Engine coolant temperature gauge Displays the engine coolant tem- perature.
  • Page 110 2. Instrument cluster Odometer and trip meters Switching the display  Items displayed switched by pressing the odom- eter/trip meter display change button. Odometer  Displays the total distance the vehicle has been driven. Trip meters “A” and “B”  Displays the distance the vehicle has been driven since the meter was last reset.
  • Page 111 2. Instrument cluster Trip information Switching the display  Items displayed switched pressing “DISP” button. Outside temperature  Displays the outside air temperature. The temperature range that can be displayed is from -40C (-40F) to 50C (122F) Current fuel consumption ...
  • Page 112 2. Instrument cluster Driving range  Displays the estimated approximate distance that can be driven with the quantity of fuel remaining. • This distance is computed based on your aver- age fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.
  • Page 113 2. Instrument cluster Stop & Start system operation time (if equipped)  Vehicles without a smart entry & start sys-  tem. The total idling stop time from when the engine switch is turned on to when it is turned to lock (when the engine is stopped by the Stop &...
  • Page 114 2. Instrument cluster Setting up the displays While the vehicle is stopped, press the “DISP” button until “SETTINGS” screen appears. Press and hold the “DISP” but- ton until the screen changes. Press and hold the “DISP” but- ton after selecting the desired setting item by pressing the “DISP”...
  • Page 115 2. Instrument cluster Press and hold the “DISP” but- ton after selecting the desired setting by pressing the “DISP” button. The display goes back to step Press and hold the “DISP” but- ton after selecting the “BACK” by pressing the “DISP” button. The display goes back to step (The display goes back to step automatically in few seconds with-...
  • Page 116 When “---C” is displayed  The system may be malfunctioning. Take your vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  Setting display automatic cancelation In the following situations, setting display in which the settings can be changed through the “DISP”...
  • Page 117 2. Instrument cluster CAUTION  Cautions during setting up the display As the engine needs to be operating during setting up the display, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
  • Page 118: Fuel Consumption Information

    2. Instrument cluster  Fuel consumption information The fuel consumption information can be displayed on the navi- gation system or multimedia system screen. Display the trip information or past record screen Press the “CAR” button, and then select “Trip information” or “Past record”...
  • Page 119 2. Instrument cluster Past record  If the “Past record” screen does not appear, select “Past record”. Best recorded fuel consump- tion Previous fuel consumption record Current fuel consumption Reset the past record data Update the past record data “Trip information”...
  • Page 120 2. Instrument cluster RAV4_OM_OM42873E_(EE)
  • Page 121: Operation Of Each Compo- Nent

    Operation of each component 3-1. Key information Keys........122 3-2. Opening, closing and locking the doors Smart entry & start system ......126 Wireless remote control ..149 Side doors......164 Back door......168 3-3. Adjusting the seats Front seats......181 Rear seats ......183 Head restraints ....187 3-4.
  • Page 122: 3-1. Key Information

    3-1. Key information Keys The keys The following keys are provided with the vehicle. Vehicles without a smart entry & start system (type A)  Master keys Operating the wireless remote con- trol function (P. 149) Valet key Key number plate Vehicles without a smart entry &...
  • Page 123: System

    3-1. Key information Using the mechanical key (vehicles with a smart entry & start system) To take out the mechanical key, push the release button and take the key out. The mechanical key can only be inserted in one direction, as the key only has grooves on one side.
  • Page 124  If you lose your keys New genuine keys can be made by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional using a master key (vehi- cles without a smart entry & start system) or the other key (vehicles with a smart entry &...
  • Page 125 If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional immediately with all remaining electronic keys that was provided with your vehicle.
  • Page 126 3-2. Opening, closing and locking the doors  Smart entry & start system Function summary The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the side doors (P.
  • Page 127 3-2. Opening, closing and locking the doors Unlocking and locking the doors Front doors  Grip the door handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The doors cannot be unlocked for 3 seconds after the doors are locked.
  • Page 128: The Doors

    3-2. Opening, closing and locking the doors Back door  Press the unlock button to unlock all the doors. The doors cannot be unlocked for 3 seconds after the doors are locked. Press the lock button to lock all the doors. RAV4_OM_OM42873E_(EE)
  • Page 129 3-2. Opening, closing and locking the doors Antenna location and effective range Antenna location  Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage compartment RAV4_OM_OM42873E_(EE)
  • Page 130 3-2. Opening, closing and locking the doors Effective range (areas within which the electronic key is  detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of either of the outside front door handles and back door opener switch.
  • Page 131 3-2. Opening, closing and locking the doors  Alarms and warning indicators A combination of exterior and interior alarms as well as warning messages shown on the multi-information display are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate mea- sures in response to any warning message on the multi-information display.
  • Page 132: Smart Entry & Start Sys

    3-2. Opening, closing and locking the doors  Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the vehicle battery from being discharged while the vehicle is not in operation for a long time. ...
  • Page 133 3-2. Opening, closing and locking the doors  Conditions affecting operation The smart entry & start system uses weak radio waves. In the following situa- tions, the communication between the electronic key and the vehicle may be affected, preventing the smart entry & start system, wireless remote control and engine immobilizer system from operating properly.
  • Page 134 3-2. Opening, closing and locking the doors  Note for the entry function  Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
  • Page 135 3-2. Opening, closing and locking the doors  Note for locking the doors  Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again.  When the lock operation is performed using the lock sensor, recognition sig- nals will be shown up to two consecutive times.
  • Page 136 3-2. Opening, closing and locking the doors  When the vehicle is not driven for extended periods  To prevent theft of the vehicle, do not leave the electronic key within 2 m (6 ft.) of the vehicle.  The smart entry & start system can be deactivated in advance. (P. 734) ...
  • Page 137 3-2. Opening, closing and locking the doors  Electronic key battery depletion  The standard battery life is 1 to 2 years.  If the battery becomes low, an alarm will sound in the cabin when the engine stops. (P. 643) ...
  • Page 138 3-2. Opening, closing and locking the doors  Certifications for the smart entry & start system RAV4_OM_OM42873E_(EE)
  • Page 139 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 140 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 141 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 142 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 143 3-2. Opening, closing and locking the doors The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/ RAV4_OM_OM42873E_(EE)
  • Page 144 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 145 3-2. Opening, closing and locking the doors The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/ RAV4_OM_OM42873E_(EE)
  • Page 146 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 147 3-2. Opening, closing and locking the doors The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/ RAV4_OM_OM42873E_(EE)
  • Page 148 (P. 129) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for details, such as the frequency of radio waves and timing of the emitted radio waves.
  • Page 149: Wireless Remote Control

    3-2. Opening, closing and locking the doors Wireless remote control Function summary The wireless remote control can be used to lock and unlock the vehi- cle. It also opens and closes the back door. Vehicles without a smart entry & start system ...
  • Page 150 3-2. Opening, closing and locking the doors Operation signals  Doors: The emergency flashers flash to indicate that the doors have been locked/ unlocked. (Locked: once; Unlocked: twice) Power back door (if equipped): A buzzer sounds and the emergency flashers flash twice to indicate that the back door is opening/closing.
  • Page 151 P. 571  Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for details.  Customization Settings (e.g. wireless remote control system) can be changed.
  • Page 152 3-2. Opening, closing and locking the doors  Certification for wireless remote control (vehicles without a smart entry & start system) RAV4_OM_OM42873E_(EE)
  • Page 153 3-2. Opening, closing and locking the doors The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing address: http://www.globaldenso.com/en/products/oem/index.html RAV4_OM_OM42873E_(EE)
  • Page 154 3-2. Opening, closing and locking the doors  Certification for wireless remote control (vehicles with a smart entry & start system) RAV4_OM_OM42873E_(EE)
  • Page 155 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 156 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 157 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 158 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 159 3-2. Opening, closing and locking the doors The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/ RAV4_OM_OM42873E_(EE)
  • Page 160 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 161 3-2. Opening, closing and locking the doors The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/ RAV4_OM_OM42873E_(EE)
  • Page 162 3-2. Opening, closing and locking the doors RAV4_OM_OM42873E_(EE)
  • Page 163 3-2. Opening, closing and locking the doors The DECLARATION of CONFORMITY (DoC) is available at the following address: http://www.tokai-rika.co.jp/pc/ RAV4_OM_OM42873E_(EE)
  • Page 164: Side Doors

    3-2. Opening, closing and locking the doors Side doors Unlocking and locking the doors The vehicle can be locked and unlocked using the key, entry function, wireless remote control or door lock switch.  Entry function (if equipped) P. 126 ...
  • Page 165 3-2. Opening, closing and locking the doors  Door lock switch Locks all the doors Unlocks all the doors  Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock button is in the lock position.
  • Page 166 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door while pulling the door handle. Vehicles without a smart entry & start system ...
  • Page 167 3-2. Opening, closing and locking the doors When all the doors are locked with the entry function (vehicles with a  smart entry & start system), wireless remote control or key The doors cannot be unlocked with the door lock switch. The door lock switch can be reset by unlocking all the doors with the entry function (vehicles with a smart entry &...
  • Page 168: Back Door

    3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened/closed by the following procedures. Locking and unlocking the back door Door lock switch  P. 165 Entry function (if equipped)  P. 128 Wireless remote control ...
  • Page 169 3-2. Opening, closing and locking the doors Opening the back door from outside the vehicle Back door opener  Vehicles without a power  back door Raise the back door while pressing up the back door opener switch. Vehicles with a power back ...
  • Page 170 3-2. Opening, closing and locking the doors Power back door switch (vehicles with a power back door) Pressing the switch closes the back door automatically. buzzer sounds.) Pressing the switch while the back door is opening/closing stops the operation. Pressing the switch again will reverse the operation.
  • Page 171 3-2. Opening, closing and locking the doors Canceling the power back door system (vehicles with a power back door) Turn the main switch in the glove box off to disable the power back door system. Inoperative Operative Adjusting the open position of the back door (vehicles with a power back door) The open position of the power back door can be adjusted.
  • Page 172 3-2. Opening, closing and locking the doors Luggage compartment light  The luggage compartment light turns on when the back door is opened with the luggage compartment light switch on.  If the back door opener is inoperative The back door can be unlocked from the inside. Remove the cover on the back door trim.
  • Page 173 3-2. Opening, closing and locking the doors  Jam protection function (vehicles with a power back door) If anything obstructs the power back door while it is closing/opening, the back door will automatically operate in the opposite direction or stop. ...
  • Page 174 3-2. Opening, closing and locking the doors CAUTION Observe the following precautions. Failure to do so may result in death or serious injury.  Before driving  Make sure that the back door is fully closed. If the back door is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the luggage compartment may be thrown out, causing an acci- dent.
  • Page 175 3-2. Opening, closing and locking the doors CAUTION  Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury.  Remove any heavy loads, such as snow and ice, from the back door before opening it.
  • Page 176 When installing an accessory part to the back door, using a genu- ine Toyota part is recommended.  Back door closer (vehicles with a power back door) ...
  • Page 177 When installing an accessory part to the back door, ask your Toyota dealer for details. RAV4_OM_OM42873E_(EE)
  • Page 178 3-2. Opening, closing and locking the doors CAUTION  Jam protection function (vehicles with a power back door) Observe the following precautions. Failure to do so may cause death or serious injury.  Never use any part of your body to intentionally activate the jam protection function.
  • Page 179 Do not touch the damper stay rod with gloves or other fabric items.  Do not attach any accessories other Damper stays than genuine Toyota parts to the back door.  Do not place your hand on the damper stay or apply lateral forces to it. ...
  • Page 180 3-2. Opening, closing and locking the doors NOTICE  To prevent back door closer malfunction (vehicles with a power back door) Do not apply excessive force to the back door while the back door closer is operating.  To prevent damage to the power back door (if equipped) ...
  • Page 181: Adjusting The Seats

    3-3. Adjusting the seats Front seats Adjustment procedure Manual seat  Seat position adjustment lever Vertical height adjustment lever (driver’s side only) Seatback angle adjustment lever Power seat (driver’s side only)  Seat position adjustment switch Vertical height adjustment switch Seatback angle adjustment...
  • Page 182 3-3. Adjusting the seats CAUTION  When adjusting the seat position Take care when adjusting the seat position to ensure that other passen-  gers are not injured by the moving seat.  Do not put your hands under the seat or near the moving parts to avoid injury.
  • Page 183: Rear Seats

    3-3. Adjusting the seats Rear seats Adjustment procedure Pull up the lever. Then lean back to the desired angle and release the lever. When a person sits in the rear center position, align all seatbacks at the same angle. RAV4_OM_OM42873E_(EE)
  • Page 184 3-3. Adjusting the seats Folding down the rear seatbacks Before folding down the rear seatbacks  Stow the rear center seat belt. (P. 40) Stow the rear seat belt buck- les. Lower the head restraint to the lowest position. (P. 187) Folding down rear seatbacks ...
  • Page 185 3-3. Adjusting the seats CAUTION  When folding the rear seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury.  Do not fold the seatbacks down while driving.  Stop the vehicle on level ground, set the parking brake and shift the shift lever to P (automatic transmission or Multidrive) or N (manual transmis- sion).
  • Page 186 3-3. Adjusting the seats CAUTION  After returning the rear seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury.  Make sure the seatback is securely locked by pushing it forward and rear- ward on the top.
  • Page 187: Head Restraints

    3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button.
  • Page 188 3-3. Adjusting the seats Removing the head restraints  Front seats  Pull the head restraint up while pressing the lock release button. Lock release button Rear seats  Pull the head restraint up while pressing the lock release button. Lock release button ...
  • Page 189 3-3. Adjusting the seats Rear seats  Align the head restraint with the installa- tion holes and push it down while press- ing the lock release button. Lock release button  Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
  • Page 190: Adjusting The Steering Wheel

    3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and press the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.
  • Page 191: Inside Rear View Mirror

    3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
  • Page 192 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror  Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode On/off When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
  • Page 193 3-4. Adjusting the steering wheel and mirrors To prevent sensor error (vehicles with an auto anti-glare inside rear view  mirror) To ensure that the sensors operate prop- erly, do not touch or cover them. CAUTION Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.
  • Page 194: Outside Rear View Mirrors

    3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left RAV4_OM_OM42873E_(EE)
  • Page 195 3-4. Adjusting the steering wheel and mirrors Folding the mirrors Power type  Press the switch to fold the mir- rors. Press it again to extend them to the original position. Manual type  Push the mirror back in the direc- tion of the vehicle’s rear.
  • Page 196 3-4. Adjusting the steering wheel and mirrors Mirror angle can be adjusted when  Vehicles without a smart entry & start system  The engine switch is in the “ACC” or “ON” position. Vehicles with a smart entry & start system ...
  • Page 197 3-4. Adjusting the steering wheel and mirrors CAUTION  Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ...
  • Page 198: Power Windows

    3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing (driver’s win- dow only) Opening One-touch opening...
  • Page 199 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional. RAV4_OM_OM42873E_(EE)
  • Page 200 3-5. Opening, closing the windows and moon roof CAUTION Observe the following precautions. Failure to do so may result in death or serious injury.  Closing the windows  Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
  • Page 201: Moon Roof

    3-5. Opening, closing the windows and moon roof  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
  • Page 202 3-5. Opening, closing the windows and moon roof The moon roof can be operated when  Vehicles without a smart entry & start system  The engine switch is in the “ON” position. Vehicles with a smart entry & start system ...
  • Page 203 3-5. Opening, closing the windows and moon roof  Moon roof open reminder function Vehicles without a smart entry & start system  A buzzer sounds and a message is shown on the multi-information display when the engine switch is turned to the “LOCK” position and the driver’s door is opened with the moon roof open.
  • Page 204 3-5. Opening, closing the windows and moon roof CAUTION Observe the following precautions. Failure to do so may cause death or serious injury.  Opening the moon roof  Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
  • Page 205: Driving

    (with M mode)....253 Cruise control.....309 Multidrive ......262 LDA (Lane Manual transmission..270 Departure Alert) ....313 Turn signal lever ....274 Toyota parking assist-sensor ....321 Parking brake ....276 All-wheel drive lock Horn........277 switch (AWD models) ..327 DPF (Diesel Particulate Stop & Start system ...328...
  • Page 206: 4-1. Before Driving

    4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 234, 238 Driving Automatic transmission or Multidrive  With the brake pedal depressed, shift the shift lever to D. (P. 246, 262, 253) Release the parking brake.
  • Page 207 4-1. Before driving Parking the vehicle Automatic transmission or Multidrive  With the shift lever in D, depress the brake pedal. Shift the shift lever to P. (P. 246, 262, 253) Set the parking brake. (P. 276) Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK”...
  • Page 208 4-1. Before driving Starting off on a steep uphill Automatic transmission or Multidrive  Make sure that the parking brake is set and shift the shift lever to D. Gently depress the accelerator pedal. Release the parking brake. Manual transmission ...
  • Page 209 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have any authorized Toyota dealer or repairer, or another duly qualified and equipped professional per- form the bedding down operation.
  • Page 210 (P. 114) Eco Driving Indicator Zone Display Eco Driving Indicator Zone Display availability can be customized at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. The default setting is off. Zone of Eco driving...
  • Page 211 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury.  When starting the vehicle On vehicles with an automatic transmission or a Multidrive, always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping.
  • Page 212 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury.  When driving the vehicle  During normal driving, do not turn off the engine. Turning the engine off while driving will not cause loss of steering or braking control, but the power assist to these systems will be lost.
  • Page 213 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury.  When driving on slippery road surfaces  Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ...
  • Page 214 4-1. Before driving CAUTION  When shifting the shift lever On vehicles with an automatic transmission or a Multidrive, do not let the  vehicle roll backward while the shift lever is in a driving position, or roll for- ward while the shift lever is in R. Doing so may cause the engine to stall or lead to poor brake and steering performance, resulting in an accident or damage to the vehicle.
  • Page 215 As a result, the discs may wear more quickly than conventional brake discs. Therefore, when replacing the brake pads, Toyota recommends that you also have the thickness of the discs mea- sured. It is dangerous to drive the vehicle when the wear limits of the brake pads and/or those of the brake discs are exceeded.
  • Page 216 4-1. Before driving CAUTION  When the vehicle is parked Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in  the vehicle when it is in the sun. Doing so may result in the following: • Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
  • Page 217 4-1. Before driving CAUTION  When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
  • Page 218 4-1. Before driving NOTICE  When driving the vehicle Do not depress the accelerator and brake pedals at the same time during  driving, as this may restrain driving torque. Automatic transmission or Multidrive   Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
  • Page 219 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional check the following: ...
  • Page 220: Cargo And Luggage

    4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. CAUTION  Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compartment: ...
  • Page 221 4-1. Before driving CAUTION  Load and distribution Do not overload your vehicle.   Do not apply loads unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.  When loading cargo on the roof luggage carrier (if equipped) Observe the following precautions: ...
  • Page 222: Trailer Towing

    Kazakhstan, Macedonia, Montenegro, Serbia, Tajikistan and Turkmenistan Toyota does not recommend towing a trailer with your vehi- cle. Toyota also does not recom- mend the installation of a tow hitch or the use of a tow hitch carrier wheelchair, scooter, bicycle, etc. Your...
  • Page 223 Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Ask your local authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further details before towing, as there are additional legal requirements in some countries.
  • Page 224 4-1. Before driving Connecting trailer lights Please consult at any authorized dealer or repairer, or another duly qualified and equipped professional when installing trailer lights, as incorrect installation may cause damage to the vehicle’s lights. Please take care to comply with your state’s laws when installing trailer lights. Important points regarding trailer loads Total trailer weight and permissible drawbar load ...
  • Page 225 4-1. Before driving Information tag (manufacturer’s label)  Gross vehicle mass The combined weight of the driver, passengers, luggage, towing hitch, total curb mass and drawbar load should not exceed the gross vehicle mass by more than 100 kg (220.5 lb.). Exceeding this weight is danger- ous.
  • Page 226 4-1. Before driving Installation positions for the towing hitch/bracket and hitch ball RAV4_OM_OM42873E_(EE)
  • Page 227 4-1. Before driving RAV4_OM_OM42873E_(EE)
  • Page 228 4-1. Before driving 546 mm (21.5 in.) 453 mm (17.8 in.) 550 mm (21.7 in.) 432 mm (17.0 in.) 551 mm (21.7 in.) 320 mm (12.6 in.) 583 mm (23.0 in.) 315 mm (12.4 in.) 602 mm (23.7 in.) 113 mm (4.4 in.) 609 mm (24.0 in.) 112 mm (4.4 in.) 713 mm (28.1 in.)
  • Page 229  Break-in schedule Toyota recommends that vehicles fitted with new power train components should not be used for towing trailers for the first 800 km (500 miles).  Safety checks before towing ...
  • Page 230 4-1. Before driving NOTICE  When the rear bumper strengthening material is aluminum Ensure the steel bracket part does not come directly in contact with that area. When steel and aluminum come into contact, there is a reaction similar to corrosion, which will weaken the section concerned and may result in dam- age.
  • Page 231 4-1. Before driving Sudden acceleration/steering input/cornering  Executing sharp turns when towing may result in the trailer colliding with your vehicle. Decelerate well in advance when approaching turns and take them slowly and carefully to avoid sudden braking. Important points regarding turning ...
  • Page 232 4-1. Before driving Transmission information  Vehicles with an automatic transmission (with S mode)  To maintain engine braking efficiency, when using engine braking, do not use the transmission in D. If in the S mode, the transmission shift range position must be in 4 or lower. (P. 249) Vehicles with an automatic transmission (with M mode) ...
  • Page 233 4-1. Before driving CAUTION Follow all the instructions described in this section. Failure to do so could cause an accident resulting in death or serious injury.  Trailer towing precautions When towing, make sure that none of the weight limits are exceeded. (P.
  • Page 234: Engine (Ignition) Switch

    4-2. Driving procedures Engine (ignition) switch (vehicles without a smart entry & start system) Starting the engine Automatic transmission or Multidrive (gasoline engine)  Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal.
  • Page 235 4-2. Driving procedures Changing the engine switch positions “LOCK” The steering wheel is locked and the key can be removed. (Vehicles with an automatic transmission or a Multidrive: The key can be removed only when the shift lever is in P.) “ACC”...
  • Page 236 If the engine does not start  The engine immobilizer system may not have been deactivated. (P. 87) Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  When the steering lock cannot be released When starting the engine, the engine switch may seem stuck in the “LOCK”...
  • Page 237  Do not race a cold engine.  If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. RAV4_OM_OM42873E_(EE)
  • Page 238: Engine (Ignition) Switch

    4-2. Driving procedures Engine (ignition) switch (vehicles with a smart entry & start system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Vehicles with an automatic transmission or a Multidrive: Check that the shift lever is set in P.
  • Page 239 4-2. Driving procedures Press the engine switch. The engine will crank until it starts or for up to 30 seconds, whichever is less. Continue depressing the brake pedal until the engine is completely started. Diesel engine only: the indi- cator turns on. The engine will start after the indicator light goes out.
  • Page 240 4-2. Driving procedures Changing engine switch modes Modes can be changed by pressing the engine switch with the brake pedal released. (The mode changes each time the switch is pressed.) Off* The emergency flashers can be used. The multi-information display will not be displayed.
  • Page 241 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P (vehicles with an automatic transmission or a Multidrive only) If the engine is stopped with the shift lever in a position other than P, the engine switch will not be turned off but instead be turned to ACCESSORY mode.
  • Page 242 If the engine does not start  The engine immobilizer system may not have been deactivated. (P. 87) Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  The steering lock may not have been canceled.
  • Page 243 When “CHECK SMART ENTRY & START SYSTEM” is displayed on the multi-information display The system may be malfunctioning. Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped profes- sional immediately. ...
  • Page 244 4-2. Driving procedures  Operation of the engine switch When operating the engine switch, one short, firm press is enough. If the switch is pressed improperly, the engine may not start or the engine switch mode may not change. It is not necessary to press and hold the switch. ...
  • Page 245 Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. RAV4_OM_OM42873E_(EE)
  • Page 246: Automatic Transmission(With S Mode)

    4-2. Driving procedures  Automatic transmission (with S mode) Shifting the shift lever Vehicles without a smart entry & start system  While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
  • Page 247 4-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the engine Reversing Neutral Normal driving S mode driving (P. 249) : Shifting the shift lever to D allows the system to select a gear suitable for the driving conditions.
  • Page 248 4-2. Driving procedures Selecting the driving mode The following modes can be selected to suit driving conditions. Eco drive mode  Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. Press the “ECO MODE” button to select Eco drive mode.
  • Page 249 4-2. Driving procedures Selecting shift ranges in the S position To enter S mode, shift the shift lever to S. Shift ranges can be selected by operating the shift lever, allowing you to drive in the shift range of your choosing. The shift range can be selected by the shift lever. Upshifting Downshifting The selected shift range, from 1 to...
  • Page 250 4-2. Driving procedures S mode   When the shift range is 4 or lower, holding the shift lever toward “+” sets the shift range to 6. To prevent the engine from over-revving, upshifting may automatically  occur.  To protect the automatic transmission, a higher shift range may automati- cally selected when the fluid temperature is high.
  • Page 251 S This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
  • Page 252 4-2. Driving procedures  AI-SHIFT The AI-SHIFT automatically selects the suitable gear according to driver per- formance and driving conditions. The AI-SHIFT automatically operates when the shift lever is in D. (Shifting the shift lever to S cancels the function.) CAUTION ...
  • Page 253: Automatic Transmission (With M Mode)

    4-2. Driving procedures  Automatic transmission (with M mode) Shifting the shift lever Vehicles without a smart entry & start system  While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
  • Page 254 4-2. Driving procedures Shift position purpose Shift position Meter display Purpose/function Parking the vehicle/starting the engine Reversing Neutral Normal “D” position driving Gears between 1 and 6 are automati- cally selected according to driving con- ditions Gear selection (P. 256) Allows suitable use of engine braking (paddle shift switches...
  • Page 255 4-2. Driving procedures Selecting the driving mode The following modes can be selected to suit driving conditions. Eco drive mode  Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. Press the “ECO MODE” button to select Eco drive mode.
  • Page 256 4-2. Driving procedures Selecting shift ranges in the D position (vehicles with paddle shift switches) To drive using temporary shift range selection, operate the “-” paddle shift switch. Changing the shift range allows restriction of the highest shift range, preventing unnecessary upshifting and enabling the level of engine braking force to be selected.
  • Page 257 4-2. Driving procedures Selecting gear in the M position To enter M mode, shift the shift lever to M. Gears can be selected by operating the shift lever, allowing you to drive in the gear of your choosing. Vehicles with paddle shift switches: Gears can be selected by the shift lever or operating the “-”...
  • Page 258 4-2. Driving procedures Gear Shift Indicator The Gear Shift Indicator display is a guide to help the driver achieve improved fuel economy and reduced exhaust emissions within limits of engine performance. When not in operation Shift-up indicator Gear Shift Indicator function ...
  • Page 259 4-2. Driving procedures Paddle shift switch (if equipped)   When the “-” paddle shift switch is operated in the D position A shift range will be automatically selected. The highest gear of the first shift range will be one gear lower than the gear in use during normal D position driving.
  • Page 260 M This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
  • Page 261 4-2. Driving procedures  AI-SHIFT The AI-SHIFT automatically selects the suitable gear according to driver per- formance and driving conditions. The AI-SHIFT automatically operates when the shift lever is in D. (Shifting the shift lever to M cancels the function.) CAUTION ...
  • Page 262: Multidrive

    4-2. Driving procedures  Multidrive Shifting the shift lever Vehicles without a smart entry & start system  While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
  • Page 263 4-2. Driving procedures Shift position purpose Shift Meter Purpose/function position display Parking the vehicle/starting the engine Reversing Neutral Normal driving Gear step selection (P. 265) Allows suitable use of engine braking (paddle shift switches activated) 7-speed sport sequential shiftmatic mode driving (P.
  • Page 264 4-2. Driving procedures Selecting the driving mode The following modes can be selected to suit driving conditions. Eco drive mode  Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. Press the “ECO MODE” button to select Eco drive mode.
  • Page 265 4-2. Driving procedures Temporarily engaged gear steps selection mode in the D posi- tion (vehicles with paddle shift switches) To drive in temporary gear steps selection mode, operate the “-” and “+” paddle shift switches. The gear steps can then be selected by operating the “-”...
  • Page 266 4-2. Driving procedures Changing gear steps in the M position To enter 7-speed sport sequential shiftmatic mode, shift the shift lever to M. Gear steps can then be selected by operating the shift lever or paddle shift switches (if equipped), allowing you to drive in the gear step of your choosing.
  • Page 267 4-2. Driving procedures Automatic deactivation of gear step selection in the D position (vehicles  with paddle shift switches) Gear step selection in the D position will be deactivated in the following situa- tions:  When the vehicle comes to a stop ...
  • Page 268 M This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
  • Page 269 When the warning message goes out, the vehicle can be driven again. If the warning message does not go out after waiting a while, have your vehicle inspected by any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional. ...
  • Page 270: Manual Transmission

    4-2. Driving procedures  Manual transmission Shifting the shift lever Fully depress the clutch pedal before operating the shift lever, and then release it slowly. Shifting the shift lever to R Shift the shift lever to R while lift- ing up the ring section. ...
  • Page 271 4-2. Driving procedures Sport mode (if equipped) Use sport mode for sporty driving or driving in mountainous regions. Press the “SPORT” button to select sport mode. The “SPORT” indicator comes on. Press the button again to cancel sport mode. Gear Shift Indicator The Gear Shift Indicator display is a guide to help the driver achieve improved fuel economy and reduced exhaust emissions within limits of engine performance.
  • Page 272 4-2. Driving procedures Gear Shift Indicator display  The Gear Shift Indicator may not be displayed when your foot is placed on the clutch pedal. Deactivation of the driving mode (if equipped)  Sport mode will be canceled if the engine is turned off after driving in sport mode.
  • Page 273 4-2. Driving procedures NOTICE  To prevent damage to the transmission Do not shift the shift lever to R without  depressing the clutch pedal.  Do not lift up the ring section except when shifting the lever to R. ...
  • Page 274: Turn Signal Lever

    4-2. Driving procedures Turn signal lever Operating instructions Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
  • Page 275 4-2. Driving procedures Turn signals can be operated when  Vehicles without a smart entry & start system  The engine switch is in the “ON” position. Vehicles with a smart entry & start system  The engine switch is in IGNITION ON mode. ...
  • Page 276: Parking Brake

    4-2. Driving procedures Parking brake Sets the parking brake Fully pull the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton.  Usage in winter time P.
  • Page 277: Horn

    4-2. Driving procedures Horn To sound the horn, press on or close to the mark.  After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (P.
  • Page 278: Dpf (Diesel Particulate Filter)/Dpnr (Diesel

    4-2. Driving procedures DPF (Diesel Particulate Filter)/DPNR (Diesel  Particulate-NOx Reduction) system When the deposit collected by the filter reaches a predetermined amount, it is automatically regenerated.  Regeneration Regeneration is performed as necessary in accordance with driving conditions.  System characteristics The DPF/DPNR system has the following characteristics: ...
  • Page 279 4-2. Driving procedures Replacing the engine oil  Make sure to use an oil of the recommended grade or of matching quality. (P. 718) DPF/DPNR system warning  Under the following driving conditions, the DPF/DPNR system warning mes- sage may come on earlier than normal. ...
  • Page 280 4-2. Driving procedures NOTICE  To prevent the DPF/DPNR system from failing Do not use fuel other than the specified type   Do not use engine oil other than the recommended type  Do not modify the exhaust pipe RAV4_OM_OM42873E_(EE)
  • Page 281: Operating The Lights And Wipers

    4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: Type A  The front position, tail, license plate and instru- ment panel lights turn on.
  • Page 282 4-3. Operating the lights and wipers Type B  The front position, tail, license plate and instru- ment panel lights turn on. The headlights and all lights listed above turn on. The daytime running lights turn on. Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams.
  • Page 283 4-3. Operating the lights and wipers Manual headlight leveling dial (if equipped) The level of the headlights can be adjusted according to the number of passengers and the loading condition of the vehicle. Lowers the level of the head- lights Raises the level of the head- lights Guide to dial settings...
  • Page 284 4-3. Operating the lights and wipers Follow me home system (if equipped) This system allows the headlights and front position lights to be turned on for 30 seconds when the engine switch is turned to the “LOCK” position (vehicles without a smart entry & start system) or off (vehicles with a smart entry &...
  • Page 285 4-3. Operating the lights and wipers Daytime running light system  To make your vehicle more visible to other drivers, the front position light turn on automatically (at an increased intensity) whenever the engine is started and the parking brake is released. Daytime running lights are not designed for use at night.
  • Page 286 4-3. Operating the lights and wipers  Light reminder buzzer Vehicles without a smart entry & start system  A buzzer sounds when the engine switch is turned to the “LOCK” position, the key is removed and the driver’s door is opened while the lights are turned on. Vehicles with a smart entry &...
  • Page 287: Automatic High Beam

    4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns high beam on or off as necessary. Activating the Automatic High Beam system Push the lever away from you with the headlight switch in...
  • Page 288 4-3. Operating the lights and wipers High beam automatic turning on or off conditions When all of the following conditions are fulfilled, high beam will be automatically turned on:  Vehicle speed is above approximately 40 km/h (25 mph).  The area ahead of the vehicle is dark. ...
  • Page 289 4-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam  Pull the lever to original posi- tion. Switching to high beam  Turn the light switch to position. The Automatic High Beam indi- cator will turn off and the high beam indicator will turn on.
  • Page 290 4-3. Operating the lights and wipers The Automatic High Beam can be operated when  Vehicles without a smart entry & start system  The engine switch is in the “ON” position. Vehicles with a smart entry & start system ...
  • Page 291 4-3. Operating the lights and wipers  In the situations below, the system may not be able to correctly detect the surrounding brightness levels, and may flash or expose nearby pedestrians to the high beam. Therefore, you should consider turning the high beams on or off manually rather than relying on the Automatic High Beam system.
  • Page 292 4-3. Operating the lights and wipers  If a warning message of the Automatic High Beam is displayed... It may indicate a malfunction in the system. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
  • Page 293  Do not modify the vehicle.  Do not replace windshield with non-genuine windshield. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  Do not replace headlights with non-genuine headlights. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 294: Fog Light Switch

    4-3. Operating the lights and wipers Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Front and rear fog light switch  Turns the front and rear fog lights off Turns the front fog lights Turns both front and rear fog lights on...
  • Page 295 4-3. Operating the lights and wipers Fog lights can be used when  Vehicles with a front and rear fog light switch  Front fog lights: The headlights or the front position lights are turned on. Rear fog lights: The front fog lights are turned on. Vehicles with a rear fog light switch ...
  • Page 296: Windshield Wipers And Washer

    4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows. Intermittent windshield wipers  Intermittent operation Low speed operation High speed operation Temporary operation RAV4_OM_OM42873E_(EE)
  • Page 297 4-3. Operating the lights and wipers If equipped, wiper intervals can be adjusted when intermittent opera- tion is selected. Increases the intermittent wind- shield wiper frequency Decreases intermittent windshield wiper frequency Washer/wiper dual operation The wipers will automatically oper- ate a couple of times after the washer squirts.
  • Page 298 4-3. Operating the lights and wipers Rain-sensing windshield wipers  Rain-sensing operation Low speed operation High speed operation Temporary operation When “AUTO” is selected, the wip- ers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain vol- ume and vehicle speed.
  • Page 299 4-3. Operating the lights and wipers The sensor sensitivity can be adjusted when “AUTO” is selected. Increases the sensitivity Decreases the sensitivity Washer/wiper dual operation The wipers will automatically oper- ate a couple of times after the washer squirts. If the headlights are on, the head- light cleaners will operate once.
  • Page 300 4-3. Operating the lights and wipers The windshield wipers and washer can be operated when  Vehicles without a smart entry & start system  The engine switch is in the “ON” position. Vehicles with a smart entry & start system ...
  • Page 301  When a nozzle becomes blocked In this case, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Do not try to clear it with a pin or other object. The nozzle will be damaged.
  • Page 302: Rear Window Wiper And Washer

    4-3. Operating the lights and wipers Rear window wiper and washer Turning the end of the lever turns on the rear window wiper, and push- ing the lever away from you turns on the rear window wiper and washer. Intermittent operation Normal operation Washer/wiper dual operation RAV4_OM_OM42873E_(EE)
  • Page 303 4-3. Operating the lights and wipers The rear window wiper and washer can be operated when  Vehicles without a smart entry & start system  The engine switch is in the “ON” position. Vehicles with a smart entry & start system ...
  • Page 304: Cap

    4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle  Close all the doors and windows, and turn the engine switch to the “LOCK” position (vehicles without a smart entry & start system) or off (vehicles with a smart entry &...
  • Page 305 Use of ethanol blended gasoline in a gasoline engine  Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
  • Page 306: Refueling

    4-4. Refueling CAUTION  When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury.  After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
  • Page 307: Opening The Fuel Tank

    4-4. Refueling Opening the fuel tank cap Pull up the opener to open the fuel filler door. Turn the fuel tank cap slowly to open. Hang the fuel tank cap on the back of the fuel filler door. RAV4_OM_OM42873E_(EE)
  • Page 308 CAUTION  When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
  • Page 309: Cruise Control

    4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
  • Page 310 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
  • Page 311 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 312 4-5. Using the driving support systems CAUTION  To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use.  Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
  • Page 313: Lda (Lane Departure Alert)

    4-5. Using the driving support systems  LDA (Lane Departure Alert) Summary of function While driving on a road that has lane markers, this system recognizes the lane markers using a camera as a sensor to alert the driver when the vehicle deviates from its lane.
  • Page 314 4-5. Using the driving support systems Turning the LDA system on Press the LDA switch to activate the system. “LDA” indicator and the lane lines will come on. Press the switch again to turn the LDA system off. The LDA system will remain on or off even if the engine switch is turned to the “ON”...
  • Page 315 4-5. Using the driving support systems Indication on the multi-information display When the LDA system is on, the lane lines are shown. The thick lane lines are shown when the right and left lane markers are recognized. The recognized side lane line is shown as the thick line when the right or left lane marker is recognized.
  • Page 316 4-5. Using the driving support systems Temporary cancelation of the LDA system  If any of the following occurs, the LDA system will be temporarily canceled. The function will resume after the necessary operating conditions have returned.  The vehicle speed deviates from the operating range of the LDA system. ...
  • Page 317 4-5. Using the driving support systems  When the following distance between your vehicle and the vehicle ahead is extremely short When the lane markers are yellow (these may be more difficult for the sys-  tem to recognize compared to white markers.) ...
  • Page 318 4-5. Using the driving support systems CAUTION  Before using the LDA system Do not rely solely on the LDA system. The LDA system does not drive the vehicle automatically, nor does it reduce the amount of care you need to take.
  • Page 319 Do not install or place anything on the hood or the grille. Also, do not install a grille guard (bull bars, kangaroo bar etc.).  If your windshield needs repairs, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
  • Page 320 When cleaning the inside of the windshield, be careful not to get any glass cleaner etc. on the lens. Also, do not touch the lens. For lens repair, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 321: Toyota Parking Assist-Sensor

    Always check the surrounding area when using this system. Types of sensors Rear corner sensors Rear center sensors Toyota parking assist-sensor switch Turns Toyota parking assist-sen- sor on/off When on, the indicator light comes on to inform the driver that the system is operational.
  • Page 322 4-5. Using the driving support systems The indicator and buzzer When a sensor detects an obstacle, the direction of and the approxi- mate distance to the obstacle are indicated and the buzzer sounds. Toyota parking assist-sensor indicator  Vehicle indicator Rear corner indicators...
  • Page 323  Toyota parking assist-sensor can be operated when Vehicles without a smart entry & start system  The engine switch is in the “ON” position and the shift lever is in R.
  • Page 324 • The area directly under the bumpers is not detected. • If obstacles draw too close to the sensor. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. • People may not be detected if they are wearing certain types of clothing.
  • Page 325 If the indicators stay on even though there is no mud, ice or snow on the sensor, the sensor may be malfunctioning. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 326 When using Toyota parking assist-sensor In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
  • Page 327: All-Wheel Drive Lock Switch (Awd Models)

    4-5. Using the driving support systems All-wheel drive lock switch (AWD models) All-wheel drive lock mode can be used when a large amount of drive power needs to be applied to all the wheels, such as when the vehicle gets stuck in mud and you need to free it. Press the switch.
  • Page 328: Stop & Start System

    4-5. Using the driving support systems  Stop & Start system The Stop & Start system stops and restarts the engine according to the clutch pedal operation for stopping and starting the vehi- cle. Stopping the engine With the clutch pedal fully depressed, stop the vehicle. Then shift the shift lever to N.
  • Page 329 4-5. Using the driving support systems Disabling the Stop & Start system Press the Stop & Start cancel switch to disable the Stop & Start system. The Stop & Start cancel indicator will come on. The engine will not stop at each stop when the clutch pedal is depressed to stop the engine (P.
  • Page 330 4-5. Using the driving support systems Operating conditions   The Stop & Start system is operational when all of the following conditions are met: • The engine is adequately warmed up. • The battery is sufficiently charged. • The driver’s door is closed. •...
  • Page 331 4-5. Using the driving support systems  In the following situations, the engine may start even without the clutch pedal being depressed. • The brake pedal is pumped or strongly depressed. • The air conditioning system is being used or turned on. •...
  • Page 332 4-5. Using the driving support systems  The Stop & Start system protection feature Vehicles without a smart entry & start system: When an excessively loud sound is being projected by the audio system, the audio system may be auto- matically cut off in order to maintain power for the Stop &...
  • Page 333 The installed battery is specific to the Stop & Start system. It should only be replaced with a battery of identical type and rating. Ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further details.
  • Page 334 If any one of the following situations occurs, the Stop & Start system may not operate correctly, thus, please have your vehicle checked by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. ...
  • Page 335: Driving Assist Systems

    4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
  • Page 336 4-5. Using the driving support systems  AUTO LSD function (2WD models) The AUTO LSD function is activated when the system is in TRC off mode. It operates when one of the drive wheels is spinning, such as when the wheel is spinning freely on ice or mud. The system applies the brakes to the spinning wheel and transfers some of the torque to the other wheel to secure drive power.
  • Page 337 4-5. Using the driving support systems When the TRC/VSC systems are operating The slip indicator light will flash while the TRC/VSC systems are operating. Disabling the TRC system If the vehicle gets stuck in mud, dirt or snow, the TRC system may reduce power from the engine to the wheels.
  • Page 338 When the “AUTO LSD” indicator light flashes even if the VSC OFF switch has not been pressed (2WD models) TRC, AUTO LSD, hill-start assist control and downhill assist control cannot be operated. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
  • Page 339 4-5. Using the driving support systems  EPS operation sound When the steering wheel is operated, a motor sound (whirring sound) may be heard. This does not indicate a malfunction.  Automatic reactivation of TRC and VSC systems After turning the TRC and VSC systems off, the systems will be automatically re-enabled in the following situations: ...
  • Page 340 The ABS, TRC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further information when replacing tires or wheels.
  • Page 341: Hill-Start Assist Control

    4-5. Using the driving support systems Hill-start assist control Assists with starting off and temporarily maintains braking power even if the foot is removed from the brake pedal when starting off on an incline or a slippery slope. To engage hill-start assist control, further depress the brake pedal when the vehicle is stopped com- pletely.
  • Page 342 • The brake pedal has been depressed for more than approximately 3 min- utes.  If the slip indicator comes on It may indicate a malfunction in the system. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. CAUTION ...
  • Page 343: Downhill Assist Control System

    4-5. Using the driving support systems  Downhill assist control system The downhill assist control system helps to prevent excessive speed on steep downhill slopes. The system will operate when the vehicle is traveling under 25 km/h (15 mph). System operation Press the “DAC”...
  • Page 344 The downhill assist control system indicator does not come on when the “DAC” switch is pressed. The slip indicator comes on.  In the above cases, have your vehicle checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. RAV4_OM_OM42873E_(EE)
  • Page 345 4-5. Using the driving support systems CAUTION  When using downhill assist control system Do not rely overmuch on the downhill assist control system. This function does not extend the vehicle’s performance limitations. Always thoroughly check the road conditions, and drive safely. ...
  • Page 346: Bsm (Blind Sport Moni- Tor)

    4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions;  The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ...
  • Page 347 4-5. Using the driving support systems Right-hand drive vehicles  BSM main switch Pressing the switch turns the system on or off. When the switch is set to on, the switch’s indicator illuminates and the buzzer sounds. Common switch for Blind Spot Monitor function and Rear Crossing Traffic Alert func- tion.
  • Page 348 4-5. Using the driving support systems The outside rear view mirror indicators visibility  When under strong sunlight, the outside rear view mirror indicator may be dif- ficult to see. Rear Crossing Traffic Alert buzzer hearing  Rear Crossing Traffic Alert function may be difficult to hear over loud noises such as high audio volume.
  • Page 349 4-5. Using the driving support systems  Certification for the Blind Spot Monitor system The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing: DoC address: http://continental.automotive-approvals.de/index.php?produkt=SRR2-A RAV4_OM_OM42873E_(EE)
  • Page 350 4-5. Using the driving support systems RAV4_OM_OM42873E_(EE)
  • Page 351 4-5. Using the driving support systems For vehicles sold in Israel  For vehicles sold in Russia  type approval number: POCC DE.ML05.H01144 For vehicles sold in Ukraine  type approval number: 1O094.000966-13 RAV4_OM_OM42873E_(EE)
  • Page 352 If the sensor or surrounding area is subject to a strong impact, always have the area inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 353: The Blind Spot Monitor Function

    4-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicles existence via the outside rear view mirror indicator.
  • Page 354 4-5. Using the driving support systems The Blind Spot Monitor function is operational when   The BSM main switch is set to on  Vehicle speed is greater than approximately 16 km/h (10 mph)  The Blind Spot Monitor will detect a vehicle when ...
  • Page 355 4-5. Using the driving support systems  Conditions under which the Blind Spot Monitor function may not func- tion correctly  The Blind Spot Monitor function may not detect vehicles correctly in the fol- lowing conditions: • During bad weather such as heavy rain, fog, snow, etc. •...
  • Page 356: The Rear Crossing Traffic Alert Function

    4-5. Using the driving support systems The Rear Crossing Traffic Alert function The Rear Crossing Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehicle’s existence through flashing the outside rear view mirror indi- cators and sounding a buzzer.
  • Page 357 4-5. Using the driving support systems The Rear Crossing Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
  • Page 358 4-5. Using the driving support systems  Conditions under which the Rear Crossing Traffic Alert function will not detect a vehicle The Rear Crossing Traffic Alert function is not designed to detect the follow- ing types of vehicles and/or objects. ...
  • Page 359: Driving Tips

    4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter  Use fluids that are appropriate to the prevailing outside tempera- tures.
  • Page 360 4-6. Driving tips Before driving the vehicle Perform the following according to the driving conditions:  Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
  • Page 361 4-6. Driving tips Selecting tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain: 3 mm (0.12 in.) in diameter 10 mm (0.39 in.) in width 30 mm (1.18 in.) in length Cross chain: 4 mm (0.16 in.) in diameter 14 mm (0.55 in.) in width...
  • Page 362 4-6. Driving tips Tire chain installation  Observe the following precautions when installing and removing chains:  Install and remove tire chains in a safe location.  Install tire chains on the front tires only. Do not install tire chains on the rear tires.
  • Page 363 Repairing or replacing snow tires (vehicles with the tire pressure warn- ing system) Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
  • Page 364: Utility Vehicle Precautions

    4-6. Driving tips Utility vehicle precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications. Utility vehicle feature ...
  • Page 365 4-6. Driving tips CAUTION  Utility vehicle precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle:  In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
  • Page 366 4-6. Driving tips Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the clo- sure of areas to off-road vehicles.  Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
  • Page 367 4-6. Driving tips CAUTION  Off-road driving precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle:  Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
  • Page 368 4-6. Driving tips NOTICE  When you drive through water If driving through water, such as when crossing shallow streams, first check the depth of the water and the bottom of the stream for firmness. Drive slowly and avoid deep water. ...
  • Page 369: Interior Features

    Interior features 5-1. Using the air conditioning Making a phone call...464 system and defogger Using the “SETUP” menu Manual air conditioning (“Bluetooth ” menu)..469 system ......370 Using the “SETUP” menu Automatic air conditioning (“PHONE” or system ......377 “TEL” menu) ....476 Rear window and outside 5-3.
  • Page 370: Manual Air Conditioning Sys

    5-1. Using the air conditioning system and defogger  Manual air conditioning system Air outlet selector dial Cooling and dehumidification function on/off button Fan speed control dial equipped) Temperature control dial Outside/recirculated air mode button Adjusting the settings To adjust the fan speed, turn the fan speed control dial clockwise (increase) or counterclockwise (decrease).
  • Page 371 5-1. Using the air conditioning system and defogger Defogging the windshield Set the air outlet selector dial to position. Set the outside/recirculated air mode button to outside air mode if recirculated air mode is used. Perform the following operations accordingly: ...
  • Page 372 5-1. Using the air conditioning system and defogger Upper body and feet Feet Feet and windshield Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) each time is pressed.
  • Page 373 5-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Front center outlets  Direct air flow to the left or right, up or down. Turn the knobs to open or close the vents.
  • Page 374 5-1. Using the air conditioning system and defogger Operation of the air conditioning system in Eco drive mode  In Eco drive mode, the air conditioning system is controlled to prioritize fuel efficiency by regulating the engine speed and compressor operation to restrict the heating/cooling capacity.
  • Page 375 5-1. Using the air conditioning system and defogger  Air conditioning system operations when the engine is stopped due to the Stop & Start system (vehicles with a Stop & Start system) When the engine is stopped due to Stop & Start system operations, the air conditioning cooling, heating and dehumidification functions turn off and only ambient temperature air is blown.
  • Page 376 5-1. Using the air conditioning system and defogger CAUTION  To prevent the windshield from fogging up Do not set the air outlet selection dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
  • Page 377: Automatic Air Conditioning System

    5-1. Using the air conditioning system and defogger  Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. The illustration below is for left-hand drive vehicles. The button positions are reversed for right-hand drive vehicles. Driver’s side temperature con- Windshield defogger button trol dial...
  • Page 378 5-1. Using the air conditioning system and defogger Using the automatic air conditioning system Press The dehumidification function begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting and humidity. Turn clockwise to increases the temperature and turn counterclockwise to decreases the temperature on the driver’s side.
  • Page 379 5-1. Using the air conditioning system and defogger Adjusting the settings manually To adjust the fan speed, press “” on to increase the fan speed and “” to decrease the fan speed. Press to turn the fan off. To adjust the temperature setting, turn clockwise to increases the temperature and turn counterclockwise to...
  • Page 380 5-1. Using the air conditioning system and defogger Defogging the windshield Press dehumidification function operates and fan speed increases. Set the outside/recirculated air mode button to outside air mode if the recirculated air mode is used. (It may switch automatically.) To defog the windshield and the side windows early, turn the air flow and temperature up.
  • Page 381 5-1. Using the air conditioning system and defogger Upper body and feet Feet Feet and windshield RAV4_OM_OM42873E_(EE)
  • Page 382 5-1. Using the air conditioning system and defogger Switching between outside air and recirculated air modes Press The mode switches between outside air mode (the indicator is off) and recirculated air mode (the indicator is on) each time is pressed. Blower customization If automatic mode is selected, only the fan speed can be adjusted according to your preference.
  • Page 383 5-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Front center outlets  Direct air flow to the left or right, up or down. Turn the knobs to open or close the vents.
  • Page 384 5-1. Using the air conditioning system and defogger Operation of the air conditioning system in Eco drive mode  In Eco drive mode, the air conditioning system is controlled as follows to pri- oritize fuel efficiency: Engine speed and compressor operation controlled to restrict heating/cool- ...
  • Page 385 5-1. Using the air conditioning system and defogger  When the outside temperature falls to nearly 0C (32F) The dehumidification function may not operate even when is pressed.  Air conditioning odors  During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
  • Page 386 5-1. Using the air conditioning system and defogger  Customization Settings (e.g. outside/recirculated air mode) can be changed. (Customizable features: P. 737) CAUTION  To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
  • Page 387: Rear Window And Outside Rear View Mirror Defoggers

    5-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mir- rors (if equipped). The illustrations below are for left-hand drive vehicles.
  • Page 388 5-1. Using the air conditioning system and defogger Operating conditions  Vehicles without a smart entry & start system  The engine switch is in the “ON” position. Vehicles with a smart entry & start system  The engine switch is in IGNITION ON mode. ...
  • Page 389: Windshield Wiper De-Icer

    5-1. Using the air conditioning system and defogger  Windshield wiper de-icer This feature is used to prevent ice from building up on the wind- shield and wiper blades. On/off The windshield wiper de-icer will automatically turn off after approxi- mately 15 minutes.
  • Page 390: Power Heater

    5-1. Using the air conditioning system and defogger  Power heater This feature is used to keep the cabin warm in cold conditions. On/off The power heater turns on about 25 seconds after the button is pressed, and takes about another 85 seconds to warm up.
  • Page 391  Do not modify or open the heater without consulting any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, as this may cause a heater malfunction or a fire.
  • Page 392: 5-2. Using The Audio System

    5-2. Using the audio system  Audio system types Vehicles with a navigation system and multimedia system  Refer to the “Navigation and multimedia system Owner’s manual”. Vehicles without a navigation system or multimedia system  CD player with AM/FM radio ...
  • Page 393 5-2. Using the audio system  Type C Title Page Using the radio P. 395 Using the CD player P. 402 Playing back MP3 and WMA discs P. 410 Operating an iPod P. 419 Operating a USB memory P. 430 Optimal use of the audio system P.
  • Page 394 5-2. Using the audio system Using cellular phones  Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. CAUTION Certification for the disc player ...
  • Page 395: Using The Radio

    5-2. Using the audio system  Using the radio Type A  Power AM/FM mode button Volume Station selectors Adjusting the frequency Seeking the frequency Scanning for receivable sta- tions  : If equipped RAV4_OM_OM42873E_(EE)
  • Page 396 5-2. Using the audio system Type B  Power Back button Volume AM/FM mode button AF/region code/TA mode setup Station selectors Adjusting the frequency Seeking the frequency Displaying station list RAV4_OM_OM42873E_(EE)
  • Page 397 5-2. Using the audio system Type C  Power AM/FM mode button Volume Station selectors Adjusting the frequency Seeking the frequency Scanning for receivable sta- tions Setting station presets Search for the desired stations by turning the “TUNE•SCROLL”  knob (type A and C) or (type B) or pressing “”...
  • Page 398 5-2. Using the audio system Scanning radio stations (type A and C only) Scanning the preset radio stations  Press and hold the “SCAN” button until you hear a beep. Preset stations will be played for 5 seconds each. To cancel, press the button again. When the desired station is reached, press the button again.
  • Page 399 5-2. Using the audio system RDS (Radio Data System) (type B only) This feature allows your radio to receive station. Listening to stations of the same network  Press the “SETUP” button. Turn to “RADIO” and press the knob. Turn the knob as corresponds to the desired mode: “FM AF” or “Region code”.
  • Page 400 5-2. Using the audio system Traffic information  Press the “SETUP” button. Turn to “RADIO” and press the knob. Turn the knob to “FM TA” mode. Press the knob to select “ON” or “OFF”. TP mode: The system automatically switches to traffic information when a broadcast with a traffic information signal is received.
  • Page 401 5-2. Using the audio system EON (Enhanced Other Network) system (for traffic announcement func-  tion) (type B only) If the RDS station (with EON data) you are listening to is not broadcasting a traffic information program and the audio system is in the TA (traffic announcement) mode, the radio will be switched automatically to a station broadcasting a traffic information program in the EON AF list when traffic information begins.
  • Page 402: Using The Cd Player

    5-2. Using the audio system  Using the CD player Type A  Power Repeat play Volume Changing the audio source/ playback CD eject Selecting a track, fast-forward- Selecting a track or displaying ing or rewinding track list Displaying text message Searching playback Random play or back button ...
  • Page 403 5-2. Using the audio system Type B  Power Repeat play Volume Changing the audio source/ playback CD eject Selecting a track, fast-forward- Selecting a track or displaying ing or rewinding text message Displaying track list Back button Random play RAV4_OM_OM42873E_(EE)
  • Page 404 5-2. Using the audio system Type C  Power Repeat play Volume Changing the audio source/ playback CD eject Selecting a track, fast-forward- Selecting a track or displaying ing or rewinding track list Displaying text message Searching playback Random play or back button Loading CDs Insert a CD.
  • Page 405 5-2. Using the audio system Selecting a track from a track list Press the “TUNE•SCROLL” knob (type A and C) or the “LIST” but- ton (type B). The track list will be displayed. Turn and press the knob (type A and C) or (type B) to select a track.
  • Page 406 Operation has stopped due to a high temperature inside the player. Wait for a while and then press the “MEDIA” button. If the CD still cannot be played back, contact any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional.
  • Page 407 5-2. Using the audio system  Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration. CDs with copy-protect features may not play correctly.
  • Page 408 5-2. Using the audio system NOTICE  CDs and adapters that cannot be used Do not use the following types of CDs. Also, do not use 8 cm (3 in.) CD adapters, DualDiscs or printable discs. Doing so may damage the player and/or the CD insert/eject function. ...
  • Page 409 5-2. Using the audio system NOTICE  CDs with a transparent or translucent recording area  CDs that have tape, stickers or CD-R labels attached to them, or that have had the label peeled off CD Player precautions  Failure to follow the precautions below may result in serious damage to the CDs or the player itself.
  • Page 410: Playing Back Mp3 And Wma Discs

    5-2. Using the audio system  Playing back MP3 and WMA discs Type A  Power Repeat play Volume Selecting a folder CD eject Changing the audio source/ playback Selecting a file or displaying folder list Selecting a file, fast-forward- ing or rewinding Searching playback Displaying text message...
  • Page 411 5-2. Using the audio system Type B  Power Repeat play Volume Selecting a folder CD eject Changing the audio source/ playback Selecting a file or displaying text message Selecting a file, fast-forward- ing or rewinding Back button Displaying folder list Random play RAV4_OM_OM42873E_(EE)
  • Page 412 5-2. Using the audio system Type C  Power Random play or back button Volume Repeat play CD eject Changing the audio source/ playback Selecting a file or displaying folder list Selecting a file, fast-forward- ing or rewinding Searching playback Displaying text message Selecting a folder Loading and ejecting MP3 and WMA discs...
  • Page 413 5-2. Using the audio system Selecting a folder Selecting folders one at a time  Press (<FOLDER) or (FOLDER>) (type A and B) or “” or “” on the “FOLDER” button (type C) to select the desired folder. Selecting a folder and file from folder list ...
  • Page 414 5-2. Using the audio system Scanning the files in a folder (type A and C only) Press the “SCAN” button. The first 10 seconds of each file will be played. To cancel, press the button again. When the desired file is reached, press the button again. Fast-forwarding and rewinding files Press and hold “”...
  • Page 415 5-2. Using the audio system Display  P. 406  Error messages “ERROR”: This indicates a trouble either in the CD or inside the player. “CD CHECK”: The CD may be dirty, damaged or inserted upside-down. “NO SUPPORT”: This indicates that the MP3/WMA file is not included in the CD. ...
  • Page 416 5-2. Using the audio system  MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 for- mat.
  • Page 417 5-2. Using the audio system  Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
  • Page 418 5-2. Using the audio system  MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
  • Page 419: Operating An Ipod

    5-2. Using the audio system  Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Connecting an iPod Open the cover and connect an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
  • Page 420 5-2. Using the audio system Control panel Type A  Power Changing the audio source/ playback Volume iPod menu mode, playback Selecting an iPod menu/song or displaying song list Selecting a song, fast-forward- ing or rewinding Random play or back button Displaying text message Repeat play RAV4_OM_OM42873E_(EE)
  • Page 421 5-2. Using the audio system Type B  Power Repeat play Volume Changing the audio source/ playback Selecting an iPod menu/song or displaying text message iPod menu mode, playback Back button Selecting a song, fast-forward- ing or rewinding Random play Displaying song list RAV4_OM_OM42873E_(EE)
  • Page 422 5-2. Using the audio system Type C  Power Changing the audio source/ playback Volume iPod menu mode, playback Selecting an iPod menu/song or displaying song list Selecting a song, fast-forward- ing or rewinding Random play or back button Displaying text message Repeat play RAV4_OM_OM42873E_(EE)
  • Page 423 5-2. Using the audio system Selecting a play mode Press (MENU) to select iPod menu mode. Turning the “TUNE•SCROLL” knob (type A and C) or (type B) clockwise changes the play mode in the following order: “Playlists” “Artists” “Albums” “Songs” “Podcasts”  “Genres”...
  • Page 424 5-2. Using the audio system Play mode list  First Second Third Fourth Play mode selection selection selection selection Playlists “Playlists” Songs select select Albums “Artists” Artists select Songs select select Albums “Albums” Songs select select “Songs” Songs select Podcasts Episodes “Podcasts”...
  • Page 425 5-2. Using the audio system Selecting songs Turn the “TUNE•SCROLL” knob (type A and C) or (type B) or   press “ ” or “” on the “SEEK/TRACK” button (type A and C) or the “ ” or “” button (type B) to select the desired song. Selecting a song from the song list Press the “TUNE•SCROLL”...
  • Page 426 5-2. Using the audio system Switching the display Press the “TEXT” button (type A and C) or (type B) to display or hide the album title. If there are continuing texts, is displayed. Press and hold the button (type A and C) or the knob (type B) to display the remaining texts.
  • Page 427 5-2. Using the audio system  iPod problems To resolve most problems encountered when using your iPod, disconnect your iPod from the vehicle iPod connection and reset it. For instructions on how to reset your iPod, refer to your iPod Owner’s Man- ual.
  • Page 428 5-2. Using the audio system  Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system.  Made for • iPod touch (4th generation) •...
  • Page 429 5-2. Using the audio system NOTICE  To prevent damage to iPod or its terminal Do not leave iPod in the vehicle. The temperature inside the vehicle may  become high.  Do not push down on or apply unnecessary pressure to the iPod while it is connected.
  • Page 430: Operating A Usb Memory

    5-2. Using the audio system  Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. Connecting a USB memory Open the cover and connect a USB memory. Turn on the power of the USB memory if it is not turned on.
  • Page 431 5-2. Using the audio system Control panel Type A  Power Selecting a folder Volume Changing the audio source/ playback Selecting a file or displaying folder list Selecting a file, fast-forward- ing or rewinding Searching playback Displaying text message Random play or back button Repeat play RAV4_OM_OM42873E_(EE)
  • Page 432 5-2. Using the audio system Type B  Power Selecting a folder Volume Changing the audio source/ playback Selecting a file or displaying text message Selecting a file, fast-forward- ing or rewinding Back button Displaying folder list Random play Repeat play RAV4_OM_OM42873E_(EE)
  • Page 433 5-2. Using the audio system Type C  Power Repeat play Volume Changing the audio source/ playback Selecting a file or displaying folder list Selecting a file, fast-forward- ing or rewinding Searching playback Displaying text message Selecting a folder Random play or back button RAV4_OM_OM42873E_(EE)
  • Page 434 5-2. Using the audio system Selecting a folder Selecting folders one at a time  Press (<FOLDER) or (FOLDER>) (type A and B) or “” or “” on the “FOLDER” button (type C) to select the desired folder. Selecting a folder and file from folder list ...
  • Page 435 5-2. Using the audio system Scanning the files in a folder (type A and C only) Press the “SCAN” button. The first 10 seconds of each file will be played. To cancel, press the button again. When the desired file is reached, press the button again. Fast-forwarding and rewinding files ...
  • Page 436 5-2. Using the audio system USB memory functions   Depending on the USB memory that is connected to the system, the device itself may not be operable and certain functions may not be available. If the device is inoperable or a function is unavailable due to a malfunction (as opposed to a system specification), disconnecting the device and recon- necting it once again may resolve the problem.
  • Page 437 5-2. Using the audio system  MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
  • Page 438 5-2. Using the audio system  File names The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma.  ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc.
  • Page 439 5-2. Using the audio system  Playback • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encod- ing and the file format, poor sound quality or noise at the start of playback may result.
  • Page 440: Optimal Use Of The Audio System

    5-2. Using the audio system  Optimal use of the audio system Type A and C Type B   Displays the “SETUP” menu Changes the following settings • Sound quality and volume balance P. 441 The sound quality and balance setting can be changed to produce the best sound.
  • Page 441 5-2. Using the audio system Using the audio control function Changing sound quality modes  Press the “SETUP” button. Turn the “TUNE•SCROLL” knob (type A and C) or (type B) to select “Sound Setting”. Press the knob. Turn the knob as corresponds to the desired mode. “BASS”, “TREBLE”, “FADER”, “BALANCE”, or “ASL”...
  • Page 442 5-2. Using the audio system Adjusting the Automatic Sound Levelizer (ASL)  When ASL is selected, turn “TUNE•SCROLL” knob (type A and C) (type B) to change the amount of ASL. “LOW”, “MID”, “HIGH”, or “OFF” can be selected. ASL automatically adjusts the volume and tone quality according to vehicle speed.
  • Page 443: Using The Aux Port

    5-2. Using the audio system  Using the AUX port This port can be used to connect a portable audio device and lis- ten to it using the vehicle’s speakers. Open the cover and connect the portable audio device. Press the “MEDIA” button repeatedly until “AUX” is displayed. ...
  • Page 444: Using The Steering Wheel Audio Switches

    5-2. Using the audio system  Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
  • Page 445 5-2. Using the audio system Turning on the power Press the “MODE” switch when the audio system is turned off. Changing the audio source Press the “MODE” switch when the audio system is turned on. The audio source changes as follows each time the button is pressed. If a mode cannot be used, it will be skipped.
  • Page 446 5-2. Using the audio system Selecting a track/file or song ® Press the “MODE” switch to select the CD, Bluetooth audio, iPod or USB memory mode. Press the “” or “” switch to select the desired track/file or song. Selecting an album (if equipped) ®...
  • Page 447: Bluetooth® Audio/Phone

    5-2. Using the audio system  ® Bluetooth audio/phone  ® Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
  • Page 448 5-2. Using the audio system  When transferring ownership of the vehicle Be sure to initialize the system to prevent personal data from being improp- erly accessed. (P. 475) ®  About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG, Inc. ...
  • Page 449 5-2. Using the audio system  Certification RAV4_OM_OM42873E_(EE)
  • Page 450 5-2. Using the audio system RAV4_OM_OM42873E_(EE)
  • Page 451 5-2. Using the audio system RAV4_OM_OM42873E_(EE)
  • Page 452 5-2. Using the audio system RAV4_OM_OM42873E_(EE)
  • Page 453 5-2. Using the audio system CAUTION  While driving Do not operate the portable audio player, cellular phone or connect a device ® to the Bluetooth system.  Caution regarding interference with electronic devices ®  Your audio unit is fitted with Bluetooth antennas.
  • Page 454: Using The Bluetooth® Audio/ Phone

    5-2. Using the audio system ®  Using the Bluetooth audio/phone Audio unit Type A  ® Bluetooth connection condi- tion If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Displays set up menu Selects items such as menu and number Turn: Selects an item Press: Inputs the selected item...
  • Page 455 5-2. Using the audio system Type B  ® Bluetooth connection condi- tion If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Displays set up menu Selects items such as menu and number Turn: Selects an item Press: Inputs the selected item Press and hold: Displays information that is too long to be dis- played at one time on the display (depending on the type of the...
  • Page 456 5-2. Using the audio system ® Steering wheel switches (Bluetooth audio)  P. 444 ® Steering wheel switches (Bluetooth phone)  Volume The voice guidance volume cannot be adjusted using this button. Off-hook switch Turns the hands-free system on/start a call On-hook switch Turns the hands-free system off/ends a call/refuse a call...
  • Page 457 5-2. Using the audio system ® Using the Bluetooth audio/phone for the first time ® Before using the Bluetooth audio/phone, it is necessary to register a ® Bluetooth device in the system. Follow the procedure below to regis- ter (pair) a device: Press the “SETUP”...
  • Page 458 5-2. Using the audio system ® Menu list of the Bluetooth audio/phone First menu Second menu Third menu Operation details Registering “Pairing” ® Bluetooth device Listing the registered “List phone” cellular phones Listing the registered “List audio” portable players Changing the pass- “Passkey”...
  • Page 459 5-2. Using the audio system First menu Second menu Third menu Operation details Adding a new num- “Add contacts” Registering a speed “Add SD” dial Deleting a number “Delete call stored in the call his- “Phonebook” history” tory Deleting a number “Delete contacts”...
  • Page 460: Operating A Bluetooth® Enabled

    5-2. Using the audio system ® Operating a Bluetooth enabled portable  player Type A  Power Changing the audio source/ playback Volume Playback/pause Search playback Selecting a track, fast-forward- Random play or back button ing or rewinding Repeat play Displaying text message Selecting an album ...
  • Page 461 5-2. Using the audio system Type B  Power Selecting an album Volume Changing the audio source/ playback Displaying text message Playback/pause Back button Selecting a track, fast-forward- Random play ing or rewinding Repeat play RAV4_OM_OM42873E_(EE)
  • Page 462 5-2. Using the audio system Selecting an album Press (<FOLDER) or (FOLDER>) to select desired album. Scanning an album (type A only) Press and hold the “SCAN” button until you hear a beep. The first 10 seconds of the first track in each album will be played. To cancel, press the button again.
  • Page 463 5-2. Using the audio system Playing and pausing tracks Press Switching the display Press the “TEXT” button (type A) or (type B) to display or hide the album title. If there are continuing texts, is displayed. Press and hold the button (type A) or the knob (type B) to display the remaining texts.
  • Page 464: Making A Phone Call

    5-2. Using the audio system  Making a phone call To enter the “PHONE” or “TEL” mode, press the off-hook switch.  Making a phone call  Dialing by inputting a name  Speed dialing  Dialing by entering the number ...
  • Page 465 5-2. Using the audio system Dialing by selecting a name Select “Phonebook” using the “TUNE•SCROLL” knob (type A) or (type B). Select the desired name using the knob and press the off-hook switch. By pressing (Add S. Dial) and one of the speed dial buttons (from [1] to [5]) while the desired name is selected, it can be regis- tered as a speed dial.
  • Page 466 5-2. Using the audio system Dialing by entering the number Select “Dial by number” using the “TUNE•SCROLL” knob (type A) (type B). Enter the phone number and press the off-hook switch. Dialing from call histories Select “All calls”, “Missed calls”, “Incoming calls” or “Outgoing calls” using the “TUNE•SCROLL”...
  • Page 467 5-2. Using the audio system When receiving a phone call Answering the phone  Press the off-hook switch. Refusing the call  Press the on-hook switch. Receiving a call when on another call  Press the off-hook switch. Pressing the off-hook switch again returns you to the previous call. Operations during a call Transferring a call ...
  • Page 468 5-2. Using the audio system Setting call volume  To decrease the volume: Turn the “PWR•VOL” knob (type A) or (type B) counterclockwise. To increase the volume: Turn the “PWR•VOL” knob (type A) or (type B) clockwise. Adjusting the ring tone volume when receiving a call To decrease the volume: Turn the “PWR•VOL”...
  • Page 469: Using The "Setup" Menu ("Bluetooth*" Menu)

    5-2. Using the audio system Using the “SETUP” menu (“Bluetooth*”  menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: Functions and operation procedures Press the “SETUP” button and select “Bluetooth ”...
  • Page 470 5-2. Using the audio system ® Registering a Bluetooth device Select “Pairing” using he “TUNE•SCROLL” knob (type A) or (type B) and press (Add New). ®  If a Bluetooth device is not connected currently ® Perform the procedure for registering a Bluetooth device from step .
  • Page 471 5-2. Using the audio system Listing the registered cellular phones Select “List phone” using the “TUNE•SCROLL” knob (type A) or (type B). The list of registered cellular phones will be dis- played.  Connecting the registered cellular phone to the audio system Select the name of the cellular phone to be connected using the “TUNE•SCROLL”...
  • Page 472 5-2. Using the audio system Listing the registered portable players Select “List audio” using the “TUNE•SCROLL” knob (type A) or (type B). The list of registered portable players will be displayed.  Connecting the registered portable player to the audio system Select the name of the portable player to be connected using the “TUNE•SCROLL”...
  • Page 473 5-2. Using the audio system Changing the passkey Select “Passkey” using the “TUNE•SCROLL” knob (type A) or (type B). Select a 4 to 8-digit passkey using the knob. Input the number 1 digit at a time. When the entire number to be registered as a passkey has been input, press (ENTER).
  • Page 474 5-2. Using the audio system Displaying the device status Select “Bluetooth info” using the “TUNE•SCROLL” knob (type A) or (type B).  Displaying the device name Select “Device name” using the “TUNE•SCROLL” knob (type A) or (type B).  Displaying the device address Select “Device address”...
  • Page 475 5-2. Using the audio system Initialization Select “Initialize” using the “TUNE•SCROLL” knob (type A) or (type B).  Initializing the sound settings Select “Sound setting” using the “TUNE•SCROLL” knob (type A) or (type B) and press (YES). For details about sound settings: P. 476 ...
  • Page 476: Using The "Setup" Menu ("Phone* Or "Tel" Menu)

    5-2. Using the audio system Using the “SETUP” menu (“PHONE” or  “TEL” menu) Functions and operation procedures To enter the menu for each function, press the “SETUP” button and follow the steps below using the “TUNE•SCROLL” knob (type A) or (type B): ...
  • Page 477 5-2. Using the audio system Adding a new phone number Select “Add contacts” using the “TUNE•SCROLL” knob (type A) or (type B).  Transferring all contacts from the cellular phone Select “Overwrite all” using the “TUNE•SCROLL” knob (type A) or (type B) and press (YES).
  • Page 478 5-2. Using the audio system Deleting call histories Select “Delete call history” using the “TUNE•SCROLL” knob (type A) (type B).  Deleting outgoing call history Select “Outgoing calls” using the “TUNE•SCROLL” knob (type A) (type B). Select the desired phone number using the knob and press (YES).
  • Page 479 5-2. Using the audio system  Deleting missed call history Select “Missed calls” using the “TUNE•SCROLL” knob (type A) (type B). Select the desired phone number using the knob and press (YES). To delete all missed call history data, press (ALL) and then press (YES).
  • Page 480 5-2. Using the audio system Deleting a registered phone number Select “Delete contacts” using the “TUNE•SCROLL” knob (type A) (type B). Select the desired phone number using the knob and press (YES). To delete all the registered phone numbers, press (ALL) and then press (YES).
  • Page 481 5-2. Using the audio system Setting call volume Select “Call volume” using the “TUNE•SCROLL” knob (type A) or (type B). Change the call volume. To decrease the volume: Turn the knob counterclockwise. To increase the volume: Turn the knob clockwise. To set the volume, press (BACK) (type A) or the back button (type B).
  • Page 482 5-2. Using the audio system Setting ring tone Select “Ringtone” using the “TUNE•SCROLL” knob (type A) or (type B). Using the knob, select a ring tone (1 - 3). To set the selected ring tone, press (BACK) (type A) or the back button (type B). Transferring call histories Select “Transfer histories”...
  • Page 483: Using The Interior Lights

    5-3. Using the interior lights Interior lights list Interior lights (P. 484) Interior/personal lights (P. 484) Engine switch light (if equipped) RAV4_OM_OM42873E_(EE)
  • Page 484: Interior Lights

    5-3. Using the interior lights Interior lights Front  Door position The interior lights come on when a door is opened. They turn off when the doors are closed. Rear  Door position The interior light comes on when a door is opened. It turns off when the doors are closed.
  • Page 485 5-3. Using the interior lights Illuminated entry system  Vehicles without a smart entry & start system  The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are open/ closed.
  • Page 486: 5-4. Using The Storage Features

    5-4. Using the storage features List of storage features Glove box (P. 487) Cup holders (P. 489) Bottle holders (P. 490) Storage boxes (P. 492) Console box (P. 488) CAUTION  Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ...
  • Page 487: Glove Box

    5-4. Using the storage features CAUTION  When driving or when the storage compartments are not in use Keep the lids closed. In the event of sudden braking or sudden swerving, an accident may occur due to an occupant being struck by an open lid or the items stored inside. Glove box Type A ...
  • Page 488: Console Box

    5-4. Using the storage features Console box Lift the lid while pulling up the lever to release the lock.  When using the console box lid as an armrest (vehicles with slide func- tion) Slide the console box lid forward as needed.
  • Page 489: Cup Holders

    5-4. Using the storage features Cup holders Front  Rear  Pull the armrest down. CAUTION  Items unsuitable for the cup holders Do not place anything other than cups, aluminum cans or portable ashtray in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
  • Page 490: Bottle Holders

    5-4. Using the storage features Bottle holders Front  Rear  CAUTION  Items unsuitable for the bottle holder Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 491: Luggage Compartment Features

    5-4. Using the storage features Luggage compartment features Cargo hooks Raise the hooks to use. The cargo hooks are provided for securing loose items. CAUTION  When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their stowed positions. Grocery bag hooks On some models: The grocery bag hook on the left side is not...
  • Page 492 5-4. Using the storage features Storage boxes Front  Open the deck board by pulling up the strap. Warning reflector etc. can be stowed. Rear  Type A  Open the deck board by pull- ing up the strap. Fold up the deck board. The lid can be removed.
  • Page 493 5-4. Using the storage features Type B  Open the deck board by pulling up the strap. CAUTION  Caution while driving Do not drive with any of the deck boards opened. Items may fall out and cause injury. Luggage cover (if equipped) Installing the luggage cover ...
  • Page 494 5-4. Using the storage features Pull out the luggage cover and hook it onto the anchors. Removing the luggage cover  Release the cover from the left and right anchors and allow it to retract. Compress the end of the lug- gage cover and lift the lug- gage cover up.
  • Page 495 5-4. Using the storage features Stowing the luggage cover (except for full-size spare tire)  Open the rear deck board and remove the deck side covers. Insert the right end of the lug- gage cover into the recess, then compress the left end of the luggage cover and insert it into the recess.
  • Page 496 5-4. Using the storage features CAUTION  When installing/stowing the luggage cover (except for full-size spare tire) Make sure that the luggage cover is securely installed/stowed. Failure to do so may result in serious injury in the event of sudden braking or a collision. ...
  • Page 497 5-4. Using the storage features Rear cargo net (if equipped) Installing the luggage cover  Position of the rear cargo net can be changed. Position A (except for full-size spare tire)  Take out the rear cargo net. Insert the right end of the rear cargo into...
  • Page 498 5-4. Using the storage features Position B  Except for full-size spare tire: Take out the rear cargo net. Insert the right end of the rear cargo into recess, then compress the left end of the rear cargo net and insert it into the recess. RAV4_OM_OM42873E_(EE)
  • Page 499 5-4. Using the storage features Stowing the rear cargo net (except for full-size spare tire)  Open the rear deck board and remove the deck side covers. Insert the right end of the rear cargo into recess, then compress the left end of the rear cargo net and insert it into the recess.
  • Page 500 5-4. Using the storage features CAUTION  When installing/stowing the rear cargo net (except for full-size spare tire) Make sure that the rear cargo net is securely installed/stowed. Failure to do so may result in serious injury in the event of sudden braking or a collision. ...
  • Page 501: Other Interior Features

    5-5. Other interior features Sun visors and vanity mirrors Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Vanity mirrors Slide the cover to open. The light turns on when the cover is opened. NOTICE ...
  • Page 502: Clock

    5-5. Other interior features Clock The clock can be adjusted by pressing the buttons. Adjusts the hours. Adjusts the minutes.  The clock is displayed when Vehicles without a smart entry & start system  The engine switch is in the “ACC” or “ON” position. Vehicles with a smart entry &...
  • Page 503: Portable Ashtray

    5-5. Other interior features  Portable ashtray The ashtray can be installed in the cup holder. (P. 489) CAUTION  When not in use Keep the ashtray closed. In the event of sudden braking, an accident may occur due to an occupant being struck by the open ashtray or ash flying out. ...
  • Page 504: Power Outlets

    5-5. Other interior features Power outlets The power outlet can be used for 12 V accessories that run on less than 10 A. Open the lid.  The power outlets can be used when Vehicles without a smart entry & start system ...
  • Page 505: Seat Heaters

    5-5. Other interior features  Seat heaters Turns on the front left seat heater (high) Turns on the front left seat heater (low) Turns on the front right seat heater (high) Turns on the front right seat heater (low) The indicator light comes on. ...
  • Page 506 5-5. Other interior features CAUTION  Burns Use caution when seating the following persons in a seat with the seat  heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
  • Page 507: Armrest

    5-5. Other interior features Armrest  Front (vehicles with slide function) Slide the console box lid for- ward or backward as needed. Pull the lid forward by holding the front of the lid.  Rear Fold down the armrest for use. NOTICE ...
  • Page 508: Coat Hooks

    5-5. Other interior features Coat hooks The coat hooks are provided with the rear assist grips. CAUTION  Items that cannot be hung on the coat hook Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
  • Page 509: Assist Grips

    5-5. Other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. CAUTION  Assist grip Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
  • Page 510 5-5. Other interior features RAV4_OM_OM42873E_(EE)
  • Page 511 Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior ..512 Cleaning and protecting the vehicle interior ...517 6-2. Maintenance Maintenance requirements....521 6-3. Do-it-yourself maintenance Do-it-yourself service precautions ......524 Hood ........528 Positioning a floor jack..530 Engine compartment..532 Tires........551 Tire inflation pressure ..563 Wheels.......566...
  • Page 512: 6-1. Maintenance And Care

    6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition:  Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 513: Maintenance And Care

    6-1. Maintenance and care Automatic car washes   Before washing the vehicle: • Fold the mirrors • Remove the antenna • Turn off the power back door (if equipped) Start washing from the front of the vehicle. Make sure to re-install the antenna and extend the mirrors before driving.
  • Page 514 6-1. Maintenance and care  Aluminum wheels (if equipped)  Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical clean- ers. Use the same mild detergent and wax as used on the paint. Do not use detergent on the wheels when they are hot, for example after ...
  • Page 515 Precautions regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 516 6-1. Maintenance and care NOTICE  To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.)  Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
  • Page 517: Cleaning And Protecting The Vehicle Interior

    6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
  • Page 518 6-1. Maintenance and care Caring for leather areas  Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets  There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 519 6-1. Maintenance and care NOTICE  Cleaning detergents Do not use the following types of detergent, as they may discolor the vehi-  cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
  • Page 520 6-1. Maintenance and care NOTICE  When cleaning the inside of the windshield (vehicles with LDA [Lane Departure Alert] and Automatic High Beam) Be careful not to touch the camera sensor (P. 293, 313). If the camera is accidentally scratched or hit, LDA and Automatic High Beam may not operate properly or may cause a malfunction.
  • Page 521: Maintenance

    Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule. For full details of your maintenance schedule, refer to the “Toyota Service Booklet” or “Toyota Warranty Booklet”. Do-it-yourself maintenance What about do-it-yourself maintenance? Many maintenance items are easy to do yourself if you have a little mechanical ability and a few basic automotive tools.
  • Page 522  Engine coolant temperature continually higher than normal (P. 109) If you notice any of these clues, take your vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. Your vehicle may need adjustment or repair.
  • Page 523 6-2. Maintenance CAUTION  If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible death or serious injury.  Handling of the battery Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
  • Page 524: Do-It-Yourself Service Precautions

    • Baking soda • Grease Battery condition (P. 542) • Conventional wrench (for terminal clamp bolts) • Distilled water • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with...
  • Page 525 6-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (P. 575) as original • Bulb with same number and watt- age rating as original Light bulbs (P. 590) • Phillips-head screwdriver • Flathead screwdriver • Wrench Radiator, condenser and ...
  • Page 526 6-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions.  When working on the engine compartment  Keep hands, clothing and tools away from the moving fan and engine drive belt.
  • Page 527 6-3. Do-it-yourself maintenance NOTICE  If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air.  If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
  • Page 528: Hood

    6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Push the auxiliary catch lever to the left and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
  • Page 529 6-3. Do-it-yourself maintenance CAUTION  Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ...
  • Page 530: Positioning A Floor Jack

    6-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.  Front  Rear RAV4_OM_OM42873E_(EE)
  • Page 531 6-3. Do-it-yourself maintenance CAUTION  When raising your vehicle Make sure to observe the following precautions to reduce the possibility of death or serious injury:  Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
  • Page 532: Engine Compartment

    6-3. Do-it-yourself maintenance Engine compartment 3ZR-FE and 3ZR-FAE engines  Fuse boxes (P. 575) Radiator (P. 541) Engine coolant reservoir Condenser (P. 541) (P. 540) Electric cooling fans Engine oil filler cap Engine oil level dipstick (P. 537) (P. 535) Battery (P.
  • Page 533 6-3. Do-it-yourself maintenance 2AR-FE engine  Fuse boxes (P. 575) Radiator (P. 541) Engine coolant reservoir Condenser (P. 541) (P. 540) Electric cooling fans Engine oil filler cap Engine oil level dipstick (P. 537) (P. 535) Battery (P. 542) Washer fluid tank (P. 547) RAV4_OM_OM42873E_(EE)
  • Page 534 6-3. Do-it-yourself maintenance 1AD-FTV, 2AD-FTV and 2AD-FHV engines  Fuse boxes (P. 575) Radiator (P. 541) Engine coolant reservoir Intercooler (P. 541) (P. 540) Condenser (P. 541) Engine oil filler cap Electric cooling fans (P. 537) Engine oil level dipstick Fuel filter (P.
  • Page 535 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil  Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
  • Page 536 6-3. Do-it-yourself maintenance Flat dipstick: Reinsert the dipstick fully. Non-flat dipstick: Reinsert the non-flat dipstick fully with its protruding areas ( illustration) pointing towards the engine. Holding a rag under the end, pull the dipstick out and check the oil level. Normal Excessive Flat dipstick...
  • Page 537 6-3. Do-it-yourself maintenance Adding engine oil  If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. 3ZR-FE and 3ZR-FAE engines 2AR-FE engine   1AD-FTV, 2AD-FTV and 2AD-FHV engines ...
  • Page 538 6-3. Do-it-yourself maintenance Engine oil consumption  A certain amount of engine oil will be consumed while driving. In the following situations, oil consumption may increase, and engine oil may need to be refilled in between oil maintenance intervals.  When the engine is new, for example directly after purchasing the vehicle or after replacing the engine ...
  • Page 539 Call any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, service station or auto parts store for information concerning recycling or disposal.
  • Page 540 Visually check the radiator, hoses, engine coolant reservoir cap, drain cock and water pump. If you cannot find a leak, have any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, test the cap and check for leaks in the cooling system.
  • Page 541 If any of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional.
  • Page 542 6-3. Do-it-yourself maintenance Battery Check the battery as follows: Caution symbols  The meanings of each caution symbol on the top of the battery are as follows: No smoking, no naked Battery acid flames, no sparks Note operating Shield eyes instructions Keep away from Explosive gas...
  • Page 543 6-3. Do-it-yourself maintenance Type B  Terminals Hold-down clamp Checking battery fluid  Check that the level is between the “UPPER LEVEL” and “LOWER LEVEL” lines. “UPPER LEVEL” line “LOWER LEVEL” line If the fluid level is at or below the “LOWER LEVEL”...
  • Page 544 Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the engine will not start even after multiple attempts, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. RAV4_OM_OM42873E_(EE)
  • Page 545 6-3. Do-it-yourself maintenance CAUTION  Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: ...
  • Page 546 6-3. Do-it-yourself maintenance NOTICE  When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off.  When adding distilled water Avoid overfilling. Water spilled during battery recharging may cause corro- sion.
  • Page 547 6-3. Do-it-yourself maintenance Washer fluid Without level gauge  If any washer does not work, the washer tank may be empty. Add washer fluid. With level gauge  If the washer fluid level is at “LOW”, add washer fluid. Using the gauge (if equipped) ...
  • Page 548 6-3. Do-it-yourself maintenance CAUTION  When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE  Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid.
  • Page 549 Even if you decide to drain it yourself, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. The water in the fuel filter needs to be drained if the warning mes- sage “DRAIN WATER FROM FUEL FILTER”...
  • Page 550 6-3. Do-it-yourself maintenance When draining the fuel filter (left-hand drive vehicles only)  Detach the packing from the clips as shown in the illustration. Release the clips and remove the cover. When installing, reverse the steps above. RAV4_OM_OM42873E_(EE)
  • Page 551: Tires

    6-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires New tread Treadwear indicator Worn tread The location of treadwear indica- tors is shown by the “TWI” or “” marks, etc., molded on the sidewall of each tire.
  • Page 552: Tire Rotation

    Front 2WD models: To equalize tire wear and help extend tire life, Toyota recommends that tire rotation is carried out approximately every 10000 km (6000 miles). Do not fail to initialize the tire pressure warning system after tire rotation. (if...
  • Page 553 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. (P. 555) ...
  • Page 554 6-3. Do-it-yourself maintenance How to initialize the tire pressure warning system  Park the vehicle in a safe place and turn the engine switch to the “LOCK” position (vehicles without a smart entry & start system) or off (vehicles with a smart entry & start system). Initialization cannot be performed while the vehicle is moving.
  • Page 555 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 556  In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equipment) tire. • A tire has been replaced with a tire that is not of the specified size.
  • Page 557 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 558 6-3. Do-it-yourself maintenance  Certification for tire pressure warning system The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing: DoC address: http://www.pacific-ind.co.jp/eng/products/car/tpms/doc/ RAV4_OM_OM42873E_(EE)
  • Page 559 6-3. Do-it-yourself maintenance The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing address: http://www.globaldenso.com/en/products/oem/index.html RAV4_OM_OM42873E_(EE)
  • Page 560 6-3. Do-it-yourself maintenance RAV4_OM_OM42873E_(EE)
  • Page 561 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear.  Do not use tire sizes other than those recommended by Toyota.  Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
  • Page 562 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or other qualified service shop as soon as possible.
  • Page 563: Tire Inflation Pressure

     Reduced driving comfort and tire life  Reduced safety Damage to the drive train  If a tire needs frequent inflating, have it checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. RAV4_OM_OM42873E_(EE)
  • Page 564 6-3. Do-it-yourself maintenance  Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following:  Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1.5 km or 1 mile, you will get an accurate cold tire inflation pressure reading.
  • Page 565 6-3. Do-it-yourself maintenance CAUTION  Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury:  Excessive wear  Uneven wear ...
  • Page 566: Wheels

     Used wheels  Bent wheels that have been straightened Aluminum wheel precautions  Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels.  When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
  • Page 567 6-3. Do-it-yourself maintenance When replacing wheels (vehicles with the tire pressure warning system)  The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and transmitters must be installed.
  • Page 568 Because tire repair or replacement may affect the tire pressure warning valves and transmitters, make sure to have tires serviced by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional or other qualified service shop. In addition, make sure to...
  • Page 569: Air Conditioning Filter

    6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK” position. Vehicles with a smart entry & start system: Turn the engine switch off.
  • Page 570 Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Toyota Service Booklet” or “Toyota Warranty Booklet”.)  If air flow from the vents decreases dramatically The filter may be clogged.
  • Page 571: Wireless Remote Control/Electronic Key Battery

    6-3. Do-it-yourself maintenance Wireless remote control/electronic key battery Replace the battery with a new one if it is depleted. You will need the following items:  Flathead screwdriver  Small flathead screwdriver  Lithium battery CR2016 (vehicles without a smart entry & start sys- tem), or CR2032 (vehicles with a smart entry &...
  • Page 572 6-3. Do-it-yourself maintenance Open the case cover using a coin protected with tape etc. and remove the depleted bat- tery. Insert a new battery with the “+” terminal facing up. Vehicles with a smart entry & start system  Take out the mechanical key. Remove the cover.
  • Page 573 Use a CR2016 (vehicles without a smart entry & start system), or CR2032 (vehicles with a smart entry & start system) lithium battery  Batteries can be purchased at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, local electrical appliance shops or camera stores.
  • Page 574 6-3. Do-it-yourself maintenance CAUTION  Removed battery and other parts These parts are small and if swallowed by a child, they can cause choking. Keep away from children. Failure to do so could result in death or serious injury.  Certification for the electronic key battery RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
  • Page 575: Checking And Replacing Fuses

    6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK”...
  • Page 576 6-3. Do-it-yourself maintenance Under the instrument panel (left-hand drive vehicles)  Remove the cover. Under the instrument panel (right-hand drive vehicles)  Remove the instrument panel under cover. Remove the cover. RAV4_OM_OM42873E_(EE)
  • Page 577 6-3. Do-it-yourself maintenance Behind the instrument panel (left-hand drive vehicles)  Remove the instrument panel. Behind the instrument panel (right-hand drive vehicles)  Remove the glove box. (P. 569) Remove the fuse with the pull- out tool. Only type A fuse can be removed using the pullout tool.
  • Page 578 Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C and D: Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Type A Type B ...
  • Page 579 6-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment type A  Fuse Ampere Circuit Multiport fuel injection system/sequential multiport fuel injection system, EFI NO.1, EFI NO.2, fuel pump Multiport fuel injection system/sequential EFI-MAIN NO.1 multiport fuel injection system, EFI NO.1, EFI NO.2 Multiport fuel injection system/sequential multiport fuel injection system, EFI NO.3,...
  • Page 580 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/sequential multiport fuel injection system Air flow sensor, fuel pump, rear O sen- EFI-MAIN NO.2 EFI NO.1, EFI NO.2 EFI NO.1, EFI NO.2 VLVMATIC VALVEMATIC system Vehicle stability control, anti-lock brake ABS NO.2 system Vehicle stability control, anti-lock brake...
  • Page 581 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Windshield wiper switch, electric current 24 WIPER-S sensor, multiport fuel injection system/ sequential multiport fuel injection system Air flow meter, purge control VSV, ACIS VSV, rear O sensor, multiport fuel injec- tion system/sequential multiport fuel injection system Air flow meter, purge control VSV, ACIS...
  • Page 582 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Left-hand headlight (low beam), manual 33 H-LP LH-LO headlight leveling dial, headlight leveling system 34 H-LP RH-LO Right-hand headlight (low beam) 35 SPARE Spare fuse 36 SPARE Spare fuse 37 SPARE Spare fuse : Vehicles with 3ZR-FE and 3ZR-FAE engines : Vehicles with 2AR-FE engine : Vehicles with 1AD-FTV engine : Vehicles with 2AD-FTV and 2AD-FHV engines...
  • Page 583 6-3. Do-it-yourself maintenance Engine compartment type B  Fuse Ampere Circuit PTC HTR NO.1 PTC heater PTC HTR NO.2 PTC heater PTC HTR NO.3 PTC heater CDS FAN Electric cooling fans RDI FAN Electric cooling fans Air conditioning system Rear window defogger, MIR HTR Daytime running lights TOWING-ALT Trailer lights...
  • Page 584 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Outside rear view mirror defoggers, mul- 14 MIR HTR tiport fuel injection system/sequential multiport fuel injection system : Replace the fuse with one of the same ampere rating as the original. RAV4_OM_OM42873E_(EE)
  • Page 585 6-3. Do-it-yourself maintenance Under the instrument panel  Fuse Ampere Circuit STOP Stop lights S/ROOF Moon roof IG1 NO.1, IG1 NO.2, IG1 NO.3, ACC On-board diagnosis system Power door lock system (side doors), D/L NO.2 main body ECU FOG RR Rear fog lights, rear fog light indicator D/L BACK Power door lock system (back door)
  • Page 586 BSM main switch, all-wheel drive lock switch, windshield wiper de- icer switch, DAC switch, multiport fuel injection system/sequential multiport fuel injection system, Toyota parking assist- 19 PANEL sensor ECU, seat heater switches, man- ual headlight leveling dial, power outlets,...
  • Page 587 6-3. Do-it-yourself maintenance Fuse Ampere Circuit 26 S-HTR RH Right-hand seat heater C/OPN, fuel pump, multiport fuel injection system/sequential multiport fuel injection 27 IGN system, stop lights, steering lock system ECU, automatic transmission ECU 28 A/B SRS airbag system ECU 29 METER Gauges and meters Alternator, headlight cleaner, rain-sens-...
  • Page 588 6-3. Do-it-yourself maintenance Behind the instrument panel  Left-hand drive vehicles  Right-hand drive vehicles  Fuse Ampere Circuit P/SEAT F/L Left-hand power seat P/SEAT F/R Right-hand power seat Power back door Front power windows, power window P/W MAIN main switch RAV4_OM_OM42873E_(EE)
  • Page 589 (P. 590) If the replaced fuse blows again, have the vehicle inspected by any autho-  rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.  If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
  • Page 590: Light Bulbs

    As there is a danger that components may be damaged, we recommend that replacement is carried out by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced.
  • Page 591 6-3. Do-it-yourself maintenance Rear  Tail light Stop/tail light Back-up light License plate lights Rear turn signal light Rear fog light RAV4_OM_OM42873E_(EE)
  • Page 592 6-3. Do-it-yourself maintenance Replacing light bulbs Headlight low beams (halogen headlights)  For the right side only: Remove the securing clip. Then move the washer tank inlet. Disconnect connector and turn the cover counter- clockwise. Unplug the connector while pulling the lock release. Turn the bulb base counter- clockwise.
  • Page 593 6-3. Do-it-yourself maintenance Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set. Set the connector. After installing the connector, shake the bulb base gently to check that it is not loose. Set the connector and install the cover.
  • Page 594 6-3. Do-it-yourself maintenance Headlight high beams  For the right side only: Remove the securing clip. Then move the washer tank inlet. (P. 592) Turn the bulb base counter- clockwise. Unplug the connector while pressing the lock release. Replace the light bulb, and install the bulb base.
  • Page 595 6-3. Do-it-yourself maintenance Turn and secure the bulb base. Shake the bulb base gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting. For the right side only: Move the washer tank inlet and install the securing clip.
  • Page 596 6-3. Do-it-yourself maintenance Front turn signal lights  Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. RAV4_OM_OM42873E_(EE)
  • Page 597 6-3. Do-it-yourself maintenance Front fog lights (if equipped)  To allow enough working space, turn steering wheel to the opposite side of the bulb to be replaced. Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac- ing the left side light bulb.
  • Page 598 6-3. Do-it-yourself maintenance Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set. Set the connector. After installing the connector, shake the bulb base gently to check that it is not loose, turn the fog lights on once and visu- ally confirm that no light is leak- ing through the mounting.
  • Page 599 6-3. Do-it-yourself maintenance Stop/tail lights and rear turn signal lights  Open the back door and remove bolts, remove the lamp assembly by pulling it directly backward from the rear of the vehicle. Turn the bulb base counterclockwise. Stop/tail lights Rear turn signal lights ...
  • Page 600 6-3. Do-it-yourself maintenance Tail lights and back-up lights  Open the back door and remove the cover. To prevent damage, cover the tip of the screwdriver with rag. Turn the bulb base counterclockwise. Tail lights Back-up lights   Remove the light bulb. Tail lights Back-up lights ...
  • Page 601 6-3. Do-it-yourself maintenance License plate lights  Open the back door and remove the cover. To prevent damage, cover the tip of the screwdriver with rag. Turn the bulb base counterclockwise. Left side Right side   Remove the light bulb. When installing, reverse the steps listed.
  • Page 602 6-3. Do-it-yourself maintenance Rear fog lights  Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. After installing the bulb base, make sure that the rubber cover Rubber is installed securely. cover RAV4_OM_OM42873E_(EE)
  • Page 603 The front position lights/daytime running lights, side turn signal lights and high mounted stoplight consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional to have the light replaced.
  • Page 604 Condensation build-up on the inside of the lens Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for more information in the following situations: Large drops of water have built up on the inside of the lens.
  • Page 605 6-3. Do-it-yourself maintenance CAUTION  Discharge headlights (if equipped) Contact any authorized Toyota dealer or repairer, or another duly qualified  and equipped professional before replacing the discharge headlights (including light bulbs).  Do not touch the discharge headlight’s high voltage socket when the head- lights are turned on.
  • Page 606 6-3. Do-it-yourself maintenance RAV4_OM_OM42873E_(EE)
  • Page 607: Steps To Take In An Emergency

    When trouble arises 7-1. Essential information 7-2. Steps to take in an emergency Emergency flashers...608 If your vehicle needs If your vehicle has to to be towed ......611 be stopped in an emergency.......609 If you think something is wrong..618 Fuel pump shut off system (gasoline engine only) ..619 If a warning light turns on or a warning buzzer...
  • Page 608: Emergency Flashers

    7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road to a breakdown, etc. Press the switch. All the turn signals will flash. To turn them off, press the switch once again.
  • Page 609: Gency

    7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
  • Page 610 7-1. Essential information CAUTION  If the engine has to be turned off while driving Power assist for the brakes and steering wheel will be lost, making the  brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
  • Page 611: Towed

    (P. 614, 617) Before towing The following may indicate a problem with your transmission. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional before towing.  The engine is operating but the vehicle will not move.
  • Page 612 7-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet(s). This should only be attempted on hard surfaced roads for short distances at low speeds.
  • Page 613 7-2. Steps to take in an emergency Installing towing eyelet Remove the eyelet cover using a flathead screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehicle body as shown in the illustration. Insert the towing eyelet into the hole and tighten partially by hand.
  • Page 614 7-2. Steps to take in an emergency Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front (2WD models) From the front (AWD models)  ...
  • Page 615 7-2. Steps to take in an emergency Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45. Do not overly tighten the tie downs or the vehicle may be dam- aged.
  • Page 616 7-2. Steps to take in an emergency CAUTION Observe the following precautions. Failure to do so may result in death or serious injury.  Caution while towing  Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelets and the cables or chains.
  • Page 617 7-2. Steps to take in an emergency NOTICE  To prevent damage to the vehicle when towing using a wheel-lift type truck When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed.
  • Page 618: If Wrong

    If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional as soon as possible.
  • Page 619: Fuel Pump Shut Off System (Gas- Oline Only)

    7-2. Steps to take in an emergency Fuel pump shut off system (gasoline engine only) To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
  • Page 620: If A Warning Light Turns On Or A Warning Buzzer Sounds

    The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Warning light...
  • Page 621 The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 622 (warning buzzer) (if equipped) Indicates a malfunction in Toyota parking assist-sensor (Flashes) : The corner and center indicators flash after the indicator for the malfunc- tioning sensor flashes and the vehicle indicator turns off while the buzzer sounds for approximately 7 seconds.
  • Page 623 7-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light goes off. Warning light Warning light/Details Correction procedure Open door warning light Check that all the doors are (warning buzzer) closed.
  • Page 624 Have the system checked by When the light comes on any authorized Toyota dealer after blinking for 1 minute: or repairer, or another duly Malfunction in the tire pres- qualified and equipped pro- sure warning system fessional.
  • Page 625 Toyota parking assist-sen- indicator (warning buzzer) (if equipped) Clean the sensors. Indicates that Toyota park- ing assist-sensor is dirty or covered with ice. : Open door warning buzzer: P. 633 : Driver’s and passenger’s seat belt buzzer: The driver’s and passenger’s seat belt buzzer sounds to alert the driver and passenger that his or her seat belt is not fastened.
  • Page 626 If the fuel tank is empty, refuel the vehicle immediately. The malfunction indicator lamp will go off after several trips. If the malfunction indicator lamp does not go off, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. ...
  • Page 627 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings  If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ...
  • Page 628 If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
  • Page 629: If A Warning Message Is Displayed

    Multi-information display If any of the warning light comes on again after the following actions have been performed, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. RAV4_OM_OM42873E_(EE)
  • Page 630 The following warning indicates the possibility of dam- age to the vehicle that may lead to an accident. Immediately stop the vehicle in a safe place and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 631 Failure to investigate the cause of the following warn- ings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional.
  • Page 632 7-2. Steps to take in an emergency Warning message Details Indicates a malfunction in the Automatic High Beam (If equipped) Indicates a malfunction in the Blind Spot Monitor (If equipped) Indicates a malfunction in the smart entry & start system (Flashes) (If equipped) RAV4_OM_OM42873E_(EE)
  • Page 633 7-2. Steps to take in an emergency Follow the correction procedures. A buzzer sounds and a warning message is shown on the multi-infor- mation display. After taking the specified steps to correct the sus- pected problem, check that the warning message goes off. Warning message Details Correction procedure...
  • Page 634 7-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the park- brake still engaged vehicle reaches a speed of km/h mph), Release parking brake. flashes and a buzzer sounds to indicate that parking brake is still engaged.
  • Page 635 7-2. Steps to take in an emergency Warning message Details Correction procedure Alerts the driver that the vehicle is out of the lane markers (while the LDA [Lane Departure Check around the vehi- Alert] system is operat- cle and steer the vehi- ing) warning cle back within the lane...
  • Page 636 Indicates that the auto- you may start the matic transmission fluid vehicle again. If the temperature is too high light does not go off, contact any autho- rized Toyota dealer (If equipped) repairer, another duly quali- fied equipped professional. Indicates...
  • Page 637 Indicates that Have the engine oil and engine oil and oil filter oil filter checked and/or should be changed changed by any autho- rized Toyota dealer or Comes approxi- repairer, another mately 30000 duly qualified (19000 miles) after the equipped professional.
  • Page 638 7-2. Steps to take in an emergency Have the malfunction repaired immediately. (vehicles with a smart entry & start system) After taking the specified steps to correct the suspected problem, check that the warning message and light go off. Interior Exterior Correction Warning message...
  • Page 639 7-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure An attempt was made to exit the Con- vehicle with the Turn tinu- electronic key and engine lock doors switch Once without first turn- lock sec- engine...
  • Page 640 7-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The driver’s door • Shift the was opened and shift closed while the lever electronic Con- Con- was not in the • Bring the tinu- tinu- vehicle, the shift...
  • Page 641 7-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure An attempt was made lock either front door by opening a door and putting the inside lock button into the lock posi- Retrieve tion, then closing Con- elec- the door with the...
  • Page 642 7-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure • When the doors Touch the were unlocked electronic with key to the mechanical key engine then switch engine switch while pressed, (Automatic depress- electronic transmission or key could not...
  • Page 643 7-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure Next time when start- engine, increase the engine Power was turned speed off due to the   slightly and automatic power maintain (Automatic off function.
  • Page 644 7-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The driver’s door was opened and Press closed with the engine engine switch switch turned while then the engine depress- switch was put in (Automatic ACCESSORY brake...
  • Page 645 7-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The engine switch has been turned Shift  Once off with the shift shift lever (Flashes) lever in a position to P. other than P or N. (Automatic transmission or Multidrive)
  • Page 646 The warning message will disappear when regeneration is complete. How- ever, if this driving cannot be carried out, or if the message does not disap- pear even after driving, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional imme- diately.
  • Page 647 100 to 300 km (62 to 187 miles), the malfunction indicator lamp may come on. If this happens, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.
  • Page 648: If You Have A Flat Tire (Vehicles With A Spare Tire)

    7-2. Steps to take in an emergency If you have a flat tire (vehicles with a spare tire) Remove the flat tire and replace it with the spare tire provided. For details about tires: P. 551 CAUTION  If you have a flat tire Do not continue driving with a flat tire.
  • Page 649 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Tool bag (if equipped) Spare tire Jack (if equipped) RAV4_OM_OM42873E_(EE)
  • Page 650 7-2. Steps to take in an emergency CAUTION  Using the tire jack (if equipped) Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ...
  • Page 651 7-2. Steps to take in an emergency Taking out the jack (if equipped) Remove the cover. Take out the jack. For loosening For tightening RAV4_OM_OM42873E_(EE)
  • Page 652 7-2. Steps to take in an emergency Taking out the spare tire Remove the rear deck board. Loosen the center fastener that secures the spare tire. CAUTION  When storing the spare tire Be careful not to catch fingers or other body parts between the spare tire and the body of the vehicle.
  • Page 653 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
  • Page 654 7-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Turn the tire jack portion hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel. They indi- cate the jack point positions.
  • Page 655 7-2. Steps to take in an emergency Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
  • Page 656 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
  • Page 657 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
  • Page 658 7-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 103 N•m (10.5 kgf•m, 76 ft•lbf) Reinstall the wheel ornament Vehicles with full wheel ornament ...
  • Page 659 7-2. Steps to take in an emergency Vehicles with center ornament  : The wheel ornament cannot be installed on the compact spare tire. Stow the flat tire, tire jack and all tools.  The compact spare tire (if equipped) ...
  • Page 660 7-2. Steps to take in an emergency  Certification for the jack RAV4_OM_OM42873E_(EE)
  • Page 661 • ABS & Brake assist • Rear view monitor system (if • VSC equipped) • TRC • Toyota parking assist monitor (if • Cruise control (if equipped) equipped) • EPS • Toyota parking assist-sensor (if • LDA (Lane Departure Alert)
  • Page 662 7-2. Steps to take in an emergency CAUTION  Speed limit when using the compact spare tire (if equipped) Do not drive at speeds in excess of 80 km/h (50 mph) when a compact spare tire is installed on the vehicle. The compact spare tire is not designed for driving at high speeds.
  • Page 663 When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as the tire pressure warning valve and transmitter may be damaged if not handled correctly.
  • Page 664: If You Have A Flat Tire (Vehicles Without A Spare Tire)

    7-2. Steps to take in an emergency If you have a flat tire (vehicles without a spare tire) Your vehicle is equipped with an emergency tire puncture repair kit. A puncture caused by a nail or screw passing through the tire tread can be repaired temporarily with the emergency tire punc- ture repair kit.
  • Page 665 7-2. Steps to take in an emergency Location of the emergency tire puncture repair kit, jack and tools Tool bag (if equipped) Emergency tire puncture repair kit 1, 2 Jack (if equipped) : Taking out the jack and tool bag (P. 651) : Use of the jack (P.
  • Page 666 7-2. Steps to take in an emergency Emergency tire puncture repair kit components Bottle Compressor Hose Stickers Air pressure gauge Power plug Compressor switch Air release cap RAV4_OM_OM42873E_(EE)
  • Page 667 7-2. Steps to take in an emergency Taking out the emergency tire puncture repair kit Open and fold up the rear deck board. (P. 492) Take out the emergency tire puncture repair kit. Before performing emergency repair Check the degree of the tire damage. A tire should only be repaired with emergency tire...
  • Page 668 7-2. Steps to take in an emergency Emergency repair method Take out the repair kit from the bag. Remove the valve cap from the valve of the punctured tire. Remove the air release cap from the hose. You will use the air release cap again.
  • Page 669 7-2. Steps to take in an emergency Remove the rubber stopper from the compressor. Connect the power plug to the power outlet socket. Left side of instrument panel Right side of instrument panel   Connect the bottle to the com- pressor.
  • Page 670 Remove any dirt and moisture from the wheel before attaching the sticker. If you are unable to apply the stick- ers, inform the nearest any autho- rized Toyota dealer or repairer, or another duly qualified equipped professional that sealant has been applied to the puncture when having the tire repaired or replaced.
  • Page 671 7-2. Steps to take in an emergency To inject the sealant and inflate the tire, turn the compressor switch on. Inflate the tire until the specified air pressure is reached. The sealant will be injected and the pressure will spike to 300 kPa (3.1 kgf/cm bar, 44 psi) or 400 kPa (4.1 kgf/cm...
  • Page 672 Turn the compres- sor switch off and contact any authorized Toyota dealer or repairer, or another duly qual- ified and equipped profes- sional. • If the tire inflation pressure...
  • Page 673 7-2. Steps to take in an emergency With the compressor switch off, disconnect the hose from the valve on the tire and then pull out the power plug from the power outlet socket. Some sealant may leak when the hose is removed. Install the valve cap onto the valve of the emergency repaired tire.
  • Page 674 If the tire inflation pressure is under 130 kPa (1.3 kgf/cm or bar, 19 psi): The puncture cannot be repaired. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. If the tire inflation pressure is 130 kPa (1.3 kgf/cm...
  • Page 675 Store the bottle in the luggage compartment while it is connected to the compressor. Taking precautions to avoid sudden braking, sudden acceleration and sharp turns, drive carefully at under 80 km/h (50 mph) to the nearest any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. RAV4_OM_OM42873E_(EE)
  • Page 676 The sealant has a limited lifespan. The expiry date is shown on the bottle. The sealant should be replaced before the expiry date. Contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional for replacement.
  • Page 677 7-2. Steps to take in an emergency  If the tire is inflated to more than the specified air pressure Disconnect the hose from the valve. Install the air release cap to the end of the hose and push the protrusion on the air release cap into the tire valve to let some air out.
  • Page 678 7-2. Steps to take in an emergency CAUTION  When fixing the flat tire Stop your vehicle in a safe and flat area.   Connect the valve and hose securely with the tire installed on the vehicle.  If the hose is not properly connected to the valve, air leakage may occur or sealant may be sprayed out.
  • Page 679 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or other qualified service shop as soon as possible.
  • Page 680: If The Engine Will Not Start

    7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 234, 238), consider each of the fol- lowing points: The engine will not start even though the starter motor operates normally.
  • Page 681  There may be a malfunction in the steering lock system (vehicles with a smart entry & start system). Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional if the problem cannot be repaired, or if repair procedures are unknown.
  • Page 682: If The Shift Lever Cannot Be Shifted From P (Except Manual Transmission)

    (a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.
  • Page 683: If The Electronic Key Does Not Operate Properly (Vehicles With A Smart Entry & Start System)

    7-2. Steps to take in an emergency If the electronic key does not operate properly (vehicles with a smart entry & start system) If communication between the electronic key and vehicle is interrupted (P. 133) or the electronic key cannot be used because the battery is depleted, the smart entry &...
  • Page 684 Firmly depress the brake pedal and check that is displayed on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional. RAV4_OM_OM42873E_(EE)
  • Page 685 Firmly depress the clutch pedal and check that is shown on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional. RAV4_OM_OM42873E_(EE)
  • Page 686 7-2. Steps to take in an emergency Stopping the engine  Automatic transmission or Multidrive  Shift the shift lever to P and press the engine switch as you normally do when stopping the engine. Manual transmission  Shift the shift lever to N and press the engine switch as you normally do when stopping the engine.
  • Page 687: If The Vehicle Battery Is Discharged

    The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
  • Page 688 7-2. Steps to take in an emergency 3ZR-FE and 3ZR-FAE engines  Remove the engine cover. Connect a positive jumper cable clamp to the positive (+) battery terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
  • Page 689 7-2. Steps to take in an emergency 2AR-FE engine  Connect a positive jumper cable clamp to the positive (+) battery terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle. Connect a negative cable clamp to the negative (-) battery termi- nal on the second vehicle.
  • Page 690 7-2. Steps to take in an emergency 1AD-FTV, 2AD-FTV and 2AD-FHV engines  Remove the engine cover. Connect a positive jumper cable clamp to the positive (+) battery terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
  • Page 691 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional as soon as possible. ...
  • Page 692 7-2. Steps to take in an emergency  When recharging or replacing the battery (vehicles with a smart entry & start system)  Vehicles with an alarm: Make sure that the key is not inside the vehicle when recharging or replacing the battery. The key may be locked in the vehicle if the alarm is activated.
  • Page 693 7-2. Steps to take in an emergency CAUTION  Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery:  When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
  • Page 694: If Your Vehicle Overheats

    After the engine has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional. RAV4_OM_OM42873E_(EE)
  • Page 695 Stop the engine immediately and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. If the fans are operating: Have the vehicle inspected at the nearest any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. RAV4_OM_OM42873E_(EE)
  • Page 696 7-2. Steps to take in an emergency CAUTION  When inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns.  If steam is seen coming from under the hood, do not open the hood until the steam has subsided.
  • Page 697: If You Run Out Of Fuel And The Engine Stails(Diesel Engine Only)

    10 seconds and try step again. If the engine still does not start, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. After starting the engine, depress the accelerator pedal lightly until the engine runs smoothly.
  • Page 698: If The Vehicle Becomes Stuck

    7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P (vehicles with an automatic transmission or Multidrive) or N (vehi- cles with a manual transmission).
  • Page 699 7-2. Steps to take in an emergency CAUTION  When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
  • Page 700 7-2. Steps to take in an emergency RAV4_OM_OM42873E_(EE)
  • Page 701: Vehicle Specifications

    Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.)...702 Fuel information ....730 8-2. Customization Customizable features ..734 8-3. Items to initialize Items to initialize ....740 RAV4_OM_OM42873E_(EE)
  • Page 702: Maintenance Data (Fuel, Oil Level, Etc)

    8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions Overall length 4570 mm (179.9 in.) Overall width 1845 mm (72.6 in.) 1660 mm (65.4 in.) Without the roof luggage carrier 1670 mm (65.7 in.) Overall height 1705 mm (67.1 in.) With the roof luggage carrier 1715 mm (67.5 in.)
  • Page 703 8-1. Specifications 3ZR-FAE engine with a Multidrive  Gross vehicle mass 2110 kg (4651 lb.) Front Maximum permissible 1150 kg (2535 lb.) axle capacity Rear Drawbar load 60 kg (132 lb.) Without brake 750 kg (1653 lb.) Towing capacity With brake 1500 kg (3306 lb.) 3ZR-FAE engine with a manual transmission...
  • Page 704 8-1. Specifications 1AD-FTV engine  2135 kg (4705 lb.) Gross vehicle mass 2190 kg (4828 lb.) Front Maximum permissible 1150 kg (2535 lb.) axle capacity Rear Drawbar load 65 kg (143 lb.) Without brake 750 kg (1653 lb.) Towing capacity With brake 1600 kg (3527 lb.) 2AD-FTV engine without DPF system...
  • Page 705 8-1. Specifications 2AD-FTV engine with DPF system  2170 kg (4784 lb.) Gross vehicle mass 2220 kg (4894 lb.) Front Maximum permissible 1150 kg (2535 lb.) axle capacity Rear Drawbar load 80 kg (176 lb.) Without brake 750 kg (1653 lb.) Towing capacity With brake 2000 kg (4409 lb.)
  • Page 706 8-1. Specifications : ZSA42L-ANFXK model : ZSA42L-ANXGK and ZSA42L-ANXXK models : ZSA44L-ANFXK model : ZSA44L-ANXGK and ZSA44L-ANXXK models : Except for Armenia, Azerbaijan, Bosnia Herzegovina, Croatia, Georgia, Kazakhstan, Macedonia, Montenegro, Serbia, Tajikistan and Turkmenistan : With model code that has “W” as the last letter. : ALA49L-ANTXYW, ALA49L-ANTGYW, ALA49L-ANFXYW and ALA49L-ANFGYW models : Vehicles with a manual transmission...
  • Page 707 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped under the right-hand front seat.
  • Page 708 8-1. Specifications Engine number  The engine number is stamped on the engine block as shown. 3ZR-FE and 3ZR-FAE engines 2AR-FE engine   1AD-FTV, 2AD-FTV and 2AD-FHV engines  RAV4_OM_OM42873E_(EE)
  • Page 709 8-1. Specifications Engine 3ZR-FE and 3ZR-FAE engines  Model 3ZR-FE and 3ZR-FAE Type 4-cylinder in line, 4-cycle, gasoline 80.5  97.6 mm (3.17  3.84 in.) Bore and stroke Displacement 1987 cm (121.2 cu.in.) Valve clearance Automatic adjustment 7.6  10 mm (0.30  0.39 in.) Generator Water pump Drive belt tension...
  • Page 710 8-1. Specifications 1AD-FTV engine  Model 1AD-FTV 4-cylinder in line, 4-cycle, diesel Type (with turbocharger) 86.0  86.0 mm (3.39  3.39 in.) Bore and stroke Displacement 1998 cm (121.9 cu.in.) Valve clearance Automatic adjustment Drive belt tension 2AD-FTV and 2AD-FHV engines ...
  • Page 711 8-1. Specifications Fuel Gasoline engine  EU area: Unleaded gasoline conforming to European stan- dard EN228 only Fuel type Except EU area: Unleaded gasoline only 3ZR-FE Research 91 or higher octane 2AR-FE number 3ZR-FAE 95 or higher Fuel tank capacity 60 L (15.9 gal., 13.2 Imp.gal.) (Reference) : With model code...
  • Page 712 8-1. Specifications Diesel engine  Without DPF system  EU area: Diesel fuel conforming to European standard EN590 Except EU area (except Russia): Diesel fuel that contains 500 ppm or less of sulfur Except EU area (Russia): Diesel fuel confirming to GOST R52368-2005 Fuel type (Sulfur max 50 ppm).
  • Page 713 Engine oil selection  “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used.
  • Page 714 “W ” as the last letter. : The model code is indicated on the manufacturer’s label. (P. 707) Recommended viscosity (SAE): SAE 0W-20 is filled into your Toyota vehicle at manufactur- Preferred ing, and the best choice for good fuel economy and good starting in cold weather.
  • Page 715 8-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
  • Page 716 8-1. Specifications Azerbaidjan, Armenia, Georgia, Kazakhstan  Turkmenistan with 2AR-FE engines, Ukraine with 3ZR-FAE and 2AR-FE engines, and Russia : With model code that has “W ” as the last letter. : The model code is indicated on the manufacturer’s label. (P. 707) Recommended viscosity (SAE): If you use SAE 10W-30 or a higher viscosity engine oil in...
  • Page 717 8-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
  • Page 718 ALA49L-ANFGYW models : The model code is indicated on the manufacturer’s label. (P. 707) “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used.
  • Page 719 8-1. Specifications Recommended viscosity (SAE): SAE 5W-30 is filled into your Toyota vehicle at manufactur- Preferred ing, and the best choice for good fuel economy and good starting in cold weather. If you use SAE 10W-30 or a higher viscosity engine oil in...
  • Page 720 ALA49R-ANFGRW models : The model code is indicated on the manufacturer’s label. (P. 707) “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used.
  • Page 721 8-1. Specifications Recommended viscosity (SAE): SAE 0W-30 is filled into your Toyota vehicle at manufactur- ing, and the best choice for Preferred good fuel economy and good starting in cold weather. Temperature range anticipated before next oil change Oil viscosity (0W-30 is explained here as an example): •...
  • Page 722 5.8 L (6.1 qt., 5.1 Imp.qt.) 2AR-FE 6.8 L (7.2 qt., 6.0 Imp.qt.) engine Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
  • Page 723: Electrical System

    Toyota Genuine Differential gear oil LT Oil type and viscosity 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further details.
  • Page 724: Automatic Transaxle

     CVT (Continuously Variable Transaxle) fluid type Using transaxle fluid other than “Toyota Genuine CVT Fluid TC” or “Toyota Genuine CVT Fluid FE” may cause deterioration in shift quality, locking up of your transaxle accompanied by vibration, and ultimately damage the transaxle of your vehicle.
  • Page 725: Manual Transaxle

    Please be aware that depending on the particular characteristics of the gear oil used or the operating conditions, idle sound, shift feeling and/or fuel effi- ciency may be different or affected. Toyota recommends to use “TOYOTA Genuine Manual Transmission Gear Oil LV” to achieve optimal perfor- mance.
  • Page 726 Toyota Genuine Differential gear oil LT Oil type and viscosity 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further details.
  • Page 727 8-1. Specifications Tires and wheels 17-inch tires  Tire size 225/65R17 102H Normal pressure: Front: 220 kPa (2.2 kgf/cm or bar, 32 psi) Tire inflation pressure Rear: 220 kPa (2.2 kgf/cm or bar, 32 psi) (Recommended cold tire ECO pressure inflation pressure) Front: 240 kPa (2.4 kgf/cm or bar, 35 psi)
  • Page 728 8-1. Specifications Compact spare tire (if equipped)  Tire size T165/80D17 104M Tire inflation pressure (Recommended cold 420 kPa (4.2 kgf/cm or bar, 60 psi) tire inflation pressure) 17  4T Wheel size Wheel nut torque 103 N•m (10.5 kgf•m, 76 ft•lbf) ...
  • Page 729 8-1. Specifications Light bulbs Light bulbs Type Headlights High beam Low beam (halogen bulbs) Low beam (discharge bulbs) Front fog lights Front turn signal lights Exterior Stop/tail lights 21/5 Tail lights Rear turn signal lights Back-up lights Rear fog lights License plate lights Vanity lights Interior light (front)/personal lights...
  • Page 730: Fuel Information

    8-1. Specifications Fuel information  Gasoline engine 3ZR-FE and 2AR-FE engines  EU area: Your vehicle must use only unleaded gasoline conforming to Euro- pean standard EN228. For optimum engine performance, select unleaded gasoline with a Research Octane Number of 91 or higher. Except EU area: Your vehicle must use only unleaded gasoline.
  • Page 731 8-1. Specifications  Diesel engine Without DPF system  EU area: Your vehicle must use only diesel fuel conforming to European standard EN590. Except EU area (except Russia): Your vehicle must use only diesel fuel that contains 500 ppm or less of sulfur and has a cetane number of 48 or higher.
  • Page 732 “E50” or “E85” and fuel containing a large amount of ethanol should not be used. The use of these fuels will damage the vehicle’s fuel system. In case of any doubt, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 733 You must ensure that refueling is carried out only from a source where fuel specification and quality can be guaranteed. In case of any doubt, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
  • Page 734: 8-2. Customization

    Vehicles with a navigation system or multimedia system: Settings that can be changed using the navigation system or multimedia system Settings that can be changed by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional RAV4_OM_OM42873E_(EE)
  • Page 735 8-2. Customization Definition of symbols: O = Available, — = Not available Custom- Default Item Function ized set- setting ting Smart entry & Operation signal start system (Emergency flashers) (P. 126) Time elapsed before the and wireless automatic door lock function remote —...
  • Page 736 8-2. Customization Custom- Default Item Function ized set- setting ting Light sensor sensitivity Standard -2 to 2 seconds Follow me home Automatic (Time elapsed before head- — O light control seconds seconds lights automatically turn off) system (P. 281) seconds Automatic High Beam (Enable/disable the opera- —...
  • Page 737 8-2. Customization Custom- Default Item Function ized set- setting ting A/C Auto switch operation Automatic Switching between outside air conditioning air and recirculated air mode system linked to “AUTO” switch (P. 377) operation Interior lights illumination control seconds Time elapsed before the interior lights turn off seconds seconds...
  • Page 738 8-2. Customization Custom- Default Item Function ized set- setting ting Sensitivity of the ambient light sensor used for dim- Standard -2 to 2 — O ming the meter lights etc. Illumination (P. 483) Sensitivity of the ambient light sensor used for bright- Standard -2 to 2 —...
  • Page 739 8-2. Customization Vehicle customization  When the doors remain closed after unlocking the doors and the automatic door lock function activates, the signals will be generated in accordance with the operation signal (emergency flashers) settings. CAUTION During customization  As the engine needs to be running during customization, ensure that the vehicle is parked in a place with adequate ventilation.
  • Page 740: 8-3. Items To Initialize

    8-3. Items to initialize Items to initialize The following items must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference Engine oil maintenance data •...
  • Page 741: Index

    Index What to do if... (Troubleshooting) .....742 Alphabetical index ......750 For vehicles with a navigation system or a multimedia system, refer to the “Navigation and multimedia system Owner’s manual” for information regarding the equipment listed below. • Navigation system • Audio system •...
  • Page 742: What To Do If

    The doors cannot be locked, unlocked, opened or closed You lose your keys  If you lose your keys or mechanical keys, new genuine keys or mechanical keys can be made by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. (P. 124) ...
  • Page 743 What to do if... (Troubleshooting) The rear door cannot be opened  Is the child-protector lock set? The rear door cannot be opened from inside the vehicle when the lock is set. Open the rear door from outside and then unlock the child-protector lock. (P. 166) If you think something is wrong The engine does not start (vehicles without a smart entry &...
  • Page 744 What to do if... (Troubleshooting) The engine does not start (vehicles with a smart entry & start system)  Did you press the engine switch while firmly depressing the brake pedal? (P. 238)  Vehicles with an automatic transmission or a Multidrive Is the shift lever in P? (P.
  • Page 745 What to do if... (Troubleshooting) The steering wheel cannot be turned after the engine is stopped  Vehicles without a smart entry & start system It is locked to prevent theft of the vehicle if the key is removed from the engine switch. (P. 236) ...
  • Page 746 What to do if... (Troubleshooting) The engine switch is turned off automatically (vehicles with a smart entry & start system)  The auto power off function will be operated if the vehicle is left in ACCESSORY or IGNITION ON mode (the engine is not operating) for a period of time.
  • Page 747 What to do if... (Troubleshooting) An alarm is activated and the horn sounds (if equipped)  Did anyone inside the vehicle open a door during setting the alarm? The sensor detects it and the alarm sounds. (P. 95) To stop the alarm, turn the engine switch to IGNITION ON mode or start the engine.
  • Page 748 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire  Vehicles with a spare tire Stop the vehicle in a safe place and replace the flat tire with the spare tire. (P. 648) ...
  • Page 749 What to do if... (Troubleshooting) RAV4_OM_OM42873E_(EE)
  • Page 750: Alphabetical Index

    Alphabetical index Alphabetical index Side and curtain shield airbags precautions ....51 A/C........370, 377 SRS airbags......46 Air conditioning filter....569 Airbag manual on-off Automatic air conditioning system........59 system ........ 377 Alarm .......... 95 Manual air conditioning Alarm ........95 system ........
  • Page 751 Alphabetical index Automatic headlight leveling Brake system ........286 Parking brake......276 Automatic High Beam ..... 287 Warning light......620 Warning message ....632 Brake assist ......335 Automatic light control Break-in tips......209 system ........285 Brightness control Automatic transmission Instrument panel light (with M mode) ......
  • Page 752 Alphabetical index Child safety ........ 62 Differential........ 723 Airbag precautions ....49 Dimension ........ 702 Back door precautions ..174 Display Battery precautions ..542, 693 Fuel consumption Child restraint system ..... 63 information......118 How your child should wear LDA (Lane Departure the seat belt ......
  • Page 753 Alphabetical index Electric Power Steering How to start (EPS)........336 the engine....234, 238 Function ........ 336 Identification number .... 708 Warning light ......622 If the engine will not start ..680 Electronic key ......122 If you run out of fuel and Battery-saving function ..
  • Page 754 Alphabetical index Fluid Automatic transaxle ....724 Gauges ........108 Brake........726 Gear Shift Indicator ..258, 271 Washer........547 Glove box ......... 487 Fog lights........294 Grocery bag hooks....491 Replacing light bulbs..597, 602 Switch ........294 Wattage......... 729 Hands-free system Front passenger’s (for cellular phone)
  • Page 755 Alphabetical index Identification ......707 Keyless entry ....126, 149 Engine........708 Smart entry & start system ... 126 Vehicle ........707 Wireless remote control ..149 Ignition switch Keys .......... 122 (engine switch) ....234, 238 Battery-saving function ..132 Ignition switch light Electronic key .......
  • Page 756 Alphabetical index Light Mirrors Engine switch light Inside rear view mirror ..191 (ignition switch light) ... 483 Outside rear view mirror Fog light switch ..... 294 defoggers ......387 Headlight switch....281 Outside rear view mirrors..194 Illuminated entry system ..485 Vanity mirrors......
  • Page 757 Folding down the rear ......256, 257, 265, 266 seatbacks ......184 Parking assist sensors Rear turn signal lights..... 274 (Toyota parking Replacing light bulbs..... 599 assist-sensor) ......321 Turn signal lever ....274 Parking brake ......276 Wattage ........ 729 Operation ......
  • Page 758 Automatic headlight warning message ....644 system ........ 285 Steering wheel ......190 Inside rear view mirror ..193 Adjustment......190 Toyota parking Audio switches...... 444 assist-sensor ...... 321 Stop & Start system ....328 LDA (Lane Departure Stop/tail lights Alert) ........
  • Page 759 608 Windshield wipers and Engine switch....234,238 washer switch..... 296 Fog light switch ..... 294 Ignition switch ....234, 238 Toyota parking Tachometer ......108 assist-sensor ...... 321 Tail lights........281 LDA (Lane Departure Light switch ......281 Alert) ........313 Replacing light bulbs.....
  • Page 760 Emergency towing ....612 Vanity lights ......501 Towing eyelet......613 Wattage ........ 729 Trailer towing ......222 Vanity mirrors ......501 Toyota parking Vehicle identification assist-sensor ......321 number ........707 Vehicle Stability Control (VSC) ........335 VSC (Vehicle Stability Control) ........
  • Page 761 Alphabetical index Windows........198 Power windows..... 198 Warning buzzers ...... 620 Rear window defogger..387 Brake system ......620 Windshield wiper de-icer ..389 Downshifting ..250, 267, 259 Windshield wipers ....296 Key reminder....131, 640 Intermittent windshield Open back door ....623 wipers .........
  • Page 762 Alphabetical index RAV4_OM_OM42873E_(EE)
  • Page 763 Alphabetical index RAV4_OM_OM42873E_(EE)
  • Page 764: Gas Station Information

    GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 528 P. 307 Hood lock release Fuel filler door opener Tire inflation pressure lever P. 528 P. 307 P. 727 Fuel tank capacity (Reference) 60 L (15.9 gal., 13.2 Imp.gal.) Fuel type P.

Table of Contents

Save PDF
