- Page 1 INSTRUCTION MANUAL AIR 26 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.0x25mm SCREW M3.5x40mm SCREW 8PCS+1spare 24PCS+1spare M3.0x10mm SCREW M3.0x16mm SCREW 6PCS+1 spare 6PCS+1 spare Eye hook Chewing Toy... - Page 5 PARTS Left side panel Back panel Front panel Right side panel Roof Drawer Upper layer Down layer Ramp 3PCS...
- Page 6 PARTS Roof of small house Front panel of small house Side panels of small house 4PCS 2PCS 2PCS Seeasw Base of seesaw Base of bowl 2PCS 2PCS Bowl...
- Page 7 PARTS...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY ① Attach the front panel Part K,the roof panel Part L to the side panels Part J by 10xP2 to finish the small house. ② Repeat the same way for the second one. X 10 Screw the ramp Part I to the layer Part G by 2xP4. - Page 9 PRODUCT ASSEMBLY Screw the ramps Part I to the layer Part H by 4xP4. Complete the two sessaws by 2xP2 each.
- Page 10 PRODUCT ASSEMBLY ① Attach the side panels Part C & D to the front panel Part A by 4xP1. ② Notice to align with the dowels. ① Attach the back panels Part B to the side panels by 4xP1. ② Notice to align with the dowels.
- Page 11 PRODUCT ASSEMBLY Slide in the tray Part E. Put the down layer to the slot of back & side panel.
- Page 12 PRODUCT ASSEMBLY Put the upper layer to the slot of back & side panel. Put the small houses to the layers.
- Page 13 PRODUCT ASSEMBLY Put the seesaw into the cage. Put the chewing toy P6 and bowl Part O & P into the cage.
- Page 14 PRODUCT ASSEMBLY Attach the roof Part F to the back panel by 6xP3. ① Attach the hook eye to left side panel. ② Tie the rope to the eye hook.
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
